13 best linear motion guide actuators

Linear motion guide actuators are essential components in various industrial applications, especially in the field of linear motion products and power transmission products. These devices are designed to provide precise linear motion and positioning control for machinery and equipment. They are commonly used in manufacturing, automation, robotics, and other industries where precise linear movement is required.

Key features and components of linear motion guide actuators include:

  1. Guide Rails: Linear motion guide actuators typically consist of two main components: a stationary rail and a moving carriage. The rail serves as a guide, providing a precise path for the carriage to move along.

  2. Carriage: The carriage is the moving part of the actuator that travels along the guide rail. It is usually equipped with bearings or rollers to reduce friction and ensure smooth motion.

  3. Ball Screw or Lead Screw: Linear actuators can use different mechanisms to convert rotary motion into linear motion. Ball screws and lead screws are common choices for this purpose. Ball screws incorporate ball bearings to reduce friction and improve efficiency.

  4. Drive Mechanism: To generate linear motion, linear motion guide actuators are equipped with a drive mechanism, which can include motors (such as stepper motors or servo motors) and other components like belts or gears.

  5. Control System: Actuators are often integrated with a control system that allows for precise positioning and movement control. This may involve feedback mechanisms, such as encoders or sensors, to ensure accuracy.

Advantages of linear motion guide actuators include:

  • Precision: Linear motion guide actuators offer high levels of precision and repeatability, making them suitable for applications where accuracy is crucial.

  • Versatility: They can be adapted for various loads, speeds, and stroke lengths, making them versatile for a wide range of applications.

  • Smooth Motion: With proper design and maintenance, these actuators can provide smooth and consistent linear motion.

  • Durability: Linear motion guide actuators are built to withstand harsh industrial environments and provide long service life.

Applications of linear motion guide actuators encompass a wide range of industries, including:

  1. CNC Machinery: Linear actuators are used in CNC (Computer Numerical Control) machines for accurate tool and workpiece positioning.

  2. Robotics: They play a crucial role in robot arms and other robotic systems to control the movement of robotic components.

  3. Semiconductor Manufacturing: Linear motion guide actuators are employed in semiconductor equipment for wafer handling and precision positioning.

  4. Packaging Machinery: These actuators help automate packaging processes by controlling the movement of packaging materials and products.

  5. Medical Devices: Linear motion guide actuators are used in medical equipment for tasks like patient positioning, X-ray table movement, and more.

  6. Material Handling: They are used in conveyors and material handling systems to transport goods with precision.

In summary, linear motion guide actuators are vital components in industrial and automation applications, providing precise and controlled linear motion. They are widely used across various industries due to their versatility and reliability in delivering accurate movement and positioning.

Below you can find our editor's choice of the best linear motion guide actuators on the market


ReliaBot 250mm MGN9 Linear Rail Guide with MGN9H Carriage Block for 3D Printer and CNC Machine

ReliaBot

Based on 22 reviews Check latest price

Product description

Packing list:

1 * 250mm MGN9 linear rail

1 * MGN9H carriage block

User questions & answers

Question: Do you have this MGN9 rail in 350mm
Answer: Hello, we will supply MGN9 rail in 350mm as soon as we can. Thanks for your support!
Question: What is the size of the steel balls? I need them to be 1.58mm and not 2.38mm. And do you have other rail length, such as 390mm
Answer: Hello, the balls in the block of MGN9 rail are 2.0mm. (2.38mm is the size of MGN12 block balls. ) We will ship 350mm 500mm 600mm MGN9 rails to Amazon warehouse as soon as we can.
Question: For the 600mm rail, i am calculating (29) holes at 20mm apart = 580mm. leaving 20mm for ends. is it: (7.5&12.5) or (10&10)mm center holes to the ends
Answer: Hello, it is (10&10)mm center holes to the ends.

FUYU FSL40 Linear Guide Slide Table Ball Screw Motion Rail CNC Linear Guide Stage Actuator Motorized Nema 23 Stepper Motor[200mm Stroke]

FUYU

Based on 3 reviews Check latest price
  • Special made nema 23 stepper motor with max speed up to 1200 rpm
  • Quality ball screw with accuracy up to ±0.03mm,also low noise when working
  • M4 screw on sideways to install end stop,and on base board for easy installnation
  • Oxided aluminum avoid rusting,extra support unit enhanced stability
  • have multi length stroke options from 50mm to 1000mm for cnc router device

