Product description

Pyle Model : PMXU83BT

8Ch Bluetooth Pro Audio DJ Sound Mixer

8Ch. Bluetooth Studio Mixer DJ Controller Audio Mixing Console System

Features:

• DJ & Studio Console Mixer System
• Multi 8Channel Audio Source Mixing
• Builtin Bluetooth Wireless Receiver
• FX (Analog Effects) & 16 Bit DSP processor
• DirecttoComputer Connect & Sound Record Ability
• LCD Digital Display & Front Panel Control Center
• Rotary Adjustment Knobs & LED Indicator Lights
• MP3 Digital Audio File Compatibility
• USB Interface: MP3 Flash Drive Reader/Computer Connection
• Connect & Stream Audio from External Devices
• 1/4’’ (L/R) MAIN Outputs
• XLR/14’’ Combo Audio LINE/Microphone Inputs
• Pair RCA (L/R) Inputs
• Pair 1/4’’ Mono + Stereo Inputs
• 1/4’’ Send + Return Inputs
• 1/4’’ Headphone Jack
• Stereo Level Fader/Slider
• Output Signal Level Indication
• BUS Audio Control, Sound Routing
• PAD Channel Source Input Switch
• Independent Channel Input Audio Configuration
• Gain, High, Mid, Low, FX/Send, Level, Base + Tone Adjustment
• +48V Phantom Power Control
• Power ON/OFF Switch
• Used for Professional Studio Applications & OnStage Performances

What’s in the Box:

• Bluetooth Studio Mixer
• Power Adapter Cable, 4Pin

Wireless Bluetooth Connectivity:

• HassleFree Audio Streaming Ability
• Works with All of Today’s Latest Devices
• (Smartphones, Tablets, Laptops, Computers, etc.)
• Bluetooth Network Name: ‘KT08UP’
• Bluetooth Version: 4.0
• Wireless Range: 15’+ ft.

Technical Specs:

• Input Mixer Channels: 8Ch. (+ FX/Headphones)
• Mic Input: Sensitivity/Impedance: 1.5mV/750 Ohm
• Input Frequency Response: 20Hz20kHz, +/3dB
• Input Distortion: 0.03%, 1kHz/150mV Input
• Channel GAIN Adjustment: +20/+64 (6/+38)
• HIGH Gain: +/15 dB, 12kHz Frequency Shelving
• MID Gain: +/15 dB, 2.5kHz Frequency Shelving
• LOW Gain: +/15 dB, 80kHz Frequency Shelving
• HIGH/MID/LOW Adjustment: 15/+15dB
• Stereo Output Level Meter: 5Segment (+6, +3, 0, 3, 10dB)
• PAD Input Channel Adjustment: 26dB
• Peak CLIP Level: < 3dB
• Phantom Power Voltage: +48V
• Power Supply: 100/240V (+/15V DC Power Adapter)
• Digital Audio File Compatibility FileTypes: MP3, WAV
• Dimensions (L x W x H): 9.3’’ x 10.8’’ x 2.6’’



The Pyle 8Ch. Bluetooth Studio Mixer DJ Controller Audio Mixing Console System DJ & Studio Console Mixer System Multi 8Channel Audio Source Mixing Builtin Bluetooth Wireless Receiver FX (Analog Effects) & 16 Bit DSP processor DirecttoComputer Connect & Sound Record Ability LCD Digital Display & Front Panel Control Center Rotary Adjustment Knobs & LED Indicator Lights MP3 Digital Audio File Compatibility USB Interface: MP3 Flash Drive Reader/Computer Connection Connect & Stream Audio from External Devices 1/4’’ (L/R) MAIN Outputs XLR/14’’ Combo Audio LINE/Microphone Inputs Pair RCA (L/R) Inputs Pair 1/4’’ Mono + Stereo Inputs 1/4’’ Send + Return Inputs.

• USB/Flash Reader /MP3 Compatibility : Connect your external USB, computer PC, flash drive or Bluetooth device to Mix & record; Use the built in controls to play/pause, skip tracks and switch between modes
• Bluetooth Wireless Music Streaming : Hassle and cable free audio streaming ability directly to the console unit; Mix your iPad, iPhone, Android smart phone to your DJ session; This audio mixer makes it a breeze to wirelessly stream all uour favorite music tunes to the mixing board easily from Pandora or Spotify
• MIC + Sterero Line Inputs : Supporting XLR and unbalanced 1/4" plug with +48V phantom button, highly accurate LED peak level indicator and ultra musical 3 band EQ on all channels; Ultra low noise, high headroom mixer with super easy functionality for professional vocal and instrumental sound
• Rugged Steel Chassis: With sealed rotary controls to resist dust and grime, this compact DJ mixer will provide total dynamic control for the ultimate in punch and clarity; This incredibly versatile mixer is great for high quality on stage performance, live gigs, and Karaoke; Effortlessly achieve premium quality crystal clear studio level quality musical playback
• New Multi Voltage Power Supply : 100V 240V (+/ 15V DC Power adapter) ideal for worldwide usage; Enjoy a value packed mixing solution today with performances that sound great each time

Product features

Professional Audio Mixer

With sealed rotary controls to resist dust and grime, this compact DJ mixer will provide total dynamic control for the ultimate in punch and clarity; This incredibly versatile mixer is great for high quality on stage performance, live gigs, and Karaoke; Effortlessly achieve premium quality crystal clear studio level quality musical playback

USB/Flash Reader /MP3 Compatibility

Connect your external USB, computer PC, flash drive or Bluetooth device to Mix & record; Use the built in controls to play/pause, skip tracks and switch between modes

Bluetooth Wireless Music Streaming

Hassle and cable free audio streaming ability directly to the console unit; Mix your iPad, iphone, Android smart phone to your DJ session; This audio mixer makes it a breeze to wirelessly stream all uour favorite music tunes to the mixing board easily from Pandora or Spotify

Mic and Stereo Line Inputs

Supporting XLR and unbalanced 1/4" Plug with +48V Phantom button, highly accurate LED Peak Level Indicator and Ultra-musical 3-band EQ on all channels Ultra-low noise, high headroom mixer with super easy functionality

8 Channels High Headroom Mixer

Supporting XLR and unbalanced 1/4" plug with +48V phantom button, highly accurate LED peak level indicator and ultra musical 3 band EQ on all channels; Ultra low noise, high headroom mixer with super easy functionality for professional vocal and instrumental sound

Product Dimension

The Pyle Professional Audio Mixer has Dimensions (L x W x H): 9.3’’ x 10.8’’ x 2.6’’ with 5.2 lbs of weight, So you can easily carry everywhere you go.

Built-in Digital Effects

For musical and non-musical applications, effects processing adds polish and professionalism to the mix. The Professional Audio Mixer Sound Board Console Desk System digital multi-effect processor, offering a comprehensive suite of editable digital effects perfect for enhancing your mix, whether adding depth to a speaking engagement or breathing new color and atmosphere into a live performance.

Product description

6-Ch. Bluetooth Studio Mixer - DJ Controller Audio Mixing Console System

Features:

DJ & Studio Console Mixer System

Multi 6-Channel Audio Source Mixing

Built-in Bluetooth Wireless Receiver

FX (Analog Effects) & 16 Bit DSP processor

Direct-to-Computer Connect & Sound Record Ability

LCD Digital Display & Front Panel Control Center

Rotary Adjustment Knobs & LED Indicator Lights

MP3 Digital Audio File Compatibility

USB Interface: MP3 Flash Drive Reader/Computer Connection

Connect & Stream Audio from External Devices

1/4’’ (L/R) MAIN Outputs

XLR/14’’ Combo Audio LINE/Microphone Inputs

1/4’’ Mono + Stereo Inputs

1/4’’ Send + Return Inputs

1/4’’ Headphone Jack

Stereo Level Fader/Slider

Output Signal Level Indication

BUS Audio Control, Sound Routing

PAD Channel Source Input Switch

Independent Channel Input Audio Configuration

Gain, High, Mid, Low, FX/Send, Level, Base + Tone Adjustment

+48V Phantom Power Control

Power ON/OFF Switch

Used for Professional Studio Applications & On-Stage Performances

What’s in the Box:

Bluetooth Studio Mixer

Power Adapter Cable, 4-Pin

Wireless Bluetooth Connectivity:

Hassle-Free Audio Streaming Ability

Works with All of Today’s Latest Devices

(Smartphones, Tablets, Laptops, Computers, etc.)

Bluetooth Network Name: ‘KT-08UP’

Bluetooth Version: 4.0

Wireless Range: 15’+ ft.

