9 best i7 cpu coolers

Product description

Cooler Master, an industry leading chassis, thermal solution, peripheral, and accessory manufacturer, signals the rebirth of a household name in computing, the Hyper 212 EVO CPU Cooler. It comes packed with an improved tower fin design, heat pipe layout, and upgraded fans and fan brackets that provide an even more extreme value for end users of all types. Dents are created when the heat pipes are sealed. The cut and seal is not a damage, after the heat pipe is full, machine will crimp it. Fan Speed: 600-2000 RPM (PWM) ± 10%, 600-1600 RPM (PWM) ± 10% (EU Version).

• Air flow: 82.9 CFM; Noise level: 36.0 decibels
• Fan dimensions:120 x 120 x 25 millimeter (4.7 x 4.7 x 1 inches)
• Heat sink dimensions: 116 x 51 x 159 millimeter (4.6 x 2 x 6.2 inch)

User questions & answers

Question:	AM4 support
Answer:	Hello Mark, Yes, the 212 Black edition does have support the AM4 right out of the box. CM-PNguyen
Question:	Will this fit a AM3+ motherboard
Answer:	Here is a video of my AM3+ motherboard with this fan inside https://www.youtube.com/watch?v=rM34Jzi-6fg and here is a a video on the Noise Level https://www.youtube.com/watch?v=fTQ2dlrpEHI
Question:	Do you add thermal compound
Answer:	Hello, Yes you would apply thermal compound. There is a small tube included with the unit. CM-PNguyen
Question:	noise
Answer:	Much quieter than a dvd rom spinning up.. Only noise is when I’m playing a severely demanding cpu game. Even then it’s barely noticeable at 2500rpm

Product features

Hyper 212 EVO

The Hyper 212 EVO cooling systems are designed and optimized to provide the best user experience and cooling potential for a new generation of processors. The Hyper 212 EVO now features four Cooler Master patented Continuous Direct Contact (CDC) heat pipes that are tightly packed into a flat array on the CPU Cooler base. This acts as a virtual vapor chamber that dissipates a large amount of heat. The aluminum fin structure has been optimized to provide the perfect performance balance.

Product description

CoolerMaster MasterLiquid ML240L RGB V2 is a refreshed design from the popular MasterLiquid Lite Series that elevates the exterior design elements The Pump of the ML240L RGB V2 has been enhanced with the newly designed 3rd Gen Dual Chamber Pump that improves the overall cooling efficiency of the AIO water cooler The radiator surface area has been enlarged to increase the surface area for heat dissipation for optimized cooling performance The ML240L RGB V2 will included the latest SickleFlow 120 RGB fan with a brand new design and Air Balance fan blades that is quieter than before without compromising on air flow and pressure.

• 3rd Generation Dual Chamber Pump for overall cooling efficiency and performance
• New SickleFlow Refreshed exterior design for improved lighting and fan blades for a quiet airflow performance
• RGB Lighting Signature cooling performance with an RGB design for all of the users wanting lighting effects that are fully customizable
• The larger surface area increased the surface area of the fins on the radiator for better heat dissipation
• Industrial grade seal high: Industrial Grade EPDM material to strengthen the seal for improved longevity and Anti-Leaking
• Controller: Included a wired RGB Controller
• CPU socket support: LGA2066, LGA2011-v3, LGA2011, LGA1200, LGA1151, LGA1150, LGA1156, LGA1155, AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1

User questions & answers

Question:	Would this work with a z370 sli slim motherbaord
Answer:	The power button is a simple switch. It will click when pressed. CM-PNguyen
Question:	Does the cooler work on a mobo intrl lg1151 socket
Answer:	Yes with the aRGB header plugged into the motherboard - you can use your motherboard RGB software to turn off the fan lights.
Question:	Is the cooler's tdp actually 130w? the listed figure is very low compared to similar cooler master aios
Answer:	Yes there is. 2 x 120mm / 2 x 140mm / 1 x 200mm -CM Myke
Question:	Hi, I have read alot of reviews saying the therr is a design flaw, Can the manufacturer guarantee that the plsstic tabs will not brake
Answer:	Because 200mm fans don't have to spin very fast in order to move a lot of air they're actually pretty quiet. I don't believe the RPM on them can get very high either so even at full speed they'd still be pretty quiet compared to a smaller fan that has to spin at a much higher RPM to get the same amount of airflow.

