12 best backup camera for jeep wranglers

Product description

Compatibility:

Fits for Jeep Wrangler 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018

Feature：

1) This is an aftermarket tailgate handle backup camera, not OEM.

2) With 1/3 PC3089 CMOS color camera, 0.1 Lux sensitivity to enhance visibility at night.

3) RCA video output plugs into NTSC video input of most after market mirrors/video receiver.

Specification:

Resolution: 972(H) x 504(V)

Image Sensor: 1/3 PC3089 CMOS

Angle: 150° Peripheral Wide View

Min Illumination: 0.1 Lux

Night Vision Distance: 35ft

Power Voltage: 12V

Operating Temperature: -20℃~+70℃

Waterproof Rate: IP68



Package Includes:

1 x Rear View Camera

1 x Long Extension Cable

1 x Adapter

1 x Instruction Manual

• ►Fixed mount rear view camera fits for 2007-2018 Jeep Wrangler. Please confirm the spoke of the wheels have a opening at 12 o'clock on the spare or this will not fit. If you need a opening at 1-2 o'clock or upside-down installation, please search B088NLMWTP
• ►Available for OEM(factory) or aftermarket display. Includes a composite (RCA) connection to the video input on the aftermarket display & an RCA harness to connect to camera with the factory display(this connection requires dealer to reprogram)
• ►HD color CCD with superior daytime and nighttime image crispness, you never worry about parking during night, cloudy, rainy day or in dark garage.
• ►The security sensor camera designed with fully sealed glue filling craft, with International Standard IP69 Waterproof Property. And it is built in guide line/distance scale line on/off switch.
• ►We offer 30 days money back guarantee, 24 months replacement warranty, lifetime support guarantee customer service and technical.

User questions & answers

Question:	So this camera will work with the factory Alpine premium audio system with navigation (sub in rear cargo area)? I’ve seen so many options from this co
Answer:	Yes, that's what my 2014 JK Polar edition has. There are included 2 adaptors, one shown in photo, plugs directly in back of factory alpine 430N premium audio and worked first time after I turned on the backup camera thru the OBD11 port using a Veepeak OBDCheck BLE+ Bluetooth 4.0 OBD2 Scanner and JScan app on my phone.
Question:	I will like to know where the red and black wire goes from the backup camera
Answer:	There should be a connector coming from the cable out of the back of the camera - the connector from the red and black wires connects to that, the other end connects to the headunit adapter.
Question:	is this compatable with a manual transmission, meaning will it come on automatically when car is put in reverse
Answer:	Hi, yes, it is compatible with a manual transmission, it can come on automatically when car is put in reverse.
Question:	Do both sets of red&black wires need to be connected or just one set
Answer:	Hi, just connect one set of wires. Any problem, just contact me!

Product features

Upgraded Reversing Camera

• High-definition color CCD lens with superior daytime image crispness and nighttime brightness, 150°degree wide viewing angle, you can check the back situation easier when reversing.
• IP68 Waterproof & Fog Resistant-Thanks to the sturdy and tightly construction, this backup camera is entirely waterproof and will never fog up after a carwash or on a rainy day.

Conveniently Switch Guidelines

No need to cut wires, switch guidelines on/off by unplugging/inserting the small black button.

Super Night Vision

Equipped with advanced Analogy High Definition, the backup camera enhances night vision in low light conditions making it easy to obtain sharp, color-accurate images at night.

Withstand Extreme Temperature

The device stands well in bad weather and extreme temperature from 4°F to 158°F, the backup camera can work without any problem.

Wire is Well Protected

The power wire is well protected by the wire loom tubing, which is resistance to abrasion & harmful chemicals corrosion, provide full protection for the power wire.

Come with Heat Shrink Wire Connectors

The insulated connectors will make your wire connection waterproof and prevent wire corrosion!

Customized Metal Non-Slip Gaskets

Customized metal anti-slip gasket with deeper serrations to enhance anti-slip and make the camera more stable.

Advanced Anti-Rust Treatment Process

The bracket is sprayed with special anti-rust paint, so you don't have to worry about the bracket rusting, which not only protects the bracket, but also extends its service life.

Product description

Compatibility:

Fits for Jeep Wrangler 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018



Feature：

1) This is an aftermarket tailgate handle backup camera, not OEM.

2) With 1/3 PC3089 CMOS color camera, 0.1 Lux sensitivity to enhance visibility at night.

3) RCA video output plugs into NTSC video input of most after market mirrors/video receiver.

