12 best handheld digital multimeters
Handheld digital multimeters, often referred to simply as multimeters, are versatile electronic test tools used by professionals and hobbyists in various fields, including electrical engineering, electronics repair, automotive diagnostics, and home improvement. These devices are designed to measure multiple electrical parameters accurately and are essential for troubleshooting, testing, and maintaining electrical and electronic systems. Here's what you need to know about handheld digital multimeters:
Basic Functionality:
Voltage Measurement: Multimeters can measure direct current (DC) voltage and alternating current (AC) voltage, making them suitable for assessing electrical circuits and power sources.
Current Measurement: They can measure both DC and AC current, allowing users to check the flow of electricity through wires and components.
Resistance Measurement: Multimeters can measure resistance (ohms) in electronic components like resistors and conductors.
Additional Functions and Features:
Continuity Testing: Multimeters often include a continuity mode that produces an audible beep when a circuit is closed (low resistance). This is useful for identifying broken wires or loose connections.
Diode Testing: Multimeters can check the functionality of diodes and semiconductors.
Capacitance Measurement: Some advanced multimeters can measure capacitance, which is useful for assessing capacitors in electronic circuits.
Frequency Measurement: Certain models can measure the frequency of AC signals, making them handy for working with oscillators and AC power sources.
Temperature Measurement: Some multimeters come with a temperature probe or input, allowing users to measure temperature in both Celsius and Fahrenheit.
Data Hold and Recording: Many digital multimeters have a "Hold" function that freezes the display, allowing users to record measurements in situations where it's challenging to read the display while taking the reading.
Display:
- Multimeters typically have a digital LCD display that shows numerical values for the measured parameters. The display may also indicate the unit of measurement.
Safety Features:
Multimeters are designed with safety in mind and often include features like overload protection, fused inputs, and input jacks that are color-coded for different measurement types.
The inclusion of safety-rated measurement categories (CAT I, CAT II, CAT III, CAT IV) on the device helps users choose the appropriate multimeter for specific applications.
Power Source:
- Most handheld digital multimeters are powered by batteries, commonly 9-volt batteries or AA/AAA batteries.
Auto-Ranging vs. Manual-Ranging:
- Some multimeters have auto-ranging capabilities, which means they automatically select the appropriate measurement range. Others require users to manually set the range.
Applications:
- Multimeters are widely used in a variety of fields, including electrical troubleshooting, electronics repair, automotive diagnostics, HVAC maintenance, and more.
Accessories:
- Many multimeters come with probes and leads for making measurements, and they may also include a protective carrying case for easy transport and storage.
Price Range:
- Multimeters are available at various price points, with basic models suitable for occasional use and more advanced models offering greater accuracy and functionality for professionals.
In summary, handheld digital multimeters are indispensable tools for electrical and electronics professionals, hobbyists, and DIY enthusiasts.They provide precise measurements of voltage, current, resistance, and other electrical parameters, making them essential for diagnosing and maintaining electrical systems, circuits, and electronic devices.
Below you can find our editor's choice of the best handheld digital multimeters on the marketProduct description
DC voltage: 200mV—2-20-200-600V±0.5%
AC voltage: 200V-600V±1.0%
DC current: 200u-2m-20m-200m-10A ±1.8%
Resistance: 200-2k-20k-200k--2MΩ±1.0%
Maximum display: 1999
Power Supply: 9V Battery(6F22) (include)
Product weight: 240g(Batteries included)
Product size: 14cm×7cm×3.4cm
Screen size: 4.6cm×1.9cm
For more specifications and using instructions, please check out the user manual.
This device includes diode, transistor, On-off measurement, data hold, and backlight.
Note:
To avoid electrical shock, remove test leads before opening case, please read the manual carefully for safety.
It is prohibited from being used close to any explosive gas, vapor or dust.
