14 best audio converter for tvs

Product description

PROZOR Digital to Analog Audio Converter converts coaxial or toslink digital PCM audio signals to analog L/R RCA and 3.5mm Jack audio.

It also can be used for PS3, XBox, Blue-ray player, HD DVD, etc. which have no RCA(L/R) outputs or 3.5mm Jack output.



Features:

Converts coaxial or toslink digital PCM audio signals to analog L/R RCA and 3.5mm Jack audio simultaneously ( not capable of being reversed)

Available for connection to an external device such as an amplifier via standard RCA jacks or a headphone via 3.5mm jack cable

Supports uncompressed 2-channel LPCM digital audio signal output

Supports sampling rate at32KHz, 44.1KHz, 48KHz and 96KHz;

24-bitS/ PDIF incoming bit stream on left and right channels

Provides electromagnetic-noise-free transmission

Easy to install and simple to operate

Compact size and easy to carry

Certificated by FCC RoHS



Specifications:

Color: Black

Housing: Full Metal

Weight: approx 90g

Input audio connector: 1 x Toslink, 1 x RCA (Coaxial)

Output audio connector: 2 x RCA(R/L), 1 x 3.5mm Jack

Powered by 5.5mm USB power cable

Consumption: 0.5W (max)

Dimension: 73 x 55 x 22 mm

Package List:

1* PROZOR digital to analog audio converter

1* Toslink cable (Optical cable)

1* USB power cable

1* User manual Note:



Do Not Use Other Plugs, It Can Only Use 5V 1A Plug



Please set your TV audio output to PCM / LPCM: Device homepage--system setting--image and sound---voice setting--digital audio output--PCM/LPCM.



If Panasonic TV, please set TV audio output to SPDIF output.



If Samsung TV, please turn on its external speakers : menu - sound - speaker settings - external speakers - on.



This DAC may have some compatibility problem with Youtube or Netflix.



Warranty:

This PROZOR Digital to Analog Audio Converter Provides 18 Months Warranty.

• PROZOR 192KHz Digital to Analog Audio Converter: Converts coaxial or toslink digital PCM audio signals to analog L/R RCA and 3.5mm Jack audio simultaneously ( not capable of being reversed)
• Input Audio Connector: 1 x Toslink, 1 x RCA (Coaxial); Output Audio Connector: 2 x RCA(R/L), 1 x 3.5mm Jack; Powered by 5.5mm USB Power Cable (Power Adapter is NOT Included); Do Not Use Other Plugs, It Can Only Use 5V 1A Plug
• Supports Sampling Rate at 32KHz, 44.1KHz, 48KHz, 96KHz, 192KHz; 24bit S/ PDIF Incoming Bit Stream on Left and Right Channels
• Supports Uncompressed 2 channel LPCM or PCM Digital Audio Signal Output; Provides Electromagnetic-noise-free Transmission(5.1 channel is incompatible, please set the audio output to PCM or LPCM）
• Easy to Install and Simple to Operate; Can be Used for PS3, PS4, Blu-ray Player, HD DVD, Home Cinema Systems, AV Amps, Etc

Product features

192kHz 24bit CS8416 Chipset

Supports sampling rate at 32KHz, 44.1KHz, 48KHz, 96KHz and 192KHz.

24-bit SPDIF incoming bit stream on left and right channels.

Size:

Easy to install and simple to operate.

Compact size and easy to carry.

Coaxial or toslink PCM 2.0 signals to analog L/R RCA and 3.5mm Jack audio.

Product description

Overview: Tec hole Aluminum digital to analog audio converter is designed to convert coaxial or To slink digital PCM audio signals to analog L/R RCA and 3. 5mm Jack audio. It also can be used for PS3, Xbox, Blue-ray player, HD DVD, etc. which have no RCA(L/R) outputs or 3. 5mm Jack output. Features: Converts Coaxial or To slink digital PCM audio signals to analog L/R RCA ( not capable of being reversed) Eliminates the Noise when No Input Signal and Automatically Mute Supports Sampling Rate at 32KHz, 44. 1KHz, 48KHz, 192kHz / 24bit Aluminum Metal Case, Lightweight and Compact Good Anti-interference Function Makes the Sound Pure and Clear Works with Any Playback Source with an Optical (TOSLINK) or Coaxial Digital Audio Output Such as Digital and HD Televisions, Satellite Receivers, CD/DVD/Blu-Ray Players and Game Consoles Specifications: Input audio connector: 1 x To slink, 1 x RCA (Coaxial), 1 x DC/5V Port Output audio connector: 2 x RCA(R/L), 1 x 3. 5mm Jack Support Audio Format: PCM Signal-to-Noise Ratio: 105DB Separating Degree(1KHZ): 94DB Response Frequency: 20Hz~20KHz -0. 2db THD+N: -90DB Total Harmonic Distortion(THD): 10Hz~20KHz 0. 25-0. 065% Blocking Time: 0. 577Fs Sampling Rate: 32~192 KHz Bit Rate: 16~24 Bit Output Impedance: 10 ohms Consumption: 0. 5W (max) Converter Shell: Aluminum Shell Color: Black Weight: 72g Size: 55*60*24mm Package Included: 1 x Digital to analog audio converter 1 x To slink cable (Optical cable) 1 x Coaxial Cable 1 x micro USB charging cable 1 x User manual 1 x Tec hole card Kindly Note: 1. Please connect with 5V USB Power Supply 2. The adapter is incompatible with 5. 1 Channel Signal such as Dolby AC3, please set the audio output to PCM or LPCM. 3. This Converter can't adjust volume, please adjust the volume by your input device or output device.

• 【Updated DAC Converter】Ideal DAC converter converts coaxial or slink digital audio signals to analog L/R RCA and 3.5mm Jack audio simultaneously (not capable of being reversed). Can be used with PS3, Xbox, Blu Ray Players, HD DVD, Home Cinema Systems, and more devices which lack RCA L/R or 3.5mm jack outputs.
• 【Plug & Play】DAC adapter comes with an optical cable and a coaxial cable to transmit digital or analog signals respectively - so you’re all set and don't need to buy one. Powered by (5V 1A) USB power cable(Does not come with adapter), 0.5W low power consumption. Easy to install, perfect for beginner.
• 【192KHz Sampling Rate Achieved】Techole Digital to Anglog Audio Converter actually supports Sampling Rate at 32, 44.1, 48, 96 and 192 KHz, and 24-bit S/PDIF Incoming Bit Stream on Left and Right Channels. Good Anti-Interference function makes the sound pure and clear.
• 【Multi-Point Connection】Input audio connector with one Toslink and one RCA (Coaxial) cables, DC 5V port, Output audio connector with two RCA(R/L) and one 3.5mm Jack. Supports uncompressed 2.1-channel PCM or LPCM digital audio signal output, will Not supports 5.1 channel Dolby sound.
• 【Aluminum Alloy Design】Aluminum Metal Case, lightweight, durable and heat-resisted. Gold Plated Sockets, enhance HD sound signals over long distance broadcasting smoothly. Note: Please set the connected device to support audio output and set the audio output to PCM or LPCM before use.