Technical Specs:

Input Mixer Channels: 6-Ch. (+ FX/Headphones)

Mic Input: Sensitivity/Impedance: 1.5mV/750 Ohm

Input Frequency Response: 20Hz-20kHz, +/-3dB

Input Distortion: 0.03%, 1kHz/150mV Input

Channel GAIN Adjustment: +20/+64 (-6/+38)

HIGH Gain: +/-15 dB, 12kHz Frequency Shelving

MID Gain: +/-15 dB, 2.5kHz Frequency Shelving

LOW Gain: +/-15 dB, 80kHz Frequency Shelving

HIGH/MID/LOW Adjustment: -15/+15dB

Stereo Output Level Meter: 5-Segment (+6, +3, 0, -3, -10dB)

PAD Input Channel Adjustment: 26dB

Peak CLIP Level: < 3dB

Phantom Power Voltage: +48V

Power Supply: 100/240V (+/-15V DC Power Adapter)

Digital Audio File Compatibility File-Types: MP3, WAV

Dimensions (L x W x H): 9.3’’ x 9.7’’ x 2.6’’

• USB/FLASH READER/MP3 COMPATIBILITY - Connect your external USB, computer PC, flash drive or Bluetooth device to mix & record. Use the built-in controls to play/pause, skip tracks and switch between modes.
• BLUETOOTH WIRELESS STREAMING - Hassle and cable-free audio streaming ability directly to the console unit. This audio mixer can wirelessly stream music tunes from iPad, iPhone and Android Smart Phone with mixing board from Pandora or Spotify.
• MIC AND STEREO LINE INPUTS - Supporting XLR and unbalanced 1/4" Plug with +48V Phantom button, highly accurate LED Peak Level Indicator and Ultra-musical 3-band EQ on all channels. Ultra-low noise, high headroom mixer with super easy functionality.
• RUGGED STEEL CHASSIS - With sealed rotary controls to resist dust and grime, this compact DJ Mixer will provide total dynamic control. This incredibly versatile mixer is great for high quality on stage performance, live gigs and Karaoke.
• NEW MULTI-VOLTAGE POWER SUPPLY - 100V-240V (+/-15V DC power adapter) ideal for worldwide usage. Enjoy a value packed mixing solution today with performances that sound great each time.

User questions & answers

Question:	Can i use the usb out to connect to my computer while still using channels 5/6 as an input
Answer:	No, it’s one or the other. There is a two position switch to choose.
Question:	Do I also need a separate headphone amp for a podcast or will this work
Answer:	No. You can plug in your headphone directly in the unit. It requires a 1/4 jack. If you are broadcasting live, you need to plug your headphone directly to the source you are broadcasting to, ie: computer mixer audio board output, otherwise you will get feedback, in this case, plugging to the Pyle unit won't help you. The Pyle unit's headphone jack will only let you hear the sound being mixed in the unit.
Question:	Is this a powered mixer
Answer:	Its just a mixer. It has no Amp. It is suppose to be connected to an Amplifier. So the Question. if you mean by power,watts or loudness, is not applicable.
Question:	What is the power output, of this unit. I am looking to use it, with (2) 10" speakers, mike, and (2) inputs. Speakers are passive (non powered
Answer:	This unit is Just a mixer ONLY. It has to be used with either a power amp or powered speakers. I have a 1000 watt amp that powers two 450 watt speakers. I entertain at Senior Facilities and use it over 200 times a year.

Product features

About us

In the late 20th century, Pyle established itself as a premium source for replacement speakers and car audio. By the year 2000, Pyle had undergone a massive transformation, expanding into the nascent market spaces of competitive car audio, home audio, marine audio, and professional audio & musical instruments - our Pyle Pro line. As you sit in your car, you are isolated from outside noise and surrounded by speakers. You become enveloped in sound. We have a wide range of speakers, amplifiers, and head units that will enrich your car audio experience. You’d be surprised at how much better your music can sound with an upgrade from the factory speakers and amplifier.

Product description

No matter what your audio mixing needs, this Pyle PMXU43BT mixing desk provides the performance and features that can take your talent to the next level. With professional sound quality, our legendary mic preamps, EQs and 16-Bit DSP Multi-FX processor makes us the envy of sound engineers and producers all around the world!







Features:



DJ & Studio Console Mixer System



Multi 4-Channel Audio Source Mixing



Built-in Bluetooth Wireless Receiver



FX (Analog Effects) & 16 Bit DSP processor



Direct-to-Computer Connect & Sound Record Ability



LCD Digital Display & Front Panel Control Center



Rotary Adjustment Knobs & LED Indicator Lights



MP3 Digital Audio File Compatibility



USB Interface: MP3 Flash Drive Reader/Computer Connection



Connect & Stream Audio from External Devices



1/4’’ (L/R) MAIN Outputs



XLR/14’’ Combo Audio LINE/Microphone Inputs



1/4’’ Mono + Stereo Inputs



1/4’’ Send + Return Inputs



1/4’’ Headphone Jack



Stereo Level Fader/Slider



Output Signal Level Indication



BUS Audio Control, Sound Routing



PAD Channel Source Input Switch



Independent Channel Input Audio Configuration



Gain, High, Mid, Low, FX/Send, Level, Base + Tone Adjustment



+48V Phantom Power Control







What’s in the Box:



Bluetooth Studio Mixer



Power Adapter Cable, 4-Pin







Wireless Bluetooth Connectivity



Hassle-Free Audio Streaming Ability



Works with All of Today’s Latest Devices



(Smartphones, Tablets, Laptops, Computers, etc.)



Bluetooth Network Name: ‘KT-08UP’



Bluetooth Version: 4.0



Wireless Range: 15’+ ft.







Technical Specs:



Input Mixer Channels: 4-Ch. (+ FX/Headphones)



Mic Input: Sensitivity/Impedance: 1.5mV/750 Ohm



Input Frequency Response: 20Hz-20kHz, +/-3dB



Input Distortion: 0.03%, 1kHz/150mV Input



Channel GAIN Adjustment: +20/+64 (-6/+38)



HIGH Gain: +/-15 dB, 12kHz Frequency Shelving



MID Gain: +/-15 dB, 2.5kHz Frequency Shelving



LOW Gain: +/-15 dB, 80kHz Frequency Shelving



HIGH/MID/LOW Adjustment: -15/+15dB



Stereo Output Level Meter: 5-Segment (+6, +3, 0, -3, -10dB)



PAD Input Channel Adjustment: 26dB



Peak CLIP Level:

• USB/FLASH READER/MP3 COMPATIBILITY - Connect your external USB, computer PC, flash drive or Bluetooth device to mix & record Use the built-in controls to play/pause, skip tracks and switch between modes
• BLUETOOTH WIRELESS STREAMING - Hassle and cable-free audio streaming ability directly to the console unit This audio mixer can wirelessly stream music tunes from iPad, iPhone and Android Smart Phone with mixing board from Pandora or Spotify
• MIC AND STEREO LINE INPUTS - Supporting XLR and unbalanced 1/4" Plug with +48V Phantom button, highly accurate LED Peak Level Indicator and Ultra-musical 3-band EQ on all channels Ultra-low noise, high headroom mixer with super easy functionality
• RUGGED STEEL CHASSIS - With sealed rotary controls to resist dust and grime, this compact DJ Mixer will provide total dynamic control This incredibly versatile mixer is great for high quality on stage performance, live gigs and Karaoke
• NEW MULTI-VOLTAGE POWER SUPPLY - 100V-240V (+/-15V DC power adapter) ideal for worldwide usage Enjoy a value packed mixing solution today with performances that sound great each time

User questions & answers

Question:	Can I use this to connect a bands instruments, bass, guitar, and vocals to the computer and record them all live at the same time
Answer:	Yes. Up to 4 instruments can be mixed into a stereo output that can go to stereo headphone and EITHER 2 speakers, a PC via a USB2 cable or to another device via Bluetooth wirelessly. There is a digital selector in top center. The USB2 can apparently also be used as input as there are playback control buttons as well. Have not tested. Note that the 2 odd looking inputs in the upper left corner are intended for mics and can take either XLR 1/4" phone plug connectors.
Question:	Can this plug directly into an iPhone using a usb to lightning adapter to record using the iPhone
Answer:	Hi, unfortunately no. You have to connect the mixer to a laptop or computer. Please check the video link below. Thank you. https://www.youtube.com/watch?v=CHc2s9Wg9ns
Question:	is it plug and play
Answer:	Yes just plug and play. I used it twice on streaming. It's very good machine.
Question:	Does this mixer has a built in sound card or will I have to use an external one if I want to records with condenser mic
Answer:	The instructions say that it includes a built in sound card; however, no matter what I do, I cannot get any microphone to cooperate with this mixer to record on a PC. While I plug and unplug the cable, feedback will record, but no voice will travel from the mic through the mixer and into the PC.