Product features

MasterLiquid ML240L RGB V2

ML240L RGB V2 is a total refresh of the popular Lite Series. The pump has been enhanced with the newly designed 3rd Gen. Dual Chamber design, improving the overall cooling efficiency of the AIO water cooler. The radiator surface area has been increased for heat dissipation and optimized cooling performance. The latest SickleFlow120 RGB fan is included with a brand new design and Air Balance fan blades that is quieter than before without compromising on air flow and pressure.

New Dual Chamber Pump

3rd Generation dual chamber pump designed for better performance and overall efficiency.

Included Wired RGB Controller & Splitter

Allows you customize colors and light effects.

Double Tubing

FEP makes it durable yet flexible. Sleeved tubing on the exterior to give it a premium look.

Product description

Thermaltake 7-bladed 92mm 4-Pins PWM Aluminum Extrusion CPU Cooling Fan for Intel Core i7/i5/i3 CLP0556-B Gravity i2 is a simple low-profile CPU cooler with a compact size 92mm fan in 7-bladed design; aluminum extrusion heatsink can dissipate heat up to 95W. Optimized solution for low power processors. Gravity i2 supports Intel Socket LGA 1150/1155/1156. P/N: CLP0556-B Compatibility: Intel LGA 1156/1155/1150/1151 Heatsink Material: Aluminum Fan Dimension: ∅92 x 25 mm Fan Speed: 1800 RPM Rated Voltage: 12 V Start Voltage: 6 V Rated Current: 0.12 A Power Input: 1.44 W Air Flow: 31.343 CFM Air Pressure: 1.484 MM-H2O Noise: 21.3 dBa Life time/Fan Life time: 40,000 hours pin connect: 3 pin Cooling Power: 95 W Heatsink Dimension: 63 H * 95.8 W * 95.8 L mm Weight: 320 g

• Aluminum Extrusion Design
• Low-profile Gravity i2 has a perfect ratio aluminum extrusion heatsink
• Compatibility: Intel Core i7/i5/i3. Socket LGA1156/1155
• Connector: 4-Pins PWM. Compact Size Fan: 7-bladed 92mm fan provides better cooling performance with low noise
• Quick and easy installation

User questions & answers

Question:	Is it compatible with the Intel Pentium G
Answer:	Probs. It can be attached to an i3 7100 which is the same size as a G3258
Question:	Will this work for hp 500-070 and what temperature can it go up to
Answer:	It should. And as for the temps youll be getting it depends on a few factors like case and airflow and the cpu your using
Question:	Please confirm the product dimensions: 13.5 x 9.5 x 22.3 inches
Answer:	I'm not sure of the dimensions. Another retailer lists the heatsink dimensions as 2.39" x 3.77" x 3.77"and the fan dimensions as 0.98" x 3.62" x 3.62" (sorry it's not metric). This heatsink fits perfectly on my Intel BOXDH77EB motherboard. My case is a Silverstone ML03. I actually have two of these, same case, same motherboard. They're quiet, have real metal screws and haven't given me any problems.
Question:	Does this come with thermal paste already applied
Answer:	No it does NOT have thermal paste pre-applied. It does however have a small packet of paste included in packaging. I strongly advise to get a tube of paste for less mess during application.

Product features

Contac Silent 12 CPU Cooler

Thermaltake Contac Silent 12 is a budget CPU cooler with excellent cooling performance, featuring a 120mm PWM controlled fan, high airflow fan blades, long life hydraulic bearing, low-noise operation as well as non-interference cooling design. The Contac Silent 12 supports all the latest Intel and AMD CPU socket.

Universal Socket Compatibility

All-in-one back-plate design offers universal Intel and AMD socket compatibility.

Intel LGA 1366/1156/1155/1151/1150/775

AMD AM4/FM2/FM1/AM3+/AM3/AM2+/AM2.

High Airflow Fan Blade Design

The fan blades are engineered to achieve the optimal cooling performance and generate large volume of air passing through the heatsink at any angle.

Special-Designed Fan Clips

The fan clips allows the fan and the cooler to combine tightly. Also, the clips make assembly and dismantling more easily in process.

