13 best consoles with kvm switches

Product description

Tripp Lite's B021-000-19 1U Rackmount Console features an integrated 19" LCD display, full 88-key keyboard and touch pad, all in a 1U rackmountable housing. This console is designed for use with a server or a KVM switch with PS/2 console connectors. Tripp Lite warrants its products to be free from defects in materials and workmanship for a period of one year from the date of initial purchase.

• 1 year warranty
• 1U rackmount console with 19 inches LCD screen, keyboard, numeric keypad and touch pad
• Compatible with PS/2 and USB computers and servers
• Space saving 1U rackmount drawer design Rackmountable in 19 Inch system rack (1U), from 27 Inch to 42 Inch deep
• Supports resolutions up to 1366 X 768

User questions & answers

Question:	The trackpad does not work, how do I get it to work
Answer:	If the track pad works only after a full power cycle of the Tripplite unit, then the issue is with the USB driver. Unplug the USB from the back and then reconnect it as it re-initializes it and the trackpad will work again. This is a common problem with all three of the units i purchased.
Question:	Hi, is possible to move it between datacenters ? I mean, I would need an extra pairs of rail for moving the device. Are there compatible rails
Answer:	Yes. You can move them side to side, but you would need to order another pair of rear brackets. The rear brackets are removable not the front.
Question:	Wondering if this unit is 19" wide? As the model number on tripplite site says it is 19" but on this page you have width as
Answer:	It is 19" wide and does fit a standard 19" cabinet. You should have a server cabinet because of the depth.
Question:	How many servers can you connect to this KVM Rack Console
Answer:	This is just a console. You can only connect it to one. What you want to do is connect this to a kvm switch and the number of servers depends on what you get. Some are 2, 4, 8, 16, etc.

Product features

Control an Entire Network in Just 1U of Rack Space

Tripp Lite's B021-000-19 1U Rackmount Console features an integrated 19 inch LCD display, full 88-key keyboard and touch pad, all in a 1U rackmountable housing. This console is designed for use with a server or a KVM switch with PS/2 console connectors. Tripp Lite warrants its products to be free from defects in materials and workmanship for a period of one year from the date of initial purchase.

Simple Installation with Space-Saving Design, USB Pass-Through & LCD Display

The B021-000-19 can be mounted in racks with depths ranging from 27 to 42 inches (rackmounting hardware included). The console is housed in an all-metal 1U sliding drawer. Simply pull it out and flip up the screen when needed, and store it back in the rack when finished. This keeps the keyboard and screen from blocking access to rack equipment when the console is not in use.

The included KVM cable kit allows for connection to a PS/2 computer or KVM, and a PS/2 to USB adapter is included, which can be used to connect to a USB computer or KVM. The unit features a USB 2.0 pass-through port for connection of a USB peripheral, such as a flash drive, CAC card reader, etc.. Your peripheral device connects to the USB type A port on the front of the unit, and your computer connects to the USB type A port on the back of the unit using a Tripp Lite UR020-Series type A M/M cable.

The B021-000-19's 19 inch LCD screen supports video resolutions of up to 1366 x 768p. DDC, DDC2 and DDC2B emulation allows the video settings of the connected computer to be automatically adjusted for optimal display on the console monitor.

Supports Multiple Platforms & 1-Year Warranty

The B021-000-19 supports both PS/2 and USB connections (USB to PS/2 adapter cable included). Because compatibility is based on common hardware standards rather than system software dependencies, almost any platform can be accommodated, including UNIX, Linux, Windows, Mac OS, Solaris and more. The B021-000-19 is also compatible with most KVMs that are equipped with PS/2 and USB console ports. This enables the B021-000-19 to be integrated into an existing system, providing enhanced management capabilities without a major investment in new hardware. No server-resident software is required, so server performance and reliability are never compromised.

For peace of mind, the B021-000-19 comes backed by a 1-year warranty. It is also manufactured in compliance with strict RoHS specifications, reflecting Tripp Lite’s commitment to environmental responsibility. The B021-000-19 is compatible with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.

Why Choose Tripp Lite?

Founded in 1922 in Chicago, Illinois, Tripp Lite is a leading manufacturer of products to power, connect, house and protect your equipment. From the largest data center to the smallest home office, Tripp Lite products keep your equipment running effectively and efficiently. Whether you need to supply power to servers and have reliable battery backup, connect high-resolution video sources to displays and digital signs, or organize and secure IT equipment in rack enclosures, Tripp Lite has the complete solution. Plus, before and after your purchase, our Chicago-based, in-house technical support specialists are available to assist you by phone, email and live chat. With over 90 years of quality products and service, Tripp Lite is a brand you can trust.

Product description

Tripp Lite's 8-port Console KVM Switch with 19" LCD is the optimal solution for controlling multiple computers from one keyboard, mouse and monitor. This single unit combines an 8 port KVM switch, keyboard, 19" LCD monitor and touchpad; all in a mere 1U of rack space. Stores neatly in the rack, pulls out when needed. Control up to 504 computers from this single console by daisy-chaining additional 16 port KVM switches (model B022-U16). Easily switch ports using the On-Console push buttons, On Screen Display (OSD) or keyboard hot key commands. Includes eight, six foot , which allow connection to either PS/2 or USB servers...no adapters needed. Includes a console cable kit that plugs into the port on the back of the unit, providing an extra HD15, USB and PS/2 ports that can be used to connect a Tripp Lite B051-000 IP Remote Access Unit or an external console. Two USB ports are provided on the front of the unit: One for attachment of a separate USB mouse, and the other for attachment of USB peripherals, such as a flash drive, external hard drive, etc. to be shared between connected servers. Compatible with all major operating systems. Constructed of heavy-duty steel housing. 1 year limited warranty.

• 1U rackmount console with built in 8 Port KVM switch, 19 LCD screen, keyboard, and touchpad
• Includes (x8) P778 Series USB/PS2 Combo KVM Cable Kits
• Additional ports are provided for the connection of an external console (PS/2 or USB) or IP remote access unit (Tripp Lite Model B051 000)
• Control up to 504 computers by daisychaining up to 31 additional B022 U16 KVM switches
• Supports video resolutions up to 1280 x 1024
• 2 level password security (up to four Users and one Administrator)
• Compatible with all major operating systems
• Constructed of heavy duty steel housing

User questions & answers

Question:	out of the box, can you just plug it into 8 computers or do you have to have another part? - thank you in advance
Answer:	This is a nice unit. I am not 100% sure about 8 computers, I only had 4 server to hook up and did without purchasing anything else. I do have a bunch of cables remaining so I believe the answer will be yes, you can hook up 8 computers without any issues.