Product description

Pyle Model : PMXU88BT

8-Ch. Bluetooth Studio Mixer

8-Ch. Bluetooth Studio Mixer - DJ Controller Audio Mixing Console System

Features:

DJ & Studio Console Mixer System

Multi 8-Channel Audio Source Mixing

Built-in Bluetooth Wireless Receiver

FX (Analog Effects) & 16 Bit DSP processor

Direct-to-Computer Connect & Sound Record Ability

7-Band EQ

32-Bit Dual Engine DSP

24-Bit ADC DAC Converter

FX Configuration Adjustment Controls

Rotary Adjustment Knobs & LED Indicator Lights

MP3 Digital Audio File Compatibility

USB Flash Drive Reader

USB Port for Desktop Connection

Connect & Stream Audio from External Devices

1/4’’ (L/R) MAIN Outputs

XLR/14’’ Combo Audio LINE/Microphone Inputs

Pair RCA (L/R) Inputs

Pair 1/4’’ Mono + Stereo Inputs

1/4’’ Send + Return Inputs

1/4’’ Headphone Jack

Stereo Level Fader/Slider

Output Signal Level Indication

BUS Audio Control, Sound Routing

PAD Channel Source Input Switch

Independent Channel Input Audio Configuration

Gain, High, Mid, Low, FX/Send, Level, Base + Tone Adjustment

+48V Phantom Power Control

Power ON/OFF Switch

Used for Professional Studio Applications & On-Stage Performances

What’s in the Box:

Bluetooth Studio Mixer

Power Adapter Cable, 3-Pin

Wireless Bluetooth Connectivity:

Hassle-Free Audio Streaming Ability

Works with All of Today’s Latest Devices

(Smartphones, Tablets, Laptops, Computers, etc.)

Bluetooth Network Name: ‘KG-08A’

Bluetooth Version: 2.0

Wireless Range: 15+’ ft

Technical Specs:

Input Mixer Channels: 8-Ch. (+ FX/Headphones)

Mic Input: Sensitivity/Impedance: 1.5mV/750 Ohm

Input Frequency Response: 20Hz-20kHz, +/-3dB

Input Distortion: 0.03%, 1kHz/150mV Input

Channel GAIN Adjustment: +20/+64 (-6/+38)

HIGH Gain: +/-15 dB, 12kHz Frequency Shelving

MID Gain: +/-15 dB, 2.5kHz Frequency Shelving

LOW Gain: +/-15 dB, 80kHz Frequency Shelving

HIGH/MID/LOW Adjustment: -15/+15dB

Stereo Output Level Meter: 12-Segment (-30, -20, -10, -7, -4, -2, 0, +2, +4, +7, +10, CLIP)

PAD Input Channel Adjustment: 26dB

Peak CLIP Level: < 3dB

Digital Audio File Compatibility File-Types: MP3, MP4, WMA, WAV

Phantom Power Voltage: +48V

Power Supply: 100/240V (+/-15V DC Power Adapter)

Dimensions (L x W x H): 16.3’’ x 12.5’’ x 3.66’’ -inches

The Pyle 8-Ch. Bluetooth Studio Mixer - DJ Controller Audio Mixing Console System - DJ & Studio Console Mixer System - Multi 8-Channel Audio Source Mixing - Built-in Bluetooth Wireless Receiver - FX (Analog Effects) & 16 Bit DSP processor - Direct-to-Computer Connect & Sound Record Ability - 7-Band EQ - 32-Bit Dual Engine DSP - 24-Bit ADC DAC Converter - FX Configuration Adjustment Controls - Rotary Adjustment Knobs & LED Indicator Lights - MP3 Digital Audio File Compatibility - USB Flash Drive Reader - USB Port for Desktop Connection - Connect & Stream Audio from External Devices - 1/4’’ (L/R) MAIN Outputs.

• fdescripRECORD AND CONNECT TO PC: This personal mixer has a USB soundcard and audio interface to record and connect to MAC or PC and it has universal digital audio file compatibility. Can be used by beginners or studio professional applications
• BLUETOOTH: This portable 8-channel DJ sound controller has Bluetooth for wireless streaming and use it as an input to mix signal with other input channels. It works with iPhone, Android, iPad, Tablet and MP3 Player. The wireless range is 15 ft
• 8-CHANNEL MIXER: The device caters multiple device connectivity because it has 8 channels. It has 2 1/4’’ (L/R) outputs, 4 XLR microphone inputs, 2 pairs RCA (L/R) inputs, 2 pairs 1/4’’ mono + stereo,1/4’’ Send + Return and 1/4’’ headphone jack
• LED INDICATOR LIGHTS: The recording mixer has LED indicator lights and rotary adjustment knobs for user convenience. It has input selection, master volume controls, independent channel balance and high, plus, low frequency adjustment
• +48V PHANTOM POWER: For reliable power source, this DJ mixer comes with a +48V Phantom power supply. Includes a 3=pin power adapter cable and the stereo output level meter is 12-Segment (-30, -20, -10, -7, -4, -2, 0, +2, +4, +7, +10, CLIP)

User questions & answers

Question:	Does the unit also function as an audio interface or soundcard controlling the volume of my computer
Answer:	Hi, you have to use an audio interface for this unit. Please check the video review using the link below. Thank you https://www.youtube.com/watch?v=2wLNNLRBRko
Question:	how many devices can it stream simultaneously within bluetooth
Answer:	Hi, you can only use 1 Bluetooth connection at a time. You may check other details of the unit by visiting our website pyleaudio.com. Type the model number on the search box PMXU88BT for more details. Thank you.
Question:	Hi, Can I use this mixer to record with usb stick without computer
Answer:	Yes. When playing music, long press to record, short press to finish recording and enter to playback the recorded music. When playing the recorded music, short press to switch into playing the USB music first track. When playing the USB music, short press to switch into playing the recorded music first track.
Question:	Hi, I'm just get this mixer today , I don't know how to turn on the sound from bluetooth, I was turn on the blue tooth in my phone "kg-08a
Answer:	Use or short press the REP/MODE button to switch into Bluetooth or USB sources. Also make sure that after pairing your device with the mixer to turn up the volume on your paired device.

Product features

8-Channel Bluetooth Studio Audio Mixer

The Pyle 8-Ch. Bluetooth Studio Mixer - DJ Controller Audio Mixing Console System - DJ & Studio Console Mixer System - Multi 8-Channel Audio Source Mixing - Built-in Bluetooth Wireless Receiver - FX (Analog Effects) & 16 Bit DSP processor - Direct-to-Computer Connect & Sound Record Ability - 7-Band EQ - 32-Bit Dual Engine DSP - 24-Bit ADC DAC Converter - FX Configuration Adjustment Controls - Rotary Adjustment Knobs & LED Indicator Lights - MP3 Digital Audio File Compatibility - USB Flash Drive Reader - USB Port for Desktop Connection - Connect & Stream Audio from External Devices - 1/4’’ (L/R) MAIN Outputs.

Features:

• Stereo Level Fader/Slider
• Output Signal Level Indication
• BUS Audio Control, Sound Routing
• PAD Channel Source Input Switch
• Independent Channel Input Audio Configuration
• Gain, High, Mid, Low, FX/Send, Level, Base + Tone Adjustment
• +48V Phantom Power Control
• Power ON/OFF Switch
• Used for Professional Studio Applications & On-Stage Performances

Technical Specs:

• Input Mixer Channels: 8-Ch. (+ FX/Headphones), Mic Input: Sensitivity/Impedance: 1.5mV/750 Ohm
• Input Frequency Response: 20Hz-20kHz, +/-3dB, Input Distortion: 0.03%, 1kHz/150mV Input
• Channel GAIN Adjustment: +20/+64 (-6/+38), HIGH Gain: +/-15 dB, 12kHz Frequency Shelving
• MID Gain: +/-15 dB, 2.5kHz Frequency Shelving, LOW Gain: +/-15 dB, 80kHz Frequency Shelving
• HIGH/MID/LOW Adjustment: -15/+15dB, Stereo Output Level Meter: 12-Segment (-30, -20, -10, -7, -4, -2, 0, +2, +4, +7, +10, CLIP)
• PAD Input Channel Adjustment: 26dB, Peak CLIP Level: < 3dB
• Digital Audio File Compatibility File-Types: MP3, MP4, WMA, WAV
• Phantom Power Voltage: +48V, Power Supply: 100/240V (+/-15V DC Power Adapter)
• Dimensions (L x W x H): 16.3’’ x 12.5’’ x 3.66’’ -inches