Optimized Silent Operation

The Contac Silent 12 comes with a LNC (Low-Noise Cable) that can reduce 24% of noise level and 27% of fan speed.

Long Life Hydraulic Bearing for Reliable and Silent Operatio

The hydraulic bearing self-lubricates with a high quality, friction-reducing substance that lowers operation noise and enhance thermal efficiency. The seal cap prevents leakage of the lubricant and improves the lifespan of the unit.

Superior Heat Dissipation

Optimized 0.4mm thickness aluminum fins with 2.2mm air gap, and 4 x Ø6mm solid copper heat-pipes are designed for rapid heat dissipation, allowing maximum heat conductivity. The tower’s side flow design delivers the best cooling performance. In addition, the heat-pipes are in continuous direct Contac with the CPU to ensure fast and efficient heat dissipation.

Non-Interference Cooling Design

The new Contac Silent 12 solves the co-existing problem of high performance RAM and CPU coolers, achieving the best RAM clearance.

Engine 27 1U Low-Profile CPU Cooler

Thermaltake Engine 27 1U Low-Profile CPU Cooler supports Intel Socket LGA 1150/1151/1155/1156, and is specially designed with 27mm height, metallic structure and copper base that offer an excellent balance between performance, size and acoustics. The compact size 60mm fan is the ideal choice for small form factor applications. Moreover, with the built-in PWM fan and metallic blades and fins design, the Engine 27 guarantees extremely low noise level without compromising on the cooling performance.

Unique Metallic Structure with Superb Heat Dissipation

Unlike traditional CPU coolers, the Engine 27 features a metallic structure and copper base that provides more fortified and efficient thermal paths for CPU. The metallic fan is designed to directly pull heat from CPU. Especially, the metallic fan base is engineered with small radial gaps that allow heat to be transferred rapidly to the rotating metallic fan. Hence, when the metallic fan blades generate cooling airflow, heat will also be transferred to the flowing air by both rotating fan and stationary fan base at the same time.

Forty Fan Blade Design for Better Cooling Performance

To make a perfect balance between cooling performance and noise level, forty fan blades are engineered to generate large volume of air passing through the heatsink at any angle. Additionally, the metallic blade rotation will create a centrifugal force on ambient air. In the meanwhile, the centrifugal forces will expel hot air so that heat can easily be taken away from the fan blades. Most importantly, this cooling technique can reduce the blade’s noise and vibration because hot air expelled will create a vacuum, and then fresh cooling air will be drawn in the heatsink.

Radial Fin Arrangement

The Engine 27 is specially designed with metallic radial fins to accelerate the thermal transfer process. Especially, the radial arrangement with 119 fin design can minimize the gap between the fan and the fins, thus, hot air can be exhausted more rapidly and efficiently.

Thermaltake Gravity i2

Gravity i2 is a simple low-profile CPU cooler with a compact size 92mm fan in 7-bladed design; aluminum extrusion heatsink can dissipate heat up to 95W. Optimized solution for low power processors. Gravity i2 supports Intel Socket LGA 1150/1155/1156.

Aluminum Extrusion Design

Low-profile Gravity i2 has a perfect ratio aluminum extrusion heatsink for better heat dissipation up to 95W.

Compact Size Fan

7-bladed 92mm fan fan provides better cooling performance with low noise. Quick and easy installation.

Product description

Intel Socket 1155/1156 Aluminum Heat Sink & 3.5" Fan w/4-Pin Connector up to Core i3 3.06GHz

• Intel Socket 1156 Aluminum Heat Sink and Fan General Features: Aluminum heat sink
• 3.5-inch (90 mm) fan DC 12V, 0.17A Supports Intel Core i3 Socket 1156 processors up to 3.06 GHz
• 4-pin power connector (12-inch length, approximate) Regulatory Approvals: UL CE

User questions & answers

Question:	Does this come with the back plate? I'm putting this in something thats not a computer case so i'll need a new heatsink with a back plate
Answer:	I use them for both. No issues at all.
Question:	Will this heatsink be compatible with 1155 socket for an i
Answer:	If they have standard micro usb port then yes
Question:	Does it come with the thermal paste strips preapplied
Answer:	The Galaxy s5 is the exact phone I use there on. They work just fine.
Question:	Compatible with lga
Answer:	Hello Tiffany,Yes, it will. Please feel free to let us know if there is anything else that we could help you with.Regards,Cable Matters