Product features

8-Port 1U Rack-Mount Console KVM Switch with 19-in. LCD + 8 PS2/USB Combo Cables

Tripp Lite's B020-U08-19-K NetDirector 8-Port Rackmount Console KVM Switch is the smart solution for controlling multiple computers and servers in IT applications.The B020-U08-19-K offers a complete network management solution. It combines an 8-port KVM switch, keyboard, touchpad, numeric keypad, 19-inch LCD and built-in IP remote access capability in a compact housing that stores neatly in a 1U rack drawer and pulls out when needed. No server-resident software is required, so server performance and reliability are never compromised. Upgradable firmware fine-tunes compatibility with emerging standards.

Supports Multiple Platforms and Simple, Flexible Network Control

The B020-U08-19-K supports both PS/2 and USB connections using eight included Tripp Lite P778-Series PS/2-USB Combo KVM Cable Kits. Because compatibility is based on common hardware standards rather than system software dependencies, almost any platform can be accommodated. Connect multiple versions of multiple platforms in any combination, including UNIX, Linux, Windows, Mac OS and Solaris.

The B020-U08-19-K is designed to ease multi-server management in data centers, server rooms and other high-density environments. BIOS-level access allows network administrators to solve complex problems efficiently and restore service before downtime affects productivity. An advanced on screen display (OSD) with high-resolution VGA video (up to 1280 x 1024) provides a graphical user interface with management tools, including custom port labeling, auto-scanning and panel array mode. Select a connected computer using on-console pushbuttons or keyboard hotkey commands. Two LEDs per KVM port indicate when a computer is connected to a KVM port and powered on and when a computer is selected. Two USB ports are provided for connection of an external mouse and flash drive.

Securely Access Servers Anywhere with IP Remote Access Capability

With the addition of an optional IP Remote Access Unit (Tripp Lite model B051-000, sold separately), the B020-U08-19-K provides secure IP remote access to connected servers/computers without requiring additional rack space. IP remote access enables system administration, BIOS-level troubleshooting, GUI application installations, equipment reboots, and more, to be accomplished from any location using a standard Web browser or multi-platform client software. A modem port provides optional out-of-band dial-up access to equipment when the network or Internet connection goes down. The B051-000 also supports USB virtual media access.

The B020-U08-19-K offers two levels of password protection (administrator/user) to prevent unauthorized persons from gaining access to connected servers/computers. IP remote access is further protected with security features, including password protection, advanced encryption, bandwidth-optimized video and detailed activity logging.

1-Year Product Warranty from a Leading Manufacturer

The B020-U08-19-K is manufactured in compliance with strict RoHS specifications, reflecting Tripp Lite's commitment to environmental responsibility. For peace of mind, it comes backed by a one-year warranty.

Founded in 1922 in Chicago, Illinois, Tripp Lite is a leading manufacturer of products to power, protect, manage, house, cool, connect and mount your equipment. From the largest data center to the smallest home office, Tripp Lite products keep your equipment running effectively and efficiently. Whether you need to supply power to servers and have reliable battery backup, connect high-resolution video sources to displays and digital signs, or organize and secure IT equipment in rack enclosure cabinets, Tripp Lite has the complete solution. Plus, before and after your purchase, our Chicago-based, in-house technical support specialists are available to assist you by phone, email and live chat. With over 90 years of quality products and service, Tripp Lite is a brand you can trust.

Product description

The 8-Port USB KVM Switch lets you manage multiple computers with just one set of keyboard, monitor and mouse. This rack mount device supports USB and PS/2 interface on the console side and USB only on the PC side. Popular hardware platforms such as PC, Linux and Mac are supported. Users can switch between PCs using hot-key or push button for flexible management. Users can also hot-plug PCs on the fly to avoid downtime. The 8-Port USB KVM Switch is the perfect choice for managing multiple PC’s.

-Controls up to 8 computers or servers.

-Supports both USB and PS/2 Interface for console port

-Supports Windows, Linux, Mac OS and more

-High video quality, up to 2048 x 1536 VGA resolution

-Firmware upgradeable via PC port

-Auto-scan for monitored PCs with adjustable scan interval from 10-99 seconds

-Keyboard status restored when switching between computers

-LEDs display for easy status monitoring

-Beeping sound for port switching confirmation (enable/disable)

-Keyboard hot key command or push button switching

-Plug & Play and Hot-Pluggable

-Standard 19” (1U) rack mount design

-2-Year TRENDnet Manufacturer’s Warranty

Package Contents:

- TK-803R

- Quick Installation Guide

- Power Adapter (9 V DC, 1 A)

-Rack mount kit

• PC & CONSOLE PORT INTERFACE: PC: 8 x VGA HDB 15-pin (female); Console: To KVM: 1 x VGA HDB 15-pin (male), To Computer: 1 x VGA HDB 15-pin (male), 1 x USB (Type A)
• MANAGE MULTIPLE PC’S: This 8-Port KVM Switch enables you to control and manage up to 8 computers or servers with just one set made up of a keyboard, monitor and mouse.
• SUPPORTED OS: The KVM switch supports Windows, Linux, Unix and Mac OS
• VIDEO QUALITY: The 8 Port Switch delivers high video quality, up to 2048 x 1536 VGA resolution
• CABLES SOLD SEPARATELY: Compatible cables for use TK-CU06 (6ft), TK-CU10 (10ft), TK-CU15 (15ft)
• USB & PS/2 INTERFACE: This rack mount device supports USB and PS/2 interface on the console side and USB only on the PC side.
• FLEXIBLE MANAGEMENT: Provides the ability to switch between PCs using hot-key or push button for flexible management
• RACKMOUNT DESIGN: The rack mount KVM switch has a standard 19” (1U) rack mount design

User questions & answers

Question:	This question pertains to tk-803r -- the 8-port mountable kvm with ps/2 and usb capabilities: are cables included? and if so, what are their lengths
Answer:	NO - you would have to purchase more. All Surface Pro's only have 1x USB port and 1x mini-Display Port (not HDMI). You would have to purchase a mini-DP to HDMI video adapter (less than $10) to use it with this switch. Microsoft does sell a port replicator (~$150), but it also only has mini-DP video ports (so it does NOT help you to buy that). "Orion" said "Micro Surface Dock" could plug into this KVM, but only "later" said that you still need a video adapter. If you need this HDMI KVM switch, the easiest/best/cheapest thing to do would be to buy a simple "mini-DP to HDMI" video adapter and plug the (now HDMI) and USB into this KVM switch.
Question:	is there a keyboerd shurtcut to swich between each port
Answer:	Its supposed to, but I have not found this magical 1080p/auto edid button that the manual keeps mentioning. So my lg ultrawide is stuck on 1080p for all 4 of my pc.
Question:	Does this come with rack-mount hardware
Answer:	Contact their support email--it is in answers to other questions which I cannot see at the moment while I'm answering this question. They are incredibly responsive--one of my cables was broken and they sent me TWO replacements within a week.
Question:	Has anyone tried this with a Raspberry Pi
Answer:	I have a ultra wide lg monitor and when I connect the kvm switch it did not go all the way to 4k. It was not supported it went to a Max of 1920 x 1080. I didn't like the way the display look. All my icon where big AF!. Kvm i switch is on a drawer...😂😂😂

Product features

KVM Interface

USB and PS/2 interface on the console side and USB only on the PC side mouse and keyboard connections.