Package Includes:
1 x Digital Multimeter
1 Pair Test Leads
1 x User's Manual
1×9V 6F22 battery ( installed)
1 x Box
- High accuracy and wide range: Accurately measure the data, DC current, DC voltage, resistance, AC voltage, transistor, diode on-off test, audible continuity test, and temperature measurement. meet your need!
- Ideal for safety and convenience: Removable plastic protective insulation cover and overload protection on all ranges for safety. Built-in kickstand for hand free use, enhance convenience.
- Backlight included: Just push to button to turn on the backlight. Showing the reading clearly even in dark areas. No need to worry about dark environment or carrying a flashlight.
- Low voltage symbol display: Show necessary data clearer, making it more convenient for you to use.
- Digital LED screen: Shows fast readout for electrical measurements. Data hold button to hold the readout data.
User questions & answers
Question: | Will this check the specific amount of AC voltage to my doorbell from the doorbell transformer |
Answer: | 83 |
Question: | Does it measure inductance |
Answer: | First let's define enclosed. If enclosed means air tight sealed and waterproof then no, do not use these bulbs. Otherwise, yes, these bulbs are fine. |
Product description
Features:
Used to measure AC/DC voltage and current, resistance, frequency, diode, triode, continuity and logic level.
Clear LCD display, easy to read the measuring results.
Designed with a bracket on the back.
Wide measuring range and high precision.
With sleep mode and data hold function.
Specification:
Measuring Range:
DC Voltage: 200mV-1000V, ±(0.5%+1dgt)
AC voltage: 20V-750V, ±(0.8%+3dgt)
DC current: 20mA-20A, ±(0.8%+1dgt)
AC current: 200mA-20A, ±(1.8%+3dgt)
Resistance: 200Ω-200MΩ, ±(0.8%+1dgt)
Capacitance: 2nF-20μF, ±(2.5%+3dgt)
Frequency: 2KHz-20KHz, ±(1.5%+5dgt)
Measurement Type:
Diode : Yes
Triode : Yes
Continuity test: Yes
Temperature test: Yes
Logic level test: Yew
Sleep mode: Yes
Data hold: Yes
Maximum display: 1999
Power supply: 6F22 9V battery (NOT included)
Color: Blue, Red, Yellow (Optional)
Note:
Please allow 1-3cm (0.4-1.18") difference due to manual measurement and slight color variation for different display setting.
Thank you for your understanding, nice day!
Package Including
1 x Multimeter (Battery not included)
1 x Protective Cove
1 x Pairs of Test Probes
1 x User Manual
- Clear LCD display, easy to read the measuring results.
- Wide measuring range and high precision.
- With sleep mode and data hold function.
- Designed with a bracket on the back.
- Used to measure AC/DC voltage and current, resistance, frequency, diode, triode, continuity and logic level.
Product description
Applications:
1. Electrical switchboards 2. HVAC systems 3. Electrical circuit faults detection 4. Installation or maintenance of electronics/factory equipment 5. Electronics component development, circuit board design 6. Users who need to distinguish between neutral/live wire frequently Specifications:
DC Voltage: 600mV/6V/60V/600V/1000V, ±(0.5%+2)
AC Voltage: 6V/60V/600V/750V, ±(0.8%+3)
ACV Frequency: 10Hz~10kHz, ±(0.1%+5)
DC Current: 60uA//600uA/6mA/60mA/600mA/20A, ±(0.8%+8)
AC Current: 60uA/600uA/6mA/60mA/600mA/20A, ±(1%+12)
Resistance: 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ, ±(0.8%+3)
Capacitor:6.000nF/60.00nF/600.0nF/6.000μF/60.00μF/600.0μF/6.000mF/60.00mF/100.0mF,±(3%+10)
Frequency: 9.999Hz~9.999MHz, ±(1.0%+5)
Temperature: –40℃~1000℃/–40°F~1832°F, ±(1.5%+5)
Features: Display Count: 6000
Manual Range: Yes
NCV: Yes
hFE: Yes
Diode Test: Yes
Continuity Test: Yes
True RMS: Yes
Fuse blowing alarm: Yes
Acousto-optic indication(NCV/continuity): Yes
High voltage false detection1000Vrms: Yes
Current (AC/DC) mode memory: Yes
Over-current alarm≥20A: Yes
Low Battery Indication: ≤2.5V
Data Hold: Yes
REL: Yes
Max/Min: V 、A
Auto Power Off: 15Min
Back light: 30s
Operation Temperature: 0℃~40℃
Safety: CAT Ⅱ 1000V/CAT III 600V
General Characteristics:
Power: 1.5V x 2
Product color: Red and Gray
Product Net Weight: 346g
Product Size: 183mm x 88mm x 56mm
Package includes:
1 x UT890C Multimeter
1 x Test leads
1 x Temperature probe
1 x Manual
- 【High Accurately Pen Type Digital Multimeter】Voltage Tester accurately measures AC Voltage:2V~600V,DC Voltage:200mV~600V, Resistance Tester from 200Ω~60MΩ,Diode test and Continuity Buzzer.