• Classic 120mm slim-tower design combines outstanding cooling performance with excellent case-, RAM- and PCIe-compatibility
• Does not overhang the RAM or PCIe slots on most current motherboards
• Highly optimised NF-F12 120mm Focused Flow fan with PWM support and Low-Noise Adaptor for automatic speed control and ultra-quiet operation
• Includes high-end NT-H1 thermal paste and SecuFirm2 mounting system for easy installation on Intel LGA1150, LGA1151, LGA1155, LGA1156, LGA1200, LGA2011, LGA2066 and AMD AM4, AM3(+), AM2(+), FM2(+)
• Renowned Noctua quality backed up by 6-year manufacturer’s warranty, deluxe choice for Intel Core i9, i7, i5, i3 (e.g. 10900K, 10700K, 10600K, 10980XE) and AMD Ryzen (e.g. 3950X, 3900X, 3700X, 3600X)

User questions & answers

Question:	How does the performance of this setup compare to say the h80i liquid cooling system or comparable ones
Answer:	I know this question is old, but I have had the h80i for two years on two rigs and I moved one over to this cooler, and now I’m buying another one of these to replace the other h80i. Temperature differences? The h80i did fine for a while, but it’s gotten slowly louder and hotter over time...liquid may be drying up. Meanwhile the noctua is quieter than the h80i EVER was, and keeps the cpu (a 4970) cool enough that it’s always running at boost clock speed. I don’t overclock, I just want my computer quiet and running fairly cool. These do the trick, and they’re far easier to assemble than the Corsair water blocks. I have a third machine that I started out with this cooler on, and it’s worked like a champ for YEARS. I’m a bit mad at myself for ever going the water cooling route.
Question:	I have a spare Noctua fan, could i mount it on the other side of the radiator for more efficient cooling? I have the ASUS Maximus Formula VI
Answer:	Who has such an expensive fan as a spare? Anyway, of course you could use it. There is an extra bracket provided for this exact application, along with some thicker anti-vibration rubber pads. I personally would mount the second fan in the exact same orientation as the first fan so that it still pulls air from the right side of your case and pushes it out the left side. I don't like air-flow working against each other. I create kind of like a wind tunnel in my case.By adding this second fan to just aid in helping to 'pull' the air through being pushed though by the first noctua nf-f12 fan, you could set both fans to about 900 rpm. Not that there isn't efficient cooling already in my case with just the one fan at 900 rpm. What model is that extra fan you have, is it another nf-f12 or nf-s12a? I would mount a nf-s12a as a second fan since the nf-f12 is optimized to push air through restrictive areas, i.e. the cpu heat sink and then I wouldn't use the thicker rubber spacers provided in the box with the NH-U12S cooler, but I would use the thinner rubber spacers already on your additional noctua fan.I am not sure why noctua provides thicker rubber pads for the second optional fan, maybe it's because they think you will use another nf-f12 pressure optimized fan and it needs that little bit more breathing space since it is more designed as a 'pushing' air type fan rather than pulling, I don't know. I would still prefer the nf-s12a as a second fan. I read reviews where a second fan on this cooler only managed to give 1-2 degrees C better temps...run a benchmark with one and then two fans, keep your eyes on your temps and if you only see a small improvement like this, I don't think I would waste such a good fan for that 1 or 2 better temps. Rather mount it as an intake fan then. Hope I could help.
Question:	Does this come with thermal paste? If so, is it applied already onto the heatsink, or does it come into a tube
Answer:	The heatsink or cpu cooler come with high quality thermal paste plus mounting for LGA 2011 and 1150. However, you need to apply the paste on top of the cpu. There are many videos on YouTube that shows you the proper way of putting it if you want to know how exactly it is applied on top of the CPU. To answer you question, it comes in a tube of about 50 ml if I am not mistken.
Question:	So if I want a Noctua cooler in something than this hideous brown, I have to buy black fans separately
Answer:	exactly!

Product features

Classic 120mm tower size for excellent overall compatibility

Standing 158mm tall, the NH-U12S is short enough to fit most modern mid- or high-end tower cases. Measuring 125mm wide (including fan and fan clips), the cooler stays clear of the top PCIe slot on standard ATX or Micro-ATX motherboards, ensuring best compatibility with SLI and CrossFire setups.