Product description

PylePro Model : PYD1964B. 56-Ch Bluetooth Pro Audio Studio DJ MixerBluetooth 6-Channel DJ Mixer 19'' 5U Rack Mount System Digital LED Illuminated Controls Features: Built-in Bluetooth for Wireless Music StreamingCompatible with All of Your Favorite Bluetooth Devices (Works with iPhone, Android, Smartphone, iPad, Tablet, PC, etc. )Mix 2 Phono, 8 Line Level and 2 Microphone Input Signals 10-Band Graphic Equalizer for (R) and (L) ChannelsTwo Balanced or 1/4'' Mono Microphone InputsSeparate Mic 1 and Mic 2 Level Controls Microphone High, Mid, Bass Tone Controls with Mic Talk-over and Mic Frequency Kill SwitchSeparate Switchable Channel 1, 2, 3, 4, Master and Zone Gain Controls with Cross FaderHeadphone Volume Control with Channel Cue Echo, Delay and Repeat Level Controls6 Added Digital Sound EffectsDigital LED Illuminated ControlsSeparate Zone, Record and Master Outputs Technical Specifications: CUE-PGM control Phono: 3 mV, 47 KOhmLine: 50 mV, 27 KOhmMIC 1, 2, & 3: 2mV, 2 K Ohm BalancedBass: 12dBHigh: 12dBOutput Amp: 0 dB 1VOutput Max: 8V Peak-to-PeakRec. : 120 mV, 5 KOhmZone: 0 dB 1 V Frequency Response: 20 Hz - 20 KHz +/- 2 dBDistortion: 0. 02%S/N Ratio: Better Than 80 dBTalkover Attenuation: -16 dBHeadphone Impedance: 16 OhmPower Source: AC90V-240V V, 60/50 Hz, 20 WUnit Dimensions (W x H x D): 19. 0'' x 3. 4'' x 9. 4'' inchesWeight: 5. 5 lbsThe Pyle PYD1964B with Bluetooth takes the professional DJ mixer to new heights with a groundbreaking combination of digital, Bluetooth and analog technologies. Bluetooth allows you to wirelessly transmit your entire MP3 library right into your mix from devices like your iPad, iPhone, Android Smart Phone or Tablet. Rock-solid construction, superb audio fidelity, high quality parts, and of course, reliability are the core ingredients of the design. Unique features provide Mobile and Club DJs tremendous flexibility and intuitive control. 2 phono, 8 line level and 2 microphone input signals with Bluetooth give you the freedom to move any source to any channel or even the same source to multiple channels for quick and easy remixing. Take full sound control with 10 Band graphic equalizer, echo, delay, repeat and added digital sound effects. Manipulate your voice with high, mid and bass mic adjustments, then use the KILL switch to cancel specific frequencies of your two microphone inputs for added special voice effects. Upgrade your system with the digital technology to take your DJ skills to the next level.

• Bluetooth: the Bluetooth DJ controller allows you to wirelessly transmit your entire MP3 library right into your mix from devices like your iPad, iPhone, Android smart phone or tablet
• Upgrade your voice: the DJ mixer controller manipulates your voice with high, mid and bass mic adjustments, then use the kill switch to cancel specific frequencies of your two microphone inputs for added special voice effects
• Quick & easy remixing: the mixer digital gives you the freedom to move any source to any channel or even the same source to multiple channels for quick and easy remixing
• Full sound control: the 6Channel mixer gives you complete control over your sound with 10 band Graphic equalizer, echo, delay, repeat and added digital sound effects
• Updated features: the mixer 6 channel features include rock-solid construction, superb audio fidelity, high-quality parts, and of course, reliability are the core ingredients of the design

User questions & answers

Question:	can I find this product anywhere else
Answer:	Yes
Question:	how do I fix a hum that increases with more volume
Answer:	there could be a an easy answer, take off all the players connected first and see if you still have the sound there of the hum, if so, it could be a bad wiring where the power is, there are hum suppressors that can help get it out, some audio leads can course it too, I have it with my computer putting a hum in it, but laptops can do the same, some fans can make the sound as well, but check the volts and hz to make sure it is the right, and do know connect the lighting on the same line the audio is on as well it can make a hum sound, all this is what I have pick up in working in nite clubs, pubs and doing mobile disco.
Question:	How to pair Bluetooth device
Answer:	Hi, the Bluetooth name "PYLEPRO" will automatically appear on your mobile phone. You may check other details of the unit by visiting our website pyleaudio.com. Type the model number on the search box PYD1964B for more details. Thank you.
Question:	Does this have the high quality aptx bluetooth
Answer:	I don't know. Even grounded I still had far more noise than my original Numark mixer. Repaired my slide pot. And sent the Pyle back. Never got to the point where I would test the signal to Bluetooth.

Product features

Pyle 6 Channel Mixer, Bluetooth DJ Controller

Bluetooth 6-Channel DJ Mixer 19'' 5U Rack Mount System Digital LED Illuminated Controls

• Upgrade your voice: the DJ mixer controller manipulates your voice with high, mid and bass mic adjustments, then use the kill switch to cancel specific frequencies of your two microphone inputs for added special voice effects
• Quick & easy remixing: the mixer digital gives you the freedom to move any source to any channel or even the same source to multiple channels for quick and easy remixing
• Full sound control: the 6Channel mixer gives you complete control over your sound with 10 band Graphic equalizer, echo, delay, repeat and added digital sound effects
• Updated features: the mixer 6 channel features include rock-solid construction, superb audio fidelity, high-quality parts, and of course, reliability are the core ingredients of the design

Product description

Six-Channel Audio Mixer with Built-in USB Interface Combines Traditional Sound Card and Mixer Function Built-in Bluetooth for Wireless Music Streaming Built-in MP3 Player with LED Display Built-in DSP Sound Effects Processor Connects USB to PC to Play & Record Music Connects USB to PC or Power Bank for Power Supply Convenience for Mobile Audio Connection & Outdoor Guitar while Playing & Singing Exquisite Plastic Chassis Mic/Stereo/MP3/USB Sound Card/Bluetooth Input Channels Main/Phones Output Channels Ultra-Low Noise Design With High Headroom Clipping LED Indicators For Left And Right Channel Smooth Rotary-Style Faders For Mic/USB/Line/Master Controls 1 XLR / 1/4'' Jack Combo Mic Input 2 RCA Stereo Inputs

• 6 CHANNEL: This wireless 6 channel audio interface controller DJ mixer machine by Pyle is the perfect way to mix audio from MP3, mic, and bluetooth connected devices. Each channel has its own independent volume control, cross fader, & gain control
• BLUETOOTH MUSIC STREAMING: This sound mixer USB interface mixer is compatible w/ bluetooth and works w/ smartphone, tablet, laptop, pc w/ simple hassle-free pairing. Wirelessly stream music like Pandora / Spotify from your device directly to your mix
• DSP SOUND EFFECT: Pyle professional audio mixer streaming system has a built-in DSP Sound effects processor with up to 16 digital effects that can be applied to synthesized or recorded sounds such as your voice and to enhance your music
• 4 INPUTS: Pyle DJ mixer USB audio interface mixer is equipped w/ dual RCA audio line-in, 1 XLR/1/4" jack combo mic input, & USB port. It also has a ¼" headphone output jack. Produce creative remix which is perfect for DJ party/music recording
• +48V PHANTOM POWER: For the reliable power source, the stage/studio sound mixing console features a +48V phantom power supply. has ultra-low noise design with high headroom and exquisite plastic chassis. Perfect for both beginners & professional

Product features

Professional Wireless DJ Audio Mixer

This wireless 6 channel audio interface controller DJ mixer machine by Pyle is the perfect way to mix audio from MP3, mic, and bluetooth connected devices. Each channel has its own independent volume control, cross fader, & gain control

Mic Talkover

Studio sound mixing device also features microphone 1 and 2 level gain and talk over control so you will have the ability to speak over audio karaoke style and add crystal clear vocals to your mix

DSP Sound effect

Pyle professional audio mixer streaming system has a built-in DSP Sound effects processor with up to 16 digital effects that can be applied to synthesized or recorded sounds such as your voice and to enhance your music

Wireless Music Streaming

This Mixer is compatible with Bluetooth and works with latest devices like smartphone, tablet, laptop, pc with simple hassle free pairing. Wireless stream music like Pandora / Spotify from your device directly into your mix

Product description

The Pyle PMX7BU Bluetooth Compact DJ Mixer will help ensure that your performances sound great every time. You’ll be able to professionally mix your entire Digital MP3 library with your turntables or other connected devices.  Bluetooth technology will allow you to instantly add wireless streaming music to your DJ session.  (Works with iPhone, Android, Smartphone, iPad, Tablet, PC, etc.) Wirelessly stream music like Pandora or Spotify from your Bluetooth device directly into your mix. Your microphones will sound crystal clear with talk over control and separate gain control. Enjoy a value-packed mixing solution with the Pyle PMX7BU Bluetooth Compact DJ Mixer.