- 【Multifunction Pen Multimeter】Humanized design with 2000 Counts,Diode Test,Continuity,Data Hold,Auto Range Control,Auto Power Off & Low Battery Indication,Back Light and Lamp Light Function.
- 【Over-range Indication】AP-38B Pen Type Multimeter support Double insulation (Class II protection),600V (CAT Ⅲ),This pen type digital multimeter is characterized at slim size, portable and stable performance,a good tool of electrical tester and household electrical problems.
- 【Auto Power Off】When measurement exceeds 15 minutes without switching mode and pressing key, the meter will switch to standby mode. Press any key to exit standby mode. And you can also press and hold "SELECT "key to choose the mode of resistance, diode or continuity test and AC/DC Voltage that you like.
- 【100% After-Sales Guarantee】1* English Manual & 2*1.5V Battery are included,AOPUTTRIVER come with 2 years warranty and lifetime technical support,if you have any questions with our product,pls feel free to contact us!we will respond to you ASAP.
User questions & answers
Question: | Puede medir capacitores |
Answer: | Yes. Does that and more. Good inexpensive product. |
Product features
AP-38B Pen Multimeter for AC/DC Voltage Resistance Diode
Humanized design with 2000 Counts, Diode Test, Data Hold, Continuity Buzzer, Auto Range Control, Low Battery Indication, Back Light and Lamp Light Function.
portable and stable performance, a good tool of electrical tester and household electrical problems.
Measure Range:
- DC Voltage Test: 200mV/2V/20V/200V/600V
- AC Voltage Test: 2V/20V/200V/600V
- Resistance Test: 200/2K/20K/200K/2M/20M Ohms
High Accuracy Pen Multi-tester
Voltage Tester accurately measures AC volt 2V ~ 600V, DC volt from 200mV ~ 600V, resistance from 200 ohm ~ 20M ohm, continuity buzzer test.
2 Protective Caps
This multimeter come with 2 protective caps, which can protect the safe of you and protect the pen multimeter when you are not use it.
Flashlight Multimeter
With bright screen back light,12mm tall digits and front LED flash light makes it easy and clear to read even in dark.
Replacement Battery
When the battery are running out, you need use a key to rotate the battery compartment, then pull out the battery cover, and replacement the new battery in.
Product description
Testing Specifications for YF-838L Digital Multimeter:
- Display: 3½ digit LCD.Max display:2000 counts
- DC Current:2mA、20mA、200mA、10A(+/- 1%+ 10)
- AC Voltage:200V、600V(+/- 1.2%+ 20)
- DC Voltage:200mV、2V、20V、200V、600V(+/- 0.5%+ 10)
- Resistance:200、2K、20K、200K、2Mオーム(+/- 0.8%+ 20)
- Temperature:-20℃〜-1000℃、-4℉〜1832℉(+/- 1.2%+ 5)
Measuring Function for YF-838L Volt tester:
- Data Hold - Press [HOLD] button to keep the data on the screen for recording.