100% RAM compatibility

Thanks to its slim design with only 45mm fin depth, the NH-U12S will not overhang the RAM slots even with two fans installed. This gives the user full access to the memory modules on all current CPU sockets and ensures 100% compatibility with tall heatspreaders or optional memory fans.

SecuFirm2 mounting system

Noctua's SecuFirm2 mounting systems have become synonymous with quality, safety and ease of use. Supporting Intel LGA1200, LGA115x (LGA1150, LGA1151, LGA1155, LGA1156), LGA2011, LGA2066 and AMD (AM4, AM3+, AM2+, FM1, FM2, FM2+), the SecuFirm2 mounting included with the NH-U12S ensures perfect contact pressure and maximum convenience on all current sockets.

NF-F12 120mm Focused Flow fan

Recommended by more than 150 hardware publications and thousands of enthusiasts world-wide, the Noctua's premium quality NF-F12 Focused Flow 120mm fan is renowned to combine superb static pressure, excellent heatsink performance and surprising quietness of operation.

Cooler Specifications

Complying with the open SecuFirm standard, the NH-U12S can be made compatible with the older LGA1366 and LGA775 sockets using the optional NM-I3 mounting kit, which is provided by Noctua free of charge. If technically possible, Noctua will also provide upgrade kits for future sockets.

Scope of delivery

• NF-F12 PWM premium fan
• Low-Noise Adaptor (L.N.A.)
• NT-H1 high-grade thermal compound
• SecuFirm2 Mounting Kit
• Anti-vibration pads and fan-clips for second NF-F12
• Noctua Metal Case-Badge

• Supports Intel Socket 150W LGA20XX/LGA1366/LGA115X and AMD Socket 140W AM4/AM3+/AM3/AM2+/AM2/FM2+/FM2/FM1
• RGB aluminum-made top cover and RGB fan are synchronized to present amazing colorful lighting effects
• RGB lighting system can be controlled by cable controller or motherboard with 12V 4 pin RGB port, including ASUS Aura, GIGABYTE RGB Fusion,and MSI Mystic Light
• 4 direct contact Heat pipes combined with upgraded 0.5mm thickness aluminum fins give excellent heat transfer for high DTP CPUs
• 120mm fan with PWM controlled function ensures less vibration, noise and turbulence

User questions & answers

Question:	Will this cpu cooler fit in an in win
Answer:	it does not use that much it uses nearly MIN:1.5w Max:5 watts
Question:	My mother board only has sata 3.0 ports. Not the bigger one the rgb controller cable has. Is there a adapter I could buy to use this feature
Answer:	Hi Jaron, The pump itself would be the light controller, you'd connect the fans to it and then the pump to the internal USB 2.0 header on your motherboard for iCue control. If you have any other questions please reach out: support.corsair.com
Question:	Does it come with a second bracket so you can mount a second fan on the opposite side? Or does it only come with the small bracket for the one side
Answer:	Based on the coldplate design and the mounting method it uses, it is CoolIt product. It is a successor to the Platinum line that was only previously offered with 240mm and 280mm versions.
Question:	Does this come with thermal paste on it? Or do you apply it yourself
Answer:	Yes, the ELITE CAPELLIX AIOs are the newest ones we've released. If you have any more questions or concerns, please feel free to contact support via our website.

