12 best eco worthy solar panels

Product description

Specification

Rated power: 100W

Voc: 21.6V

Vop: 17.3V

Short circuit current (Isc): 6.13A

Working current (Iop): 5.78A

Output Tolerance: ±3%

Temperate coefficient of Isc: (010+/- 0.01) %/℃

Temperate coefficient of Voc: - (0.38 +/-0.01) %/℃

Temperate coefficient of power Voc: -0.47%/℃

Temperature range: -40℃to +80℃

Frame: Heavy duty aluminum

Kind of connection: waterproof junction box, can be customized

Guarantee of power: 90% within 10 years 80% within 25 years

Kind of glass and its thickness: Low Iron, high transparency tempered glass of 3.2mm

SLA Battery Voltage: 12V

Size: 39.8*20.1*1.4 inch



Package included:

1pc 100W Mono PV Solar Panel with Connectors.

• [ Size ] - 39.8*20.1*1.4inch (1010*510*35mm). Daily output 500wh depends on the sunlight availability.
• [ Use ] - Basic generator component for 12V/24V battery charging for on-grid, off-grid and hybrid power system for home,garden,RV,Boat and agriculture.
• [ Durable ] - Withstand high wind (2400Pa) and snow loads (5400Pa), the surface is made up of 3.2mm low Iron glass, the monocrystalline modules are framed by 35mm width aluminum alloy, which is 2~5mm wider than the others'.
• [ Feature ] - Each solar panel comes with a pair of 35 inches cables. By-pass diodes are pre-installed in waterproof IP-65 rated junction box to minimize power drop caused by shade and ensure excellent performance in low-light environments.
• [ Easy to Install ] - Plug & play designed Connector in the cables for quick installation and pre-drilled holes on the back of the panel allow for fast mounting it on the roof or bracket.

User questions & answers

Question:	Please reply. i have. now a 100w panel produci g only 68% on sun peak time 5w when no sun how much will your produce
Answer:	Yes it is compatible
Question:	I'm looking for a solar panel with a female 12v adapter to charge a power pack i already own. Will this model work
Answer:	I am afraid the charge controller you received is dumb, pls get back to our support team, will ship you one BRAND NEW replacement as we promsied. You can find the contacts in the USER MANUAL. or sent email to [email protected]
Question:	Can this item really produce 100watts or close to 100watts? What is the max charge this item can produce
Answer:	No, lead acid batteries only!!
Question:	On Amazon this item is listed with two completely different dimensions. What is its actual size
Answer:	3m/9.8FT

Product features

100W Solar Panel

• Maximum Power: 100W
• Open Circuit Voltage (Voc): 21.6V
• Max Power Voltage (Vpm): 17.3V
• Short Circuit Current (Isc): 6.17A
• Working Current (Iop): 5.78A
• Output Tolerance: ±3%
• Charge Voltage: 12V
• Maximum System Voltage: 1000V DC
• Temperature Range： -40℃ to +80℃(-40°F to +176°F)
• J-Box IP Rating: IP65

Easy Installation

Durable

Reliable

Widely Use

Product description

Warm Tips

Please check your solar panel size before purchasing

About mounting total solar panel width is 107 inches

Installation angle: 30°degree Solar Panel length size max. is 55 inches.

25°degree Solar Panel length size max. length is 65 inches.

18°degree Solar Panel length size max. is 89 inches

Widely Use

You can put battery, controller, inverter at backside of the mounting system. It can save lots of room and use solar power system easier.

Add concrete/pole can make a solar power store house to in store things and use free solar power energy Package Includes

7.84 inches C T-type Steel*2pcs

19.68 inches C T-type Steel*2pcs

39.37 inches C T-type Steel*2pcs

12.79 inches C T-type Steel*2pcs

57.08 inches C T-type Steel*4pcs

Connecting Bolt*4pcs

Edge Pressure*4pcs

Base*4pcs

Universal Joint*4pcs

Middle Pressure*6pcs

Inscribed Bolt*8pcs

Short Bolts*8pcs

End Cap*8pcs

Expansion Screw*8pcs

Long Bolts*12pcs

• ECO-WORTHY Multi-Panels Mount has the capability to fit 1-4pcs different size ECO-WORTHY panels or other brands standard panels
• Galvanized Steel construction, sturdy and durable. Three-legged structure make mounting steady. You can put battery, controller, inverter at backside of the mounting system. It can save lots of room and use solar power system easier.
• It’s ideal for larger installations, such as ground, flat roof, cabins and backyard sheds.Anywhere roof mounting is not a possibility, this solar panel mount can be applied
• Adjustable angle from 18° to 30° Degree, right angle for best solar power. Fixed on ground resistant wind and rain, well protect solar panel and easy to clean
• The Multi-Panel Mount is compatible with the ECO-WORTHY 100 Watts monocrystalline, and 120 Watts monocrystalline and 195 Watts solar panels.