- Transistor Test - Can be measured without a test lead.
- Backlight - Suitable for a variety of work environment.
- Continuity - Built-in buzzer will sound if resistance is less than 90 ohm.
- Low Battery Voltage Indication
- Overload Protection
- Diode Test
Package Included:
- 1* YF-838L Digital Multimeter
- 1*Screwdriver
- 1*Thermocouple Probe
- 1*Test Lead
- 1*9V(6F22) battery
- 1*Instruction Manual
Add to Cart➤Buy with Confidence➤Infurider will provide lifetime technical support, if you have any questions with our products. Do not hesitate to contact us:[email protected]
- ✔【Pro Hobbyist DMM】Display with 2000 counts,Volt meter can accurate measure AC/DC voltage,DC amperage,ohm,resistance,temperature,diode,continuity,NPN PNP transistor hFE.
- ✔【Overload Protection 】Built-in IEC-1010 & CATIII 600V over-voltage protection.Compact and high precision electrical tester for troubleshoot a variety of automotive and household electrical problem.
- ✔【Multi-Function Voltmeter】Comes with quick response continuity test with Alarm, diode test, transistor testing,Backlight, Data Hold, Low battery indication.K type thermocouple included.
- ✔【Humanized Design】 With rubber protective case for anti-drop protection.Removable the ABS protective insulation cover to exchange battery.Built-in kickstand for hand free use,enhance convenience.
- ✔【Buy with Confidence】Infurider provide lifetime technical support, if you have any questions with our products. Do not hesitate to contact us! we will respond to you within 24 hours.
- Aenllosi Hard Case for Fluke 101/106/107 Handheld Digital Multimeter
- Features: Case is made of supreme quality, durable EVA, crush resistant, anti-shock, water resistant material provides adequate protection from bumps, scratches and splashes
- With Internal mesh pocket can store other accessories at your convenience
- Internal size: 4*6.5*2.5 inch, external size:3*6*2.5 inch, weight:200g.
- For sale is case only, device and accessories are not included.
User questions & answers
Question: | Would this fit the 179 model |
Answer: | Mine measures 6’’x 3” inside. Each half shell is 1” deep, so 2 inches when closed. |
Question: | Will this fit the Fluke 101+ along with the magnetic stand and test leads |
Answer: | The case is described as being for the 101/106/107 models, so I would say it will fit the 106. |
Question: | What are internal dimensions? It seems the advertising dimensions are reversed and not correct |
Answer: | No,it can not. |
Question: | Is this case suitable for my Fluke 106? After all, these models have different sizes |
Answer: | I believe it would register the specific amount of voltage. |
Product description
Why do you choose us:
✔High-tech chip
LIUMY LM2020 emphasis on functional combination for field testing process, not to replace the meter. It reflects the high-tech, using a dedicated chip has, as the wave function, you can view the waveform signal 1MHZ within.
✔Extensive detection function and range
Features include DC/AC voltage /current, resistance, capacitance, frequency, diode / continuity test. Can be home, school, power plant, work area has excellent performance!
✔Save money
As a large number of measuring instruments waveform, you will find LM2001 is the most affordable one, spend the price of a multimeter, you can have a table can be seen, as the wave of the waveform, value for money!
Specification:
Analog Bandwidth: 0~ 1MHz
The maximum real-time sampling rate: 2.5 Msps
DC voltage: 0mV ~ 1000V ± (1.5% rdg + 10dgt)
AC voltage: 0 mv ~ 750V ± (1.0% rdg + 10dgt)
DC Current: 0mA ~ 10.00A ± (1.2% rdg + 10dgt)
AC current: 0mA ~ 10.00A ± (1.5% rdg + 10dgt)
Resistance: 0W ~ 40MΩ ± (3.0% rdg + 5dgt)
Capacitance: 0nF ~ 100.0μF ± (3% rdg + 10dgt)
Frequency: 0kHz ~ 5MHz ± (1.0% rdg + 5dgt)
Diode test: open circuit voltage of about 1.5 V, judgement resistance about 50MΩ.