• 【Single Tower Dual Silent Fan Setting】Two full function 120mm 5V 3Pin addressable RGB, 12V 4Pin PWM fans adopt silentPro blades design with Corona LED frame to increase air convection efficiency and greatly improve heat dissipation. Stable operation and reduce noise. The fan supports for automatic speed control, at 1000~2000±10%RPM. 6 different solid colors and 10 lighting modes controlled by remote controller, unlimited changes.
• 【E-sports Plexiglass Definable RGB LED Top Guard】Plexiglass definable RGB LED top guard, syncs with FRGB addressable version, protects heat pipes from damage. Anti-oxidation protective layer for surface treatment, ensure light transmission and avoiding glare. Sync with the FRGB fan lights like rainbow, stylish and cool, full of personality. It can be also switched to solid light mode. Include RGB controller.
• 【High Efficiency Closed Air Duct Enclosure Design】GI-D66A HALO FRGB cpu cooler with close air channel design, prevents air from overflowing. The air is blown directly to the base and the heat pipe, the cpu cooler cools down more quickly. The aluminum heatsink material maintain the light weight and good corrosion resistance, and significantly improve heat dissipation efficiency.
• 【6 Heat Pipes Direct Touch and Super Heat Dissipation·230W TDP】6 pcs 6mm nickel plating copper powder heat pipes U type for fast thermal conduction, 55X35mm aluminum base with HDT (Heat pipes Direct Touch). The heat pipe is in direct contact with the CPU to achieve efficient and rapid heat transfer for maximum heat dissipation. TDP is up to 230W, greatly improved heat dissipation performance.
• 【Universal Metal EasySET Pro Bracket】Compatible with Intel LGA2066 / 2011 / 1150 / 1151 / 1155 / 1156 / 775 / 1366 and AMD AM4 / FM2+ / FM2 / FM1 / AM3+ / AM3 / AM2+ / AM2. Easy to install, more stable, and the heat pipe is in derectly contact with the CPU, the motherboard is effectively protected from being bent and deformed.

Product features

PCCOOLER - GAMEICE GI-D66A Tower Air Cooling CPU Cooler Is More Distinctive and Innovative, Provides You with Excellent System Solution of Cooling.

GI-D66A HALO FRGB

GI-D66A cooling system is designed and optimized to provide excellent user experience and cooling potential for a new generation of processors.

Aluminum Base with 6 Heat Pipes Direct Touch

• 55X35mm aluminum base with HDT(Heat Pipes Direct Touch) and 6X6mm copper powder heat pipes U type for accelerated thermal transfer.
• Anti-oxidation nickel plating prevents corrosion and TDP is up to 230W, Direct contact eliminates a thermal resistance and keeps continuous contact between CPU and cooler compared to generic metal bases thereby increasing efficiency.

Definable RGB LED Top Guard Sync with Fan ARGB

• Definable RGB LED top guard with anti-oxidation protective layer, which syncs with fan ARGB lights like rainbow to present amazing colorful lighting effects. GI-D66A cpu cooler can also be controlled to a solid light mode, like full red, full orange, full yellow, full green, full blue, full purple.
• RGB lighting system is easily controlled by included RGB controller or motherboard software, set lights effortlessly. Compatible with ASUS AURA, Asrock RGB, Gigabyte fusion, Msi RGB motherboard lighting software.

Two Full Function PWM Fans with Dual RGB Lighting Loop

• Dual RGB intelligent speed control quiet fans at 1000~2000±10%RPM, SilentPro blades design with Corona LED frame provide sufficient air static pressure to improve cooling performance of the cpu cooler.
• Complete RGB-cooled system with an additional fan, featuring 18 individually addressable RGB LEDs split between two separate light loops.

Close Air Channel Design For More Cooling

• GI-D66A HALO FRGB cpu cooler with close air channel design, prevents air from overflowing. The air is blown directly to the base and the heat pipe, the cpu cooler cools down more quickly.
• The side air duct can show the faint light of the fan, improves visual effects.

Thickness Aluminum Fins Improve Heat Dissipation Efficiency

• The aluminum heatsink material maintain the light weight and good corrosion resistance, significantly improve heat dissipation efficiency.
• High-density aluminum fins are designed for accelerated thermal distribution, providing processor superb cooling performance during operation and excellent balance between airflow and static pressure to take the heat away.

Easy Installation CPU Cooler

• Provided with highly durable and optimized universal metal EasySET Pro bracket, ensures easy installation on all motherboards.
• Please pay attention to the motherboard output current if you want to install more fans on the motherboard.

Brilliant RGB Needed in Your Gaming Rig.