User questions & answers

Question:	Can i use this to take optical out from a tcl tv to my older philips receiver and play tv output through the speakers hooked up to the receiver
Answer:	As long as your Phillips is analog it should work. This box takes digital or optical and converts it to analog if you are going from optical to digital or vise versa I don't believe it's made for that
Question:	Anyone getting hiss noise when there is no input source to the DAC
Answer:	Yes, I am getting a very loud hiss when my source (desktop) turns off or when the input is not plugged into anything. Very annoying and I'll be looking for a different optical DAC
Question:	can it be used for dolby-5.1 technology? my new tv have this function
Answer:	Most DAC converters in the market only support LPCM/ PCM format, not compatible with 5.1 Channel Signal Such as Dolby AC-3/DTS. You have to set your smart TV to PCM format output each time. If you need a DAC that doesn't require TV to be set to PCM audio, I would recommend this one. https://www.amazon.com/dp/B07DVWSWLQ It supports DTS/ Dolby AC3/ LPCM/ PCM/ RAW, Can Decode Dolby/DTS 5.1CH Digital Audio into 2.0CH Analog Audio Output without Setting Audio Output Format. No need to set to PCM like other DAC, so convenient.
Question:	How long is the usb power cable? Does it go into a wall socket to provide power to the adapter itself
Answer:	The manual reads, "Please connect with 5v USB power supply." However, 5V is the USB standard for all USB ports, so you can plug the USB cable that comes with it into any device you have which has a USB port (note: all versions of USB use 5v) e.g., the you can plug the USB cable into the USB port on your TV itself or into virtually any modern gaming console. No wall socket necessary. It's purely optional.

Product features

Additional cables

Built-In Active IC Chipset

Aluminium Material

Widely Application

• 192Khz 24Bit sampling rate: Support 192Khz 24Bit sampling rate on the optical and SPDIF signal,built-in interference immunity and no signal input squelch circuit
• Widely compatible with 32~600 Ω headphones：Designed for game player and music fancier ，support all headphones within 32~600Ω
• Volume adjustment knob : Built-in volume adjustment circuit and control knob ,completely solve the problem of low volume when using high-impedance headphones used in DAC products , with surging power and full thrust
• Bass adjustment knob: The 192KHz DAC innovatively designed bass adjustment function，Can provide stunning stereo sound, heavy bass effect, create the perfect environment different from the sound field, gain the effect was very obvious, which makes you reveled in a world by bass
• The design of portable and fashion aluminum alloy shell and gold-plated interface improved overall immunity ,it makes the sound clear and pure .Widely compatibility ,it can be used for PS3,PS4,Blu-way player,HD DVD,Home Theatre system, etc. Easy to install , plug and play

User questions & answers

Question:	What is the function of the bass knob
Answer:	The size of the bass can be adjusted, but the effect of the treble cannot be adjusted. Adjust bass only
Question:	Does this product increase the volume when used with PS4 and headphones
Answer:	Of course, when using PS4 optical to headphones. You can turn the volume knob of the digitizer to control the volume. There is also a bass knob to adjust the bass effect. it's great
Question:	Does the accessory include a power adapter
Answer:	Hello, in order to improve customer shopping experience. The upgraded version of this DAC converter includes a standard 5V1A power adapter
Question:	Do the volume control and bass control work in tx mode
Answer:	This unit is not a "transmitter". I think what your asking is does it change the sound of the output. The answer then would be "Yes." This unit takes the digital audio from the TV digital output plug and then converts it to a regular analog audio output signal. Example: I have a small Bluetooth transmitter that I use for my earphones. It uses normal analog. I can't plug it into the speaker output jack of the TV because those jacks cut the speaker off. So I needed another audio output to plug it into. The only other audio output on the TV was a 192 KHz digital output jack. So I use the DAC (Digital to Analog Converter) to convert that digital TV audio to analog and then I plug the Bluetooth transmitter into the DAC converter. The Base and Volume control does work to change the audio level and base into the Bluetooth transmitter. I hope that helped.

Product features

Introduction：

This product is designed for professional audio signals,Can easily convert Coaxial or Toslink interface to RCA analog audio interface and 3.5mm headphone jack.

The professional audio amplifier chip and volume adjustment knob are designed to directly drive the headphones and adjust the output volume. The product also designed a bass adjustment knob, which can easily control the bass component to meet different customer needs.

Support 192KHz 24Bit Sampling Rate

Support 32KHz,44.1KHz,48KHz,96KHz, 192Khz 24Bit sampling rate on the optical and SPDIF signal,built-in interference immunity and no signal input squelch circuit

Aluminum alloy shell and strong and easy to carry

The aluminum alloy shell of the product is strong and not easy to damage

Small size, easy to carry.

Widely compatible with 32~600 Ω headphones

Designed for game player and music fancier ，support all headphones within 32~600Ω .

Volume adjustment knob

Built-in volume adjustment circuit and control knob ,completely solve the problem of low volume when using high-impedance headphones used in DAC products , with surging power and full thrust

Bass adjustment knob

Designed bass adjustment function，Can provide stunning stereo sound, heavy bass effect, create the perfect environment different from the sound field, gain the effect was very obvious, which makes you reveled in a world by bass.

Widely Compatible

Widely compatible，the digital-to-analog converter is compatible with TV, DVD, PS3, PS4, audio amplifier system, earphones and other devices

Note:

1. Before power on, you must turn the adjustment knob counterclockwise to minimize the volume to avoid damage to your hearing!

2. Before use, please set the audio output channel of your signal source devices such as DVD, TV, PS4 and other devices to SPDIF, and set the output audio format to PCM.

Product description

Overview:

This digital to analog audio converter is designed for either house or professional audio switching.

Connect to TV with a Toslink cable (also called Digital SPDIF or Optical Cable) or Coaxial cable.

Connect to amplifier with a RCA Audio cable or headphone with a 3.5mm Stereo Jack cable simultaneously

It also can be used for PS3 XBox Blu Ray Player, HD DVD, etc. which have no RCA(L/R) outputs or 3.5mm Jack output

This Converter is small in size and quite easy to install. Features:

Converts Coaxial or Toslink Digital Audio Signals to Analog L/R RCA & 3.5mm Jack Audio Simultaneously (Not Support Reversed)

Support Connect to an amplifier via standard RCA jacks or a headphone via 3.5mm jack cable

Supports uncompressed 2-channel LPCM digital audio signal output

Supports sampling rate at 32KHz, 44.1KHz, 48KHz and 96KHz

24-bit SPDIF incoming bit stream on left and right channels

Provides electromagnetic-noise-free transmission

Certificated by FCC ROHS Specifications:

Color: Black

Weight: approx 90g

Dimension: 73 x 55 x 22 mm

Consumption: 0.5W (Max)

Converter Unit: FCC, CE, UL

Power Supply: UL, CE, FCC

Powered by 5.5mm USB Power Cable(Power Adapter is Not Included) Input Audio Connector: Toslink, RCA (Coaxial)

Output Audio Connector: RCA(R/L), 3.5mm Jack Package List:

1 x Digital to Analog Audio Converter

1 x Toslink Cable (Optical cable)

1 x USB Power Cable (Power Adapter is Not Included)

1 x User Manual Note: The SPDIF input must be Stereo PCM, please configure the output of your device. It won't work with Dolby 5.1.