User questions & answers

Question: What is the duty cycle for this motor? Can it be run continuously
Answer: yes, it could run continuously. and the motor is nema 23 stepper motor, that is 800RPM max. For more questions, please email me: mika at fuyuautomation.com
Question: what is the Diameter of the lead screw
Answer: The diameter is 16mm,screw pitch is 5mm. Sorry,this is ball screw,not lead screw,please confirm. How long stroke do need? Elina
Question: Can you provide documentation for the motor
Answer: yes, please contact me , so I could send you the spec of motor mika at fuyuautomation.com
Question: How can I mount to the motion slider? It says there are 8 holes but are the holes threaded? What size are the 8 holes
Answer: Dear Rallyboard, We added a fixing screw on the motion slider. If you want I can send you a photo which makes it clear. (my e-mail address is [email protected]) Size = M4 Best regards, Josine Comus International

Product features

FLS40 Linear Guide Specification

Effective Stroke: 200mm

Total Length: 399mm

Tatal Height: 80mm

Slide Width: 40mm

Maximum Horizontal Load: 25kg

Maximum Vertical Load: 15kg

Max Horizontal Speed: 150mm/s[max loading]

Max Vertical Speed: 88mm/s[max loading]

Ball Screw Model: G1610

Nema 23 Stepper Motor

Default Nema 23 stepper motor, provide sufficient power, accept customization Nema 17 , Nema 24 stepper motor and servo motor ,

Motion Slider

Aluminum alloy made motion slide, with blacken processing,6 holes on left side to install G1605 or G1610 ball screw, left and right side have 2 holes for each, totally have 8 holes for installnation carrying items on the top of slide

High Quality Ball Screw

We make high quality C7 G1610 ball screw as its default ballscrew; accept customization for ball screw model of G1605 when need. also accept other model ball screw

M4 Screws

On the back of linear guide have multi M4 screws, below 500 stroke linear guide, have 10 pieces of M4 screws, above 500mm stroke linear guide, insert 20 pieces of M4 screws

FLS40 Other Stroke Linear Guide

FLS40 G1610 Ballscrew Linear Guide with Nema23 Stepper Motor

ASIN: B07CYT75HZ 50mm stroke ASIN: B0784G4TYM 100mm stroke

ASIN: B077Q7QGF6 150mm stroke; ASIN: B078BQ6NBD 250mm stroke

ASIN: B077QLVRRB 300mm stroke; ASIN: B077QD96W1 350mm stroke

ASIN: B0784G53D4 400mm stroke; ASIN: B077QHNCS7 450mm stroke

ASIN: B077Q8LVLW 500mm stroke; ASIN: B0784FYLWV 600mm stroke

ASIN: B077QD97SW 700mm stroke; ASIN: B078BPZM1T 800mm stroke

ASIN: B077QHND39 900mm stroke; ASIN: B0784G58S7 1000mm stroke

Linear Rail 50mm / 100mm / 150mm/ 200mm Linear Stage Actuator with Square Linear Rails Mini Slide Table + NEMA 11 Stepper Motor for DIY CNC Router Milling Machine (100mm)

Based on 9 reviews Check latest price

Product description

Note:

1. Screw specifications T0601-100mm, the first two T6 represents the diameter of the screw 6 mm, the second two represents the screw guide (pitch) 1 mm, the last 100 mm represents the effective stroke of the slide.

2. this slider contains 28 linear motors by default.

3. it can fold horizontal cross, Longmen, three axis and four axis.




Features

Name: 28 step motor trapezoidal wire guide slide

Travel Length: 100mm

Screw specification: T6*1

( We also have Screw specification T6*2 , T6*4 , T6*6 , T6*12 , if you need , please send us a message )

Screw precision: 0.1mm

Fastest speed: 40mm/s

Maximum load level: 3KG

Vertical maximum load: 1KG

Material: Aluminum alloy and stainless steel

Voltage: 24V

Motor current: 0.6A

Torque: 0.07NM

Step angle: 1.8 degrees

Motor size: 28*28*30mm



Package Included

1 x T0601-100 Stroke slide table (including motor)

  • 100mm ( 4 inch ) Length Travel Linear Stage Work Table with NEMA 11 Stepper Motor;
  • Maximum load level: 3 KG , Vertical maximum load: 1 KG ;
  • With high precision, high efficiency, long life, low coefficient of friction, versatility, etc;
  • Made of high quality Aluminum alloy and stainless steel;
  • Screw Specification: T6*1. ( We also have Screw specification T6*2 , T6*4 , T6*6 , T6*12 , if you need change , please send us a message )