CPU Compatibility: Intel LGA2066/2011/1150/1151/1155/1156/775/1366 and AMD AM4/FM2+/FM2/FM1/AM3+/AM3/AM2+/AM2

TDP:230W, Overall Dimension: 135(L)X105(W)X160(H)mm（Please confirm that D66A can match your motherboard size）

RGB Version: AURA 5V 3Pin addressable, Fan Dimension: 120×120×25mm

Included Fans: 2pcs, Fan Speed: 1000~2000±10%RPM,

Max. Air Flow: 72CFM, Max. Static Pressure: 2.36mmH2O

Noise: 8~29.1dB(A), Rated Voltage: 12VDC

Operating Voltage: 8~13.2VDC, Started Voltage: 7.5VDC

Rated Current: 2*0.22~0.39A(Fan Moto)+2*0.3A(RGB)+0.2A(RGB)

Powder Input: Single fan:4.7W+1.5W; Top guard RGB: 1.5W

Bearing Type: Hydraulic Bearing

Package Contents:

1 x CPU Cooler, 1 x Accessories Bag, 1 x Backplate,

2 x Intel Bracket, 2 x AMD Bracket, 1 x RGB Controller,

1 x 1-to-2 RGB Bifurcate Cable, 1 x 3 Pin 5V / D / GND FRGB Self-locking Connector,

1 x Thermal Paste, 1 x Quick Install Guide, 1 x Installation

• Compact dual-tower design combines strong cooling performance with excellent case-, RAM- and PCIe-compatibility
• Only 110mm height is ideal for HTPCs, ITX, Small Form Factor or 3U builds; Does not overhang the RAM or PCIe slots on most current motherboards
• Highly optimised NF-A9 92mm fan with PWM support and Low-Noise Adaptor for automatic speed control and ultra-quiet operation
• Easy-to-install SecuFirm2 multi-socket mounting system for Intel LGA1200, LGA1150, LGA1151, LGA1155, LGA1156, LGA2011, LGA2066 & AMD AM2(+), AM3(+) FM1, FM2(+) AM4
• Includes award-winning NT-H1 thermal compound.Trusted Noctua quality backed up by 6-year manufacturer’s warranty

User questions & answers

Question:	my trusted nh d15s is too big for me, would this be a good replacement? thanks
Answer:	GB-BRI7H-8550 if it has an "H" after the i7 (or the i5) it should support the 2.5 inch hard drive
Question:	Do you have to remove the motherboard to install this on an LGA
Answer:	Yes you are able to add an M.2 and a 2.5" SSD at the same time.
Question:	Will this work with any am3+ socket? i see it says backplate required what does that mean? and will this fit in most towers
Answer:	Ubuntu worked fine out of the box. No issues.
Question:	Does this come with thermal compound
Answer:	Yes

Product features

Low-profile tower design with 3U compatibility

While most low-profile coolers blow air towards the motherboard, the NH-D9L is a tower style cooler that blows parallel to the mainboard, which allows for superior airflow efficiency in cases with front intake and rear exhaust fans that create an airflow path parallel to the mainboard. The NH-D9L's reduced height of 110mm also allows it to fit 3U chassis. This makes it ideal for noise-sensitive 3U applications in fields such as audio or video processing.

100% RAM compatibility

With its 95x95mm footprint, the NH-D9L does not overhang the RAM slots on current Intel and most AMD mainboards. This gives the user full access to the memory modules and ensures 100% compatibility with tall heatspreaders or optional memory fans.

100% compatibility with PCIe cards on mini-ITX

With its 95x95mm footprint, the NH-D9L does not overhang the RAM slots on current Intel and most AMD mainboards. This gives the user full access to the memory modules and ensures 100% compatibility with tall heatspreaders or optional memory fans.

NF-A9 premium fan

The highly optimised features Noctua's proprietary AAO frame as well as sophisticated aerodynamic design measures such as Flow Acceleration Channels, which allows it to further improve the renowned efficiency of Noctua's previous 92mm models and contributes to the NH-D9DX i4' superior cooling performance.

Cooler Specifications

• NF-A9 PWM premium fan
• Low-Noise Adaptor (L.N.A.)
• NT-H1 high-grade thermal compound
• SecuFirm2 Mounting Kit
• Fan-clips for second NF-A9
• Noctua Metal Case-Badge

Fan compatibility

92x92x25

• Supports Intel Socket 130W LGA20XX/LGA1366/LGA115X/LGA775 and AMD Socket 125W AM4/AM3+/AM3/AM2+/AM2/FM2+/FM2/FM1
• 120x120x25mm PWM fan with blue LED
• 4 sintered powder heatpipes directly touch the CPU surface
• Extra fan clips provided allow adding a second fan
• Can be easily installed without moving the motherboard