User questions & answers

Question:	Can I install panels that are 67.3 x 39.1 x 1.57 in? Thanks
Answer:	you can add them as long as you don't go over the inverter limit. For the batteries just string them for charge
Question:	Can this system support 79.06"x39.45"x1.57" panel weight 51.81lbs? if so how many pieces
Answer:	Hello, the plug of the inverter is an American universal plug, can be used for American equipment.
Question:	What is the width of the base that is flush against the roof? I have a trapezoidal metal roof and want to ensure it can fit between the 3 inch gaps
Answer:	Hello, you just need to ground the inverter.
Question:	This mount can hold a hurricane winds? and can install it on a concrete flat roof
Answer:	The seller makes this very confusing in the description. Our order arrived with a battery cable with two ring terminals for the (+) and (-) side of the battery. It's about 10 feet long with Chinese only writing on the jacket with no indication of gauge. However, since you need to wire up the two batteries in parallel, you'll need to cut part of the cable and crimp on your own ring terminals to make the connection between the two batteries. So in a way, yes, you do need a battery cable but only between the two batteries to wire them in parallel and there is plenty of extra with the supplied cable. Hope that helps!

Product features

Package Includes

• 7.84 inches C T-type Steel*2pcs/19.68 inches C T-type Steel*2pcs
• 39.37 inches C T-type Steel*2pcs/12.79 inches C T-type Steel*2pcs/57.08 inches C T-type Steel*4pcs
• Connecting Bolt*4pcs/Edge Pressure*4pcs/Base*4pcs/Universal Joint*4pcs/Middle Pressure*6pcs
• Inscribed Bolt*8pcs/Short Bolts*8pcs/End Cap*8pcs/Expansion Screw*8pcs/Long Bolts*12pcs

How to Install?

1. Please use the accessories 1 2 3 4 and 12 to be the fix part of the bracket.
2. Please use the fixed part in Figure 1 and then add 5 and 13 accessories to form a tripod.
3. Please connect 6 7 and 11 parts to form 2900 C T-type Steel as figure C shows.
4. Please use the tripod in Figure 2, the 2900 C T-type Steel in Figure 3 and 8 accessories to build a frame as Figure 4 shows.Please use the 15 accessories to fix the frame to horizontal ground. Install the 14 accessories on the frame as Figure 4 shows.
5. Three-legged structure make mounting steady.
6. Adjustable angle from 18° to 30° Degree,right angle for best solar power.
7. You can put battery, controller, inverter at backside of the mounting system. It can save lots of room and use solar power system easier.
8. Fix the solar panels to the frame in Figure 8 with accessories of 9 and 10 respectively as Figure 8 shows.

• [Plug & Play] SAE connectors cable is easy to install and virtual free maintenance
• [Widely Used] Ideal solar power kit for variety of off grid applications including chicken coop, gate opener, water pump, electric fence, barn, shed, cabin etc where 12V deep cycle battery is used as well as charge and maintain Cars, RVs, Boats, Trailer, Truck battery
• [Durable Panel] Waterproof 25 Watt solar panel with 9.84ft SAE connector cable, SAE connectors easy to connect and disconnect with controller, plug and play
• [Full Protections] USB charge controller prevents battery from over charge, dischage and short circuit, reversed polarity protection. Two indicators for checking status of charging and discharging
• [Free Maintenance] 1 year warranty and 24/ 7 technical support team, call ECO-WORTHY hotline whatever any question or concern you have

User questions & answers

Question:	I've seen mixed responses here; can this panel directly power a dc fan that is wired to the load side of the controller without a battery
Answer:	Yes. I directly wired two 5V DC muffin fans to the solar panel bypassing the controller. Since all they do is vent hot air out of the chicken coop, I didn't need a battery. When the sun is out, it gets hot in there and the fans come on. When the sun goes behind the clouds or sets in the evening, the fans quit. I didn't need constant power and the fans were cheap enough that I didn't worry that they would last forever, just long enough to get through the heat! Oh and they are still working, only I reversed direction and they circulate the heat now that its colder.
Question:	is the panel waterproof
Answer:	Yes，the panel is waterproof.
Question:	Can I use this to bring power to a heated pet water bowl? If so, how would you connect it since there is no actual outlet on there
Answer:	Hi David, if the heated pet water bowl is DC load, you need one small 12v battery, pls connect the battery, pet water bowl and solar panel to the charge controller, then the kit will bring power to the pet water bowl. If the pet water bowl is AC load, then you need one additional inverter to convert the voltage from 12v to 110v for the pet water bowl. Any further question, pls feel free to contact us [email protected].
Question:	I received my solar panel kit and I noticed on the back of the panel it says it's a 22v (24volt) panel. Is this going to safely charge my 12V battery
Answer:	The open circuit voltage (no load) will be 22.4 volts, but the voltage under load will be much lower, depending on the load. The charge controller will assure that the voltage at the battery does not exceed the 14 to 15 volt range while charging, and will also drop the voltage to the 13.8 volt "float" charge level when charging is complete. The controller will also prevent the discharging of the battery when the solar panel is not in the sun.