• 3 CHANNEL: This portable professional wireless 3 channel Dj mixer machine by Pyle is the perfect way to easily mix audio from MP3 and bluetooth connected devices. Each channel has its own independent volume controls and cross fader
• DJ CONTROLLER: The Dj mixer audio streaming system has Aux inputs switchable between line level and phono input. The PHONO inputs for channel 2 are for turntable connection and the LINE inputs may be used for connecting tape decks, CD or MD player
• BLUETOOTH MUSIC STREAMING: This Mixer is compatible with bluetooth and works with latest devices like smartphone, tablet, laptop, pc w/ simple hassle free pairing. Wirelessly stream music like Pandora / Spotify from your device directly into your mix
• 5 INPUTS: Pyle mixer is equipped w/ dual phono RCA audio line in, 2 1/4" balanced TRS microphone in, and a USB flash drive reader. It also has a ¼" headphone jack. Produce highly creative remixes which is perfect for dj party / music recording
• MIC TALK OVER: The PMX7BU stage / studio sound mixing device also features microphone 1 and 2 level gain and talk over control so you will have the ability to speak over audio karaoke style and add crystal clear vocals to your mix

User questions & answers

Question:	is it easy to sync songs with the mixer
Answer:	Yes, work perfect for mi!
Question:	Would Amazon Echo Dot be able to connect to this device and auto play music
Answer:	I'm an end user. The Eco dot has 3.5mm in and out jacks. The mixer you are looking at has ample rca connectors. You will have to purchase an rca to 3.5 mm cable. Here is a sample, Interconnects Axxess A35-RCA-6 6 Ft RCA Cable to Male 3.5mm High Quality Audio Connector.
Question:	Can this mixer connect via blutooth to wireless/blutooth amplified speakers
Answer:	Yes, if use a Bluetooth transmitter like the one at the following link, but with Bluetooth there is always latency (delay) so it will be a little weird using a microphone. Works great for music though. TaoTronics Bluetooth Transmitter and Receiver, Digital Optical TOSLINK and 3.5mm Wireless Audio Adapter for TV / Home Stereo System - aptX Low Latency https://www.amazon.com/dp/B01KO1JNCA/ref=cm_sw_r_cp_api_NvkqzbGV6EKBV
Question:	How do i connect this mixer to my laptop
Answer:	You need a cable with a 1/8 " connector on one end which plugs into your headphone jack on your computer. On the other end of the cable you need RCA connectors. You can buy a 1/8" to RCA cables on Amazon. They have dozens to choose from. With that arrangement you can play music from your computer through the mixer. The output from the mixer is also RCA connectors. So you will need a cable with RCA connectors on one end which will be plugged into the output from the mixer and on the other end of these cables you will need either RCA connectors if you are plugging it into a home stereo amp or 1/4" connectors if you are plugging it into a DJ or band type amp sound system. If your laptop has bluetooth capability like mine does and like my ipad and iphone does, you connect via bluetooth. It is really simple. You just set the mixer to the bluetooth setting on channel 3 on the mixer and it will automatically find your laptop bluetooth signal and pair it(connect to it)

Product features

Bluetooth 3-Channel DJ MP3 Mixer

The PMX7BU Bluetooth Compact DJ Mixer will help ensure that your performances sound great every time. You’ll be able to professionally mix your entire Digital MP3 library with your turntables or other connected devices. Bluetooth technology will allow you to add your iPad, iPhone, Android Smart phone or tablet to your DJ session wire-free. Wirelessly stream music like Pandora or Spotify from your Bluetooth device directly into your mix. Your microphones will sound crystal clear with talk over control and separate gain control. Enjoy a value-packed mixing solution with the Pyle PMX7BU Bluetooth Compact DJ Mixer.

Bluetooth Wireless Music Streaming

This Bluetooth Multi-Channel DJ Mixer is compatible with all your favorite Bluetooth devices. The PMX7BU lets you stream from your Bluetooth compatible device directly to the unit. Get rid of those extra cables, and enjoy crisp sound with a rapid wireless setup. This feature makes it a breeze for you to be able to wirelessly stream all your favorite tunes to the unit right out of the box quickly and easily.

Mix Aux Inputs

The PMX7BU allows you to easily combine and mix the 2 AUX input sources with Bluetooth audio or MP3’s. This feature lets you plug any audio source (microphone, phone, MP3 player etc.) and combine it with the Bluetooth audio, USB flash MP3’s or any audio channel in your unit. The AUX inputs are also switchable between line level and phono input.

USB Flash Reader

A built-in USB flash reader allows you to load your USB stick or device with MP3s and play them through your mixer. Enjoy all the benefits of MP3’s with the ability to use your channels normally. Just plug it in and you are ready to access all your files.

Bluetooth/MP3 Controls

Once connected to your USB flash reader or Bluetooth device you may use the built-in controls to access your USB flash and Bluetooth device’s MP3’s. You may play/pause, skip tracks and switch between modes with these controls.

Product description

Features: - Level and Echo Control - Includes Music Volume Control - Two Individual MIC Volume Controls - Two Wired MIC Inputs - Stereo RCA Audio Input - Stereo 3.5 AUX Input - Stereo RCA Audio Output and 6.35 Mono Output - With Cable for TV, PC, Smartphone, and Speaker - Ideal for Karaoke and house parties - Simple Menu-Free Operations - Integrates with TV or Home Theater - RCA Coaxial Audio Input Jacks for Connecting CD/DVD Players - Designed to Provide Multi-Source Mixing for Solo Singers or Duets What's in the Box: - Mixer - Power Adapter - Audio (2RCA) Cable - Audio (3.5mm) Cable - Audio (6.35mm) Cable Technical Specs: - S/N ratio: > 95dB - T.H.D: <0.5% - LINE Input Sensitivity: 380mV/-8.5dB - MIC Input Sensitivity: 5mV/-46dB - LINE Input Impedance: 20KO - MIC Input Impedance: 600O - Power Supply: DC12V/200mA - Construction Material: Engineered ABS - Product Dimensions (L x W x H): 6.7" x 4.4" x 1.3" -inches

• INSTANT KARAOKE FUN: Just connect the RCA type audio input jack to audio source such as DVD player & the audio output jack to your TV or active speaker w/ the included RCA audio/video cable for limitless KTV entertainment both kids & adults can enjoy
• ADJUSTABLE ROTARY CONTROLS: The professional karaoke mixer is equipped w/ rotary adjustment controls to easily adjust echo, tone, volume of mics/music & audio from external devices to your desired level. Works w/ computer, speaker, amplifier, etc
• TWO MICROPHONE INPUTS: This portable karaoke mixing device by Pyle can support up to 2 wired microphones. Equipped w/ individual mic volume controls w/ level & echo control. Other inputs include RCA & AUX 3.5mm. Also includes RCA & 6.35 mono outputs
• INTEGRATES WITH TV: Dance or move around the room to entertain the crowd w/ this karaoke audio mixer, a great addition to your home entertainment system. Ideal for karaoke & house parties. Equipped w/ RCA coaxial input for connecting CD/DVD players
• SIMPLE MENU-FREE OPERATION: The compact karaoke audio mixer is easy to operate w/ simple controls. Designed to provide multi-source mixing for solo singers or duets. Works with TV, PC, smartphone & speakers. Includes necessary cables & power adapter

Product description

Features: - professional 3-channel DJ mixer - built-in BT for wireless music streaming - cue select for pre-listening - digital LED display - compatible with all of your favorite BT devices - combine & mix aux input sources with BT audio or MP3 - aux inputs switch between line level and Phono input - phono RCA audio line inputs for connecting external devices - 1/4” balanced TRS microphone jacks - microphone 1 and 2 level gain and talk-over control - mic talk-over ability to speak over audio, karaoke style - 1/4” headphone jack with volume control - AMP Master output (L/R) - USB flash drive Reader - independent Channel controls cross fader - easily mix & control MP3 and BT connected devices - (L) and (R) RCA Master output with stereo technical Specs: - LED screen size: 2. 76’’ x 0. 98’’ - Phono inputs 1 and 2: 90mV 1 kHz, unbalanced inputs - line inputs 1 and 2: 0. 6V, unbalanced inputs - mic input: 120mV, balanced inputs - headphones: 300MW @ 1% THD - signal-to-noise ratio (s/N): > 78dB (line in) - crosstalk: > 50dB (line in) - distortion (THD): < 1% - Frequency response: 20Hz - 20kHz - power consumption: Max 5 W - Dimensions (H x W x d): 5. 31'' X 9. 25'' X 1. 97'' Inches - Weight: 1. 98 lbs.