4) The mirror monitor is a normal mirror, not auto dimming.

When you reverse, the LCD Monitor will work automatically, and when you drive forward, it is only a mirror.

5) About Anti-Glare Screen:

"Glare" not only affects viewing and safety when driving, but also affects vision health.

An anti-glare display can effectively reduce this effect. The LCD screen can be seen even when lighting and sunlight.

6) With adjustable automotive bracket, the screen could be adjustable by rotating the support stand to view different angle. For easy installation and stand alone.

Housing is made of high quality automotive materials, can work constantly for long time.



Specification:

Resolution: 972(H) x 504(V)

Image Sensor: 1/3 PC3089 CMOS

Angle: 150° Peripheral Wide View

Min Illumination: 0.1 Lux

Night Vision Distance: 35ft

Power Voltage: 12V

Operating Temperature: -20℃~+70℃

Waterproof Rate: IP68

Monitor Size: 4.3inch

Display Screen: TFT LCD

Brightness: 480cd/m2

Contrast: 300:1

Consumption: <2W

Video: AV1-for VCD/DVD/DVR, AV2-for backup camera



Package Includes:

1 x Rear View Camera

1 x Car Rear View Anti-Glare Mirror Monitor

1 x Video Cable & Power Cable

1 x Long Extension Cable

1 x Instruction Manual

1 x Adapter

1 x Bracket

• ✔The fixed mount rear-view camera only fits for 2007-2018 Jeep Wrangler. Mounts on the spare tire for an OEM look. IP68 waterproof housing with anti-fog lens, waterproof, dust-proof, anti-fog, shock-proof.
• ✔High-definition color CCD with superior daytime image crispness and nighttime brightness, 150°degree wide viewing angle, you can check the back situation easier when reversing.
• ✔Terminates with RCA for use on most aftermarket radios with video input.
• ✔The 4.3 inch clip-on mirror display acts like regular reflective rear view mirror as well as a HD LCD car security monitor. With special anti-glaring screen film, there is no glare when lighting and sunlight, ensure driving safety and protect eyesight. Please note that the clarity of the mirror will be slightly lower because of the anti-glare film.
• ✔Note: Please remove your original mirror down and check the mount, make sure it is the same as ours bracket shown. If you find the bracket isn’t suitable for your car, PLEASE CONTACT US!

User questions & answers

Question:	I currently do not have a backup camera, why do i need to have my radio reprogrammed for a 1997 jeep tj? is that only for jeeps with backup camras
Answer:	Hi, if it is the first time you install the backup camera, then you need to reprogram your factory radio to activate camera feature first.
Question:	Does this work on a manual transmission
Answer:	Yes, it does.
Question:	Can this camera be always on
Answer:	Yes, depending on where you connect the power line.
Question:	Weave a 2018 jeep wrangler unlimited. the mirror does not have any wires attached to it. will this product work
Answer:	The new kit comes with a complete new mirror. You remove the old one and the new one with a built in screen goes on the original windshield mount

Product features

UPGRADED CCD LENS

High-definition color CCD lens with superior daytime image crispness and nighttime brightness, 150°degree wide viewing angle, you can check the back situation easier when reversing.

IP68 Waterproof & Fog Resistant-Thanks to the sturdy and tightly construction, this backup camera is entirely waterproof and will never fog up after a carwash or on a rainy day.

CONVENIENTLY SWITCH GUIDELINES

No need to cut wires, switch guidelines on/off by unplugging/inserting the small black button.

SUPER NIGHT VISION

Equipped with advanced Analogy High Definition, the backup camera enhances night vision in low light conditions making it easy to obtain sharp, color-accurate images at night.

WITHSTAND EXTREME TEMPERATURE

The device stands well in bad weather and extreme temperature from 4°F to 158°F, the backup camera can work without any problem.

Product description

Our Rear View Camera Reverse Camera is designed for Jeep Wrangler years 2007-2018



Installation Tips:



Camera cable connection:

1,with the arrows to align, it is tips for match between camera cable and the extension cable;



Camera power:

1,Connect the red wire from our extension cable to a 12 volt power source.

2,A detection wire on RCA side should connect to some radio which has a reverse wire



Aftermarket Display:

1, Use Camera RCA to connect aftermarket Display video input.