Product features

Upgrade SAE Connectors 25W 12V Solar Panel Power Kit

Suitable for shed, cabin, gate opener, chicken coop. water pump etc

Charge and maintain Cars, RVs, Boats, Trailer 12V deep cycle batteries.

Can offer power to DC load and charging phone simultaneously when connecting battery

Solar Panel 25w

Rated Power: 25W

Voltage at Pmax (Vmp):18V

Short Curcuit Current (Isc):1.22A

Pre-drilled holes easy to mount

Pre-attached 9.84ft cable at panel backside

Dimensions (L x W x H):16.9x13.4x0.6 inches

3A Solar Charge Controller

USB port can charge phone

Charge and load indicators

Pre-drilled mounting holes

Over voltage protection

Low voltage protection

Size:4.6 x 2.2 inches

SAE Connector Extension Cables

16.9 inches O ring terminal cable

18.5 inches isolated battery clips cable

Avoid short circuit

Easy to connect with battery

Waterproof with high quality clips

Make installation easier for starter

Install Solar Power Kit in Minutes

1.Connect Battery with Controller by SAE Cable(Battery Not Include)

2.Plug & Play Solar Panel with Controller

3.Put the solar panel in full sun

SAE connectors easy to connect and disconnect, plug and play.

Chicken Coop

Door Opener/ Electric Fence

Charge Car/RV/Boat Trolling Motor/12V SLA Battery

Frequently Questions & Answers

1.Q: Is the solar panel waterproof?

A: Yes,the panel is waterproof.

2. Q: What's else do I need for this kit?

A: A 12 Volts Deep Cycle/ AGM/ SLA battery.

3.Q: Why do I receive a solar panel kit without SAE Connectors?

A: In order to make install easier, we upgrade this kit on 20th March,2020. Appreciate for your cooperation and understanding.

4.Q: Why do I receive a controller without USB port?

A: As product upgrade new design controller with USB port.

If you receive older controller pls tell us by email.

• Output Power: 800Wh daily output depends on the sunlight availability, ideal for RV, Home, Boat, Camper, Caravan, Golf car, Electric car, Yacht, Boat, Tent or backpack etc.
• Solar Panel: Corrosion-resistant aluminum frame for extended outdoor use, allowing the panels to last for decades as well as withstand high winds (2400Pa) and snow loads (5400Pa)
• Complete solar panel kit with 2pcs 20Ah lithium battery and 1000W solar inverter, easy setting up.
• Widely Use: with 20A LCD charge controller, can expand this kit up to 360W (12V)
• Warranty: 1 Year product warranty, any problems about the product please feel free to contact us

User questions & answers

Question:	Can i use this on a sailboat i am wanting to get more panels to make 550 watts could i do this with this setup? Thank you for your time
Answer:	Hi, you can use this solar panel kit on a sailboat. This solar panel kit come with 20A charge controller that can handle 360W solar panel when 12V. If you need 550 watts solar panel, you can buy this 600W solar panel kit, you can click this link for your reference :(https://www.amazon.com/dp/B079QH61YT). Wish it helps.If you have any problems, pls feel free to contact us through Amazon email.
Question:	Do I need to ground all negative terminals (solar panel, controller, inverter, and battery) to a standard 8ft. grounding rod driven into the Earth
Answer:	Hello, you just need to ground the inverter.
Question:	What plug type is required on the ac output of the inverter? it’s not a standard 110-120vac receptacle
Answer:	Hello, the plug of the inverter is an American universal plug, can be used for American equipment.
Question:	This is where I'm seeing about a Cable."You only need one battery cable, and this solar panel kit includes all cables except the battery cable
Answer:	The seller makes this very confusing in the description. Our order arrived with a battery cable with two ring terminals for the (+) and (-) side of the battery. It's about 10 feet long with Chinese only writing on the jacket with no indication of gauge. However, since you need to wire up the two batteries in parallel, you'll need to cut part of the cable and crimp on your own ring terminals to make the connection between the two batteries. So in a way, yes, you do need a battery cable but only between the two batteries to wire them in parallel and there is plenty of extra with the supplied cable. Hope that helps!

Product features

Package included:

• 2pcs 100W Monocrystalline Solar Panel
• 1pc 20A PWM Charge Controller with 5A USB Port
• 2pcs 20Ah LiFePO4 Lithium Iron Phosphate Battery
• 1pc 1000W 12V DC-110V AC Pure Sine Wave Inverter
• 1 pair of Y Branch Solar Panel Connector（parallel connection）
• 2 set Z Mounting Brackets
• 1 pair of 16.4ft 12AWG Solar Extension Cable
• 1 pc 6.56ft 11AWG Controller-Battery Extension Cable

ECO-WORTHY 100W Solar Panel

• Rated power: 100W
• Open-Circuit Voltage (Voc): 21.6V
• Short circuit current (Isc): 6.13A
• Working current (Iop): 5.78A
• Output Tolerance: ±3%
• Temperature range: -40℃to +80℃
• Size: 39.8*20.1*1.4 inch
• Weight:18.96 pounds