User questions & answers

Question: What happens if you try to run the motor when the platform is already at one end? Is there a way to read out platform position
Answer: The moter will stall and you will skip steps and loose position. If you crash at high speed it may bind sufficiently that you will need to back it off by hand. It is open loop. There is no encoder. You will need to track position yourself. Use a good homing switch, because my software allowed it I also have end of travel switches now installed. There is significant (for me) backlash in the system so position is reliable in one direction only and the addition of a moter encoder would not be of much assistance here in tracking position.
Question: Number of wires on the motor
Answer: 4
Question: Can be this item sold with no stepper motor? I need to put a wheel instead
Answer: I have ordered and used 4 sets of this linear stage. All came with stepper motors attached to the frame using 4 screws. There are other types with just the frame. Not sure if this one has an option without actuator installed. You can unscrew/detach the actuator and add extension shaft/wheel to the end.
Question: Is the slide table supposed move/wiggle at all? I bought 4, one is very tight and doesnt move at all, 3 can wiggle slightly when I move them
Answer: I bought four, and they all wiggle slightly. The screw of one of them appears to be off-center compared to the shaft of the stepper motor. You can see that the shaft moves up and down as it rotates but this did not create a problem for me. Overall, I was happy with the quality of this product for the price that I paid for it.

FUYU FSL40 Linear Guide Slide Table Ball Screw Motion Rail CNC Linear Guide Stage Actuator Motorized Nema 23 Stepper Motor[1000mm Stroke]

FUYU

Based on 7 reviews Check latest price

Product description

Effective Stroke: 1000mm

Total Length:
1199mm

Tatal Height:
80mm

Slide Width: 40mm

Maximum Horizontal Load:
20kg

Maximum Vertical Load:
10kg

Max Horizontal Speed:
230mm/s[max loadings]

Max Vertical Speed:
50mm/s[max loadings]

Ball Screw Model:
G1610

Ball Screw Accuracy Class:
C7

Stepper Motor Parameter:

Step angle:
1.8°

Rated Voltage: 1.7v

Motor flange size:
57mm

Motor length:
56mm

Holding torque:
0.95 N.m

Current:
2.0A

Resistance:
1.32Ω

FLS40 Series G1610 Ballscrew Linear Guide with Nema23 Stepper Motor

ASIN: B07CYT75HZ 50mm stroke

ASIN: B0784G4TYM 100mm stroke

ASIN: B077Q7QGF6 150mm stroke

ASIN: B077Q8T6Y3 200mm stroke

ASIN: B078BQ6NBD 250mm stroke

ASIN: B077QLVRRB 300mm stroke

ASIN: B077QD96W1 350mm stroke

ASIN: B0784G53D4 400mm stroke

ASIN: B077QHNCS7 450mm stroke

ASIN: B077Q8LVLW 500mm stroke

ASIN: B0784FYLWV 600mm stroke

ASIN: B077QD97SW 700mm stroke

ASIN: B078BPZM1T 800mm stroke

ASIN: B077QHND39 900mm stroke

ASIN: B0784G58S7 1000mm stroke

Please contact us when you need suggestions on choose this kind of item

  • Special made nema 23 stepper motor with max speed up to 1200 rpm
  • Quality ball screw with accuracy up to ±0.03mm,also low noise when working
  • M4 screw on sideways to install end stop,and on base board for easy installnation
  • Oxided aluminum avoid rusting,extra support unit enhanced stability
  • have multi length stroke options from 50mm to 1000mm linear guide for cnc router device

User questions & answers

Question: Where can i get cad drawings for the fsl40 travel lengths of 150mm and 500mm
Answer: The cad drawings for the hardware was on the Amazon page. The stroke length is in the part number.
Question: Is the stepper motor's speed fully programmable in both directions
Answer: yes, it could be programmed
Question: When will the 1000mm be available
Answer: I'm pretty sure I own a few. Look again.
Question: My stepper motor is not working. It is super tight and we have to move it with a wrench? Is there any way to reduce the stiffness of the stepper motor
Answer: Try disconnecting the power. Steppers should be hard to turn with the coils powered. If you are talking power off, then it sounds like yours is broken. I can spin mine easily.

FUYU FSL40 Linear Guide Slide Table Ball Screw Motion Rail CNC Linear Guide Stage Actuator Motorized Nema 23 Stepper Motor[700mm Stroke]

FUYU

Based on 1 reviews Check latest price

Product description

Effective Stroke: 700mm

Total Length:
899mm

Tatal Height:
80mm

Slide Width: 40mm

Maximum Horizontal Load:
20kg

Maximum Vertical Load:
10kg

Max Horizontal Speed:
230mm/s[max loadings]

Max Vertical Speed:
50mm/s[max loadings]

Ball Screw Model:
G1610

Ball Screw Accuracy Class:
C7

Stepper Motor Parameter:

Step angle:
1.8°

Rated Voltage: 1.7v

Motor flange size:
57mm

Motor length:
56mm

Holding torque:
0.95 N.m

Current:
2.0A

Resistance:
1.32Ω

FLS40 Series G1610 Ballscrew Linear Guide with Nema23 Stepper Motor

ASIN: B07CYT75HZ 50mm stroke

ASIN: B0784G4TYM 100mm stroke

ASIN: B077Q7QGF6 150mm stroke

ASIN: B077Q8T6Y3 200mm stroke

ASIN: B078BQ6NBD 250mm stroke

ASIN: B077QLVRRB 300mm stroke

ASIN: B077QD96W1 350mm stroke

ASIN: B0784G53D4 400mm stroke

ASIN: B077QHNCS7 450mm stroke

ASIN: B077Q8LVLW 500mm stroke

ASIN: B0784FYLWV 600mm stroke

ASIN: B077QD97SW 700mm stroke

ASIN: B078BPZM1T 800mm stroke

ASIN: B077QHND39 900mm stroke

ASIN: B0784G58S7 1000mm stroke

Please contact us when you need suggestions on choose this kind of item

  • Special made nema 23 stepper motor with max speed up to 1200 rpm
  • Quality ball screw with accuracy up to ±0.03mm,also low noise when working
  • M4 screw on sideways to install end stop,and on base board for easy installnation
  • Oxided aluminum avoid rusting,extra support unit enhanced stability
  • have multi length stroke options from 50mm to 1000mm for cnc router device

User questions & answers

Question: Is this stepper motor bipolar or unipolar? If unipolar, 5 wires or 6 wires
Answer: yes, it's bipolar that is 4 wires
Question: What is the black block made of
Answer: It’s aluminium ingot
Question: In the above diagram you imply that everything is ready to go with the slider. What would I need to write some python code from a Linux laptop
Answer: Hi,this product is just like the picture, that is with only the stepper motor. to make it work, you also need a stepper driver, a controller and maybe a dc power supply. For linux, it's related with controller.

CNC Linear Motion Rail Guide 200mm Stroke Ball Screw Linear Stage Actuator with Dust Cover for Nema23 Stepper Motor Z Axis CNC Router

Heechoo

Based on 19 reviews Check latest price

Product description

Package Included

1 x linear rail slider

1 x Nema23 motor base(not include motor)

1 x 10 to 8mm Coupling

If your motor shaft is not 8mm, please contact us and I will replace the coupling for you.



Parameters

1.Work slide table: 60*120mm .Front panel height :89mm, rear plate height: 61mm.

2.Professional screw support is installed before and after to improve the linear actuator's high life and accuracy

3. Metal dust cover integrated design, perfect fit, effectively prevent 80% of chip erosion rail screw

4. Overall horizontal maximum load: 50kg, vertical installation maximum load: 20kg.Maximum running speed: 50mm/s

5. Ball screw type: 1605 (diameter 16mm, lead 5mm . Each revolution of the motor, the slider moves 5mm)

6. Ball screw accuracy: C7,Repeat positioning accuracy: ± 0.03mm

7. Material: Aviation Aluminum 6061,sandblasted on the surface

8. Can be equipped with electric: 57 stepper motor, servo motor (customer needs different flexible configuration)



If you need to buy limit switches,Please search:B082FFNH5P

40% discount when purchased with a linear screw slide



We have 3D drawings and CAD drawings.Can help you verify your design project in advance

If you have any questions, please feel free to contact me for an after-sales engineer. email: [email protected]

  • linear motion actuator with dust cover,It can reduce the pollution of the processing rod to the screw and improve the overall service life.
  • Quality ball screw(16mm,Pitch 5mm) with accuracy up to ±0.03mm,also low noise when working.
  • Linear guide rail Stork:100mm/4" 200mm/8" 300mm/12" 400mm/16" 500mm/20” 600mm/24” free for users to choose.
  • Standard aluminum alloy profile structure, sandblasted on the surface, beautiful and rustproof, precision hole position CNC processing.
  • Convenient and Easy in use, Smooth operation, can be directly fold X axis/Y axis/X axis

User questions & answers

Question: what spindle holders are compatible with this z-axis
Answer: This model recommended to install a 60mm diameter spindle.Need to process a gantry plate, please contact to obtain design documents or CAD-3D files. If you need to install a larger spindle,Recommended choice B07T89X1N9
Question: Is this compatible with shapeoko xxl
Answer: Hi,We can provide product CAD drawings and technical parameters, you need to check it yourself, we have not used shapeoko xxl. Recommended that you use 3D software for model analysis
Question: What is the maximum travel on each of the sizes
Answer: The maximum travel on each of the sizes =The Stroke long. When you choose 200mm size,the maximum travel=200mm; When you choose 300mm size,the maximum travel=300mm. For detailed dimensions and 3D files, you can contact our after-sales mailbox ([email protected]) to obtain.
Question: what is the height of this unit from the bottom face to the mounting surface of the slide table
Answer: Dear customers, The height of this unit from the bottom face to the mounting surface is 63mm,For more sizes, please contact us for standard CAD drawings and 3D files.