• 3 CHANNEL: This portable professional wireless 3 channel Dj mixer machine by Pyle is the perfect way to easily mix audio from MP3 and bluetooth connected devices. Each channel has its own independent volume controls and cross fader
• DJ CONTROLLER: The Dj mixer audio streaming system has Aux inputs switchable between line level and phono input. The PHONO inputs for channel 2 are for turntable connection and the LINE inputs may be used for connecting tape decks, CD or MD player
• BLUETOOTH MUSIC STREAMING: This Mixer is compatible with bluetooth and works with latest devices like smartphone, tablet, laptop, pc w/ simple hassle free pairing. Wirelessly stream music like Pandora / Spotify from your device directly into your mix
• 5 INPUTS: Pyle mixer is equipped w/ dual phono RCA audio line in, 2 1/4" balanced TRS microphone in, and a USB flash drive reader. It also has a ¼" headphone jack. Produce highly creative remixes which is perfect for dj party / music recording
• MIC TALK OVER: The PMX7BU stage / studio sound mixing device also features microphone 1 and 2 level gain and talk over control so you will have the ability to speak over audio karaoke style and add crystal clear vocals to your mix

User questions & answers

Question:	Is this recommended for making rap music vocals in the studio
Answer:	The unit is not suited for professional vocal recording. It isn’t that type of mixer. It’s a novice DJ mixer. It is designed to mix multiple channels of media for DJ entertainment purposes, and amateur applications of that, at best. If your goal is to record professional studio vocals, look into a pro audio interface and a mixer designed for studio recording of vocals and instruments. There are literally thousands of options and price ranges in that realm to choose from, not to mention endless videos on the subject of audio recording.
Question:	I have separate dj & karaoke setups & need a sound mixer (fx) exclusively for my karaoke player & mic's for powered speakers. is this a best option
Answer:	I don't know if it's the best for you but it has been an excellent choice for me. I use it to mix 3 audio signals and a set of UHF microphones through an A-D converter cable into a MacBook Pro USB-C port. We use it for Zoom conferencing and have been extremely happy with the mixer. The digital conversion cord we use is this one: https://www.amazon.com/gp/product/B079CBGDST/ref=ppx_yo_dt_b_asin_title_o09_s00?ie=UTF8&psc=1
Question:	Can it connect to my Bluetooth sound bar
Answer:	I think the Bluetooth works as an input for only. There’s no panel/remote to assign the output to connect to a bluetooth-enabled source (sound bar).
Question:	How does this connect to a laptop? looking for way to connect wireless mics, even ext sound cards havent worked hoping this is the answer
Answer:	If your wireless mic is Bluetooth it should connect to this.

Product features

Pyle 3 Channel Bluetooth Compatible DJ Controller Sound Mixer

This portable professional wireless 3 channel Dj mixer machine by Pyle is the perfect way to easily mix audio from MP3 and bluetooth connected devices. Each channel has its own independent volume controls and cross fader.

This Mixer is compatible with bluetooth and works with latest devices like smartphone, tablet, laptop, pc with simple hassle free pairing. Wirelessly stream music like Pandora / Spotify from your device directly into your mix.

Wireless DJ Audio Mixer - 3 Channel Bluetooth Compatible DJ Controller Sound Mixer, Mic-Talkover, Dual RCA Phono/Line in, Microphone Input, Headphone Jack

The Dj mixer audio streaming system has Aux inputs switchable between line level and phono input. The phono inputs for channel 2 are for turntable connection and the line inputs may be used for connecting tape decks, CD or MD player. This DJ mixer is equipped w/ dual phono RCA audio line in, 2 1/4" balanced TRS microphone in, and a USB flash drive reader. It also has a ¼" headphone jack.

Product description

Features: - Hassle-Free wireless microphone system - Multi-Source audio signal mixing ability - control audio levels from external devices - mixer receiver System for convenient sound level adjustment - Wireless BT music streaming Ability - dual fixed frequency system design - adjustable rotary controls: echo, tone, volume: mic 1, mic 2 - wired microphone support 1/4’’ mic inputs - 1/4’’ mic inputs - RCA Audio (L/R) & Video signal input/output jacks - rear panel 1/4’’ mixed output - adjustable antennas for extended wireless range - includes handheld wireless microphones - Rugged microphone construction & steel mesh grill - convenient on/off/mute power switch - Battery operated mic, requires 'AA' Batteries, included - ultra-wide frequency range - built-in acoustic pop filter - ideal for speech, karaoke, DJ sound & house party audio Bluetooth connectivity: - simple & Hassle-Free Pairing - Works with all of your favorite devices - (Smartphones, Tablets, Laptops, Computers, etc.) - Wireless BT network Name: 'PyleUSA' - Wireless BT version: 4.2 - Wireless BT range: 60’ ft What's in the box: - Audio mixer receiver - wall power adapter - 1/4’’ audio cable - 3.5mm to 2RCA audio cable - audio + video (3RCA) cables - handheld microphones - 'AA' Batteries technical specs: - UHF fixed frequency: S12: 517.6Mhz(f1) +521.5Mhz(f2); S34: 533.7Mhz(f3)+537.2Mhz(f4) - Wireless operation Range: up to 165’+ ft. - modulation Mode: FM - Maximum deviation: +/-75Khz - Frequency Response: 80-18khz (+/-3dB) - Frequency stability: 20Ppm - Audio dynamic range: >90dB - S/N ratio: >95dB - T.H.D: 50dB - line input sensitivity: 380mV/-8.5dB - mic input sensitivity: 5mV/-46dB - line input impedance: 20 KO - mic input impedance: 600O - receiver Power supply: 120/240V (18V/500mA Power adapter) - mic element: dynamic - Antenna: built-in Housing - RF output: <10mw - Spurious Emission: <-40dB - battery operated mic, requires 'AA' Batteries each - current Dissipation: <120mA - microphone Dimensions (L x D): 9.6’’ x 1.5’’ (each) - base receiver Dimensions (L x w x H): 8.3’’ x 4.4’’ x 1.7’’

• UHF NARROW BAND: The portable wireless mic set features UHF audio transmission for unsurpassed performance w/ high signal over noise ratio for clear, noise & distortion-free, crisp vocal & excellent sound reproduction unlike other low grades VHF unit
• BLUETOOTH-COMPATIBLE: The wireless handheld microphone has bluetooth streaming ability that works w/ latest devices. Additional features include multisource audio signal mixing ability, dual fixed frequency, EQ controls & built-in acoustic pop filter
• BATTERY OPERATED: The dual microphone features 2 AA battery-operated design while the receiver features a simple plug-in operation via a power adapter. Features independent channel volume control so you can balance the vocals as desired
• SUPPORTS WIRED MIC: The audio mixer receiver features 2 ¼” wired microphone inputs, RCA audio & video signal input/output & rear panel ¼” mixed output. The UHF wireless microphone is ideal for speech, karaoke, DJ sound, and house party audio
• COMPLETE SET: The wireless professional microphone comes w/ mixer receiver, 2 handheld transmitter mic, power adapter, ¼” audio cable, 3.5mm-2RCA audio cable, 2 audio + video 3RCA cables & 4 AA batteries. Can be used for home & business application
• Connector Type: 3.5 Mm Jack
• Power Source Type: Battery Powered

Product features

Portable UHF Wireless Microphone System

The Portable Receiver auto searches for the best channel for a reliable Performance and Distortion-Free sound and it also automatically syncs to the transmitter. Hands-free which makes it ideal for karaoke, video & voice recording, interviews, conference or stage presentation

UHF NARROW BAND

The portable wireless mic set features UHF audio transmission for unsurpassed performance w/ high signal over noise ratio for clear, noise & distortion-free, crisp vocal & excellent sound reproduction unlike other low grades VHF unit.

BLUETOOTH-COMPATIBLE

The wireless handheld microphone has bluetooth streaming ability that works w/ latest devices. Additional features include multisource audio signal mixing ability, dual fixed frequency, EQ controls & built-in acoustic pop filter

BATTERY OPERATED

The dual microphone features 2 AA battery-operated design while the receiver features a simple plug-in operation via a power adapter. Features independent channel volume control so you can balance the vocals as desired

SUPPORTS WIRED MIC

The audio mixer receiver features 2 ¼” wired microphone inputs, RCA audio & video signal input/output & rear panel ¼” mixed output. The UHF wireless microphone is ideal for speech, karaoke, DJ sound, and house party audio