Video Resolution

Supports up to 2048 x 1536 VGA resolution.

8-Port KVM

Manage up to 8 computers with this rackmount USB KVM switch.

• 【16 IN 1 OUT Enterprise Grade HDMI KVM Switcher】TESmart 16 Ports HDMI KVM switch supports USB 2.0 hub and USB 2.0 keyboard /mouse. Support resolution up to 3840*2160@60Hz. Support Unix /Windows /Debian /Ubuntu /Fedora /Mac OS X /Raspbian /Ubuntu for Raspberry Pi and other Linux based system.
• 【USB 2.0 Ports & Auto Switching】 With extra standard two USB 2.0 hub ports, it is possible to connect bar code scanner, USB hard drive or other USB devices to KVM just as you have plug these devices directly to computer. No delay is introduced after switch channel by keyboard and mouse smooth switch. Support auto switching to monitor computers in a specified time interval.
• 【Standard 1U 19-inch Rack Mount】With 8 Pcs 5ft(1.5m) HDMI USB KVM Dedicated Cable, eliminate the troubles you find matching cable, save your time and extra expenses. It is perfect for standard 1U height and 19-inch Cabinet/Rack Design if you maybe use Cabinet/Rack. With 2 Pcs Rack Ears perfect use for Standard 1U 19-inch Cabinet/Rack.
• 【Smart EDID & RS232 ,LAN Port Control】With EDID emulators in every input ports, keep PCs always have correct display information, prevent display settings changed while switching input ports. Switching can be controlled through variable methods, such as the front panel source selector buttons, RS232 commands, IP commands, IR signals and hot keys on keyboard.
• 【★FREE LIFETIME SUPPORT】100% satisfaction guarantee, no risk purchase.We are factory and professional manufacturer of KVM Switch products, so we have better quality and price for you, Free 3 Years Warranty service and Technical Support from TESmart. If you need more cables, please purchase: https://www.amazon.com/dp/B075FRFXNX

User questions & answers

Question:	Is there a lag with either the keyboard or mouse communication
Answer:	No keyboard or mouse lag has been noticed including when the ports are switched.
Question:	Can I use this as usb switch only for 16 computers without using any of the video connectors
Answer:	Yes, you can use it without the video connectors. You do not need to use the HDMI port to activate the KVM's input.
Question:	How do I keep it from beeping
Answer:	You need to access the controls with the Control Application. You can download it on our BuyTESmart website. Go to the Product Page and there's a Support Tab that has the downloads for each model.
Question:	I'm looking for a way to hook 16 video game consoles to one tv will this work
Answer:	Yes. That is one of the features of these KVM's. It can support computers or HDMI only video devices.

Product features

TCP/IP console interface

used for selecting input source only . could not transfer keyboard and mouse date or even the video and audio

for the software application or API document for the RS232 and LAN port,you can download it from te-smart website or send email to us via amazon order , we will send to you soon.

RS232 serial commands

used for selecting input source only . could not transfer keyboard and mouse date or even the video and audio

for the software application or API document for the RS232 and LAN port,you can download it from te-smart website or send email to us via amazon order , we will send to you soon.

The Port Indicated for "Keyboard and Mouse"

It is recommended to use a normal keyboard and mouse to connect to the KVM switch

Switching the input sources by Keyboard hotkeys and Mouse gesture

KVM Switcher with 2* USB ports

Support USB 2.0 port ,you can attach USB drive, printer, barcode scanner or other USB devices

Premium Features

*Adjust time interval of auto-scan from 5 seconds to 60 minutes

*Switch inputs with remote control, keyboard, push buttons, or mouse

*Transmit audio to output video device via HDMI connections

*Adjust time interval of auto-scan from 5 seconds to 60 minutes

*Support HDCP 2.2

Package Contents

• 16x1 HDMI KVM Switcher
• DC 12V Power Adapter
• 8* 5ft HDMI USB KVM Cables
• IR Remote Control (requires standard CR2025 battery)
• Remote Control Receiver
• Rack Mounting Ears
• 3 Pin Connector for RS232
• English Manual

Product description

Tripp Lite’s B040-008-19 KVM Switch gives you a rack-mountable keyboard, LCD and touchpad in a single console that occupies only 1U of rack space. Easy to install and use, it’s the cost-effective solution for controlling up to 8 directly connected computers/servers.



The B040-008-19 has a built-in 19” LCD screen that supports video resolutions up to 1366 x 768. You can switch easily between the 8 ports using on-console push buttons, an on-screen display (OSD) or keyboard hot key commands. Password protection prohibits unauthorized users from accessing the connected computers.

• 1U rackmount console with built in 8 Port KVM switch, 19 LCD, keyboard, and touchpad
• Directly control up to 8 computers, or increase the number of connected computers to up to 248 by daisychaining up to 15 B042 Series KVM switches
• Built-in monitor supports video resolutions up to 1366 X 768
• On Screen Display (OSD) menu for intuitive, easy control of the KVM
• Add IP Remote Access with a Tripp Lite B051 000

User questions & answers

Question:	Rack mount slides addtional item or built onto the tray
Answer:	The slides are included and built into the Tray that holds the monitor?
Question:	I purchased this 11 months ago and the keyboard stopped working. What's the warranty path
Answer:	The B040-016-19 has a 1-year warranty. We would recommend contacting us as soon as possible to begin your warranty claim. Please reach out to our Chicago-based Tech Support Team at 773-869-1234 (M-F 7AM-6PM Central) at your earliest convenience.
Question:	Rack mount slides addtional item or built onto the tray
Answer:	The slides for rack mounting are built into the Tray that holds the monitor?
Question:	So does the keyboard and mouse/touchpad work over vga
Answer:	For every server connected to the B040-008-19, a KVM to server cable with VGA and USB/PS2 connectors is needed. Our 6 ft. version of this cable is P780-006. If you have any other questions or need any assistance, please reach out to our Chicago-based Presales Applications Team at 773-869-1773 (M-F 8AM-6PM Central) or [email protected].