Included two kinds OEM Monitor Adapter: Allows the use of our aftermarket camera on OEM monitor systems. Works on:

JEEP Commander (2008-2010)

JEEP Compass (2009-UP)

JEEP Grand Cherokee (2008-2013)

JEEP Liberty (2008-2013)

JEEP Patriot (2009-2015)

JEEP Wrangler (2007-UP)

Specifications:

Requires CANBUS interface to operate, 22-pin GMLAN RSE harness

Retains factory backup camera when factory radio is replaced with an aftermarket radio



Note:

Some Jeep radio may need to be unlock then backup camera can be carry on. It means the factory radio will require programming.

This cable only serves the purpose to connect backup camera with display, do not work as the item that help you unlock the head unit screen.

In this case, you should go to the Jeep dealership for programming or DIY by purchasing a third party programmer.

• 【Fits:】This car backup camera fits for Jeep Wrangler years 2007-2018. Mounts on the spare tire for an OEM look.
• 【Waterproof & parking line removable option.】Waterproof feature take you no need afraid of rain or a car wash, parking line removable option fits you different need.
• 【OEM MONITOR ADAPTER.】Allows use of the aftermarket camera on OEM monitor systems.
• 【Bring You Safety Driving.】This car rear view camera is a good assistance when you do car parking, it shows a clear image for the driver.
• 【Warranty.】Any missing parts or defective item, contact us and we could send a new one as replacement.

User questions & answers

Question:	Will this fit a 6 bolt x 5.5" (139.7mm) bolt pattern
Answer:	its for the stock JK pattern
Question:	Will it work with after market tires and wheels
Answer:	Yes, this Jeep Wrangler Spare Tire Mount camera could work with after market tires and wheels.
Question:	I wired the green wires together and the lines are gone but now I have these ugly parking cones still. How do you get rid of parking cones
Answer:	Could you please contact us seller directly? We could have more communication about what this happen. And once it is confirmed that is a defective item, we could send you a new one as replacement.
Question:	Not working in my jk. connected to right rear grey/white backup wire, grounded at the light. no image in my alpine head unit. any ideas
Answer:	If red power wire and ground wire connect well, and all harness connect correct, but still no video on display, in order to unlock the head unit screen. it may need go to the Jeep dealership for programming or DIY by purchasing a third party programmer.

Product features

Good lens full color image

Our cameras are designed to improve safety during driving by providing high quality images of surrounding areas and obstacles in the vicinity of the vehicle

Video Input Harness

Come with Backup Camera Video Input Harness,allows you to connect the aftermarket backup camera with stock navigation/factory head unit.

Default parking line on

Parking line display for proper parking and reversing without relying on side mirrors alone. It offers safety for your Jeep Wrangler JK .

parking line" tag on

If you want to remove the camera's default parking lines from the screen, use your wire strippers to expose the copper of both green wires, then use a wire crimper and butt connector to join them.

Camera w/Spare Tire Mounting Bracket for Jeep Wrangler JK 2007-2018

This is an aftermarket camera w/Spare Tire Mounting Bracket for Jeep Wrangler JK 2007-2018, for the power supply, connect the red wire from our cable to a 12 volt power source.

Spare tire mounting bracket is made of high quality material,it can work constantly for long time.

• 【BACKUP CAMERA】Compatible with Jeep Wrangler JK models (2007-2018); spare tire mount included; IP-67 water resistant with 170 degree viewing angle and parking guidelines
• 【NO DEALER PROGRAMMING REQUIRED】Easy plug-and-play install; Included module unlocks backup camera usage on your OEM video-enabled radio
• 【EXTRA UNLOCKED FEATURES】Module also adds additional A/V input/output, reverse trigger, and allows GPS entry while in motion (intended for passenger use).
• 【USA-BASED SUPPORT】Need help during your install? Our USA-based, MECP-certified support team is just a phone call away with over 30 years of car install experience.

User questions & answers

Question:	Do the lines on the monitor turn to show the direction of travel or are they static and not move
Answer:	They do not move! There is an option to turn them off.
Question:	Will it work with a manual transmission
Answer:	Yes I have it hooked up to my jeep with a six speed and it works perfectly
Question:	Does the camera have night vision capability
Answer:	No, and if it is supposed to it doesn’t work very well at all. The picture is very good with a little light, but with no light you can’t see very well.
Question:	Do I still need a dealer to unlock any features with your kit? Is this truly ready to use without dealership support
Answer:	Yes, I just installed it on my 2013 JKUR with factory Nav. The module unlocked the features and it was for the most part plug n play. The only problem is the instructions are somewhat crappy. Theres a specific step about plugging the trigger wire (for the camera) into power and mounting the ground wire. Didnt properly explain any of this. I pretty much had to guess this step but it is critical as camera wont get power without it.