20A PWM Charge Controller with 5A USB Port

• Battery voltage :12V/24V auto
• Charge current: 20A
• Working current: 5.5A
• Usb port: 5V/2A
• Size/Weight: 138*85*30mm /150g
• Can be expanded 300W or 700W Solar System

20Ah LiFePO4 Lithium Iron Phosphate Battery

• Battery Capacity：20AH
• Battery Voltage：12V
• Continuous Charge/ Discharge Current：20A
• Peak Charge/ Discharge Current: 30A
• Maximum Charge Voltage：14.5V
• Discharge Cut-Off Voltage：10V
• perating Temperature: Discharging: -4°F to 140°F
• Battery Size：7.1*6.3*3 inch
• Battery Weight：4.85 lbs

1000W 12V Pure Sine Wave Inverter

• Output Volt: 110V AC
• Continuous Power: 1000W
• Surge Power: 2000W
• Frequency: 60Hz
• Effienvy: >90%
• USB Output:5V
• Fuse: 35A
• Over Load Shut Down: 120W over 10 second
• Over Thermal Protection:shut down the output
• Working Temperature: -10℃~+50℃

• Portable & Foldable :It is a ready-to-use plug and play portable solar briefcase. Pre-installed controller and Pre-wired battery clips for charging 12V battery. With handle, convenient to carry.
• Easy Operation: open up the folding solar panel, battery clips allow for simple connection to the battery. Aluminium stand quickly starts to generate more energy and you can use this solar suitcase to power up any 12V DC devices
• Wide Application: Ideal for hiking, camping, and military use, off-grid solar panel system, caravan, RV, boat, Green house solar panel system, solar pump watering system etc.
• Controller Protection: Pre-installed solar charge controller protects the system from over-charge, over-discharge, over-load, and reverse-connection
• Package includes: 1pc 120W Foldable Mono Solar Panel Kit ( 2pcs 60W Mono Solar Panel & 1pc pre-installed 20A charge controller & 1 pair pre-installed 10ft solar cables with 1 pair 30A alligator clips & 1 set adjustable aluminium stand, handle and latches)

User questions & answers

Question:	Can someone post how many different type 12v deep cycle batteries the pwm controller supports? for ex li-ion, gel type, wet cell, dry cell agm type
Answer:	Dear friend, this unit has a built-in lithium battery, which cannot be replaced by users, but the built-in lithium battery has a long life span and the charging cycle exceeds 3000 times (12 years)
Question:	Is this charge controlled considered a smart-charger like a battery tender, to prevent battery cooking
Answer:	I wouldn't know why you would want to leave it plugged into the wall all the time. I can charge mine and use it over a 3-day's.then when it gets down to one green light I set the solar panel in sun or plug it in the wall and charge it in a day. So if you leave it plugged into the wall AC and use it while it's plugged in yes I would assume the battery would die twice as fast.
Question:	Is there a protective case available for this panel
Answer:	This doesnt have an outlet on it, just a USB and the ports for the lights that come with it. You'll likely need something much stronger with an outlet on it unless you have a USB low-power heater.
Question:	Is the alligaror clips interchangable with other connections
Answer:	perfec

Product features

ECO-WORTHY 120 Watt 12 Volt Foldable Mono Solar Panel Kit

Max Power at STC: 120W

Open circuit voltage (Voc): 21.6V

Short circuit current (Isc): 6.66A

Optimum operating voltage (Vmp) : 17.8 V

Optimum operating current (Imp) : 7.32A

Output Tolerance: ±3%

Solar cell materials: Monocrystalline

Frame and leg: Heavy duty aluminum

Kind of glass and thickness: Low Iron, high transparency tempered glass of 3.2mm

Folding Dimensions: 31*20*2.8in (790*510*70mm)

Reliable

Durable

Safe

High efficiency

• 0.8kWh daily output depends on the sunlight condition, means can full charge a 12V 80Ah battery
• 20A PWM controller with built-in LCD display and dual USB port for mobile device
• Package included: 2 pcs 100W mono solar panel + 2 set of Z style mounting brackets + 20A solar controller + 1 pair of 16.4ft 10 awg solar cables + 1 pair of 2-in-1 connectors
• Easy to install with Z brackets, it can fast mount panels on the roof , each panel comes with 3ft cables for easy hookup
• 1 year warranty with 24/7 technical team, call ECO-WORHTY hotline for a solution