Product features

8-Port VGA KVM Switch Rack Console 1URM with 19" LCD Monitor, Keyboard, Mouse

The B040-008-19 NetController 8-Port Console KVM switch allows a user to directly connect up to 8 computers or daisy chain up to 15 B042-Series KVM Switches to control up to 248 from a single keyboard, monitor and mouse. Switch between connected computers via Pushbutton, On Screen Display (OSD), or Hotkey commands. Connect computers to the KVM using a Tripp Lite P780-Series USB/PS2 Combo KVM cable kit. Cable kits come with both USB and PS/2 connectors, allowing you to connect to either a USB or PS/2 computer without the need to purchase additional cables or adapters. Additional VGA and USB ports are located on the back panel of the unit, allowing for the connection of an external VGA monitor and USB keyboard or mouse, or a Tripp Lite B051-000 IP remote access unit.

Network Management, Daisy Chain for More Control and Supports Multiple Platforms

The B040-008-19 offers a complete network management solution. It combines an 8-port KVM switch, keyboard, touch pad, numeric keypad, and 19-in. LCD in compact 1U housing suitable for installation in racks from 27 to 42 inches deep. The B040-008-19 stores neatly in a rack drawer and pulls out when needed. No server-resident software is required, so server performance and reliability are never compromised. Hot pluggable functionality enables servers or computers to be added or removed with no need to power down the KVM switch or disrupt the entire system. Upgradable firmware fine-tunes compatibility with emerging standards.

The B040-008-19 is capable of controlling up to 248 servers/computers by daisy-chaining additional KVMs (Tripp Lite models B042-008 or B042-016). This gives network managers the flexibility to add capacity when it's needed, accommodating growing data center requirements without disrupting existing equipment.

The B040-008-19 supports both PS/2 and USB connections (Tripp Lite P780-Series combo KVM cable kits required; sold separately). Because compatibility is based on common hardware standards rather than system software dependencies, almost any platform can be accommodated. Connect multiple versions of multiple platforms in any combination, including Windows, Mac, Linux and Sun.

High Resolution VGA, Optional IP Remote Access and Password Protected

An advanced on screen display (OSD) with high-resolution VGA video up to 1366 x 768 provides a graphical user interface with management tools including custom port labeling, auto-scanning and panel array mode. Users may also select a connected computer using on-console pushbuttons or keyboard hotkey commands. Two LEDs per KVM port indicate when a computer is connected to a KVM port and powered on, and when a computer is selected.

With the addition of an optional IP remote access unit (Tripp Lite model B051-000, sold separately), the B040-008-19 provides secure IP remote access to connected servers/computers without requiring additional rack space. IP remote access enables system administration, BIOS-level troubleshooting, GUI application installations, equipment reboots and more to be accomplished from any location using a standard Web browser or multi-platform client software. A modem port provides optional out-of-band dial-up access to equipment when the network or Internet connection goes down. The B051-000 also supports USB virtual media access.

The B040-008-19 offers two levels of password protection (administrator/user) to prevent unauthorized persons from gaining access to connected servers/computers. IP remote access (if provided by the optional IP remote access unit) is further protected with security features.

1-Year Warranty and Why Choose Tripp Lite?

For your peace of mind, the B040-008-19 comes with a 1-year warranty and is manufactured in compliance with strict RoHS specifications, reflecting Tripp Lite’s commitment to environmental responsibility.

Founded in 1922 in Chicago, Illinois, Tripp Lite is a leading manufacturer of products to power, protect, manage, house, cool, connect and mount your equipment. From the largest data center to the smallest home office, Tripp Lite products keep your equipment running effectively and efficiently. Whether you need to supply power to servers and have reliable battery backup, connect high-resolution video sources to displays and digital signs, or organize and secure IT equipment in rack enclosures, Tripp Lite has the complete solution. Plus, before and after your purchase, our Chicago-based, in-house technical support specialists are available to assist you by phone, email and live chat. With over 90 years of quality products and service, Tripp Lite is a brand you can trust.

Product description

Tripp Lite's B070-016-19-IP, NetCommander Rackmount Console IP KVM switch, is a cost effective and highly flexible system for controlling up to 256 computers from either a single 19" LCD display console, or, from a remote location. The number of connected computers can be increased by cascading additional Tripp Lite B072-008-1 or B072-016-1 KVM switches. Switching between attached servers can be accomplished via the On Screen Display (OSD) or Hotkey commands.Utilizing Tripp Lite B078-101-Series server interface units, KVM cabling is kept to a minimum via Cat5e/6 patch cables. Servers can be located up to 100 ft. from the switch.Password feature provides additional security to prevent unauthorized access to attached computers. All rackmount hardware is included, and is designed for easy, one person installation. Fits into any rack from 27" to 42" deep. 2-post rackmounting available using Tripp Lite's B019-000. Compatible with all major operating systems. (Mac not compatible over IP) Constructed of heavy-duty steel housing. 1 year limited warranty.

• Combines 16-port KVM switch, 19” LCD screen, keyboard and touchpad in a single 1U rack-mountable drawer
• Control computers/servers locally or via LAN, WAN or Internet; Simultaneous support for 2 users – 1 local, 1 remote
• Cat5e/6/6a cabling lets you locate servers up to 100 ft. from the switch
• Use a plug-and-play Server Interface Unit, B078-101-USB-1(for USB) with each server that will be connected with Cat5 cable
• 1-Year Limited Warranty & TAA-Compliant. Mounts into 19”-wide rack, 27”-42” deep; can be mounted in 2-post rack with Tripp Lite’s B019-000

User questions & answers

Question:	Does it come with console cables, or they have to be purchased separately
Answer:	The unit comes on its own without the cables, but the interface is rj45 so just use cat5 patch cables or make them to the length you need like i did. The actual vga / usb adapters need to be purchased that connect to the server. Thanks

Product features

Access Servers and Control IP-Enabled PDUs from Anywhere

The B070-016-19-IP offers a complete network management solution. It combines a 16-port KVM switch, keyboard, touch pad, numeric keypad, 19-in. LCD and built-in IP remote access capability in a compact housing that stores neatly in a 1U rack drawer and pulls out when needed. No server-resident software is required, so server performance and reliability are never compromised. Upgradable firmware fine-tunes compatibility with emerging standards.

Simple, Flexible Network Control of Multiple Computers

The B070-016-19-IP is designed to ease multi-server management in data centers, server rooms and other high-density environments. BIOS-level access allows network administrators to solve complex problems efficiently and restore service before downtime affects productivity. An advanced on screen display (OSD) with high-resolution VGA video up to 1366 x 768 provides a graphical user interface with management tools including custom port labeling, auto-scanning and panel array mode. Users may also select a connected computer using on-console pushbuttons or keyboard hotkey commands. Two LEDs per KVM port indicate when a computer is connected to a KVM port and powered on, and when a computer is selected.