Product features

Backup Camera Kit Compatible with Wrangler JK; Waterproof Reverse Camera with Parking Guidelines & Plug-and-Play Video Interface

Easily add a backup camera to your Jeep Wrangler's video-enabled factory radio with this all-in-one bundle from EchoMaster!

Using your Jeep Wrangler's factory navigation monitor, this convenient package includes everything you need to add a backup camera. The camera comes with a spare tire mount that seamlessly integrates the camera behind your Jeep's spare tire. The camera provides parking guidelines and a clear video image with a super-wide 170-degree viewing angle behind your Jeep.

Also included, is the Jeep specific backup camera interface. This plug-and-play interface is the brains behind the scenes that allows for a super-easy installation and unlocks extra features for your Jeep. Simply detach the factory connector and connect the interface with the included T-harness. Not only can you use your Jeep's monitor with your backup camera, the interface also allows you to enter GPS destinations while driving (intended for passenger use), and adds an extra A/V input and output.

With so many features, this backup camera package is an easy choice for Jeep Wrangler owners looking to add a backup camera!

Features

• Sleek camera with easy-to-install spare tire mount Discreet design integrates backup camera with your spare tire.
• Tri-color parking guidelines Helps guide you into parking spots.
• 170° viewing angle Offers an expansive view of the area behind your vehicle.
• IP67-rated water-resistant Operates in all weather conditions.

What's Included

• Interface Module
• Spare tire mount reverse camera
• Harnesses
• Install Guides

Easy To Install

Sleek camera with easy-to-install spare tire mount Discreet design integrates backup camera with your spare tire.

Parking Lines

Tri-color parking guidelines Helps guide you into parking spots.

170° viewing angle

Offers an expansive view of the area behind your vehicle.

IP67-rated water-resistant

Operates in all weather conditions.

Specifications

• Sensor Type: 1/4" CMOS
• Min. Illumination (LUX): 0.5
• Viewing Angle: 170°
• Water/debris-proof Rating: IP67
• Parking Lines: Selectable
• Image (Mirrored / Non-mirrored): Selectable

• ▷ Unique high mount shock-proof rear view camera, fits for Jeep Commander (2008-2010) Compass (2009-UP) Grand Cherokee (2008-2013) Liberty (2008-2013) Patriot (2009-2015) Wrangler (2007-UP) Rubicon( 2007-2020).
• ▷ High-definition color CCD with superior daytime image crispness and nighttime brightness, 150°degree wide viewing angle, you can check the back situation easier when reversing.
• ▷ Innovative spare tire adjustable mounting bracket, fits for all kinds of aftermarket spare tires. IP68 waterproof, anti-fog lens with weatherproof housing.
• ▷ Available for factory or aftermarket display. Includes a composite (RCA) connection to the video input on the aftermarket display & an RCA harness to connect to camera with the factory display(this connection requires dealer to reprogram).
• ▷ We offer 30 days money back guarantee, 3 YEARS replacement warranty, lifetime support guarantee customer service and technical.

User questions & answers

Question:	Red wire that doesn’t plug in to the radio, where does this one go
Answer:	Hi, are you referring to the red wire next to the RCA plug? if so, you don't need to connect it if your radio is factory, any questions please contact us via amazon or [email protected]!
Question:	Can the camera be mounted upside-down? (Arranged towards 6pm of spare wheel) Will it be displayed correctly
Answer:	Not upside down, because there is no way to tell the camera to flip.
Question:	Can anyone explain what the red +/blk - wire next to the RCA output is used for
Answer:	Hi, this is a new wiring harness, if you have connected to the reversing light, you can insulate this ed +/blk - wire. If you have more questions, please contact us.
Question:	Does this provide the lines on the screen for guidance
Answer:	Yes, you will need to unplug the black button for reference line to appear.

Product features

Upgraded Reversing Camera

• High-definition color CCD lens with superior daytime image crispness and nighttime brightness, 150°degree wide viewing angle, you can check the back situation easier when reversing.
• IP68 Waterproof & Fog Resistant-Thanks to the sturdy and tightly construction, this backup camera is entirely waterproof and will never fog up after a carwash or on a rainy day.

Conveniently Switch Guidelines

No need to cut wires, switch guidelines on/off by unplugging/inserting the small black button.

Adjustable Neck

The adjustable neck allows the camera to adjust up, down, left and right to fit the camera head between different spoke patterns on most wheel designs, both factory and aftermarket wheels for the Jeep Wrangler.