Product description

Pyle model: pad15mxu3-ch recording USB mixer audio interface3-channel USB Audio/sound mixer recording interface with built-in rechargeable battery Features: flexible connectivity for a variety of external devicesultra-low noise design with high head room integrated sound card for computer recording support USB interface: connect to Mac/ PC built-in rechargeable battery smooth Rotary-Style faders for mic/USB/line/master controls extremely musical 2-band EQ & pan, on each channel combo microphone jack connector – XLR and 3.5Mmrca (L/R) stereo input and output Connector RCA (L/R) Input connectors voice echo effect/delay feature audio signal clip LED indicator lights input selection/ control buttons independent Channel + master volume controls independent Channel balance/high + low frequency adjustment used for beginner & professional sound applications Universal digital audio file compatibility in the box: mixer interface USB cable wall adapter technical specs: Phantom power: +18Vmic sensitivity: 1.3mV/1.7Kω(gain max)ch.1 sensitivity: 5mV/12kω(gain max)ch. 2/3 Sensitivity: 260mV/16kω2-tk: 300mV/22kωoutput level: 5.8V Max (main; monitor)frequency range: 20 -21000 hot.H.D.: ≤0.05%S/N ratio: 81Dbeq range: bass 15dB/80Hz, high 15dB/12Khzheadphone impedance: ≥16ωusb interface: SB 2.0, Windows 98SE+, Macc OS 9.Rechargeable battery: 3.7V Lithium Ion, 600Mahpower supply: USB, 5V/500Ma (type-b)dimensions (L x W x H): 3.97’’ x 5.31’’ x 1.77’’ - inches The Pyle channel USB Audio/sound mixer recording interface is like a portable recording studio. It's perfect for computer-based audio editing while adding fine-tune adjustments to your sound. The mono input channel allows you to connect a (phantom-powered) microphone. At the XLR jack, a Phantom power of +18V is always present. The stereo input channel allows you to connect an audio source with line signal level. In addition, the mixer is provided with connections for a recorder and Headphones. The mixed signal is sent to the output via RCA jacks and the USB port. It is also possible to use the USB port as an input to transfer audio data from the computer to the mixer. When connecting the mixer to a computer, power is supplied via the USB connection.

• Compact and versatile: this portable 3-Channel USB Audio/ sound mixer recording interface by Pyle is the perfect way to mix audio from multiple sources like a PC, iPhone, Android, laptop, gaming console, mic, guitar, and more At home or in studio
• Multiple connectivity: device includes microphone jack to connect mono signal such as XLR mic or 1/4" Line level to Ch1. Stereo input RCA jacks to connect CD/ MP3 player to channel Ch2/ 3, and RCA output for amplifier/ recorder
• Independent controls: Ch1 and Ch2/ 3 have independent level knobs to mix the input signals of Ch1 and line/USB or to fade in and out. Each channel also features pan controls for effects
• Usb interface and mix monitoring: This personal mixer has a USB port to connect to a power supply or a computer and use it as an audio output and input interface and a 3.5 mm jack for mix monitoring via headphones
• Rechargeable battery: This multi channel battery powered DJ music mixer system also features a built in 3.7V Lithium Ion, 600mAh rechargeable battery with a maximum operating time of 4 hours for audio mixing on the go

Product features

The Inputs

Each and every channel features a choice of powerful plug-ins and effects to dial in the perfect sound for whatever you’ve got plugged in.

Rechargeable Battery

This multi channel battery powered DJ music Mixer system also features a built in 3.7V Lithium Ion, 600mAh rechargeable battery with a maximum operating time of 4 hours for audio mixing on the go.

The Most Intuitive Control

You can customize the work surface for your specific application with view groups and access limiting to only show the controls you need. Powerful processing includes total control over all inputs and outputs, ensuring you can create a fantastic sounding mix easily.

USB Interface and Mix Monitoring

This personal mixer has a USB port to connect to a power supply or a computer and use it as an audio output and input interface and a 3.5 mm jack for mix monitoring via headphones.

3-Ch Recording USB Mixer Audio Interface

The Pyle 3-Channel USB Audio/Sound Mixer Recording Interface is like a portable recording studio. It's perfect for computer-based audio editing while adding fine-tune adjustments to your sound. The mono input channel allows you to connect a (phantom-powered) microphone. The stereo input channel allows you to connect an audio source with line signal level. In addition, the mixer is provided with connections for a recorder and headphones. The mixed signal is sent to the output via RCA jacks and the USB port. It is also possible to use the USB port as an input to transfer audio data from the computer to the mixer. When connecting the mixer to a computer, power is supplied via the USB connection.

Product description

Pyle Model : PDKWM802BU.5



Wireless Microphone & Bluetooth Receiver System, Audio Sound Mixer Receiver - Includes Handheld Mics, MP3/USB/SD Readers

Features:

• Multi-Source Audio Signal Mixing Ability
• Control Audio Levels from External Devices
• Mixer Receiver System for Convenient Sound Level Adjustment
• Bluetooth Wireless Music Streaming Ability
• Includes Handheld Wireless Microphones
• Dual Fixed Frequency System Design
• Adjustable Rotary Controls: Echo, Tone, Volume: Mic 1, Mic 2
• Front Panel Digital LCD Display
• USB Flash & SD Memory Card Readers
• Features Wired Microphone Support
• 1/4’’ -inch Mic Inputs
• RCA Audio (L/R) & Video Signal Input/Output Jacks
• Rear Panel 1/4’’ -inch Mixed Output
• Adjustable Antennas for Extended Wireless Range
• Rugged Microphone Construction & Steel Mesh Grill
• Convenient ON/OFF Power Switch
• Ultra-Wide Frequency Range
• Built-in Acoustic Pop Filter
• Ideal for Karaoke, DJ Sound & House Party Audio



  Bluetooth Wireless Connectivity:
• Simple & Hassle-Free Pairing
• Works with All of Your Favorite Devices
• (Smartphones, Tablets, Laptops, Computers, etc.
• Bluetooth Network Name: 'O2CABT'
• Bluetooth Version: 3.0
• Wireless BT Range: 35’ ft.



  What's in the Box:
• Audio Mixer Receiver
• Handheld Microphones
• 1/4’’ Audio Cable
• RCA (Audio/Video) Cables
• Wall Power Adapter
• 'AA' Batteries
• Remote Control



  Technical Specs:
• Microphone System: UHF Fixed Frequency
• Wireless Operation Range: Up to 165’+ ft.
• Mic Element: Dynamic
• Oscillation Mode: PLL
• Frequency Response: 80-20kHz (+/-3dB)
• T.H.D: <0.5%
• S/N Ratio: >90dB
• Spurious Emission: >40dB
• Maximum Deviation: +/-55Khz
• Audio Dynamic Range: >100dB
• LINE input sensitivity: 380mV/-8.5dB
• MIC input sensitivity: 5mV/-46dB
• LINE input impedance: 20KΩ
• MIC input impedance:50KΩ
• Digital Audio File Support: MP3
• Maximum USB/SD Card Support Size: Up to 32 GB
• Battery Operated Mic, Requires 'AA' Batteries Each
• Power: 110/220V (12V Power Adapter)
• Microphone Dimensions (L x D) 9.6’’ x 1.4’’-inches (Each)
• Base Receiver Dimensions (L x W x H): 9.4’’ x 6.3’’ x 1.7’’ -inches
•



  The Pyle Wireless Microphone & Bluetooth Receiver System, Audio Sound Mixer Receiver - Includes Handheld Mics, MP3/USB/SD Readers - Multi-Source Audio Signal Mixing Ability - Control Audio Levels from External Devices - Mixer Receiver System for Convenient Sound Level Adjustment - Bluetooth Wireless Music Streaming Ability - Includes Handheld Wireless Microphones - Dual Fixed Frequency System Design - Adjustable Rotary Controls: Echo, Tone, Volume: Mic 1, Mic 2 - Front Panel Digital LCD Display - USB Flash & SD Memory Card Readers - Features Wired Microphone Support - 1/4’’ -inch Mic Inputs - RCA Audio (L/R) & Video Signal Input/Output Jacks - Rear Panel 1/4’’ -inch Mixed Output - Adjustable Antennas for Extended Wireless Range - Rugged Microphone Construction & Steel Mesh Grill.

• HOME ENTERTAINMENT: Allows you to connect the RCA audio input jack to an audio source such as DVD player and the output jack to your TV and speaker w/ the included RCA AV cable for limitless ktv entertainment that both kids and adults can enjoy
• ADJUSTABLE LEVELS: This portable karaoke system by Pyle is equipped with rotary knob adjustment controls to easily adjust echo, tone, volume of your mics, music, and audio level from external devices to your desired level
• 2-MIC SETTINGS: The professional karaoke system supports up to 2 wired dynamic microphones and up to 2 wireless mics so you can choose from wireless/wired microphone depending on your preference. Two handheld mics w/ built-in pop filter are included
• WORKS WITH MANY DEVICES: It is compatible with computer, TV, iPad, Laptop, iPad, tablets, smartphone, speaker, DVD player, and amplifier. It also features an mp3 mode which lets you sing over songs playing in USB, SD card, and Bluetooth
• 165+ FT RANGE: This wireless microphone karaoke system features a UHF wireless operation range of up to 165’+ ft. Allows you to dance to the beat and entertain the crowd while singing with its adjustable antenna to extend wireless range

User questions & answers

Question:	Is there a manual for this. i lost mine and the pyle website download is corrupted
Answer:	Hi, please copy and paste the link below to your browser. Thank you https://www.dropbox.com/s/8hvsqtwqft2xlf6/PDKWM802BU.pdf?dl=0
Question:	What is wattage
Answer:	Hi, this unit doesn't have a wattage. You have to connect this unit to your amplifier. Thank you.
Question:	How many watts is this
Answer:	Hi, there's no wattage for this unit. You may check other details of the unit by visiting our website pyleaudio.com. Type the model number on the search box PDKWM802BU for more details. Thank you.