Supports Multiple Platforms

The B070-016-19-IP supports both PS/2 and USB connections using B078-101-series USB or PS/2 server interface units and inexpensive, readily available Cat5 patch cables. Connected computers/servers can be located up to 100 feet from the switch. Because compatibility is based on common hardware standards rather than system software dependencies, almost any platform can be accommodated. Connect multiple versions of multiple platforms in any combination, including Windows, Mac*, UNIX, Linux and DOS operating systems.

Expandable to Control Up to 256 Computers/Servers

The B070-016-19-IP is capable of controlling up to 256 servers/computers by cascading additional Tripp Lite B072-series KVM switches. This gives network managers the flexibility to add capacity when it''s needed, accommodating growing data center requirements without disrupting existing equipment.

Secure Access at Every Connection

The B070-016-19-IP provides secure IP remote access to connected servers/computers without requiring additional rack space. IP remote access* enables system administration, BIOS-level troubleshooting, GUI application installations, equipment reboots and more to be accomplished from any location using a standard Web browser or multi-platform client software. Dual bus support permits simultaneous access for one local and one remote user. The LCD incorporates a grayscale option to improve transfer speed in low bandwidth situations.

Maintain Secure Connections

The B070-016-19-IP offers two levels of password protection (administrator/user) to prevent unauthorized persons from gaining access to connected servers/computers. IP remote access is further protected with security features including password protection, advanced encryption, bandwidth-optimized video and detailed activity logging.

One-Year Warranty and Environmentally Responsible Design

The B070-016-19-IP comes backed by a one-year warranty and is manufactured in compliance with strict RoHS specifications, reflecting Tripp Lite’s commitment to environmental responsibility.

Why Choose Tripp Lite?

Founded in 1922 in Chicago, Illinois, Tripp Lite is a leading manufacturer of products to power, protect, manage, house, cool, connect and mount your equipment. From the largest data center to the smallest home office, Tripp Lite products keep your equipment running effectively and efficiently. Whether you need to supply power to servers and have reliable battery backup, connect high-resolution video sources to displays and digital signs, or organize and secure IT equipment in rack enclosure cabinets, Tripp Lite has the complete solution. Plus, before and after your purchase, our Chicago-based, in-house technical support specialists are available to assist you by phone, email and live chat. With 95 years of quality products and service, Tripp Lite is a brand you can trust.

Product description

The UPtyma 17.3 1U Rackmount console kit is a high performance KVM console that combines a Full HD 17.3” LCD monitor with keyboard and touch pad in a dense lightweight 1U form factor. The 1U rackmount form factor is designed to allow a KVM console switch to be mounted directly behind it. The Full HD display supports video resolutions from 640 x 480 through 1920 x 1080 at 60 and 75 Hz refresh rates. Product allows multi-port KVM switch to be mounted behind in the same 1U of space to manage multiple systems.

• Lightweight, 11.43 lbs./Toolless installation. (single person)
• Front access 2 USB 3.0 pass-through ports for media devices.
• Short-depth (17.05in.) Rack Console includes 17.3" LCD, 104 Keyboard/Touchpad.
• 3 Button Touchpad supports Linux. World Wide / TAA compliant.
• Made in USA

User questions & answers

Question:	Do you need additional rack mount hardware are is all included? Looks this needs some kind of rails to be pushed into
Answer:	This unit includes tool-less rails that will install into square or round hole racks.
Question:	is there a way to lock it closed for transit
Answer:	This unit does not have any locking nor latching mechanism. It seems to simply be hinged shut by some spring resistant hinges. You could clamp/lock it with external accessories - but it does not come with anything to lock/latch it closed.
Question:	I do not see any side brackets, so how does it screw into the front of the rack or is there additional hardware required
Answer:	It is tool-less, no additional hardware (cage nuts or screws) is required.
Question:	How does this actually mount to a 19" rack? Any pictures
Answer:	I don't have a picture - but it came with a rail kit that made it very easy to mount. Size the rails to your rack depth, mount it, then slide the unit on the rails.

Product description

Tripp Lite's 8-port Console KVM Switch with 17" LCD is the optimal solution for controlling multiple computers from one keyboard, mouse and monitor. This single unit combines an 8 port KVM switch, keyboard, 17" LCD monitor and touchpad; all in a mere 1U of rack space. Stores neatly in the rack, pulls out when needed. Control up to 504 computers from this single console by daisy-chaining additional B022-016 or B022-U16 16 port KVM switches. Easily switch ports using the On-Console push buttons, On Screen Display (OSD) or keyboard hot key commands. Control PS/2 or USB computers/servers using P774-Series (PS/2) and P776-Series (USB) KVM Cable kits. Includes an extra HD15 and PS/2 ports on the rear of the unit, which allows for connection of a Tripp Lite B051-000 IP Remote Access Unit or an external console. Compatible with all major operating's systems except Mac and Sun. Constructed of heavy-duty steel housing. 1 year limited warranty.

User questions & answers

Question:	What are the dimension of this item? i need a small rack kvm
Answer:	Yes it comes with 2 mounts. One curved and one flat. I also removed the one that mounts the camera on the box and mounted it on my front handle bars. So you could say 3 mounts.

Product features

NetDirector 8-Port 1U Rack-Mount Console KVM Switch with 17-inch LCD

Tripp Lite's B020-008-17 NetDirector 8-Port Rackmount Console KVM Switch is the smart solution for controlling multiple computers and servers in IT applications. The B020-008-17 offers a complete network management solution. It combines an 8-port KVM switch, keyboard, touch pad, numeric keypad and 17-inch LCD in a compact housing that stores neatly in a 1U rack drawer and pulls out when needed. No server-resident software is required, so server performance and reliability are never compromised. Hot pluggable functionality enables servers or computers to be added or removed with no need to power down the KVM switch or disrupt the entire system. Upgradable firmware fine-tunes compatibility with emerging standards.

Supports Multiple Platforms and Simple, Flexible Network Control

The B020-008-17 supports both PS/2 and USB connections (Tripp Lite P774-Series PS/2 and P776-series USB KVM cable kits required; two 6-foot PS/2 cable kits included; USB cable kits available separately). Because compatibility is based on common hardware standards rather than system software dependencies, almost any platform can be accommodated. Connect multiple versions of multiple platforms in any combination, including Windows, UNIX, Linux and more.

The B020-008-17 is designed to ease multi-server management in data centers, server rooms and other high-density environments. BIOS-level access allows network administrators to solve complex problems efficiently and restore service before downtime affects productivity. An advanced on screen display (OSD) with high-resolution VGA video up to 1280 x 1024 provides a graphical user interface with management tools including custom port labeling, auto-scanning and panel array mode. Users may also select a connected computer using on-console pushbuttons or keyboard hotkey commands. Two LEDs per KVM port indicate when a computer is connected to a KVM port and powered on, and when a computer is selected.