Super Night Vision

Equipped with advanced Analogy High Definition, the backup camera enhances night vision in low light conditions making it easy to obtain sharp, color-accurate images at night.

Withstand Extreme Temperature

The device stands well in bad weather and extreme temperature from 4°F to 158°F, the backup camera can work without any problem.

Product description

Easily add a backup camera to your Wrangler with this backup camera and spare tire mount from EchoMaster!

Equipped with parking lines, this CMOS, bullet-style camera mounts conveniently behind your spare tire with a simple mounting bracket, letting you relax as you reverse your vehicle with newfound ease.

FEATURES

✔ Sleek camera with easy-to-install spare tire mount

Discreet design integrates backup camera with your spare tire.

✔ Tri-color parking guidelines

Helps guide you into parking spots.

✔ 170° viewing angle

Offers an expansive view behind your vehicle.

✔ IP67-rated water-resistant and debris-proof camera

Provides trouble-free operations in all weather conditions. Protected against rain, snow, dirt, or dust.

✔ 0.5 LUX

Functional even at low light levels.

SPECS

Field of View: 170 degrees

Resolution: 648x488

Sensor: 1/4" CMOS

Model Number: EM-JP-CAM

UPC: 609098832748

Color: Black

Manufacturer's Warranty - Parts: 1 year

WHAT'S IN THE BOX

Bullet-style backup camera with video cables

Spare tire bracket

Hole saw (optional use to fit camera in other spaces)

Manual

• 【EASY-TO-INSTALL】Discreet design integrates backup camera with your spare tire.
• 【TRI-COLOR PARKING GUIDELINES】Helps guide you into parking spots.
• 【170° viewing angle】Offers an expansive view of the area behind your vehicle.
• 【 IP67-rated water-resistant】Operates in all weather conditions.
• 【COMPATIBLE】Designed to work with aftermarket displays. Display/monitor not included.

User questions & answers

Question:	Do you have a shorted cable available, like 12 - 18" ? My Jeep has the connectors at the tailgate. The supplied cable is much too long
Answer:	We only have the length cable that is provided with this camera. If you had a previously installed camera on your Jeep you would want to make sure the existing is pinned the same as the Echomaster camera before plugging it in to a different brand cable.
Question:	It is only required to plug in to my jeep 2014 and it will works? or it requires anything else to view on my display
Answer:	You’ll want the one that has the wiring harness for factory install, assuming your Jeep has a factory display radio. If not, you need a new radio that has a video display, and then can get this camera and save $150
Question:	Will this work if you use a cover over your spare wheel
Answer:	You would need to remove your tire cover in order to have view from the camera. This camera mounts in between the spokes of the rear tire and would be blocked by a tire cover.
Question:	Will this fit a 1998 Jeep Wrangler
Answer:	I don’t know, I would check the description of the product and it will tell you the exact years and models it will fit

• How many times have you been backing out of your driveway or a parking spot only to have a little kid dart behind your automobile, seemingly out of nowhere? The camera is a perfect solution, you will have eyes in the back of your head
• Easy to install: 2 Installation options,you could choose bracket mounting or flush mounting as per your case
• Rear/Front Switchable: Optional Customized Distance Scale Lines & Mirror/Normal Image Switchable - You Can Use it as Rear View Backup Camera or Front/Side Camera Note: By default this is a reverse camera (mirror image) with distance scale line
• 170 Degree Wide View Angle to help you see blind area where your eyes can't reach.Work with your head units or aftermarket LCD/TFT displays with standard RCA input only,Suitable for variety of vehicles: car, mini-truck, mini-van etc,12V working Voltage ONLY,Support NTSC only
• Reliable and friendly customer service,1 Year Warranty,Ready to respond within a 24 hour time frame,30-Day Money Back Guarantee

Product features

Get a Better View Angle

If you want to get a perfect view angle, before drilling a hole, please seriously check and test to find where is the best position to mount this camera, please rotate the middle housing part of the camera (maximum 360 degrees) or move the bracket (maximum 90 degrees) to get the best view angle.

Super Night Vision

With advcanced night vision technology, it is easy to see things clearly in the dark, because its accurate recognition of lawns, stones, lakes, so it will be a reliable assitant at night. It also has clear and true color image at daytime, you can see the true color of the things you pass by.

Parking Safely

It is difficult to park without a rear view camera even though you are an experienced driver, we cannot see all of the area behind of our vehicles. With this 170° large Viewing angle reverse camera, you can see clearly everything at the back of your car and quickly and safely park you car well.