FUYU FSL40 Linear Guide Slide Table Ball Screw Motion Rail CNC Linear Guide Stage Actuator Motorized Nema 23 Stepper Motor[150mm Stroke]

FUYU

Based on 3 reviews Check latest price
  • Special made nema 23 stepper motor with max speed up to 1200 rpm
  • Quality ball screw with accuracy up to ±0.03mm,also low noise when working
  • M4 screw on sideways to install end stop,and on base board for easy installnation
  • Oxided aluminum avoid rusting,extra support unit enhanced stability
  • have multi length stroke options from 50mm to 1000mm linear guide for cnc device

Product features

FLS40 Linear Guide Specification

Effective Stroke: 150mm

Total Length: 349mm

Tatal Height: 80mm

Slide Width: 40mm

Maximum Horizontal Load: 25kg

Maximum Vertical Load: 15kg

Max Horizontal Speed: 150mm/s[max loading]

Max Vertical Speed: 88mm/s[max loading]

Ball Screw Model: G1610

Nema 23 Stepper Motor

Default Nema 23 stepper motor, provide sufficient power, accept customization Nema 17 , Nema 24 stepper motor and servo motor ,

Motion Slider

Aluminum alloy made motion slide, with blacken processing,6 holes on left side to install G1605 or G1610 ball screw, left and right side have 2 holes for each, totally have 8 holes for installnation carrying items on the top of slide

High Quality Ball Screw

We make high quality C7 G1610 ball screw as its default ballscrew; accept customization for ball screw model of G1605 when need. also accept other model ball screw

M4 Screws

On the back of linear guide have multi M4 screws, below 500 stroke linear guide, have 10 pieces of M4 screws, above 500mm stroke linear guide, insert 20 pieces of M4 screws

FLS40 Other Stroke Linear Guide

FLS40 G1610 Ballscrew Linear Guide with Nema23 Stepper Motor

ASIN: B07CYT75HZ 50mm stroke ASIN: B0784G4TYM 100mm stroke

ASIN: B077Q8T6Y3 200mm stroke; ASIN: B078BQ6NBD 250mm stroke

ASIN: B077QLVRRB 300mm stroke; ASIN: B077QD96W1 350mm stroke

ASIN: B0784G53D4 400mm stroke; ASIN: B077QHNCS7 450mm stroke

ASIN: B077Q8LVLW 500mm stroke: ASIN: B0784FYLWV 600mm stroke

ASIN: B077QD97SW 700mm stroke; ASIN: B078BPZM1T 800mm stroke

ASIN: B077QHND39 900mm stroke; ASIN: B0784G58S7 1000mm stroke

FUYU FSL40 Linear Guide Slide Table Ball Screw Motion Rail CNC Linear Guide Stage Actuator Motorized Nema 23 Stepper Motor[400mm Stroke]

FUYU

Based on 3 reviews Check latest price

Product description

Effective Stroke: 400mm

Total Length:
599mm

Tatal Height:
80mm

Slide Width:
40mm

Maximum Horizontal Load:
25kg

Maximum Vertical Load:
15kg

Max Horizontal Speed:
150mm/s[max loading]

Max Vertical Speed:
88mm/s[max loading]

Ball Screw Model:
G1610

Ball Screw Accuracy Class:
C7

Stepper Motor Parameter:

Rated Voltage:
1.7v

Step angle:
1.8°

Motor flange size:
57mm

Motor length:
56mm

Holding torque:
0.95 N.m

Current:
2.0A

Resistance:
1.32Ω

FLS40 Series G1610 Ballscrew Linear Guide with Nema23 Stepper Motor

ASIN: B07CYT75HZ 50mm stroke

ASIN: B0784G4TYM 100mm stroke

ASIN: B077Q7QGF6 150mm stroke

ASIN: B077Q8T6Y3 200mm stroke

ASIN: B078BQ6NBD 250mm stroke

ASIN: B077QLVRRB 300mm stroke

ASIN: B077QD96W1 350mm stroke

ASIN: B0784G53D4 400mm stroke

ASIN: B077QHNCS7 450mm stroke

ASIN: B077Q8LVLW 500mm stroke

ASIN: B0784FYLWV 600mm stroke

ASIN: B077QD97SW 700mm stroke

ASIN: B078BPZM1T 800mm stroke

ASIN: B077QHND39 900mm stroke

ASIN: B0784G58S7 1000mm stroke

Please contact us when you need suggestions on choose this kind of item

  • Special made nema 23 stepper motor with max speed up to 1200 rpm
  • Quality ball screw with accuracy up to ±0.03mm,also low noise when working
  • M4 screw on sideways to install end stop,and on base board for easy installnation
  • Oxided aluminum avoid rusting,extra support unit enhanced stability
  • have multi length stroke options from 50mm to 1000mm for cnc router device