• 【eSynic DAC Converter with 3.5mm Jack and RCA】The Audio Converter Converts Coaxial or Optical Digital PCM Audio Signals to Analog RCA L/R and 3.5mm Jack Audio Simultaneously, You can Play Music and Share at the Same Time; Great Idea for Your Bluetooth Headphone/Speaker with Your TV.
• 【Supports Mainstream Digital Optical/Coaxial Input】Support Sampling Rate at 32, 44.1, 48, and 96 KHz, 24-bit SPDIF Incoming Bit Stream on Left and Right Channels, Provides Electromagnetic-noise-free Transmission.
• 【Supports Uncompressed 2-channel LPCM or PCM】This DAC Converter Support 2-channel LPCM or PCM Digital Audio Signal Output, (NOTE: Not for 5.1 Channel, Please Set The Audio Output to PCM or LPCM. If Samsung TV or LG TV Audio Format Set To PCM/ LPCM without Sound, Please also Turn On Its External Speakers)
• 【Aluminum Alloy Shell and Gold Plated Interface Design】Overall Shielding without Signal Interference, Gold Plated Sockets, Enhance HD Sound Signals over Long Distance Broadcasting Smoothly.
• 【Plug and Play】No Need to Install Drivers, Come with 1m Fiber Optic Cable and 5.5m USB Power Cable, Easy to Install and Operate; Also, Compact Size, Easy to Carry, Ideal for Home or Professional Audio Switching Such As PS3, PS4, Blu-ray Player, HD DVD, Home Cinema Systems, AV Amps.

User questions & answers

Question:	Will this connect to my tv optical out and allow me to connect my headphone jack so i can privately listen to my tv
Answer:	It has a headphone jack, but make sure you get the one with a volume control. Amazon item number B073PYN7L5
Question:	Will this work with my samsung tv that has an spdif outlet. i want to connect to a bose speaker with an rca to 3.5mm cord. what more do i need
Answer:	You’ll need an spoof cable to go from the TV to this unit and a power source for the unit too. Use a powered USB port on the TV or an A/C adapter with a USB outlet. Then from this unit you’ll need a 3.5 MM cable from this unit to your speaker.
Question:	My projectors connecttion for a speaker is a 3.5mm line in and the speakers only connect with optical audio will this work
Answer:	No it will not. It goes the other way. I just did it the 3.5 is the output not input
Question:	Is this all i need to enable my Samsung tv to hook up 3.5mm headphones?? does it come with everything i need
Answer:	No, it is missing the AC to USB (5 volt) power connector, and RCA to 3.5mm connector

Product features

Aluminum Alloy Design

Aluminium alloy case with gold plated interface provides good anti-interference and makes the sound pure and clear. Enhance HD Sound Signals over Long Distance Broadcasting Smoothly.

High Performance Chip

Provides electromagnetic-noise-free transmission, supports sampling rate at 32, 44.1, 48 and 96kHz, 24-bit S/PDIF incoming bit stream on left and right channels.

Package Includes

1 x Digital to analog audio converter, 1 x 1m Toslink Cable (Optical cable), 1 x 5.5m USB power cable(Power Adapter is Not Included), 1 x User manual

Product description

Overview:

With volume adjustment button, Techole digital to analog audio converter is designed to convert coaxial or Toslink digital PCM audio signals to analog L/R RCA and 3.5mm Jack audio. It also can be used for PS3, XBox, Blue-ray player, HD DVD, etc. which have no RCA(L/R) outputs or 3.5mm Jack output.

Features:

1. Volume Adjustable: Easy to adjust the volume with the volume adjustment button.

2. Built-In Active IC Chipset: Converts Coaxial or Toslink digital PCM audio signals to analog L/R RCA ( not capable of being reversed).

3. Aluminum Material: Unlike other ABS material, uses aluminum metal material, lightweight and compact.

4. High Definition Sound: Good Anti-interference Function Makes the Sound Pure and Clear, eliminating the Noise when No Input Signal and Automatically Mute.

5. Widely Application: Works with Any Playback Source with an Optical (TOSLINK) or Coaxial Digital Audio Output Such as Digital and HD Televisions, Satellite Receivers, CD/DVD/Blu-Ray Players and Game Consoles, supporting Sampling Rate at 32KHz, 44.1KHz, 48KHz, 192kHz / 24bit

Specifications:

Input audio connector: 1 x Toslink, 1 x RCA (Coaxial), 1 x DC/5V Port

Output audio connector: 2 x RCA(R/L), 1 x 3.5mm Jack

Support Audio Format: PCM

Signal-to-Noise Ratio: 105DB

Separating Degree(1KHZ): 94DB

Response Frequency: 20Hz~20KHz -0.2db

THD+N: -90DB

Total Harmonic Distortion(THD): 10Hz~20KHz 0.25-0.065%

Blocking Time: 0.577Fs

Sampling Rate: 32~192 KHz

Bit Rate: 16~24 Bit

Output Impedance: 10 ohms

Consumption: 0.5W (max)

Converter Shell: Aluminum Shell

Color: Black

Weight: 0.16lb

Size: 2.17*2.36*0.94in

Package Included:

1 x Digital to analog audio converter

1 x Toslink cable (Optical cable)

1 x Coaxial Cable

1 x micro USB charging cable

1 x User manual

1 x Techole Warranty card

• 【Upgrade Volume Adjustable】Techole upgraded digital to analog audio converter comes with a volume adjustment button. Unlike other converter, it is more convenient for you to adjust volume when you are enjoying TV, movie, music or games. ✅Please remember set TV into "PCM" mode.
• 【Updated DAC Converter】Ideal DAC converter converts coaxial or slink digital audio signals to analog L/R RCA and 3.5mm Jack audio simultaneously (not capable of being reversed). Can be used with PS3, Xbox, Blu Ray Players, HD DVD, Home Cinema Systems, and more devices which lack RCA L/R or 3.5mm jack outputs.
• 【Plug & Play】DAC adapter comes with an optical cable and a coaxial cable to transmit digital or analog signals respectively - so you’re all set and don't need to buy one. Powered by (5V 1A) USB power cable(Does not come with adapter), 0.5W low power consumption. Easy to install, perfect for beginner. ✅RCA cable is not included!
• 【192KHz Sampling Rate Achieved】Techole Digital to Anglog Audio Converter actually supports Sampling Rate at 32, 44.1, 48, 96 and 192 KHz, and 24-bit S/PDIF Incoming Bit Stream on Left and Right Channels. Good Anti-Interference function makes the sound pure and clear.
• 【Multi-Point Connection】Input audio connector with one Toslink and one RCA (Coaxial) cables, DC 5V port, Output audio connector with two RCA(R/L) and one 3.5mm Jack. Supports uncompressed 2.1-channel PCM or LPCM digital audio signal output, will Not supports 5.1 channel Dolby sound.

