Product description

Module parameters Module Properties: non-isolated step-up module (BOOST) Input voltage: 10-32V Output voltage: continuously adjustable (12-35V) fixed output (arbitrary choice between 12-35V), purchase please tell the shopkeeper. Output Current: 10A (MAX) Input current: 16A (MAX) (more than 10A, please enhance heat dissipation,) Output power: natural cooling 100W (MAX), strengthening cooling 150W (MAX) real power use when deciding whether to make more practical circumstances plus the fan, be sure to ensure that the heat sink temperature does not exceed 80 degrees. Easy to drive 65W 90W including dual-core laptop Laptop module temperature with 12V battery with ordinary 19V 3.42A about 45 degrees Conversion efficiency: 94% (input 16V output 19V 2.5A when measured) (for reference only) Output Ripple: 2% (MAX) 20M-bandwidth Operating temperature: Industrial grade (-40 ° to + 80 °) (ambient temperature exceeds 40 degrees, lower power use, or plus fan) Full load temperature rise: 45 °

User questions & answers

Question:	Are these power converters regulated output? if input voltage drops will output voltage stay consistent
Answer:	The output voltage will not change if the input power is sufficient
Question:	Someone answered that to change the output voltage you adjust the potentiometer, but I don't see how to do that from the pictures
Answer:	There is a small pot and is easy to adjust
Question:	Can this be used as a step down converter by running it in rverse
Answer:	No you cannot run this reversed. If you do it can burn! All you can do is apply input voltage, say you applied at the input 12 volts you can increase your voltage at the out terminal by turning the potentiometer from about 9 volts to 45 volts. So it reduces first and then goes on increasing.
Question:	The module makes a long continuous beep sound when i connect it to my led. what does that mean? also, module only outputs 1a
Answer:	this module not applicable LED

Product description

Specifications:

Input voltage: 2V - 24V

Output voltage: 5V - 28V

Output current: max. 2A

Efficiency: > 93%

Size: 36 mm x 17 mm x 6.5 mm

Pin Definition: Input to IN-IN + / Output to OUT-OUT +



Warning:

1.Do not reverse the positive and negative poles to avoid any possible damage.

2.This module is only for raising the voltage; Input voltage should not be over than 24V to avoid any possible damage

3.Please make sure output voltage is stable before using the module to avoid any possible damage

4.Do not use without load or light load (less than 10% of output power) or connect too much things on one module

5.Do not connect too much load on the output voltage

6. Please use the heat sink when working for long hours.



Package includes:

6 x MT3608 Module

• 1.Input Voltage: DC 2V-24V; Output Voltage: DC 5V-28V; Maximum Output Current: 2A
• 2.Application: This converter is widely used for storage batteries, power transformers, DIY an output adjustable mobile power, like 5V, 9V, 12V, 28V output, etc.
• 3.Equipped with MT3608 voltage booster chip with high conversion efficiency up to 93%
• 4.Note: If the output voltage cannot be adjusted and always equal to the input voltage, please turn the potentiometer counterclockwise for more than 10 turns firstly.
• 5.MT3608 includes under-voltage lockout, current limiting, and thermal overload protection to prevent damage in the event of an output overload

User questions & answers

Question:	will these handle a 5v usb input to 8.4v output? can these handle typical ma output from a usb charger or small solar cell
Answer:	Yes they should work for your application. In my case, I have 3.7V input from a Li-ion battery and 5V output. The load is 30mA but peaks at 350mA under full load and the output does not sag.
Question:	Safe with a 9v battery
Answer:	Yes as long as the battery can supply the load current. Some users have reported that if the output voltage is set at the high end and the current demand is high, the converter can fail.
Question:	What are the physical dimensions of one boost converter, not the package? Thanks
Answer:	The dimensions are 1 3/8”L x 5/8”W x 1/4”H.
Question:	What is the minimum voltage boost this will control? i’m looking for .5-1vdc control only. thx
Answer:	I've only played with this so far, but it has given a steady state 1:1 voltage output. Don't know yet about dynamic response

Product description

10 Pieces MT3608 DC-DC boost converter 2A adjustable step up module voltage regulator board input voltage 2V-24V to 5V-28V output voltage



Specifications:

Maximum output current: 2A

Input voltage: 2V-24V

Maximum output voltage: 28V

Efficiency: 93% in maximum

(Minimum) (input-output) difference voltage when input is at (2 V and 50% of max-input-V), loading at (50% and full rated current).