Product description

Pyle Model : PPHP28AMX

PA Speaker & Amplifier Mixer DJ Kit

Stage & Studio DJ Speaker & Mixer Bundle Kit - 8’’ Bluetooth PA Loud-Speakers, 8-Ch. Audio Mixer, Speaker Stands, Wired Microphone (300 Watt)

Features:

All-in-One DJ Audio Loud-Speaker Kit

8-Channel Powered Amplifier Audio Mixer

Dual Molded Cabinet PA Speakers

Sound System: 8’’ Speakers, 1’’ Tweeters

Bluetooth Wireless Music Streaming Ability

Active 2-Way, Full Range Stereo Sound

MP3 Digital Audio File Support

USB Flash & SD Memory Card Readers

+48V Phantom Power

XLR 3-Pin Connectors

1/4'' Microphone / Guitar Inputs

Independent Adjustable Channel Controls

Treble, Bass, Effect Volume Configuration

5-Band Graphic EQ

Digital Echo Effects Control

RCA (L/R) Audio Line Input/Output Jacks

Universal Speaker Stand Mount Support, 35mm

Rugged & Heavy-Duty Molded Cabinet Housing

Ability to Connect Additional Microphones, Instruments, DJ Equipment

Convenient System Design Assembles & Disassembles for Quick Setup

Perfect for On-Stage Performances, Crowd Control, Public Gathering Events

Bluetooth Wireless Streaming:

Instantly Receives Wireless Music Streaming Audio

Works with All of Your Favorite Devices

(iPhone, Android, Smartphones, iPad, Tablet, MP3 Player, etc.)

Bluetooth Version: 3.0

Bluetooth Network Name: 'PyleUSA’

Bluetooth Wireless Range: Up to 65'+ ft.

What's in the Box:

Amplifier Mixer Console

8’’ PA Speakers

Tripod Speaker Stands

1/4’’ Connection Cables

Wired Handheld Mic

Power Cable

Technical Specs:

Speaker Power Output: 300 Watt MAX

Tweeter Type: 1" Titanium Horn Driver (x2)

Subwoofer Type: 8’’ Long Throw (x2)

Subwoofer Frequency: 48Hz-4500Hz (±10dB)

Speaker Magnet: 30 oz (x2)

Impedance: 4 Ohm

Speaker Sensitivity: 90dB

Power Mixer Sensitivity: -14dB

S/N Ratio: 75dB

T.H.D.: 9.2%

Frequency Response: 48-18Khz (±10dB)

Maximum USB/SD Card Support: Up to 32GB

Digital Audio File Support: MP3, WMA, MP3Pro

+48V Phantom Power: ON/OFF

Power Supply: 100-240V, 60/50HZ

Single Speaker Dimensions (L x W x H): 11.22’’ x 9.84’’ x 17.72’’ -Inches (Each)

Amplifier Mixer Dimensions (L x W x H): 11.61’’ x 7.09’’ x 18.11’’-Inches

The Pyle Stage & Studio DJ Speaker & Mixer Bundle Kit - 8’’ Bluetooth PA Loud-Speakers, 8-Ch. Audio Mixer, Speaker Stands, Wired Microphone (300 Watt) - All-in-One DJ Audio Loud-Speaker Kit - 8-Channel Powered Amplifier Audio Mixer - Dual Molded Cabinet PA Speakers - Sound System: 8’’ Speakers, 1’’ Tweeters - Bluetooth Wireless Music Streaming Ability - Active 2-Way, Full Range Stereo Sound - MP3 Digital Audio File Support - USB Flash & SD Memory Card Readers - +48V Phantom Power - XLR 3-Pin Connectors - 1/4'' Microphone / Guitar Inputs - Independent Adjustable Channel Controls - Treble, Bass, Effect Volume Configuration - 5-Band Graphic EQ - Digital Echo Effects Control.

• 8 CHANNEL MIXER: This portable stage and studio PA speaker system and DJ mixer bundle by Pyle includes an 8 channel powered amplifier console audio mixer with digital LCD display which is perfect for mixing audio from multiple sources
• 300 WATT POWER: The dual heavy duty PA loudspeakers are equipped w/ 300 watt 8" full range subwoofer speaker and 1" tweeter for full range surround stereo sound reproduction. the box also includes universal speaker stand mount support for easy setup
• BLUETOOTH AUDIO STREAMING: The PA loud speaker set features bluetooth for wireless audio streaming and works with devices like iPhone, android mobile phone, iPad, tablet, PC. Ideal for personal indoor home and outdoor use
• 9 INPUTS: Aside from the Bluetooth connection the product also features a USB flash and SD memory card readers, XLR 3 pin connectors, 1/4" microphone / guitar inputs, and RCA (L/R) audio line input / output jacks
• BUNDLE INCLUSIONS: The bundle includes an amplifier mixer console, two 8" PA speakers and a wired handheld Mic. Two tripod speaker stands, two 1/4" connection cables, and power cable are also included in the package.

User questions & answers

Question:	My delivery date is still tbd but i ordered on prime. can you let me know when i will receive this. thanks
Answer:	Pretty quickly, just days, not weeks.
Question:	I already have an amplifier. Could I connect amplified signal to this unit
Answer:	Hi, you can connect the speaker to your amplifier as long as your amp can handle the wattage. Thank you.
Question:	Can I plug my guitar into it
Answer:	Yes but NO....it has a standard guitar port but they are NOT IN LINE with all the echoes and tone control....oh and it’s a Left or Right side only. They call this Channel 5 and 6! If you want you’re guitar to plug in so you have tone and echo control, (Channel 1-4) you’ll have to buy a three prong adapter that crosses over to guitar port. WATCH OUT THO, THESE LIKE TO CRACKLE AND BUZZ. Buy good ones!!! I bought this system thinking I could carry my guitar in one hand and this system in another and set up in no time. It sounds okay at best! I added a powered subwoofer. Now the hopes of carry in and out are no longer a reality. Voice sounds good, but guitar straight in doesn’t. Hince the sub I added. Your guitar will sound like one made out of a tin box! I hate that I bought this system! Go for a good one and pay a grand! You won’t regret it. Also the system gets hot and starts sounding worse. You have to turn it off when not playing. I thought I could Bluetooth to my phone when taking breaks from performing and letting some tunes play, nope, turn it off to cool down or sound like poo on the next set! This is no way close to a pro set up. If you are messing around in your home, sure. This will not last more than a few gigs and it got set up in my basement as a practice set.
Question:	does it have phantom power
Answer:	I believe it does Travis. I’ve packed it away now. Or is double check. But I’m sure I bought it with that in mind because of my microphones. Overall is a good wee system for the money. My only issue was it has echo but no reverb. But still decent. Served its purpose for me.

Product features

Features:

• All-in-One DJ Audio Loud-Speaker Kit
• 8-Channel Powered Amplifier Audio Mixer
• Dual Molded Cabinet PA Speakers
• Sound System: 8’’ Speakers 1’’ Tweeters
• Bluetooth Wireless Music Streaming Ability
• Active 2-Way Full Range Stereo Sound
• MP3 Digital Audio File Support
• USB Flash & SD Memory Card Readers
• +48V Phantom Power

Features:

• Treble Bass Effect Volume Configuration
• 5-Band Graphic EQ
• Digital Echo Effects Control
• RCA (L/R) Audio Line Input/Output Jacks
• Universal Speaker Stand Mount Support 35mm
• Rugged & Heavy-Duty Molded Cabinet Housing
• Ability to Connect Additional Microphones Instruments DJ Equipment
• Convenient System Design Assembles & Disassembles for Quick Setup
• Perfect for On-Stage Performances Crowd Control Public Gathering Events

Bluetooth Wireless Streaming:

• Instantly Receives Wireless Music Streaming Audio
• Works with All of Your Favorite Devices
• (iPhone Android Smartphones iPad Tablet MP3 Player etc.)
• Bluetooth Version: 3.0
• Bluetooth Network Name: 'PyleUSA’
• Bluetooth Wireless Range: Up to 65'+ ft.

What's in the Box:

• Amplifier Mixer Console
• 8’’ PA Speakers
• Tripod Speaker Stands
• 1/4’’ Connection Cables
• Wired Handheld Mic
• Power Cable