User questions & answers

Question:	If i merge pc stereo audio into rca input to the unit, will the rca output be stereo? the product info is unclear
Answer:	Dear Customer, Thank you for your question.Our product converts coaxial or slink digital audio signals to analog L/R RCA. Best regards, Jenny.
Question:	I bought this hoping it would help me use my soundbar with my Roku player, which is connected to the TV via an HDMI cord. How could I set this up
Answer:	Dear Customer, Thank you for your question. Does your roku player have audio output？If it don't, you can connect ROKU to the TV, the TV has digital audio and then output to the product, the product to the sound bar. Best regards, Jenny.
Question:	Is it normal to hear a hissing sound in the background
Answer:	Dear Customer, Thank you for your question.I do apologize for the problem that you mentioned.I want to ask if your device is hissing when it is turned on or off? The following is the hissing of the device: 1. Hissing when your device is off is a bug in the product chip, the current echoes, but it disappears as soon as it is turned on. 2. When your device sizzles when it is turned on, could you check if the cable is plugged in well? If it still can't solve your problem, could you please contact us directly via Amazon message service according to the following link? https://www.amazon.com/gp/your-account/order-history Best regards, Jenny.
Question:	I am unable to use with yamaha mg10xuf 10-channel analog mixer. any tips
Answer:	Having just reviewed the features of that mixer, all I can offer may just be obvious suggestions: Using channel inputs 5~8, make sure your channel faders are increased sufficiently after you have turned the volume pot up on said converter... don't forget, you'll need to add a 5V power supply (not included) to the provided power cable.

• DAC Audio converter- Please turn off the Dolby sound, Input signal source such as TV etc, need to set the audio format: PCM; Can be Used for PS3, PS4, Xbox, Blu-ray Player, HD DVD, Home Cinema Systems, AV Amps, Etc ( not capable of being reversed,This DAC converter can only be used as digital in to analog out)
• Converter output analog audio with 1M Fiber Optical Cable. Make sure you have to remove the Clear Protector Caps from the Optical Cable【Please note: This product only needs USB power supply, any mobile phone charger or computer USB port can be used. When you encounter noise or mute problems, you only need to replace the audio cable or set the PCM audio to solve it. Contacting the seller’s technical support is the best choice】
• Provides Electromagnetic-noise-free Transmission;Overall Shielding without Signal Interference, Gold Plated Sockets; (5.1 channel is incompatible, Supports Uncompressed 2-channel LPCM or PCM Digital Audio Signal Output
• 【Please check Amazon ’s post-sale mail first, The seller provides lifetime after-sales service】Supports Sampling Rate at 32KHz, 44.1KHz, 48KHz and 96KHz; 24-bit S/ PDIF Incoming Bit Stream on Left and Right Channels;It is recommended that customers use Amazon's coaxial or optical cables
• Easy to Install and Simple to Operate; Inner special IC unit of amplify analog audio signal to ensure strong and steady signal out; Ultra low jitter and high fidelity design using new receiver & D/A converter chip

Product features

Digital to Analog Audio Converte

Input Audio Connector: 1 x Toslink, 1 x RCA (Coaxial); Output Audio Connector: 2 x RCA(R/L), 1 x 3.5mm Jack; Powered by 5.5mm USB Power Cable (Power Adapter is NOT Included); Do Not Use Other Plugs, It Can Only Use 5V 1A Plug

Specifications:

1.Housing: Full Metal

2.Weight: 90g

3.Input audio connector: 1 x Toslink, 1 x Coaxial

4.Output audio connector: 2 x RCA(R/L), 1 x 3.5mm Jack

5.Powered by 5V/1A power adapter

6.Consumption: 0.5W (max)

7.Dimension: 75 x 55 x 22mm

Audio adapter optical coax to rca aux

Ideal DAC converter converts coaxial or slink digital audio signals to analog L/R RCA and 3.5mm Jack audio simultaneously (not capable of being reversed). Can be used with PS3, Xbox, Blu Ray Players, HD DVD, Home Cinema Systems, and more devices which lack RCA L/R or 3.5mm jack outputs.

Digital to analog audio converter

Converts coaxial or toslink digital PCM audio signals to analog L/R RCA and 3.5mm Jack audio simultaneously ( not capable of being reversed)

Audio dac

Easy to Install and Simple to Operate; Can be Used for PS3, PS4, Apple TV, Xbox, Blu-ray Player, HD DVD, Home Cinema Systems, AV Amps, etc.

Product description

Musou HDMI ARC Audio Adapter supports Toslink, Coaxial or ARC audio input then Toslink/Coaxial/ L/R or 3.5mm headphone out to soundbar, Speaker, home theater, A/V receivers etc.Perfect audio converter and HDMI ARC adapter extractor

Note:

1. If you are using stereo R/ L or 3.5mm jack output to your audio receiver, please set your audio source(such as your TV) to PCM/ LPCM. This unit can not support 5.1 or 7.1 audio via stero R/ L or 3.5mm jack output.

2. If you are using HDMI ARC input, please make sure you are using standard 19+1 high level HDMI cables.

3. Make sure the power supply is properly connected (5V1A), and when connecting to different output ports, you need to selectively turn off Dolby sound (Dolby 5.1, Dolby +).

4. Some TVs need to set the "audio external output" option, if your TV does not have ARC function, please use optical fiber or coaxial interface to connect. Switch "A-T-C" needs to be adjusted to the corresponding position in time.

Specifications:

1. Input: Toslink x 1, Coaxial x 1, HDMI ARC x 1

2. Output: Toslink & Coaxial & Stereo R/ L & 3.5mm jack(simultaneously)

3. Support audio format: LPCM2.0/ DTS/ Dolby-AC3

4. Output cable distance: ≤10m(Use the optical fiber cable loss less the 0.2Db/m )

5. Powered by 5V/ 1A power adapter

6. Support last time working state memory when power off

7. Dimension (L x W x H): 114 x 48 x 23 (mm)

8. Weight: 138g

Package Contents:

1xMusou ARC audio extractor

1x5V/1A Power Adapter

1xUsers Manual

• 【Multifunction DAC Audio Converter】Input: Toslink x 1, Coaxial x 1, HDMI ARC x 1; Output: Toslink & Coaxial & Stereo R/ L & 3.5mm jack output at the same time,Can be used as digital to analog audio converter,hdmi ARC audio adapter;Digital coaxial to optical Toslink Bi-Directional converter (▲ Note:not support reverse use like Analog to Digital function)
• 【HDMI ARC Adapter (Audio Return Channel)】 HDMI ARC audio adapter can extract HDTV or projection audio that supports ARC and convert it to the audio format you need for output.( Note: If you need to use the HDMI ARC channel to transmit audio, the HDMI device (TV or projection, etc.) must support the ARC function and 19+1 HDMI cable require
• 【Audio Output Simultaneously】 This HDMI ARC Adapter can send audio from TV (Support ARC function) to Optical/ Coxial/ 3.5mm/ L/R audio through ARC Adapter via HDMI/ARC interface and out audio simultaneously. (▲ NOTE: It is Incompatible Dolby AC3/ Dolby Digital Plus etc., Please Set the Audio Output to PCM or LPCM before Using)
• 【Multiple types of audio output】HDMI ARC to Optical Toslink(SPDIF) RCA(L/R) Stereo Analog Outputs Audio 3.5mm Audio Output. Optical Toslink supports incoming 2.0CH, 5.1CH Dolby Digital, DTS (Note: Not support Dolby Digital Plus and above); ▲ Note: If you are using stereo R/ L or 3.5mm jack output, this unit can only support LPCM/ PCM audio format input(Note: Dolby is not supported at this time)
• 【Plug and Play】Easy to Install and simple to operate. Perfect audio converter DAC and HDMI ARC adapter extractor for television to output audio to soundbar, amplifier, speakers or headset (▲ Note:After connect this HDMI ARC DAC Adapter,the signal converter can not adjust receiver's volume).