Continuity Test: determine resistance: about 30
Fuse specification: 500mA/250V, 10A/250V
Display: 240 * 320 LCD Color Screen
Input resistance: About 10MΩ
Working current: About 65mA
Sleep current: About 35μA
Usage time: More than 10 hours
Battery: 3 AA battery (included)
Storage capacity: DMM 100 groups of data, waveform 10 group records
Dimensions: 83mm * 160 mm * 32mm
Weight: 180g
Backlight: Constantly on
Auto shutdown: 15 minutes or disabled
Package included:
1 x LM2020 Oscilloscope Multimeter
2 x Test Lead
1 x Portable Bag
1 x English User Manual
3 x AA battery
- ▼FASTER SAMPLING SPEED - 2.5Mpsp high-speed A/D data collecting, high sampling rate and high bandwidth, one-key transform to waveform function furing measuring.3 waveform scanning modes: automatic/conventional/single. Improve work efficiency.
- ▼MORE POWERFUL DETECTION RANGE -DC voltage 0 ~ 1000V, AC voltage 0 ~ 750V, DC/AC Current 0 ~ 10A, Resistance 0 ~ 40MΩ, Capacitance 0 ~ 100μf, Frequency 0 ~ 5MHZ, Diode / Continuity open circuit voltage 1.5V, judgement resistance 50Ω. Transistor amplification test to meet all test requirements.
- ▼MORE ACCURACY -Dedicated Chip, the automatic waveform capture function, easy operation. The software calibration technology, memory calibration coefficients. Measure more accurately.
- ▼LED BACKLIGHT & STORAGE / READOUT - Analog broadband range up to: D AC ~ 1MHz, Display hold, storage / readout up to 10 waveforms and 100 sets of measurement values. 240X320 color screen with LED backlighting. More clear and suitable for working at night.
- ▼OVERLOAD PROTECTION & MULTI-PURPOSE - Built-in 500mA/10A double protective tube, dual protection of the instrument. Can choose to automatically shutdown or continuous operation, applicable to the workplace such as family, school, and factory. DISTORTION DETECTION ALSO Protect safety.
User questions & answers
Question: | Does anyone know if there is a way to disable the beep sound every time a button is pressed? I did not see anything about this in the manual |
Answer: | That depends on your doctor if you’re in pain management. My doctor had a cutoff of 10ng/ml. I was using hemp oil and failed. |
- Storing 100 sets of data and 10 waveforms independently. Capable of holding waveform and data during measurement, easy to view and analyze. Displaying historical data and real-time measurement on the same screen with particular record reading mode for easy comparison.
- Digital multimeter with 200K high-speed A/D sampling, 4000 counts auto-range, one-button switch of graphical waveform display during measurement. High reliability with panel calibration technology and memory calibration, sparing the need for adjustment with potentiometer.
- Analog broadband range up to: D AC ~ 10kHz, Display hold, storage / readout up to 5 waveforms and 100 sets of measurement values. 128X64 high contrast LCD with LED backlighting. Suitable for working at night. DETECTION ALSO Protect safety.convenient for small capacitors to measure quickly.
- DC voltage 0 ~ 1000V, AC voltage 0 ~ 750V, DC/AC Current 0 ~ 20A, Resistance 0 ~ 20MΩ, Capacitance 0 ~ 20μf, Frequency 0 ~ 200KHZ, Diode / Continuity Test, Remote control test。 AC voltage bandwidth up to 20KHz. Innovative design for the one-key silent mode, quiet in mastery. Extending battery life with automatic shutdown function.