User questions & answers

Question:	CE marking on this product
Answer:	70% real world output is about average output. So you can expect about 11a total output from a 200w panel.
Question:	how many amps does the load connection have. I want to run a 5 amp fan
Answer:	With all solar panels you do not hook the panel directly to the battery you have to have a charge controller. I use mine every day to charge my jump box and batteries for my solar generator. Works very well. I do recommend opening the black box and making sure all you tabs are connected well, before installing.
Question:	Can I pair mor then the 2 solar panels? I want to put a total of
Answer:	In Full sun light it can produce 4-5 amps at about 18-20 volts. Doing the math 4x18=72 watts. I did measure under ideal conditions 20V and about 5A. Doing the math 5x20=100 watts. But But realistically under most conditions the average out put on a give full Sun cloudless day it is more like 4A and 19 volts. 4x19=76watts. Every installation and location is efferent, but this is a rough theoretical estimation. I fireguard on the slightly lower side as dust on the panels and in the air, haze and clouds (often there are high thin clouds that are not easily seen on a bright day). Also remember if you use a charge controller made for solar panels, like I do( Amazon has some $20 dollar ones for small arrays liket I use), The controller will very the charging current as needed to charge the battery. So when you install the panels place them so you get the most Sun Light for the longest time in both summer and winter. The angle of the Sun on the panel can vary greatly if the panel is mounted in a fixed position. This is the easiest mounting method and the most common method. It is less expensive and low maintenance as there are no motors or moving parts. Figure about a 20-23 degree angle of the panel to the Sun as the earth is tilted about that much. This change through the year, but is a good rough guide to start. You may want to do something different at your location. I use two of them and charge two 146 amp hour deep cycle batteries and my panels are not tilted as I live in an apartment and cant mount them like I would like to do. On Sunny days the two panels can take two to four days to fully charge the TWO Batteries depending how much I use the during any given day. But remember my Installation the panels are in a sheltered place and NOT Tilted. So I think if the two panels were mounted like they need to be( As I suggested above) they would work better. Hope this helps. As you can tell it is not a fixed answer as there are many thing that govern the output of the solar panel(s).
Question:	Will this work with an agm battery
Answer:	hello, 47.6(Length) x 21.3(Width) x 1.2(Height) inch is the size for unpacked panel, and 55(L) x 23.3(W) x 1.4(H) inch is packing size. Hope it will solve your problem. Thank you.

Product features

100W Solar Panel

• Rated power: 100W
• Open circuit voltage (Voc): 21.6V
• Max power voltage (Vpm): 17.3V
• Short circuit current (Isc): 6.17A
• Working current (Iop): 5.78A
• Output Tolerance: ±3%
• Temperature range： -40℃ to +80℃

Tell your friends you're using clean power - ECO WORTHY

20A Charge Controller

• New coming with unique and special design
• More details and Wiring Sequence in below

Tell your friends you're using clean power - ECO WORTHY

16.4ft Cables

• 1pc 16.4ft red cable and 1pc 16.4ft black cable with connector
• For extending the cables of panel, and connecting to controller

Tell your friends you're using clean power - ECO WORTHY

Z Mounting Bracket

• 4pcs Z Shape Solar Panel Brackets
• 8pcs Stainless Steel Nuts
• 8pcs Cap Bolts

Tell your friends you're using clean power - ECO WORTHY

2-in-1 connectors

• For connecting 2 solar panels in a series.
• It comes 2 pcs per pack.

Fits Battery Voltage: 12V/24V

• 4-Stage(EQU, Bulk, ABS, Float) charge and PWM charge automatically between solar panel and battery in the solar system.
• For avoiding short circuit, please connect the component as 1.Battery , 2.Solar Panel , 3. Load.

Rated Discharge Current: 20A

• Built-in industrial micro controller.
• Easy to use: Big LCD display, it clearly indicate the status and data, and conveniently switched modes and parameter configuration.
• suitable for home, industrial and commercial etc.

USB Output: 5V/3A

• 2 USB sockets, which support to charge 2 devices simultaneously (Note: power from battery, not from solar panel)

Easy Installation

Reliable

Widely Use

Durable

• [High Capacity Battery] 18W solar panel with 26000mAh lithium battery, full charged by one day, charge cycles are more than 3000 times(12years)
• [Bright Lights] Using Nichia LED, with lower consumption but brighter as about 140lms each light, lighting 3 nights. Each light got an individual On/Off switch for saving energy
• [Two Charging Ways] Plug and play, easy and fast! Solar panel(DC) when sunny day, or plugging it into the wall(AC) when cloudy weather before you go camping. (TIPS:When charging, please turn on the blue switch)
• [Lightweight and Compact] The generator only weights 2.1lbs, take it to go camping, hiking, fishing, expedition, hunting, outdoor activities and home as emergency power supply
• [Reliable Quality] Using lithium iron phosphate battery, and has BMS protection system to provide comprehensive protection for your equipment. We offer 90-Day FULL REFUND service and 5-Year Product Service, JUST BUY WITH CONFIDENCE!

User questions & answers

Question:	What batteries are used in this unit? Are they user replaceable
Answer:	I couldn't find one but not being used in Europe where the regulations are stricter. Being used in USA. Perhaps you could e mail the company.
Question:	Will it hurt the battery if I leave it plugged in to my AC wall socket all of the time
Answer:	It's a 12v setup rated at 200watts peak performance (an ideal number, not a realistic number), so it can provide 200/12=16.7amps under ideal conditions. The charge controller is rated at 20a, so can easily handle the panels max output. How you set it up, equipment efficiencies, and solar conditions will affect the real power output. I use mine in a battery setup to keep them charged, and infrequently run an inverter off the batteries as needed, so I am not really tracking direct usage/amps....
Question:	Can i use this unit for to turn on electric heater in winter and how long hours if unit is full charge
Answer:	Yes, you can add 2 more on this 200W kit. Be care for the panel array wiring connection, you need to wire them as 24V system.
Question:	Al conectar la bacteria se enciende algún botón o toca esperar unos minutos a que coja carga
Answer:	Dear customer, Yes, it works with AGM battery.