User questions & answers

Question:	Can this extract audio from an hdmi capable that is plugged into the hdmi output of source equipment
Answer:	this hdmi arc extractor It is to extract audio from the HDMI port that supports ARC function to the fiber/coaxial/RL channels/3.5 jack output sound, you need to confirm whether your HDMI port has ARC function to output to corresponding receiving device. If without ARC function,please check ASIN: B06XDNJ6RM (supports 1080p) or B06ZYN46VK (supports 4K), which can extract audio directly from the hdmi port. Please contact us with any questions:https://www.amazon.com/hz/help/contact/A3GE4HK1J73CN8?marketplaceID=ATVPDKIKX0DER&sellerID=A3GE4HK1J73CN8&_encoding=UTF8&ref_=v_sp_contact_seller&
Question:	After I connect this unit, can I use the remote control of the firestick to control the volume
Answer:	yes, your remote control works the same as before. I have connected the device to external speakers set that have volume control and amplifier. The audio adapter works both with fiber optic and HDMI ARC.
Question:	My power was disconnected and the wires were accidentally disconnected. The wire was stuck in the gap in the table and I accidentally torn it. Does th
Answer:	Hi, I suggest you contact the seller directly so that you can resolve your issue faster.
Question:	my tv have arc port and toslink port, will this works with all?can this converter support dolby
Answer:	support HDMI arc or toslink input as signal source,need select correct position,A-->hdmi arc,T-->Toslink,C--->coaxial,toslink port support 5.1CH Dolby Digital any problem please contact:https://www.amazon.com/hz/help/contact/A3GE4HK1J73CN8?marketplaceID=ATVPDKIKX0DER&sellerID=A3GE4HK1J73CN8&_encoding=UTF8&ref_=v_sp_contact_seller&

Product description

Features:

Digital to Analog Audio Converter, Convert Coaxial/ Toslink/ Optical to Analog L/R Audio, with 3.5mm Audio Output, It can Connect to the Headphone, Headphone Amplifier Function.

With IR wireless remote control, easily adjust volume/ choose coaxial or toslink input/ Mute/ Power ON or OFF by using the IR wireless remote. In order to received signal better please make sure the remote is facing the infrared IR indicator on the converter.

Supports 192kHz, 2.4Bit sampling rate.

Aluminum Metal case, lightweight and compact. Anti-interference function makes the sound pure and clear.



Specification:

Support Audio Format: PCM

Signal-to-Noise Ratio: 105DB

Separating Degree（1KHZ）: 94DB

THD+N: -90DB

Total Harmonic Distortion(THD): 10Hz~20KHz 0.25-0.065%

Blocking Time: 0.577Fs

Sampling Rate: 32~192 KHz

Bit Rate: 16~24 Bit

Input Electrical Level: ±0.3V

Output Electrical Level: 3V

Maximum Output Power: 0.3W

Earphone Output Power: 0-250mW

Output Impedance: 10 ohms

Working Voltage: +5V

Dimension: 4.54" x 2.45" x 0.76"

Weight: 160g

Please NOTE:

1. SET your TV's Audio Output to the PCM/LPCM Format.

2. This converter doesn't Support 5.1 Channel Such As Dolby and DTS.

3. PS4 Pro and PS4 Slim CANNOT use this converter as they haven't Optical fiber output interface.

4. For Samsung TV, if there is no sound even you set the audio output to the PCM/LPCM format, please turn ON the TV external speakers (Menus-Sounds- Speaker Setup- HESB/external speaker-ON)

Package Includes:

1 x Digital to Analog Audio Converter

1 x IR Remote Control

1 x Toslink Cable (Optical Cable)

1 x USB Cable

1 x User Manual

• 【Digital to Analog Audio Converter】-- It converts Coaxial/Toslink/Optical to Analog L/R audio with 3.5mm audio output, ( NOT capable of being reversed); It can be connected to the headphone, headphone Amplifier
• 【Supports Mainstream Digital Optical/Coaxial Input】-- Provides electromagnetic-noise-free transmission, Supports sampling rate at 32, 44.1, 48, 96,192khz, and 24-Bit SPDIF incoming bitstream to left and right channels
• 【Supports 2 Channel LPCM or PCM Digital Audio Signal】-- Some TV may have PCM/LPCM as the default setting. Otherwise, please set it to PCM or LPCM as below: Setting--Sound--Audio Format, such as Samsung TV, LG TV. (Not support Dolby, DTS, or other 5.1 channel surround sound signals)
• 【IR Remote Control】-- With IR Remote control, you can easily adjust volume/choose coaxial or toslink input/mute/power on or off; No need to leave the comfortable sofa. (In order to receive signal better, please aim at the infrared IR indicator on the converter when using the remote control), it can increase or decrease 40db based on the original output volume (without headphone connected)
• 【Toslink Cable+Coaxial cable+USB Charger】-- Two cables are included for most devices, Compatible with HD TV, PS3, PS4, Xbox One, HD DVD, Sky HD, Apple TV, Plasma, Blu-Ray, Home Cinema Systems, AV Amps, etc. USB charger for power is included also

User questions & answers

Question:	What batteries do you need and how much do they cost
Answer:	Do you mean the battery for remote control? It is CR2025 cell battery. You can find it on amazon.
Question:	What kind of tv headset is compatabile with the Samsung smart tv series 5 49 inch
Answer:	It can work with 3.5mm TRS standard headset.
Question:	What is amps of wall charger
Answer:	It is 5V1A
Question:	Can i hook a older soundbar to a newer LG tv
Answer:	If your TV has an optical interface and the soundbar has left and right channels, you can use it

Product features

Specification

• Support Audio Format: PCM/LPCM
• Sampling Rate: 32~192 KHz
• Bit Rate: 16~24 Bit
• Maximum Output Power: 0.3W
• Earphone Output Power: 0-138mW
• Output Impedance: 10 ohms
• Working Voltage: +5V

IR Remote Control

1. Adjust volume for up or down (Increase or decrease 40db based on the original output volume)
2. Note: The sound will be low if you connect L/R Channel and headphone at the same time.
3. Select coaxial or toslink input
4. Turn ON/OFF the Converter

PCM/LPCM only

It is important that the digital audio output of your device defaults to or can be set to PCM/LPCM output. Otherwise the sound output will be noise/static.

Settings mode

Device main page -- system settings-- image and sound -- sound settings -- digital audio output -- PCM/LPCM

Package

• 1 * Digital to Analog Audio Converter
• 1 * IR Remote Control
• 1 * 1.5m Toslink Cable (Optical Cable)
• 1 * 1.5m Coaxial Cable
• 1 * USB Cable
• 1 * USB Charger
• 1 * User Manual

Product description

All ESYNIC Product Comes with 18-Month WarrantyOverview:

1. This ESYNIC DAC converter, easily convert Coaxial/Toslink/Optical to RCA analog audio interface and Connects to an External Device Such as an Amplifier via 3.5mm Headphone Jack.

2. Supports 192kHz, 2.4Bit sampling rate, with Volume Adjustment Control.Features:

1. Toslink & Coaxial Input Interface: Connect to DVD, HD player or other devices.

2. RCA Output Interface: Connect to the audio amplification device with RCA interface.

3. 3.5mm Audio Output Interface: Connect to your headphone.