Securely Access Servers Anywhere with IP Remote Access Accessory

With the addition of an optional IP remote access unit (Tripp Lite model B051-000, sold separately), the B020-008-17 provides secure IP remote access to connected servers/computers without requiring additional rack space. IP remote access enables system administration, BIOS-level troubleshooting, GUI application installations, equipment reboots and more to be accomplished from any location using a standard Web browser or multi-platform client software. A modem port provides optional out-of-band dial-up access to equipment when the network or Internet connection goes down. The B051-000 also supports USB virtual media access.

The B020-008-17 offers two levels of password protection (administrator/user) to prevent unauthorized persons from gaining access to connected servers/computers. IP remote access (if provided by the optional IP remote access unit) is further protected with security features including password protection, advanced encryption, bandwidth-optimized video and detailed activity logging.

1-Year Product Warranty from a Leading Manufacturer

The B020-008-17 is manufactured in compliance with strict RoHS specifications, reflecting Tripp Lite's commitment to environmental responsibility. For peace of mind, it comes backed by a one-year warranty.

Founded in 1922 in Chicago, Illinois, Tripp Lite is a leading manufacturer of products to power, protect, manage, house, cool, connect and mount your equipment. From the largest data center to the smallest home office, Tripp Lite products keep your equipment running effectively and efficiently. Whether you need to supply power to servers and have reliable battery backup, connect high-resolution video sources to displays and digital signs, or organize and secure IT equipment in rack enclosure cabinets, Tripp Lite has the complete solution. Plus, before and after your purchase, our Chicago-based, in-house technical support specialists are available to assist you by phone, email and live chat. With over 90 years of quality products and service, Tripp Lite is a brand you can trust.

Product description

Tripp Lite's B070-016-19-IP2 Net Commander 16-Port Cat5 1U Rack-Mount Console KVM Switch includes a full keyboard, 19-inch LCD screen and touchpad in a 1U rack-mount console. It connects up to 16 computers and/or servers and allows you to control them locally or remotely via LAN, WAN or web browser. Connect computers/servers up to 100 feet away using Cat5e/6 cabling and a compatible Tripp Lite B078-Series server interface unit (B078-101-USB2 required for Fast Virtual Media speeds up to 12 Mbps). Dual 10/100 LAN ports ensure uninterrupted remote access in case one port should fail. A local user and two remote users can log on simultaneously and switch between the 16 ports using an on-screen display, hotkeys or remote toolbar. Multi-level password protection prohibits unauthorized access. The LCD supports video resolutions up to 1366 x 768. Dual serial ports allow control of serial devices, such as IP PDUs, firewalls and routers. You can assign individual ports to an IP PDU port to power on/off the server connected to that port. The heavy-duty steel housing slides neatly into the rack when not in use. Free Net Commander-AXS management software is available to access and control your Tripp Lite Net Commander IP KVM switches (B070 and B072 Series). From a single interface, you can access server ports on any of your KVM switches, power cycle or power on/off outlets of IP PDUs, and manage KVM settings. This software can be found at the Technical Support link in the right-hand column. 1-Year Limited Warrant.

• Includes 16-Port KVM Switch, 19 in. LCD, Keyboard and Touchpad; Mounts in 1U of space in EIA-standard 19 in. rack
• Connects up to 16 computers/servers up to 100 ft. away via Cat5e/6 cabling and Tripp Lite B078 Series SIUs
• Java-based application allows Windows computers to control a target server via web browser from any location over a secured IP connection
• Up to 3 users (1 local, 2 remote) can sign in simultaneously
• 1-Year Limited Warranty

Product features

Access Servers and Control IP-Enabled PDUs from Anywhere

This KVM’s built-in IP remote access enables system administration, BIOS-level troubleshooting covering the entire spectrum of crash scenarios, GUI application installations and equipment reboots from any location. A Java-based application allows Windows computers to control a target server via web browser; a non-browser client is available for remote access without Java. NetCommander-AXS software, which is free on TrippLite.com provides a single convenient interface that gives you control over all your NetCommander IP KVM switches.

The B070-016-19-IP2 also lets you add IP PDUs as devices that can be controlled by the KVM. Users can assign individual ports on the KVM to a PDU port to power cycle or power off/on the computer or server connected to that port.

Control Multiple Computers from 19" LCD Console or Remote Location

Tripp Lite's B070-016-19-IP2 NetCommander Cat5e/6 IP Console KVM Switch is the optimal solution for controlling up to 16 connected computers and servers locally or remotely from virtually anywhere in the world. The unit features a built-in 19” LCD and supports VGA video resolutions up to 1366 x 768 locally or 1920 x 1080 remotely. This KVM mounts into 1U of any standard 19” rack. Each connected computer/server can be located up to 100 ft. from the KVM switch using Cat5e/6 cabling and a B078-Series Server Interface Unit.

Support for 2+1 Users

The B070-016-19-IP2 enables control of multiple computers with simultaneous support for two remote users, plus a third local user. The three users can each access a different port on the KVM at the same time. Up to five users can share a single session.

Supports Multiple Platforms

The B070-016-19-IP2 supports PS/2 and USB connections (Tripp Lite B078-101-PS2, B078-101-USB-1 or B078-101-USB2 Server Interface Unit and Cat5e/6 patch cabling required, sold separately) and is compatible with Windows and Linux operating systems.

Access Virtual Media

With the B070-016-19-IP2, users are provided Virtual Media access, which allows an .iso file located in a shared folder of a SAMBA or NFS server to be mounted to a target server and accessed as if it were directly stored on it. The Fast Virtual Media KVM system (U.S. Patent #9,417,720) supports data transfer rates up to 12 Mbps (B078-101-USB2 required to achieve high-speed transfer).

Secure Access at Every Connection

This KVM switch incorporates the most advanced encryption technologies with three levels of password protection. The B070-016-19-IP2 supports TLS 1.2 security protocol. An SSL certificate can be installed to ensure secure transactions between web servers and browsers. Remote authentication support is achieved via full-screen graphical OSD with multi-level authentication (administrator and user) so users can quickly and efficiently manage installations. The B070-016-19-IP2 supports RADIUS and LDAP/S as well as IPv4 and IPv6 protocols.

Dual Serial Ports for Local Device Control

The B070-016-19-IP2’s dual serial ports connect serial-manageable devices such as PDUs, firewalls, and routers for comprehensive local device management.

Additional Premium Features

Other rich features include dual 10/100 Mbps LAN ports to provide redundancy in the event of a crash, SNMP messaging and a log function that records events such as logins, reboots and network settings changes. This KVM is also TAA-compliant for GSA Schedule purchase.