Product features

Specification

Product details

1: Built-in lamp

2: Power indicator light

3: Charging input

4: USB output

5: Self-contained power switch

6: Switch

7: DC output

Lighting function

• Each light string has a separate switch
• One bulb can illuminate continuously for 40 hours
• Two bulbs can illuminate continuously for 20 hours
• Three bulbs can illuminate continuously for 14 hours

Packaging includes

• 1pc 84Wh Power Station (26ah LiFePO4 Battery) with 1pc USB Charge cable
• 1pc 18W Solar Panel with extension cable
• 3pcs bulbs with 9.84ft extension cable for each bulb
• 3pcs S-Hooks

Product description

195W 18V Solar Panel Specifications



Rated power: 195W

Voc: 21.6V

Vop: 18.0V

Short circuit current (Isc):10.83A

Working current (Iop): 9.02A

Output Tolerance: ±3%

Temperate coefficient of Isc: (0.10+/- 0.01)%/℃

Temperate coefficient of Voc: - (0.38 +/-0.01)%/℃

Temperate coefficient of power Voc: -0.47%/℃

Temperature range: -40℃~+80℃

Frame: Heavy duty aluminum

Kind of glass and its thickness: Low Iron, high transparency tempered glass of 3.2mm

SLA Battery Voltage: 12V

Size: 58.3x26.3x1.4inches

weight 29.2 Lbs

6 String Combiner Box

Input Circuits/Circuit Breakers :6

Circuit Breaker Rating :10A

Max Total DC Output Current :60A

Max Input Voltage Rating:250V

Max Output Voltage Rating:250V

Protection Grade :IP65

Operational Environment Temperature :-30~+70 centigrade

Relative Humidity :0-95%

Cooling Method :Natural Cooling

Surge Lightning Protection:Yes

Dimension:10.3"x12.6"x4.5"

Shipping Weight :11.69lbs

60A LCD Charge Controller

Maximum Charging Current:60A

Maximum Loading Current: 60A

Rated Voltage: 12V/24V

Charging Circuit Voltage: <200mv

Working Tacitly Approved: Charge Off

Temperature Compensation: -4.7mv/cell°C

Environment Temperature: -15°C to +60°C

Waterproof Class: IP22

Deep Cycle battery is main part for solar panel charge system



Specification

Normal Voltage: 12V

Rated Capacity(20hr): 100AH

Constant voltage charge 25℃

Standby use:13.6-13.8v

Cycle use:14.7-15V

Initial current:20A Max

Battery Cell Type: Lead Acid

Battery dimensions: 330mm x 175mm x 190mm (13''*6.9''*7.5'')

Weight: 28kg (61.7lbs)

• 9kwh daily output depends on the sunlight availability. This kit will meet daily basic electric needs, ideal for RV/Boat/Home use
• For charging battery and a backup power, which can provide power for household air conditioning, TV, refrigerator, computer and lighting
• Corrosion-resistant aluminum frame for extended outdoor use, allowing the panels to last for decades as well as withstand high winds (2400Pa) and snow loads (5400Pa)
• Correct connection order: First connect the 24V battery pack to the 60A charge controller, then connect the PV (solar) array to the combiner box, then connect the combiner box to the controller, lastly connect the inverter to the battery
• Package List:12pcs 195W Solar Panel+ 6 String PV Combiner Box+ 60A Controller+ 4pcs 100Ah Battery+ 3500W 24V-110V Off Grid Inverter+ Solar Cables + Z Bracket

User questions & answers

Question:	What is your warranty
Answer:	Need wire from inverter and controller to battery.
Question:	What else is needed to install this kit , or rather what else is needed to make this kit work besides what you supply
Answer:	I bought a higher end inverter. I wouldn't feel comfortable. It would probably over heat.
Question:	Do you have a larger combiner box? I would like to connect in more panels in the future
Answer:	Hi, the package would be shipped out from the warehouse in CA /NJ.
Question:	Wiring diagram shows a 48V setup
Answer:	100 ah 50 ah if you dont want to discharge your batteries past recommended depth of discharge

Product features

195W Mono Solar Panel

• Rated power: 195W
• Nominal Voltage: 18 Volts
• Maximum/Peak Voltage(Vmp): 21.6V
• Maximum/Peak Current(Imp): 9.02A
• Size: 58.3x26.3x1.4inches
• Weight: 29.2 lbs

6 String Combiner Box

• Input Circuits Breakers: 6
• Circuit Breaker Rating: 10A
• Protection Grade: IP65
• Surge Lightning Protection: Yes
• Size: 10.3*12.6*4.5 inch (260*320*115mm)
• Weight: 10.8 lbs (4.9kg)