4. Eliminates the noise when no input signal and automatically mute when input non-audio signal.

5. Supports sampling rate at 192kHz 24bit, Supports Volume Adjustment.

6. Aluminum Metal case, lightweight and compact. Anti-interference function makes the sound pure and clear.Specification:

Support Audio Format: PCM

Signal-to-Noise Ratio: 105DB

Separating Degree（1KHZ）: 94DB

THD+N: -90DB

Total Harmonic Distortion(THD): 10Hz~20KHz 0.25-0.065%

Blocking Time: 0.577Fs

Sampling Rate: 32~192 KHz

Frequency: 99.99Hz/999.9Hz/9.999kHz/99.99kHz/999.9kHz/9.999MHz ±(0.1%+2)

Duty Cycle:1-99%,±(0.8%+2)

Range Selection: Auto / Manual Ranging

Max Display: 6000 counts

Sample Rate: 3 times/s

Bit Rate: 16~24 Bit

Input Electrical Level: ±0.3V

Output Electrical Level: 3V

Maximum Output Power: 0.3W

Earphone Output Power: 0-250mW

Output Impedance: 10 ohms

Working Voltage: +5V.Maximum Voltage:6V

Maximum Power Consumption: 100mA

Operating Temperature Range: -10-70℃

Torage Temperature Range: -60-150℃

Operating Humidity Range: 10% - 80%RH（No Condensation

ESD Protection Human Body Model: ±8kV(Air-gap Discharge) ±4kV(Contact Discharge) Package Content:

1 x Digital to Analog Audio Converter

1 x Toslink Cable (Optical Cable)

1 x Power Adapter

1 x User Manual

• 【eSynic 192KHz Digital to Analog Audio Converter】Converts Digital Coaxial/Toslink/Optical PCM Audio Signals to Analog L/R Audio and 3.5mm Audio Signals Output.
• 【Supports Volume Adjustment】Professional Audio Amplifier Chip and Volume Adjusting Knob, Allowing You to Drive Your Headphone Directly and Adjust the Output Volume. A Similar Amp function allows You Adjust the Headphone Jack and RCA Interface Volume Simultaneously.
• 【192kHz 24-bit Sampling Rate】Supports Sampling Rate at 32, 44.1, 48, 96 and 192kHz, and 24-bit S/PDIF Incoming Bit Stream on Left and Right Channels. Provides Electromagnetic-noise-free Transmission.
• 【Aluminum Alloy Shell with Power Adapter】Aluminum Alloy Shell and Gold Plated Interface Design Improve Overall Anti-Interference And Makes The Sound Pure And Clear, Comes with 5V/1A Adapter, Enhance HD Sound Signals over Long Distance Broadcasting Smoothly.
• 【Audio Format: PCM/LPCM】Easily Install and Operate, Suitable for PS3 HD DVD PS4 Sky HD Plasma Blu-ray Home Cinema(NOTE: Not Compatible with 5.1 Channel Signal (Such as Dolby AC3), Please Set the Audio Output to PCM or LPCM Before Using the Item.)

Product features

192kHz DAC Converter Support Volume Adjustment.

This eSynic DAC converter, easily convert Coaxial/Toslink/Optical to RCA analog audio interface and connects to an External Device such as an Amplifier via 3.5mm Headphone Jack.

Volume Adjustment Control

The volume adjustment knob can be used to adjust the volume of the earphone jack and the RCA interface at the same time.

Aluminum Alloy Shell

Aluminium alloy case with gold plated interface provides good anti-interference and makes the sound pure and clear.

Digital to Analog Audio Converter with DC 5V 1A USB Power Plug

Comes with 5V/1A Adapter, Enhance HD Sound Signals over Long Distance Broadcasting Smoothly. (In Order To Ensure the Normal Operation of the Product, Please Use the Official Standard 5V 1A Adapter To Power the DAC Conerter. )

• Input Electrical Level: ±0.3V
• Output Electrical Level: 3V
• Maximum Output Power: 0.3W
• Working Voltage: +5V
• Maximum Voltage:6V
• Maximum Power Consumption: 100mA

Product description

Overview:

It converts Coaxial or Toslink digital audio signals to analog L/R RCA and 3.5mm Jack audio.

It also can be used for PS3, XBox, Blue-ray player, HD DVD, etc. which have no RCA(L/R) outputs or 3.5mm Jack output.

Feature:

Available for connection to an external device such as an amplifier via standard RCA jacks or a headphone via 3.5mm jack cable

Support sampling rate at 32,44.1,48 and 96KHz

Provide electromagnetic-noise-free transmission

Specification:

Color: Black

Housing: Full Metal

Input audio connector: 1 x Toslink,1 x RCA (Coaxial)

Output audio connector: 2 x RCA(R/L), 1 x 3.5mm Jack

Dimension: 48 x 48 x 20 mm

Weight: 72g

Package Included:

1 x DA converter with 3.5mm jack

1 x Toslink cable (Optical cable)

1 x USB Power Cable

1 x User Manual

Notice:

1. This DAC supports digital PCM or LPCM audio format, Please kindly set your digital audio device such as TV, TV BOX, or game console into PCM or LPCM audio before using, NOT support DTS ,Dolby AC3. Setting Path：Device Homepage -- System Setting -- Image and Sound -- Voice Setting -- Digital Audio Output -- PCM/LPCM.

2. If there is still no sound even after your TV is set to PCM/ LPCM Audio Format, please turn on the external speakers of your TV (It may happen to Samsung TV etc), or test the DAC by connecting PS3, Xbox. Setting Path:Menu -- Sound -- Speaker Settings -- External Speakers -- ON.

3. If the volume (from DAC output) is not loud enough, please connect the output of DAC with low-impedance cellphone headset, headphone amplifier, or power amplifier.

Warranty,Every LiNKFOR Product will be Backed with 18-month-warranty and Lifetime Customer Support

• 【DAC Converter】 It Converts Coaxial or Toslink Digital Audio Signals to Analog L/R Audio and Available for Connection to an External Device (NOTE: It is Incompatible with 5.1 Channel Signal Such as Dolby AC3, DTS, Please Set the output Audio mode of the device to PCM or LPCM before Using)
• 【Supports Mainstream Digital Optical/Coaxial Input】 Sampling Rate at 32, 44.1, 48, and 96 KHz, 24-bit S/PDIF Incoming Bit Stream on Left and Right Channels
• 【Multi-Point Connection】 The Adapter Output RCA L/R and 3.5mm Jack Simultaneously, You can Play Music and Share at the Same Time
• 【High-grade Aluminum Alloy Design】 Overall Shielding without Signal Interference, Gold Plated Sockets, Ensure high-quality audio signal to send
• 【Plug and Play】 No Need to Install Drivers, Easy to Install and Operate; Also, Compact Size, Easy to Carry, Ideal for Home or Professional Audio Switching.Warranty,Every LiNKFOR Product will be Backed with 18-month-warranty and Lifetime Customer Support

User questions & answers

Question:	If I am watching tv with analog headphones on using this converter, will others in the room be able to hear the tv
Answer:	Might depend on the TV. On a Samsung TV, once you plug in an optical cord it shuts off the internal sound ability. You usually get a 'fixed' line out so your volume control on the TV will be ineffective - so you will probably need a headphone amp with volume controls if you are attaching headphones - or you'll just get 'loud'.
Question:	Does this component work with a 50" led samsung? apparently it's a whole thing for these audio converters to be incompatible with samsungs. https://ww
Answer:	Thanks for your asking. For your problem,yes it will work great ,Please follow our setting steps when you use the product you need to change the Audio format to PCM/LPCM and change you TV to the external speaker setting it will work . All our products have full 18 months warranty, if there is any problem,we will try our best to solve, please rest assured. Anne LiNKFOR Customer Service Team [email protected]
Question:	Just purchased a 2018 samsung un55nu800d. it has an digital audio (optical) out. i have an older amplifier which is rca in. will this work
Answer:	Yes it will. My LG TV has optical out to my older Bose amp which is RCA in and it works perfectly. But it does require a USB port on the TV for power.
Question:	dose this unit need an external power source
Answer:	Yes ,our product has the USB power cable,so you need to use the external power plug. We advice that you use the 5V 1A USB Plus to power the product.