- Built-in 500V/20A explosion proof fuse, 20A AC and DC test. 0mf gear position: high capacitance and high accuracy are guaranteed. Realizing one-button automatic waveform capture, operator-friendly to learn and operate. Effectively eliminating lead resistance, distributed capacitance or interference signals with relative value measurement (clearing).
Product features
Oscilloscope Multimeter 2-in-1
Built-in 500V/20A explosion proof fuse, 20A AC and DC test. 0mf gear position: high capacitance and high accuracy are guaranteed. Realizing one-button automatic waveform capture, operator-friendly to learn and operate. Effectively eliminating lead resistance, distributed capacitance or interference signals with relative value measurement (clearing).
Multimeter
Digital multimeter with 200K high-speed A/D sampling, 4000 counts auto-range, one-button switch of graphical waveform display during measurement. High reliability with panel calibration technology and memory calibration, sparing the need for adjustment with potentiometer.
DC voltage 0 ~ 1000V, AC voltage 0 ~ 750V, DC/AC Current 0 ~ 20A, Resistance 0 ~ 20MΩ, Capacitance 0 ~ 20μf, Frequency 0 ~ 200KHZ, Diode / Continuity Test, Remote control test. AC voltage bandwidth up to 20KHz. Innovative design for the one-key silent mode, quiet in mastery. Extending battery life with automatic shutdown function.
Oscilloscope
Storing 100 sets of data and 10 waveforms independently. Capable of holding waveform and data during measurement, easy to view and analyze. Displaying historical data and real-time measurement on the same screen with particular record reading mode for easy comparison.
Analog broadband range up to: D AC ~ 10kHz, Display hold, storage / readout up to 5 waveforms and 100 sets of measurement values. 128X64 high contrast LCD with LED backlighting. Suitable for working at night. DETECTION ALSO Protect safety.convenient for small capacitors to measure quickly.
- 【2 IN 1 COLOR SCREEN OSCILLOSCOPE】 Handheld Oscilloscope Function & Digital Multimeter Function, Digital Multimeter functions integrated multifunctional handheld instrument, ideal for field use.
- 【DIGITAL OSCILLOSCOPE MAIN FUNCTION】 2-channel ,25MHz digital storage oscilloscope,6000 words True RMS, True 6000 words RMS digital multimeter, 100MSa / s real-time sampling rate, 25MHz real-time bandwidth.
- 【HANDHELD OSCILLOSCOPE MATERIAL AND LANGAUGE SWITCH】ABS on the outside(such as BNC connector. With some metal for connection on the inside.Chinese got it back to English, step is Power on - menu - F4 - F2
- 【EQUIPED WITH OSCILLOSCOPE & DMM FUNCTION】Equiped with oscilloscope function and DMM function. Oscilloscope--- automatically capture waveform, read out, waveform display processing, single & dual cursor measurements, scanning and recorder function.
- 【STANDARD USB INTERFACE】Through the PC software can easily communicate with a computer for data analysis and test results archive, through the USB interface and the computer connection, transmission, you can analyze and print data from the oscilloscope.