Image Flip Function

L002 backup camera supports Normal and Mirror image. You can install it in front/rear of your car to avoid any blind spot, the default is mirror image for rear view（keep the green wire).

Note: if the green wire is cut, it can't connect again, so please make sure you want a rear view camera or front view camera before you cut it.

170 Degrees Wide View Angle

RAAYOO L002 flush or bracket mount front/side/rear view camera adopt the 170°wide viewing camera lens, effectively help you see more area where your rear view mirror cannot reach, See wider,More safer.

Support Any Car Stereo with Standrad RCA Video Input

Works with your head units or aftermarke LCD/TFT displays with standard RCA input, 12V working Voltage ONLY,Please check if your display support RCA video input before make a order.

Get Better Your Rear View Image

RAAYOO L002 flush or bracket mount bind spot vehicle backup camera adopt 2020 latest 6pcs all-glass large aperture lens to provide HD resolution clear and true color image image for your vehicle without delay, No purple issue.

Easy to Install

1.Find a proper location to mount this reverse camera.

2.Connect the power wire of camera to your reversing light,postive to reversing light+,negative to revesing light - or ground.

3.Connect the video cable of camera to the head unit of your vehilce. Note:Please test the backup camera before rounting the video cable Connect trigger A with B if your head unit with a trigger wire A, if not, no need connect them.

4.Start the vehicle and gear on reverse to test the camera.

Above is the installation instruction for backup camera, you need to cut the green thin wire and white thin wire if you want to install it as a front view camera.

Product description

Specification:

Camera Sensor  CCD

Viewing Angle (H) 170°

Viewing Angle (V) 90°

Power Supply 12v

Waterproof IP67 - IP68

TV System NTSC / PAL

Package weight:1.73lb

Feature

Multi-function Rear-vision integration kit with interface for All Jeep Wrangler Vehicles.

OEM-style Spare Tire Mount Rear-view Camera included

Terminates with RCA for use on most aftermarket radios with video input

Interface includes Audio / Video Input to connect an extra A/V source

Automatically switches to Rear-view when car is in Reverse mode

Plug & Play Installation

Unique high mount camera system for Jeep Wrangler willys exclusive design

OEM validated camera Cmos technology for superior daytime image crispness & nighttime brightness



Package include:

1xbackup camera+ power wire

• Noted:If your jeep upgrading from no camera to reverse camera and head unit have no way to show reversing, you should go to Jeep dealership for programming or purchasing a Bluetooth obd dongle may helpful. Compatible for Jeep Wrangler 2007- 2018, Jeep Wrangler Rubicon Unlimited, JKU Rubicon.
• A good solution for jeep reverse parking. Removable guideline, select remove guideline or keep it in the help of instruction.
• Installation was pretty straightforward. Good quality power and ground wires. NOTED: Power running must be 12V. For your safe do not use ignition power to the camera or may cause resistors in the plug to get hot and possibly melt.
• Heavy duty camera lens. 170° wide angle camera HD lens CCD sensor to provide you a good vision at daytime and night. Support NTSC/PAL TV system. Waterproof IP67, lens has been sealed well to withstand the sand of dunes, mud from the bogs, or the flying debris of the trails.
• Comes with 2 standard Factory radio Uconnect MyGIG Media RCA Adapter, Terminates with radio plug to connect your head unit.

User questions & answers

Question:	How do u get the parking lines to appear
Answer:	backup camera comes with a small white loop, in there you can take out the back cap, parking lines will appear
Question:	will this work with the existing screen on a 2017 Sahara with Navigation System
Answer:	I put it on a 2014 Rubicon stock radio w/ nav, and it works great. I got a Bluetooth obd2 dongle and turned on functionality with OBD JScan android app. The installation instructions that come with it are crap so you gotta kinda know what you're doing.
Question:	If I need to rotate the camera to align with an opening in the wheel, will the camera be able to adjust to appear vertical
Answer:	No the image will appear upside down.
Question:	Where can I find better installation directions
Answer:	If you send questions to the e-mail address on the instruction sheet they will get back to you within 24 hours. I sent questions and pictures and they responded in kind. Once I received their response, it was very straightforward installation. If you are looking for how to take the dash apart to gain access to the radio, there is a YouTube video on removing and replacing the radio. I found it all to be fairly easy once I understood the wiring and probably took a total of 3-4 hours from start to finish.

Product features

RED WOLF JEEP Spare Tire Backup Camera

We are trying our best to provide safe and comfortable driving conditions to you!

Glass Camera Lens

Glass camera lens, High temperature resistance, long life!