User questions & answers

Question: How stable is the table? looking to use this as a cnc press brake backstop. is there any wiggle in the table? will this work with a gecko g
Answer: it's very stable if you mount it in good. please contact me directly to send you the motor drawing. mika at fuyuautomation.com
Question: What is the stroke size in regards to
Answer: Hi, The travel length is 50~1000mm. Any other questions, please contact me. mika at fuyuautomation.com
Question: What kind of power supply will I need
Answer: hi dear, you will need the dc power supply that could transfer 110~220V AC to be 24V DC to match your stepper driver. any other questions, contact me. mika at fuyuautomation.com Regards, Mika
Question: Looking for a 1000 mm linear rail ball screw 12 volt stepper motor
Answer: sorry that we don't have 12V step motor. But we could provide the linear without motor. You could attach your own 12v stepper motor

ZooTek DC12V 4inch Stroke Linear Actuator 225LB/900N Maximum Lift for Electroic, Medical, with Mounting Brackets

ZT Factory

Product description



Specification:



Color: Silver



Material: Aluminum Alloy



Input Voltage: DC 12V



Rated Current: 3Amp



Stroke length = 100mm(4")



Retracted length = 205mm(8.2");



Extended Length= 305mm(12.2")



Rated Load: 900N



Travel Speed: 10mm/s



Limit Switch: Built-in



Working Temperature: -20ºC to 65ºC



Protection Class: IP54



Duty Circle: 25%



Noise Level: <50dB



How To Install



1. Prepare to connect the two wires of the actuator to a 12 volt battery.



2.Blue wire to the positive terminal and grey wire to negative terminal will make the actuator extend. To make it retract, just reverse the terminal connections.



3.To simplify the last step, you can prepare a reverse polarity relay or switch for the actuator. When you want the actuator to extend and retract, just press the switch.



4. Your actuator will hold its position when the power is off. It will automatically stop when reaches the end.



5.The actuator has pre-installed inner limit switch, it cannot be adjustable.



How to protect your actuator:



1. Please use the 12V DC power adapter.



2. Please do not exceed the rated load.



3. All the actuators have duty cycle, they are unable to work all the time without stop. The duty cycle of this actuator is 20%. it means that your actuator needs 4 minutes to rest for every 1 minute of work. If the actuator keeps working for long time, the motor is easily burnt out.



4. Please be careful, the actuator not completely waterproof .



What you will get



1 X 4" Linear Actuator



2 X Mounting Bracket



1 X Screw Set



  • 4 inch stroke length, 8 inch(205mm) retracted length, 12 inch(305mm) extended length
  • Material: High quality aluminum alloy material, sturdy enough and with fashion look, High performance motor ,Built-in high quality limit switch
  • Low noise as designed: level under 50dB, it has been carefully considered for the ears of your family and neighbours.
  • Easy install: linear actuator solutions are able to fit in almost any industrial machine or piece of automated machinery. Easy to install and integrate into most control systems, like Arduino, control boxes or any other Microcontroller kit.
  • Widely used: In DIY pet feeder,Marine,Automotive, Medical Devices and Engineering Industry, massage sofa, recliner, TV lifter, lifting table, electric window opener etc.

ZooTek DC12V 6inch Stroke Linear Actuator 225LB/900N Maximum Lift for Recliner TV Table Lift Massage Bed Electric Sofa with Mounting Brackets

ZT Factory

Based on 1 reviews Check latest price

Product description



Specification:



Stroke length = 150mm(6inch)



Rated Load: 1000N (225lbs)



Rated voltage:12V



Rated current:3Amp



Max Travel Speed: 0.47inch/sec (12mm/s)



Limit Switch: Built-in



Wire: 35.4inch(90cm) 18awg cooper wire



Working Temperature: -20ºC to 65ºC / (-14.8ºF to 149ºF)



Duty Circle: 25%



Sound:low-noise(under 50dB)



Protection Class: IP65



How To Install



1.Prepare a 12 volt battery,connect and test,linear actuator's wire doesn't distinguish positive or neigative







2.The actuator will hold its position when the power is off. It will automatically stop when hit the limit.



3.The actuator has pre-installed inner limit switch, it cannot be adjustable.



4.The package comes with mounting brackets.



How to protect your actuator:



1. Please use the 12V DC power adapter



2. Please do not exceed the rated load



3. All the actuators have duty cycle, they are unable to work all the time without stop. The duty cycle of this actuator is 20%. it means that your actuator needs 4 minutes to rest for every 1 minute of work. If the actuator keeps working for long time, the motor is easily burnt out.