Product description

Easily convert digital audio signals (Coaxial and SPDIF Optical Toslink) to analog audio (RCA L/R and 3.5mm jack) simultaneously, support uncompressed 2-channel LPCM or PCM digital audio signal output, and electromagnetic-noise-free Transmission.

Support sampling rate at 32KHz, 44.1KHz, 48KHz and 96KHz; 24-bit S/PDIF incoming bit stream on left and right channels

Kindly note: Please set the audio output to PCM or LPCM on your devices

What's Included

1 X Digital to Analog Audio Converter

1 X Toslink cable (Optical cable)

1 x 5V Power adapter

1 X User Manual

OK!

• 【Digital-to-Analog】Simple solution to convert digital coaxial or optical audio to 3.5mm jack or RCA L/R analog audio signal (not capable of being reversed)
• 【Plug and play】Optical or digital coaxial audio output from your source devices (such as HDTV) to this converter, then RCA L/R or 3.5mm AUX to your headphone or stereo speaker (Please set PCM/LPCM audio when using)
• 【Simple Settings】Just set the audio format to uncompressed 2-channel LPCM or PCM in your TV or other source devices. Sampling rate support 32KHz, 44.1KHz, 48KHz, 96KHz and 192KHz 24-bit
• 【Durable Quality】Heavy-duty aluminum alloy enclosure protects the insides and keeps the unit cool by aiding in quick heat absorption and dissipation
• 【100% Satisfaction Guarantee】Years of experience in audio & video products allows us to have the ability to provide you with premium quality products and professional support services. If you have any questions before or after purchase, please feel free to reach out to us on Amazon or Google, 100% satisfaction guarantee!

User questions & answers

Question:	I'm experiencing brief drop in audio output about every 15 minutes when listening to a cd on a sony ubp-x800. player is set to pcm. any idea why
Answer:	I set my DVD player & TV sound output to RAW. It didn't sound that good when I had it set on PCM. Don't know if this will fix the problem, but its worth a try.
Question:	It looks like this will convert the digital audio out from TV to rca inputs to my receiver/amplifier. Is the signal at receiver level or just speakers
Answer:	This is just a digital audio signal into an analog audio signal, no video.Just the speakers.
Question:	Tv has only optical port for audio.My stereo amp only coax. On this product i see only one coux out. will i get mono or stereo? Thank you
Answer:	First, there is no coax "OUT" port on this device, only coax in. The red and white RCA connections give you the left and right stereo audio signals after conversion from the optical fiber input connected to the TV. Unless you have a most unusual stereo amp, you have multiple choices on the back of the amp for RCA left and right audio connections. Using a standard audio jumper cable with the red and white RCA connectors on both ends, hook this box to an unused port ( ie Tape), select that input for the amp and you should be good.
Question:	how long can you leave it on
Answer:	I bought this converter a few months ago to use for connecting an HDTV to an old analog stereo receiver for better quality audio instead of the horrible audio from the built in TV speakers. We leave it on 24/7 watching movies from the hard drive on our PC, Netflix, Amazon movies and for our DVD player. When we leave the house we always put a movie on and set our media player to loop so it stays on as long as we are gone IT HAS NEVER BEEN TURNED OFF.. IT HAS WORKED FLAWLESSLY AND SEEMS TO BE THE BEST DEVICE FOR THE PRICE I HAVE EVER PURCHASED..

• Digital to Analog Audio Decoder: Support Dolby DTS Dolby AC3 5.1CH Decoding; Support Optical/SPDIF/Coaxial/Dolby 5.1CH/DTS/PCM2.0 to L/R RCA 2.0CH Analog audio out.
• High-performance Decoding Chip: L/R interface support L/R dual channel analog output; Support 192k_24bit format lossless decoding, basically no volume loss and improve sound quality.
• Good input/output interface ensures good contact and no noise. You may adjust the output volume by 20-level tuning.You can switch optical/coaxial input via dial switch.
• 1xMini USB power Cable; 1xOptical Cable 4.0 (1m);1x3.5mm Jack to 2x RCA Plugs include in package for Prozor DAC with DTS/Dolby Decoder.
• Application: Digital to Analog Audio Converter With DTS/Dolby Decoder widely used with TV, computer, set-top box, PS4, XBOX and other equipment to expand the lossless sound system.

User questions & answers

Question:	Will this work on Samsung 43 7100 series TV
Answer:	It will work on any TV or audio device with digital output
Question:	How does this hook up to 5.1 if it only has 2 RCA ports but my system has
Answer:	Buy three of them, or just cut the extra wires off.
Question:	What is the maximum distance over fiber? I need about 30m
Answer:	Thirty meters is really pushing it. Thirty feet maybe. Every thing I can find says the best bet is to get an optical to digital converter and run wired digital from the converter. The wire cable is much tougher than the fiber, and it will hold up longer. The connecting pieces are better (stronger) as well.
Question:	Will this work with an lg soundbar
Answer:	I don't own a soundbar. I tried using it on my home theater system to connect to my 4K tv and it only gave me sound thru 2 speakers.

Product features

PROZOR Digital to Analog Audio Converter with DTS/Dolby Decoder DAC Decode Converter

Digital fiber coaxial to analog digital conversion mode volume adjustment, support DTS Dolby AC3 5.1 channel audio decoding.

High-performance decoding of new chips and DACs, basically no volume loss, can adjust the volume, can improve the sound quality.

Support button to adjust the volume (20-level fine-tuning), support the DIP switch to switch the fiber or coaxial input mode.

Input coaxial port and output R/L port, good contact and no noise.

Digital to Analog Audio Decoder:

1. Support DTS Dolby AC3 5.1 channel audio decoding.

2. Support L/R dual channel analog output (RCA interface).

3. Support PCM and DTS/Dolby RAW, can decode 5.1 source to 2.0 channel output, improve sound quality, support 192k_24bit format lossless decoding.

4. Support button to adjust the volume (20-level fine-tuning), support the DIP switch to switch the fiber or coaxial input mode.

Connection:

Before installation,please make sure all devices you wish to connect have been turned off.

1).Connect the audio source device to the converter using appropriate Toslink or Coaxial cables.

2).Connect the AV receivers or Amplifiers to the converter using appropriate R/L cable.