User questions & answers
Question: | Does it have signal generator function |
Answer: | Power on - menu - F4 - F2 |
Question: | How do you do the probe compensation using the scope it's a EM |
Answer: | Hi Yes, of course. All parameters can be transferred to the computer, stored in the computer |
Question: | I got it stuck on chinese language and can't get it back to english, can someone list exact steps? i've followed the book and no option for english |
Answer: | I’m not sure but I think that the 179 is larger then the case. Carlos |
Question: | Can the resistance and voltage readings of the dmm be acquired thru the usb |
Answer: | Yes https://www.amazon.com/gp/aw/review/B07J5H5SWF/R2Y0JE7Y1VXVQ5?ref=pf_vv_at_pdctrvw_srp |
Product description
Specifications:
●Model:DSO1062B●Bandwidth:60MHz
●Channel:2
●Real-Sample Rate:1GSa/s
●Equivalent Sample Rate:25GSa/s
●Record Length:1M
●Rish time:≤1.7ns/≤3.5ns/≤5.8ns
●Timebase Accuracy:±50ppm
●Time Base Range:2ns/div-40s/div / 4ns/div-40s/div / 4ns/div-40s/div
●Input Impandance:1MΩ
●VOLTS/DIV Range:2mV/div~5V/div
●A/D Converter:8bit
●Position Range:±50V(5V/div), ±40V(2V/div~500mV/div), ±2V(200mV/div~50mV/div), ±400mV(20mV/div~2mV/div)
●DC Gain Accuracy:
±3% for Normal or Average acquisition mode, 5V/div to 10mV/div;
±4% for Normal or Average acquisition mode, 5mV/div to 2mV/div
●Bandwidth Limit:20MHz
●Trigger Types:Edge, Video, Pulse, Slope, Over time, Alternative
●Trigger Source:CH1, CH2
●Math:+,-,x,÷,FFT, Invert
●Cursor Measurement:
Voltage difference between cursors: △V;
Time difference between cursors: △T;
Reciprocal of △T in Hertz (1/ΔT);
●Auto Measuerment:Frequency, Period, Mean, Pk-Pk, Cycli RMS, Minimum, Maximum, Rise time, Fall Time, +Pulse Width, -Pulse Width, Delay1-2Rise, Delay1-2Fall, +Duty, -Duty, Vbase, Vtop, Vmid, Vamp, Overshoot, Preshoot, Preiod Mean, Preiod RMS, FOVShoot, RPREShoot, BWIDTH, FRF, FFR, LRR, LRF, LFR, LFF
●DMM Max. Resolution:6,000 Counts
●Testing Modes:Voltage, Current, Resistance, Capacitance, Diode & Continuity
●Max. Input Voltage:AC: 600V, DC: 800V
●Max. Input Current:AC:10A , DC: 10A
●Max. Input Impandance:10MΩ
●Display:5.6"TFT 16K Color Display, 640*480 dots
●Size:245mm x 163mm x 52mm
●Weight:1.3KG(Without Package)
●Standard Probe:PP80x2
- The lead time is about 3-4 business days, Fedex/DHL shipping time to USA is 5-7 days.
- If any questions, please contact us first.
User questions & answers
Question: | does the hantek dso1062b come with abuilt in function wave form generator |
Answer: | yes |
Question: | Does it run on batteries or mains power only |
Answer: | It seems to have a rechargeable battery built in to it. You just plug in the ac adapter to charge it. It will run from the internal battery or while plugged in to the adapter. |
Question: | Hello, the product includes the internal battery |
Answer: | Sorry, it has NOT signal generator function, this is 2 in 1 Handheld Digital Storage Oscilloscope Digital Multimeter. |
Question: | under technical details , it states that batteries are not included. Which is it |
Answer: | Low Frequency compensation adjustment. Low frequency response can be matched to the oscilloscope by adjusting the compensation frimmer on the head of the probe. Contect the probe to the oscilloscope and to a 1KHz square waveform source.For X1X10 probes,switch to the X10 position. Set the oscilloscope to display two to three cycles and two to six vertical divisions.Carefully adjust the firmmer tool to obtain the flattest tops to the square waves displayed on this oscilloscope |
Product description
The Fluke 107 digital multimeter is made to fit the way you work It is designed to fit in the palm of your hand and go with you no matter where your job takes you. Fluke 107 Palms sized Digital Mustimeter with Frequency, Diode Test Leads, and 2 AAA Batteries (Installed) User's Manual Smart Strap.