4. Please be careful, the actuator not completely waterproof



Package Included:



1 X6" Linear Actuator



2 X Mounting Bracket



1 X Screw Set



  • Specification-Stroke length = 150mm(6"); Retracted length = 260mm(10.4"); Extended Length= 410mm(16.4"); Travel speed = 0.39 inches/sec (10 mm/s);Maximum current draw = 3Amps; Maximum Load = 225lbs(900N).
  • Material: High quality aluminum alloy material, sturdy enough and with fashion look, High performance motor ,Built-in high quality limit switch
  • Low noise as designed: level under 50dB, it has been carefully considered for the ears of your family and neighbours.
  • Widely used: In chicken coop door,solar tracker system,Marine,Automotive, Medical Devices and Engineering Industry, massage sofa, recliner, TV lifter, lifting table,etc.
  • Package Included: 1pc 12V 6 Inch Linear Actuator with 2pcs mounting brackets.

FUYU FSL40 Linear Guide Rail Slide Ball Screw Motion Table CNC Linear Guide Stage Actuator Motorized Nema 23 Stepper Motor[50mm Stroke]

FUYU

Based on 3 reviews Check latest price
  • Special made nema 23 stepper motor with max speed up to 1200 rpm
  • Quality ball screw with accuracy up to ±0.03mm,also low noise when working
  • M4 screw on sideways to install end stop,and on base board for easy installnation
  • Oxided aluminum avoid rusting,extra support unit enhanced stability
  • have multi length stroke options from 50mm to 1000mm linear guide for cnc device

User questions & answers

Question: Does it work ttwith tb6600 4a 9-42v motor river? do you have a code? i plan to use arduino uno r3 as controller board
Answer: The matched is 2-phase nema 23 stepper motor, if your driver could be ok with it, then it's availbale.

Product features

FLS40 Linear Guide Specification

Effective Stroke: 50mm

Total Length: 249mm

Tatal Height: 80mm

Slide Width: 40mm

Maximum Horizontal Load: 25kg

Maximum Vertical Load: 15kg

Max Horizontal Speed: 150mm/s[max loading]

Max Vertical Speed: 88mm/s[max loading]

Ball Screw Model: G1610

Nema 23 Stepper Motor

Default Nema 23 stepper motor, provide sufficient power, accept customization Nema 17 , Nema 24 stepper motor and servo motor ,

Motion Slider

Aluminum alloy made motion slide, with blacken processing,6 holes on left side to install G1605 or G1610 ball screw, left and right side have 2 holes for each, totally have 8 holes for installnation carrying items on the top of slide

High Quality Ball Screw

We make high quality C7 G1610 ball screw as its default ballscrew; accept customization for ball screw model of G1605 when need. also accept other model ball screw

M4 Screws

On the back of linear guide have multi M4 screws, below 500 stroke linear guide, have 10 pieces of M4 screws, above 500mm stroke linear guide, insert 20 pieces of M4 screws

FLS40 Other Stroke Linear Guide

FLS40 G1610 Ballscrew Linear Guide with Nema23 Stepper Motor

ASIN: B0784G4TYM 100mm stroke; ASIN: B077Q7QGF6 150mm stroke

ASIN: B077Q8T6Y3 200mm stroke; ASIN: B078BQ6NBD 250mm stroke

ASIN: B077QLVRRB 300mm stroke; ASIN: B077QD96W1 350mm stroke

ASIN: B0784G53D4 400mm stroke; ASIN: B077QHNCS7 450mm stroke

ASIN: B077Q8LVLW 500mm stroke; ASIN: B0784FYLWV 600mm stroke

ASIN: B077QD97SW 700mm stroke; ASIN: B078BPZM1T 800mm stroke

ASIN: B077QHND39 900mm stroke; ASIN: B0784G58S7 1000mm stroke

Mini Electric Linear Actuator Stroke 2"–Force 4.5 lbs–12V | High-Speed 0.6"/sec–Weight 0.15KG Ideal for Intelligent Range Hood, Fan Blades, Cabinets, Window Opener, Robotics, Home Automation

ECO LLC

Based on 57 reviews Check latest price

Product description

ECO LLC --- 10 years experience in Linear Actuator production. Expert in providing all kinds of linear actuator.Mainly serve customers in the fields of medical equipment, financial equipment, construction machinery, etc.



Product features



✦Specification:Stroke length = 2 inches (50mm);Travel Speed: 0.6in/sec(15mm/sec); Retracted length = 60mm(2.4"); Extended Length= 132mm(5.2"); Maximum Load = 4.5lbs(20N);Inner Tube: Stainless Steel Tube;Input Voltage: 12VDC;Temperature: 0-50 degrees Celsius.