One-Year Warranty and Environmentally Responsible Design

For peace of mind, the B070-016-19-IP2 comes backed by a one-year warranty and is manufactured in compliance with strict RoHS specifications, reflecting Tripp Lite’s commitment to environmental responsibility.

Why Choose Tripp Lite?

Founded in 1922 in Chicago, Illinois, Tripp Lite is a leading manufacturer of products to power, protect, manage, house, cool, connect and mount your equipment. From the largest data center to the smallest home office, Tripp Lite products keep your equipment running effectively and efficiently. Whether you need to supply power to servers and have reliable battery backup, connect high-resolution video sources to displays and digital signs, or organize and secure IT equipment in rack enclosure cabinets, Tripp Lite has the complete solution. Plus, before and after your purchase, our Chicago-based, in-house technical support specialists are available to assist you by phone, email and live chat. With 95 years of quality products and service, Tripp Lite is a brand you can trust.

Product description

The B021-000-19-HD2 1U Rack-Mount Console combines a full keyboard, numeric keypad, touchpad and 19-inch color LCD for easy all-in-one control of a computer, server or KVM switch. Easy to install and simple to operate, it slides neatly into 1U of rack space when not in use. The rear DVI-I console port supports both digital and analog video signals for connecting to a DVI- or VGA-enabled server or KVM switch (a DVI to VGA adapter is included). The LCD screen supports video resolutions up to 1920 x 1080 (1080p). Video settings of the connected computer are automatically adjusted for optimal display on the LCD screen. USB 2.0 pass-through ports on the front and rear allow you to connect a USB peripheral, such as a flash drive or CAC card reader, to your computer with a USB cable (sold separately). The B021-000-19-HD2 mounts into 1U of space in an EIA-standard 19-inch rack using the included mounting brackets and user-supplied screws. Simply pull out the steel drawer and flip up the screen when needed, then slide it back into the rack in automatic sleep mode when you're finished. This keeps the keyboard and screen from blocking access to rack equipment when the console is not in use. This console is compatible with all major operating systems and KVM switches with a VGA or DVI monitor port and USB keyboard/mouse ports. This enables the B021-000-19-HD2 to be integrated into an existing system to provide secure management of critical network systems without a major investment in new hardware. 1-Year Limited Warranty.

• Space-Saving Console for IT Environments Where Rack Space Is Limited with 19 in. LCD monitor, keyboard, numeric keypad and touchpad
• Supports video resolutions up to 1920 x 1080 (1080p)
• Accepts Digital and Analog Video Signals with DVI-I port allowing connection to DVI digital or VGA analog server or KVM switch
• Mounts in 1U of space in EIA-standard 19 in. 2- and 4-post racks.Operating Temperature Range:32 to 104 F (0 to 40 C)
• 1-Year Limited Warranty.Input Frequency:50/60Hz

User questions & answers

Question:	How is the keyboard and touchpad connected to the workstation/server. I don't see cabling connections on the rear for these
Answer:	The port that looks like DVI accepts the included composite cable that includes USB on one end which connects to the server/pc

Product features

Provides Simple, All-in-One Control of a Computer, Server or KVM Switch

Easy to install and simple to operate, Tripp Lite's B021-000-19-HD2 1U Rack-Mount Console combines a full keyboard, numeric keypad, touchpad and 19-inch color LCD (with support for 1080p resolutions) in a 1U rack drawer for compact storage and quick access. Because of its compact size, it’s perfect for IT environments where rack space is limited.

Easy to Set Up and Use

The B021-000-19-HD2 integrates easily into your existing system. It’s compatible with all major operating systems and KVM switches with a VGA or DVI monitor port and USB keyboard/mouse ports. Housed in an all-metal 1U sliding drawer, it mounts with included hardware into any EIA-standard 19-inch rack. Simply pull it out and flip it open when you need it, and slide it back when you don’t. No server-resident software is required, so performance and reliability are never compromised.

Supports Digital and Analog Signals

A DVI-I port supports both digital and analog video signals for connecting to a DVI-enabled server or—when using the included DVI-to-VGA adapter a VGA-enabled server or KVM switch. The 19-inch LCD screen supports video resolutions up to 1920 x 1080 (1080p). DDC2B emulation allows the video settings of the connected computer to be automatically adjusted for optimal display on the console monitor.

Allows Connection of USB Peripherals via USB Pass-Through

A USB 2.0 pass-through port on the B021-000-19-HD2’s console allows you to connect a USB peripheral, such as a flash drive or CAC card reader, to your computer. Simply connect your device to the USB-A port on the front of the console, and use the included KVM cable kit to connect your server or KVM switch (with USB hub port) to the USB-A port on back.

TAA-Compliant and One-Year Warranty

The B021-000-19-HD2 is compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.

The B021-000-19-HD2 comes with a one-year product warranty. It’s manufactured in compliance with strict RoHS specifications, reflecting Tripp Lite’s commitment to environmental responsibility.

Why Choose Tripp Lite?

Founded in 1922 in Chicago, Illinois, Tripp Lite is a leading manufacturer of products to power, connect and protect your equipment. With a large selection of connectivity products, Tripp Lite has everything from USB hubs and reversible USB cables to fiber-optic cables and over Cat5e/Cat6 signal extenders. Whether you need to connect high-speed networks to switches, routers and servers in your data center, or send high-resolution video signals to displays and digital signs, Tripp Lite has the complete solution. Plus, before and after your purchase, our Chicago-based, in-house technical support specialists are available to assist you by phone, email and live chat. With over 95 years of quality products and service, Tripp Lite is a brand you can trust.

Product description

This 8 port rackmount KVM console provides complete keyboard, monitor and mouse control for eight computers. The rackmount console installs into 1U of rack space, offering a space-efficient solution for complete console control. This 8 port KVM switch provides all the essential controls you’ll need to manage your server room at a low cost. The console features a built-in touchpad, keyboard for intuitive control and an LCD display that supports resolutions up to 1280 x 1024. This versatile rack-mount LCD console has a 19 in. screen. The increased screen space allows you to run multiple applications on the same screen, increasing your productivity. The console slides out from 1U of rack space, enabling you to easily monitor and control eight servers and even more if connecting through a KVM switch. The rackmount VGA console features a handle for easy sliding in and out of the server rack, keeping your area organized and clutter-free. The rackmount LCD features an 8 port KVM module, which enables you to connect it directly to eight servers. You can also connect to additional servers by connecting to KVM switches in a cascaded (daisy-chained) configuration. The KVM module offers the flexibility you need for easily integrating the console into your existing server infrastructure. The 8 port rackmount KVM console is backed by a StarTech.com 2-year warranty and free lifetime technical support.