3500W 24V-110V Inverter

• Output voltage: 110VAC
• Continuous power: 3500W
• Frequency: 50 / 60Hz
• USB output: 1A 5VDC
• Working input: 24VDC

60A Charge Controller

• Maximum Charging Current: 60A
• Rated Voltage: 12V/24V
• Working Temperature: -35℃--75℃
• Size: 7.72”*3.23”*1.5
• Weight:1 lbs (0.45kg)

100AH Battery

• Rated Capacity(20hr): 100AH
• Battery Cell Type: Lead Acid
• Comes with: 2 sets of cord
• Size: 13*6.9*7.5inch
• Weight: 61.7lbs (28kg)

Solar Cable with Connector

• 12AWG solar cable with connector
• 16ft red cable and 16ft black cable to connect with solar panel

Z Brackets

• Material: stainless steel
• Size about 2.16*1.49*0.78inch
• Fits for solar panels installed on the RV, house, and boat

Customer Questions & Answers

1. Q:Will this kit come with multiple packages?

A: Yes, as this is a large kit, there are several packages, if you don't receive all the items please tell us by email.

2. Q: What's function of Combiner Box?

A:This solar combiner box with high-voltage fuses, over-voltage and over-current protection

3. Q: Where can I buy more Battery?

A: Here is ASIN B07BC7G2JX

4. Q: If I need larger or custom kit what can I do?

A: Please tell us with detail information such as load appliance watt, voltage and working hours by email, we will customize the most suitable kit for you.

• 10 DC Adapters for 95% Power Station: 8mm for Jackery/Goal Zero，5.5*2.1mm for Flashfish and 5.5 *2.5mm for Rockpals etc
• Battery Charge Protection: 20A LCD controller can protect Lithium/Gel/Lead acid battery from overcharge and short circuit while charging, 5V USB ports for phones,tablets
• Increase 20% DC Charging Speed: Upgrade from 100watts to 120watts, generate 0.5kwh max per day under 4hs full sunshine
• Get up to 25% Sunlight: The tilting kickstands allows you to get up to 25% more solar energy than flat laying. The 3 meters cable allow solar panel to follow the sun without worrying about power station over heating
• Light Weight & Compact Design: 9lbs(4.2kg) only, A zippered pouch stores controller and necessary cords handy. Carry it wherever you go

User questions & answers

Question:	How many can be put together and would they be able to keep a camper batteries charged
Answer:	I was able to keep my battery charged just fine with a single panel. You can connect them in series or parallel, depending on your energy needs. I assume as many as you need.
Question:	If my generator only supports mppt controller, will that be an issue using this to full functionality
Answer:	I'm not sure. This panel includes a PWM controller which is less capable than an MPPT, but the charge controller only applies if you are charging something that does not include its own type of charge controller. It is possible your generator USES an MPPT already (most if not all "solar generators" that I know of have a controller), but I can't say for sure based on the information you've provided - I would need more to give you a better answer.
Question:	Will this hook directly up to the solar plug on a solar ready RV
Answer:	I ordered a 14 gauge, 3 foot SAE plug extension, cut one plug end off, wired directly to the battery controller's out terminal (CHECK POLARITY !), a 15' SAE extension cord, and plug directly into my trailer's SAE solar plug port. Charges my trailer battery just fine.
Question:	How come this panel can not be used with the jackery portable power station explorer 500 but it can be used with the smaller jackery units
Answer:	You absolutely CAN use this panel with the Explorer 500 - I have used this exact panel to power my Jackery 500 more than once (at quite an impressive rate, I might add). The only reason this panel is not compatible right out of the box is because it doesn't have an adapter large enough. The only thing you would need is an MC4 to 8mm adapter, which you can easily find on Amazon (I spent $25 for a really nice 3-ft MC4 to 8mm adapter from SolarEnz).

Product features

Please note:

1. When connecting with solar generator, controller display and USB port can not work.
2. The controller only works when connected to the battery. When the battery is under the over-discharge protection, charging will not work until the battery voltage returns to 12.6V.

3 meter cable

• The cable is 3 meters (9.84 feet) in length.
• With this length, you can benefit from a wider space to mobilize, or keep your generator in the shade and away from heat

4 Bunckles

• We offer you a better alternative solution for caravans.
• Installation is simple using the hooks, easy to uninstall and folds like a handbag.

2 Kickstands

• 2 kickstands are made behind the panel.
• A declination angle helps absorb the sun better.

The Parameters

• Open circuit voltage: 21.6V
• Short circuit current: 7.1A
• Maximum voltage: 18V
• Maximum current: 6.67A
• Folded Dimensions:21.5*14.6*2.5 inches
• Expanded Dimensions:62.2*21.5*0.2 inches

• Daily Output generate 1.5KWH under 4 hours full sunshine
• Each Solar Panel Size:58.3x26.3x1.4inches, weight 29.2 Lbs
• Bypass diode minimizes power drop caused by shade and ensures excellent performance in low-light environments
• Corrosion-resistant aluminum frame for extended outdoor use, allowing the panels to last for decades as well as withstand high winds (2400Pa) and snow loads (5400Pa)
• One year warranty, 90% efficiency rate within 10 years

User questions & answers

Question:	Does it come with charge controller? How many panels i can expand this system
Answer:	I bought my panels in the early spring, and have not donr anything so far
Question:	Can this be wired in series with a 150w panel to use in a 24v system
Answer:	Yes, this solar panel can be used to charge solar generator with the right adapter
Question:	With the right adapter, could this panel be used to charge a Jackery 500 solar generator
Answer:	It will help maintain if night temperatures are high. Won't help when night temps are in the 30's. My experience was water circulated to fast not enough heat time.