✦Advantage:Our Linear Actuator with Linear Reciprocating Motor and Durable Stroke Ideal for Intelligent Range Hood, Fan Blades, Cabinets, Window Opener, Robotics, Home Automation.

✦Feel Stop: Stop at Any Position,With Automatic Machine Lock, It will Automatically Stop When It Reaches the Top.

✦Safe and Worry-Free: Overcurrent Protection, Short Circuit Protection, Overload Protection, Overvoltage Protection.

✦1 Year product warranty,any problems about the product please feel free to contact us.

  • ✦Specification:Stroke length = 2 inches (50mm);Travel Speed: 0.6in/sec(15mm/sec); Retracted length = 142mm(5.59"); Extended Length= 190mm(7.5");Maximum Load = 4.5lbs(20N);Inner Tube: Stainless Steel Tube;Input Voltage: 12VDC;Temperature: 0-50 degrees Celsius.
  • ✦Advantage:Our Linear Actuator with Linear Reciprocating Motor and Durable Stroke Ideal for Intelligent Range Hood, Fan Blades, Cabinets, Window Opener, Robotics, Home Automation.
  • ✦Feel Stop: Stop at Any Position,With Automatic Machine Lock, It will Automatically Stop When It Reaches the Top.
  • ✦Safe and Worry-Free: Overcurrent Protection, Short Circuit Protection, Overload Protection, Overvoltage Protection.
  • ✦1 Year product warranty,any problems about the product please feel free to contact us.

User questions & answers

Question: amps drawn please
Answer: Depends entirely in the load. You can pull down the datasheet as a PDF from the Net. Max current as I recall is 500 milliamps approx at extreme load, but mine often operate under 50 milliamps.
Question: I want to hook this up to an hbridge, how many amps does this pull when in use
Answer: I’m not sure I run it off of a 7.2 volt battery pack with an esc
Question: Is there a spec sheet avaliable? I need to model this for a project
Answer: Nothing came with unit No paperwork
Question: Can anyone provide the datasheet for this? I've searched all part numbers and I'm not coming up with anything
Answer: Please see the second picture or contact the customer service request manual, thank you

High Speed 700 MM 28 INCH Stroke Belt Drive Linear Guide Rail Motion Slide Actuator Module for CNC Linear Position Kit

Heechoo

Based on 5 reviews Check latest price

Product description

Parameters

Aluminum Profile (wide* high): 45x45 mm;

Mounting screws: 6*M5;

Material: Aviation Aluminum 6061,sandblasted on the surface;

Slider specification: 95.5*75mm;

Right angle / twist: ≦0.1mm/300mm;

Precision: 0.1mm;

Torque: 0~15N.M;

speed: 0~1500mm/s;

Bearing capacity: 300N;

Synchronous wheel model: HTD3M ;

Timing belt specifications: Polyurethane steel wire HTD3M, width 15MM;

Timing belt number: 24 teeth;

Can be equipped with electric: 57 stepper motor, servo motor (Default with NEMA 23 motor).

Factory direct sales, accept custom orders, delivery time 1-2 weeks.



Application

Used in CNC machining, laser machining, 3D printing, robot automation, CNC milling machines, DIY, etc.



We have 3D drawings and CAD drawings,Please contact us by email: [email protected]



Package Included

1 x slider table

1 x Nema23 Motor bracket(without motor)

1 x Coupling(8 to 12 mm)

2 x foot mounting bracket

  • High precision belt driven linear actuator, the positioning repeatability is ± 0.1mm;
  • Convenient and Easy in use, Smooth operation and low noise,maximum speed 1500mm/s
  • Comes with NEMA 23 motor base(not motor) and foot mounting bracket, free to replace;
  • Standard aluminum alloy profile structure, sandblasted on the surface, beautiful and rustproof, precision hole position CNC processing;
  • Can be directly fold cross slide, gantry sliding table, 3-axis, 4-axis, multi-axis combination in use.

User questions & answers

Question: What motor and gearbox should be used to move a 50lb (20kg) load on the sled
Answer: Hi For to move a 20kg load,The carrying capacity of a single set of equipment is insufficient, and two units are required to be used in combination. You can contact us by email([email protected]) to provide you with a combination plan. It is recommended to use 4.5Nm stepper motor.
Question: It says in the title 1500mm 40inch stroke, but is it 1500mm 60 inches
Answer: Yes,1500MM is 60 inches,We will modify it.
Question: Do you have any faster shipping options
Answer: The Models with a stroke more than 900mm(Like 1000/1100/1200/1300/1400/1500 mm stroke),no faster shipping options. Because it is long and needs to be shipped via FedEx,Shipping to the US takes 7-10 days.
Question: how is this controlled for photography
Answer: This product can be used for photography.Operate by adding a stepper motor and drive controller.

Latest Reviews

View all