Easy Install

Mounting is easy and good look

What We Include

Mounting Accessories and instruction

Other Advantage

Spare tire camera consists of a high-quality shell, At the same time, camera lens is resistant to high temperatures and can be used normally even in extremely hot temperature!

Product description

Feature：

Suitable for safety and security.

Appliacable to all type of vehicles.

Made of high quality and durable material.

High-definition and 150 degree viewing angle.

Built-in guideline for instant distance calculation.

Waterproof and can be installed on your license plate.

Easy installation and can be installed in several ways.

Can be connected to any type of monitor with a composite yellow RCA jack for crystal clear resolution.



Specification:

Lens: 1.7mm

Waterproof rate: IP68

Lens Angle(Deg.): 150°

Power Supply(DCV): 12V

Resoulution(TV Lines): 480

Minimum Illumination: 0.1LUX

Operating temperature: -20℃~+70℃



Package inclueds:

1 x Car rear view camera

1 x Video and power cable (5M)



Note:

This camera has a normal image which can be adjusted on the monitor connected with it.

• ★This license plate mounting backup camera is designed for JEEP Wrangler 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018.
• ★Wide view angle 150° with 1.7mm lens and great night vision. With the waterproof rate of IP68, shockproof, anti-interference and resistance to high/low temperature.
• ★If it is the first time you install the backup camera, you may be required to go to your dealer to program the radio to enable backup camera feature. If you need the video wire harness RCA Plug for your OEM display, here's the link. https://www.amazon.com/gp/product/B07WZXCNV3
• ★Please note that this is a license plate camera, so the reverse image may not be in the center.
• ★Replaces easily by popping the OEM license plate tag light holder out and popping the camera in. But needed a little adjustment for some models, such as, file a small groove in the license plate frame. Please tell us when you meet problems.

User questions & answers

Question:	Does the camera view get obstructed by the rear-mounted spare tire on a Jeep
Answer:	No because the camera does not view from the center of the jeep it is off set to the license plate position. Just remember that when backing up.
Question:	I don't know if others can see the same picture as I do, but do they really think we can't read that blurred out license plate
Answer:	What does this have to do with the product?
Question:	I just received the camera I ordered today and the picture of the lines that are coming from the camera have a red coax plug and a yellow coax plug
Answer:	Should have came with a wire harness also, the yellow is your video and the red is the power, the red goes to your reverse light letting the camera know to turn on. The yellow will hook into the back of your display (radio, mirror or lcd screen) which ever one you are having it go to.
Question:	Will this work with 2015 factory radio for Jeep Wrangler
Answer:	Hi, yes, it can work with 2015 factory radio for Jeep Wrangler 2015.

Product features

Upgraded Lens & Clearer Image

The upgraded lens has no IR, so the image does not appear purple and the picture quality is clearer.

Built-in Multi-Function Switcher

Built-in PAL/NTSC switcher & distance guide line Yes/No switcher.

• Cut off the green line to switch PAL/NTSC;
• Cut off the blue line to hide the guideline.

Super Night Vision

Equipped with advanced Analogy High Definition, the backup camera enhances night vision in low light conditions making it easy to obtain sharp, color-accurate images at night.

Withstand Extreme Temperature

The device stands well in bad weather and extreme temperature from 4°F to 158°F, the backup camera can work without any problem.

Product description

Finally - an answer for Jeep Wrangler owners who want to add the safety and practicality of Rear Vision. This kit is designed for vehicles with a factory display or factory navigation radio. It includes a programming module that temporarily plugs into the OBDII port to code the radio. No dealer activation needed! Guidelines not available on this camera. This kit is only compatible with factory wheels. If you have aftermarket wheels you will want SKU: 5CS-JTR-ADJ-NAVI for an adjustable bracket. NOTE: NAVIGATION SYSTEM IN PHOTO IS NOT INCLUDED, you must have the factory display radio for this kit to work.

• Unique high mount camera system for Jeep Wrangler - far superior to a license plate mounted alternative where the image would be offset
• Innovative spare tire hub mounting bracket
• Full length PRELOOMED chassis wiring harness included - terminates with factory display radio terminals so it's plug and play!
• No dealer radio programming necessary - Use the included programming module to reprogram your display radio (Radio NOT included)
• CCD technology for superior daytime image crispness & nighttime brightness-NO parking Guidelines.