Product features

2pcs 195 Watts 12 Volts Monocrystalline Solar Panel

• Rated power: 195W
• Open-Circuit Voltage (Voc): 21.6V
• Short circuit current (Isc): 10.83A
• Working current (Iop): 9.02A
• Output Tolerance: ±3%
• Size: 58.3x26.3x1.4inches
• weight: 29.2 Lbs

• [ Feature ] - Environmental protection and energy saving, built-in blocking diode to prevent reverse discharge, not only maintains the battery lifetime but also extends its usage life, keep the battery from drain dead .
• [ Wide Use ] - Perfect trickle charger/maintainer for 12V batteries of cars, motorcycles, boats, snowmobiles, tractors etc. The dimensions is 8.7in x 7.5in
• [ Warm Tip ] - Please remove the protective plastic film from the right corner of the panel before using it. The cigarette plug option only works if it has constant power when the key is out of the ignition. When you start the car, please remove the solar panel from the car battery. The suckers help to attach the solar panel on the smooth surface like windshield.
• [ Suitble For ] - Charging 12V battery in emergency, suitable for the vehicles in outdoor work, travel or camping training, and the vehicles are put for a long time. Easy to install and completely maintenance-free.
• [ Updates ] - Comes with the cigarette lighter adapter and 1 pair of battery clips. Unique design-high quality clips to prevent short circuits. The panel is well packaged in a firm box, avoiding crashing.

Product features

Package Includes:

• 1 * 12V 5W Solar trickle charger with 57inch (145cm) cord
• 1 * Alligator clip adapter with 22.8inch (58cm) cord
• 1 * Cigarette lighter adapter with 22.8inch (58cm) cord
• 4 * PVC Suckers

12V Car Battery Charger

Maximum Power (Pmax): 5W

Open-circuit Voltage (Voc): 22.41V

Short-circuit Current (Isc): 0.3A

Maximum Working Voltage (Vpm): 17.9V

Maximum Working Current (Ipm): 0.28A

Dimension

Net Weight: 0.76lb ( 345g )

Size: 8.07inch*9.25inch ( 20.5cm*23.5cm )

Plug&Play SAE connector

Solar Panel SAE connector is plug and play, no need to recognize positive or negative, simple and easy to use.

Note:As this is 5w solar panel main function is prevent battery drain out, not for full charging your battery

Cigarette Lighter

Plug the cigarette lighter to socket when use it to charge or maintain vehicle's battery, really plug and play.

Note:In some makes of vehicles, the cigarette lighter may not operate when the ignition is turned off. If so, you can connect directly to the battery using alligator battery clamps and cables.

Alligator Clip Adapter

Use the red and black battery clamps to trickle charge and maintain 12 V battery, make sure they connect correctly.

Built-in blocking diode

Built-in blocking diode to prevent reverse discharge.

this solar power panel on your windshield with the suction cups or fix it on the sun visor with the back strips.

• Solar Power: 12V 50W portable solar kit. Ideal for hiking, camping, military use, off-grid solar panel system, caravan, RV, boat, solar pump watering system etc.
• Easy Operation: open up the folding solar panel, alligator clips allows for quick connection to the 12V DC system.
• Portable & Convenient: Foldable suitcase easy to carry. Pre-installed charger controller and Pre-wired for 12V system charging, easy install
• Durable &Sturdy: Resistance to salt corrosion and humidity. High modules conversion efficiency.
• Package includes: 1pc 50W folding poly solar panel kit (2pcs 25W poly solar panels & 1pc pre-installed 3A charge controller & 1 pair pre-installed 10ft solar cables with 1 pair 30A alligator clips & 1 set adjustable aluminium stand, handle and latches)

User questions & answers

Question:	Is there a kit/adapter to charge USB devices such as tablets and cell phones, etc
Answer:	Dear friend, this controller cannot support lithium batteries, so it cannot charge 16 ah Lifepo S4 batteries
Question:	Will it charge a lifepo s4 battery that is 16 ah
Answer:	Hi Susan, if you connect battery's Positive & Negative to the kit's battery clips backwards, it will burn the controller. Hope you won't hook up the kit to battery backwards.An further question, pls feel free to contact us, thanks.
Question:	What would happen if you hook it up backwards
Answer:	Ship with FEDEX, it may cost you both the shipping and the tax.Please contact me with Amazon email.thanks
Question:	Shipping to jordan through ups or feddex ? how much does it cost
Answer:	Hello, this link does not include the controller. This link contains 16pcs 195W solar panel.