• TECH SPECIFICATIONS: Rackmount KVM Console, 19" Active Matrix TFT LCD Monitor, 1280 x 1024, 8 port VGA KVM switch w/ 6 ft cables, 99 key full keyboard + numeric keypad & trackpad; Supports USB 20
• PROFESSIONAL & SECURE: Customizable hot-keys, on-screen display (OSD), multi-level user security, user access levels / port permissions, & auto scan
• INTEGRATED DESIGN: Combines a KVM + Console w/ integrated power supply into 1U of rack space allowing space for other equipment Mount depth: 238" [605 cm] to 35" [89 cm] (incl mounting hardware)
• HEAVY DUTY: LCD KVM drawer has durable steel construction and heavy duty rail design that supports frequent use in operating environments from 0C to 40C (32F to 104F) with an MTBF of 50,000 hours
• TESTED & PROVEN: This OS independent rack console is universally compatible w/ leading servers and backed by a StarTechcom 2-year warranty and free lifetime 24/5 multilingual technical support

Product description

Remote Access This 500 ft VGA KVM over IP extender lets you control a server, computer, or multiple computers (connected through a KVM switch) over a standard CAT5 or CAT6 UTP network cable connection, at distances of up to 500 ft (150 m) away. Supported resolutions are 1280x1024 at 300 ft and 1024x768 at 500 ft. The KVM over CAT5 extender is great for maintaining network security with long distance local access without being exposed over IP, as well as controlling remote machines and monitoring computer-controlled equipment in factories and warehouses. Simple, Secure and Easy to Use This KVM over Ethernet extender is simple to use and easy to install; it requires no drivers or software, delivering a hassle-free plug and play experience. Plus, the extender supports any operating system to ensure broad compatibility. The KVM extender features intuitive hotkey commands and supports most combo keyboard and mouse sets (including wireless). For added convenience, PC connection cables are included with this product for a ready out of the box solution. Space Saving You can use your existing keyboard, mouse, and monitor to access both the server room and your office computer over Ethernet, saving space and avoiding the need for a dedicated remote console by allowing you to switch between workstation view and KVM view at the remote location. This USB VGA KVM extender is TAA compliant and backed by a StarTech.com 2-year warranty with free lifetime technical support.

• CONVENIENT ACCESS: Use the VGA over CAT5 extender to operate a USB & VGA KVM or PC up to 500ft away as if it were right in front of you. For added convenience, the extender features auto-switching and dedicated control options.
• COST-EFFICIENT KVM EXTENSION: The KVM over IP extender provides a low-cost way to convert existing standard KVM units into remotely accessible hardware extending your hardware’s capabilities.
• FLEXIBLE CONFIGURATION: This KVM console extender can be used with a single computer or connected to an existing KVM switch. It offers broad support for newer USB keyboards, mice, and even most combo/wireless configurations.
• EASY INSTALLATION: With support for plug and play connectivity, this KVM over Ethernet extender is easy to install using industry-standard UTP network cable and is OS independent, requiring no software or drivers for installation.
• INDUSTRY-LEADING SUPPORT: StarTech.com offers a 2-year warranty and free lifetime technical support on this 500ft CAT5 KVM extender, and has been the choice of IT professionals and businesses for over 30 years.

User questions & answers

Question:	Does this Extender kit provide a KVM switch at the local position/computer or is it simply an Extender and you have to purchase a KVM switch as well
Answer:	Has a light perfumy scent, almost as if flipping through a magazine smell but a little more pleasant.
Question:	The ethernet cable is IP, meaning you could connect over a network infrastructure
Answer:	yes, it is. one of the best quality tan extenders on the market at the moment.
Question:	What is the maximum resolution
Answer:	white
Question:	Is this USB 2.0 speed
Answer:	no bronzers

• ★ 1 IN 8 Out: One USB Keyboard & Mouse console controls 8 computers, Save keyboards and mouses
• ★ Supports multifunction mice. Multiplatform support - Windows, Mac, Linux and Sun
• ★ USB mouse port can be used for USB 1.1 hub ad USB 1.1 peripheral sharing
• ★ Plug and Play: You can pull of the Devices or the KVM no need To Puff off the KVM Switch nor The Connected Devices. No power needed.
• ★ 2 Ways to Switch: 1: Desktop Switch: With 2M Remote switcher 2:Button Switch: press key to select PC

User questions & answers

Question:	do the channel switch light up when pressed to indicate a visible channel selection
Answer:	Yes
Question:	How is this different from the rijer rj8t01?: https://www.amazon.com/gp/product/b01dkme5oq
Answer:	These two KVM switches almost the same function, the RJ801 can be connected to printer or scanner, This one can't connect printer or scanner.
Question:	will the mouse and keyboar work when you connect it through a vga to dvi-d converter ? neither the computer or the video cards i am using have vga
Answer:	I am using it in a rack with Mac Minis which use a converter to Mini Display Port and it works fine, so I don't see why DVI would be any different.
Question:	I see the monitor connector but how does the switch connect to the mouse and keyboard for each computer
Answer:	It adopts sepcial KVM cable - to the PC end, there are VGA and USB connectors; to the KVM switch end, there is VGA connector only, but it has USB signal inside. The 3 USB ports are to connect keyboard, mouse and other usb devices like printer, flash drive, etc.

Product features

Feature

1: USB2.0 port KVM switch

2: Manual switch. via push button

3: LED display for monitoring status.

4: Support Microsoft Intellimouse, Logitech Net Mouse, etc

Resolution:

Housing: Metal Max resolution: 1920*1440Support :1280x720px ppor: 640x480px , 800x600px ,1280x720px, 1920x1440pxCable length: 8*1.5m.Support bluetooth keyboard, mouse connect 8 pc and if you connect one of the input ,it will power supply, so you don't need a charger

Heat dissipation

Metal body shield strong heat dissipation The body is made of metal, which effectively reduces the signal interference and effectively improves the The heat dissipation effect can work stably for a long time.

Switch with your hands

It support Panel button switching

Desktop remote control

No software required PC selection via Push Buttons.

Non power

Hot Plug-add or remove connected PCs for maintenance without powering off the KVM switch or PCs.

Compatible with

For computers, game consoles, TV boxes, DVDs, TVs, notebooks, projectors, monitors, etc. Video and mouse and keyboard switching and manipulation of VGA output devices.

Compatible with a variety of mainstream servers and operating systems Support DOS, WIN DOWS9X, NT, WIN2000, WINXP, WIN7, LINUX, NOVELL and other operating systems.

Package

KVM Switch x1

Ext. switcher x1

User's manualx1

KVM cable 1.5m (about 5 feet) x8