User questions & answers

Question:	does it replace the factory radio and navigation system
Answer:	Hi Carmen, No, You will use your vehicle's factory radio and navigation system. The kit comes with a programming module to reprogram your display radio to recognize that the vehicle has a camera now. This will allow you to view your backup camera on your factory screen. Thanks, Tricia
Question:	Would this camera fit my 2013 Jeep Wrangler
Answer:	Yes it will provided you have the MyGig display radio system.
Question:	How do i know if this will work with my 2016 wrangler ? i’m not sure what radio i have but i do not have the factory sub woofer
Answer:	This kit is compatible with 2007-2018 Jeep Wranglers with a factory display radio / factory navigation radio. Thank you, Hillary
Question:	Is it possible to see the install guide to see if i can diy
Answer:	Yes you can google the unit and it will show you install direction this is very easy to install just FYI if you have oversize tires you'll need to modify the bracket to get it out for a full view

Product description

Easily add a backup camera to your Jeep Wrangler with this backup camera and spare tire mount from AMINORD!

FEATURES

♥Easy to install.

♥High-definition color CCD with superior daytime image crispness and nighttime brightness, 170°degree wide viewing angle, you can check the back situation easier when reversing.

♥IP68-rated water-resistant and debris-proof camera.

Provides trouble-free operations in all weather conditions. Protected against rain, snow, dirt, or dust.

♥0.1 LUX, Functional even at low light levels.

SPECS:

Field of View: 170 degrees

Resolution: 1000 TV Lines, (1280*720)

Sensor: SONY CCD Sensor.

Package List:

1 x Rear View Camera with 1m/3.2ft Power Cable

1 x Adjustable Tire Mount Bracket

1 x 6m/19.6ft Video Extension Cable

1 x Adapter

1 x Manual(if you find no user manual,please email us,we will send it to you)

• [Compatibility]: Perfectly compatible with Jeep Wrangler with OEM Radio. (Years: 2007+)
• [Resolution]: 1000 TV Lines, [ANGLE]: Wide View 170 °
• [IP68-rated water-resistant]:Operates in all weather conditions, the best waterproof camera on amazon.com so far.
• [Upgrade Model]: Higer hardware configration with Lower price, supplied by the AMINORD's factory directly.
• [2 Years Warranty]: Place order with 100% confidence at Aminord-Direct, free return or replacement in 6 months.

User questions & answers

Question:	I have a 2007 wrangler with a pioneer AVH211 radio will it plug and play
Answer:	Generally, OEM radio needs to be unlocked.
Question:	Will work on aftermarket tires
Answer:	Yes, it works on aftermarket tires.
Question:	I have a 2016 jku sahara with a 430n radio that has been flashed for a brandmotion backup cam. do i have to have it reflashed if i change to this
Answer:	Hi, good day,sir. No need. plug and play.
Question:	Got 2020 Rubicon wangler
Answer:	Yes.

Product description

Product parameters

Resolution: 800 TV lines

TV System: NTSC

Night Vision: Yes

Power Supply: 12V

Parking Guideline: Yes

ANGLE: Wide View 170 Degrees

Reversing Image: Mirror Image

Waterproof Rating: IP67

Power Consumption: 120mA

Video Output: CVBS RCA Connector (1.0VP-P, 70OHM)

Working Temperature: -20 ℃ to 75 ℃, RH 95% MAX

Storage Temperature: -40 ℃ to 80 ℃, RH 95% MAX

Car Model:

For Jeep Wrangler 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018

Important Note:

Please make sure there's a hole at the 12 o'clock on the spare hub, otherwise this Rear View Backup Camera can not be installed.

• Designed for Jeep Wrangler 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018
• This reversing camera is mountted on the spare tire. Please make sure there's a hole at the 12 o'clock on the spare hub.
• Resolution: 800 TV lines. Effective pixels: 976 * 497
• Waterproof Parking Camera: You do not need to worry the backup camera will not work on rainy days.
• Terminates with RCA for use on most aftermarket radios with video input. If it is the first time you install the backup camera, then please go to your dealer to reprogram your factory radio first.

User questions & answers

Question:	Will it work with after market tires and wheels
Answer:	Yes, my tires are after market preoducts
Question:	I will like to know where the red and black wire goes from the backup camera
Answer:	There should be a connector coming from the cable out of the back of the camera - the connector from the red and black wires connects to that, the other end connects to the headunit adapter.
Question:	Are these delivered with instructions
Answer:	Yes, my friend, the package comes with instructions.
Question:	will this work in a 2018 jeep wrangler JK with a factoery 430 radio without navigation
Answer:	Works on my 2015 Wrangler JK.