3).Package material Audio Connector-2 x RCA Male/1 x 3.5mm Stereo Female

No Noise:

Input coaxial port and output R/L port, good contact without noise

Application:

Widely used with TV, computer, set-top box, PS4, XBOX and other equipment to expand the lossless sound system

Package:

1x Main unit(Digital to Analog Audio Converter With DTS/Dolby Decoder)

1xMini USB power Cable

1xUser manual

1xOptical Cable 4.0

1x3.5mm Jack to 2x RCA Plugs

Product description

Features: 1. One HDMI input convert to one HDMI + Audio (SPDIF+R/L) output. 2. One audio support: SPDIF + R/L analog Audio Output. 3. Input Resolution : Up to 1080P (50/60Hz)/ 720P/ 480P. 4. HDMI to achieve the synchronization of audio signal separation. There are PASS. 5. 2. 0CH/ 5. 1CH there kinds of audio mode options. 6. LED indication: When source of sink is working, LED relative to is light. 7. Supports Apple TV and various Blu-ray player. 8. No Signal Loss. 9. Need DC5V 1A power input (USB Cable Included). Specification: HDMI resolution : 24/50/60fs/1080p/1080i/720p/ 576p/576i/480p/480i Support video color format : 24bit deep color 30bit, 36bit Audio output : L/R+SPDIF Max bandwidth : 225MHz Max baud rate : 6. 75Gbps Input/Output TMDS signal : 0. 5~1. 5Volts p-p(TTL) Input/Output DDC signal : 5Volts p-p(TTL) Input cable distance : How to Use: 1. HD Source connects to the input HDMI port. 2. HD Display connects to the output HDMI port. 3. Audio equipment connects to the R/L port. 4. The optical cable of Audio equipment connects to the SPDIF port. 5. Plug the 5V 1A DC power adapter. Package Content: 1 x HDMI Converter 1 x USB Power Cable 1 x User Manual

• 【1080P HDMI to HDMI Audio Extractor】One HDMI Input Convert to One HDMI + Audio (SPDIF+R/L + 3.5mm Analog Audio) Output. (Powering Advice: Using a Good Quality 5V/1A Mobile Phone or Tablet Adapter Via the USB Power Cable to Power the Converter)
• 【Gold-plated Connector + Power ON/OFF Switch】Metal Casing Design, Overall Shielding without Signal Interference, Gold Plated Connector, Enhance HD Video Signals. Power ON/OFF Switch for Turning On/ Off Our Extractor, Protect Its Service Life.
• 【3 Audio Mode Options】with Pass, 2CH and 5. 1CH Three Audio Mode Options, SPDIF Output Supports Pass 2CH PCM, 5. 1CH Dolby Digital, DTS (Dolby Digital Plus not Supported); Analog RCA L/R and 3.5mm Jack Output Supports 2CH PCM Stereo Audio.
• 【1080P High HDMI Resolution】Supports HDCP 1. 3, Video EDID Pass Through, Up to Full HD 1080P, Compatible with 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i. (Not Compatible with HDCP 1. 4 4K and Fire TV, Fire TV Stick)
• 【Wide Compatibility】Support 24 bit/Deep Color 30bit, 36bit per Channel (36bit all Channel) Deep Color. Compatible with Blu-ray DVD Player HD box Apple TV PS3 PS4(Note: Do NOT Plug TV to HDMI IN Port Because Our Extractor Support the HDMI ARC Function.)

User questions & answers

Question:	Does this require power? what if there isn't a usb connection near by
Answer:	Plugging it in with hdmi cable turned to power on for me. I have it hooked up to my PS3 and had to use the usb plug in order to get the images to show up on my tv. I plugged the usb where the remote connects and had to run an hdmi from ps3 to box and one from the box to the tv. I am using it to plug in my sound bar. Because my tv doesn't have an optical cord connection. I hope this helps.
Question:	Tv only has input (no output) options. it has an hdmi connection. will the box connect tv hdmi to box input & then box optical to sound bar optical
Answer:	Yes,it can be connected in this way. Connection: TV BOX --- HDMI Cable --- HDMI Input --- HDMI Audio Extractor --- HDMI Ouput --- HD TV, Spdif Output --- Optical Cable --- Sound bar.Kindly note that our HDMI audio converter can only support 1080P@60Hz resolution. If the source device you used is 4K@60hz (HDMI 2.0 and HDCP2.2), please set the resolution of your input device to 1080p@60hz or 720P@60Hz to try.
Question:	I see it works with game systems and firesticks. Will it work with a cable box
Answer:	jusst as long as your cable box has a HDMI port it will work
Question:	Will this work with a PC/Mac
Answer:	Yes, it can. But please kindly note that the PC/Mac just can be a input device to connect to our converter, please check if your pc or mac has the HDMI output interface, if yes, it can work.

• 【Analog to Digital Converter】 Convert R / L RCA or 3.5mm Jack analog stereo audio signal into digital coaxial audio and Toslink Spdif Optical digital audio at the same time. ▲ Note: This is not a digital-to-analog audio converter.
• 【8-96KHz Sampling Rate】Support uncompressed 2-channel LPCM digital audio signal output, and support 8-96 KHz output sampling rate. With the latest aluminum frame shell, it is more durable and provides better heat dissipation performance.
• 【Plug and Play】Easy to install and easy to operate. You only need to connect your analog-to-digital audio converter and power adapter to use. ▲ Note: Please select PCM / LPCM format on the TV, and then turn off the Dolby sound (eg Dolby Digital, DTS 5.1, Dolby-AC3).
• 【Broad Compatibility】Hdiwousp ADC converter is compatible with devices with RCA plug or 3.5mm jack output, such as PS3 / MP3 / DVD player / smartphone / laptop / TV / radio / digital audio receiver / home theater system etc.
• 【You Will Get】1x analog to digital audio converter, 1x fiber optic cable, 1x user manual, 1x power adapter. In addition, we also provide you with friendly and convenient customer service to solve your problems in a timely manner. If you have any questions, please contact us, we will deal with them immediately within 24 hours.

User questions & answers

Question:	I have an old teac ad-600 cassette/cd player(rca analog) and want to play it thru an old yamaha htr-4066, via the optical or coaxial ports. work
Answer:	I’m not familiar with your specific devices... but this little unit will take your analog output and turn it into a signal that will feed into an optical port... and for twenty bucks what do you have to loose😉
Question:	Will it improve the sound quality of my old TV
Answer:	I wouldn't think so, unless the rca inputs on your tv are damaged. It's not adding anything to the audio signal, just converting it from analog to digital. A process that's inherently lossy, as you have to sample the signal for the conversion. It does do a nice job, especially for the price. I'm happy with mine, but I wouldn't purchase it expecting it to enhance anything. Some avrs have features like that though.
Question:	My newly bought tv has dolby settings. does it support dolby sound
Answer:	haven't tried it, but I think it is not supported.
Question:	how long is the optical cable
Answer:	About 12”

Product features

Additional Cables

• Package included: fiber optic cable, USB power supply, 5V1A power adapter, friendly user manual

Built-in High-quality Chipset

• Built-in high-quality chip, signal transmission is more stable!

Aluminium Material

• Aluminum shell, effectively reduce surrounding signal interference, stronger and more durable!

Before using the product correctly, you have to read the precautions! ! !

• Device homepage- system sting-image and soun--voive setting dgital audio output-PCM/LPCM.
• If Samsung TV, please turn on its external speakers : menu - sound - speaker setings - extemal speakers - on.