- Voltage, resistance, continuity, capacitance
- Input terminal for AC and DC current measurements to 10 A and current
- Backlit display
- Data hold
- Diode test, plus frequency and duty cycle measurements
User questions & answers
Question: | Is this a low impedance meter |
Answer: | Yes this is a low Z meter |
Question: | What size case do you need for the Fluke 107 meter |
Answer: | Fluke soft case C-01 will fit the Fluke 101,106 and 107 meters and TL75 test leads. It's a snug fit and comes with a belt loop for easy carry around the job site. If you want a larger soft case with extra room for accessories get the C115 case. I have both and they work very well. |
Question: | Does this come as a unit alone, or does this include test leads and the magnetic stand |
Answer: | The Fluke 107 comes with Fluke TL75 test leads and a magnetic stand called a "Smart Strap". |
Question: | Does this come with a bag (soft case) to carry it around |
Answer: | no sir, no soft case |
Product features
Fluke 107 Palm-sized Digital Multimeter
The Fluke 107 is a compact, easy to use tool. It is a palm-sized digital multimeter that delivers safe, reliable measurements time after time.
The Fluke 107 is a great product made to fit the way you work! It is the only Fluke digital multimeter designed to fit in the palm of your hand and go with you no matter where your job takes you.
Product description
ANNMETER AN-38A Pen Type Multimeter featured the easy operation of one button, large LCD display with backlight. Accurate AC/DC Voltage Measurement, Resistance, Continuity Test and Phase Rotation Test are supported.
Function Overview:
◆ Auto Power Off: √
◆ Double-pole test: √
◆ Phase Rotation Test: √
◆ Auto ranging 7-690V: √
◆ Backlight & Lamp light: √
◆ Resistance, continuity Test: √
◆ Continuity Warning Buzzer: √
◆ AC/DC Voltage Measurement: √
Specification:
- IP Grade: IP64
- Resolution: 1V
- Accuracy:±(3%+3)
- Weight: 0.67 Pound
- Dimension: 9.88x3x1.1''
- Test Current: Approx. 1.5μA
- Phase Range: 120±5 degree
- Voltage Range: 50-690V AC/DC
- LCD Voltage Range: 12-690V AC/DC
- LED Voltage Range: 12-690V AC/DC
- Power System: 3-phase 4-wire system AC
- Continuity Detection Range: 0-550kΩ (±200k)
Package included:
- 2* 1.5V Battery
- 1* User Manual
- 1* AN-38A Pen Type Multi-meter
- ▶ [Simple & Easy Use] AN-38A One push button operation, auto power on and automatically and goes into a self-diagnostic test make it easy to use instrument for AC/DC Voltage Testing. Auto Ranging with High Accuracy ±(3%+3) 5V.
- ▶[Smart & Versatile] Digital Multimeter judges the measurement parameters automatically and support auto range. Comes with Auto Data Hold of the DC/AC voltage detection. Support AC/DC voltage(7-690V), Resistance, Continuity Test (0-550kΩ) and Phase Rotation Test.
- ▶[Large LCD Display] The large display shows all necessary data on one screen allows you to read clearly. The LCD display is clear to read at night since the Backlight and flashlight design, simply press more than 2s to turn on the backlight and short press for flashlight.
- ▶ [IP64 Dust and Waterproof Rating] IP64 grade of the Voltage Tester makes it durable for the need of HVAC and Electrical work, meanwhile prolong the service life of the product.
- ▶ [Portable Size Voltmeter ] Portable design makes it easy to carry, the small size is convenient for putting it in your pocket. This Pen-type Multimeter is ideal for the purpose of HVAC, Electrical work, or home use.
Latest Reviews
View all
Sse Digital Slr Camera
- Updated: 28.01.2023
- Read reviews

Curling Iron With Glove Hairs
- Updated: 13.07.2023
- Read reviews

Beard Growths
- Updated: 20.04.2023
- Read reviews

English Language Instruction
- Updated: 02.01.2023
- Read reviews

Panasonic Electric Showers
- Updated: 25.07.2023
- Read reviews