Product size: 36 x 17 x 14 mm/ 1.42 x 0.67 x 0.55 inch (L x W x H)



Method of use:

The adjustment of potentiometer can adjust output voltage, output voltage is greater than the input voltage.



Package includes:

10 x MT3608 DC-DC step up power apply module



Attention:

The input voltage should not exceed the maximum input voltage.

The peak current output current no more than TV university.



Tips:

Reverse the potentiometer 20 times before taking the goods to test.

Some customers report that the output voltage of the module cannot be adjusted and is always equal to the input voltage. When you encounter this kind of problem, please turn the potentiometer counterclockwise for more than 10 turns, and then use the module to adjust the voltage normally.

• The maximum output current: 2A; The input voltage: 2V - 24V
• The maximum output voltage: 28V; Efficiency: max 93%; Product size: 36 x 17 x 14 mm/ 1.42 x 0.67 x 0.55 inch (L x W x H)
• Method of use: the module of the IN+ and - after 2-24V, IN adjusting the potentiometer can adjust output voltage, output voltage is greater than the input voltage
• Matters needing attention: 1. The input voltage should not exceed the maximum input voltage; 2. The peak current output current is no more than TV university
• Package included: 10 x MT3608 DC-DC step up power apply module booster power module, max output is 28V

User questions & answers

Question:	Can this be used to power an Arduino nano using an 18650 cell
Answer:	Yes. This will boost a 3.7vdc 18650 cell to an output voltage of 5vdc. You will need to carefully set the output voltage using the trim pot.
Question:	The boards came in one piece. What is the recommended method to separate them
Answer:	I flexed by hand them like you do with a cracker and they break exactly at the joint, I did it carefully and it worked in all instances I had to use a new board.
Question:	Can input voltage polarity be reversed back and forth on this converter to forward and reverse a dc motor connected to the output
Answer:	No! You can use it as isolated 5v supply for a stepper driver.
Question:	Does it need a heat sink when used for 5v to 12v? (2A
Answer:	It would help it transfer heat through the chips a lot better a small heat sink works great

Product description

Voltage and current correspondence:

Starting voltage 0.8V, output current 7MA

Input 1-1.5V, output 5V 40-100MA

Input 1.5-2V, output 5V 100-150MA

Input 2-3V, output 5V 150-380MA

Input more than 3V, output 5V 380-480MA



This is a voltage boost converter module. When using it, be sure to observe the following conditions:

The input voltage cannot be greater than the nominal voltage, otherwise the module will burn out

The input power must be greater than the output power, otherwise the output voltage will be less than the nominal voltage

The output load cannot be greater than the nominal load, otherwise the output voltage will be less than the nominal voltage



Note:

The installation of electronic modules requires basic knowledge and requires a certain electronic professional foundation and hands-on ability. Please purchase carefully!

Manual measurement, with small error. Please check size in detail before purchase.

Real colors may slightly differ from the pictures, as it depends on specific monitor settings and light brightness.



We highly appreciate all customers opinions to improve the selling, also if anything you unsatisfied, please contact us for probable best solution.



Package Includes: 5Pcs

• DC-DC boost converter module, operating frequency 150KHZ, typical conversion efficiency of 85%.
• Pin 2.54MM pitch.
• Input voltage: 0.9-5V, output voltage: 5V, maximum output current: 480 mA.
• Dimensions: 11mm x 10.5mm x 7.5mm (ultra-small module, 1mm=0.0393inch)
• Weight: about 1g

Product description

DROK DC to DC Voltage Boost Converter



Parameters

Input voltage: DC 8V-60V

Input current: 0-15A

Output voltage: DC 10V-120V

Output current: 0-15A

Output ways : 1

Conversion efficiency: 85%

Working frequency: 150KHz

Short circuit protection: 20A fuse

Operating temperature :﹣40℃~+85℃



Features

1. Adopts advanced microprocessor, can regulate output voltage and current accurately;

2. Has a fan to dissipate heat, can work stably for a long term;

3. Has memory saving function, can store 10 groups of parameters and they can be freely stored and called out;

4. All display by digits, convenient and easy to use;

5. Has constant voltage and constant current;

6. Uses 4 digits high brightness LED, can display output voltage, current, power and capacity and other parameters;

7. Voltage, current, power, capacity and other parameters can be switched to display automatically or manually;

8. Can be set whether to output automatically when power on;

9. The set voltage and current values can be saved by key.



Note

1. It can only boost voltage.

2. There should not be a great deal of difference between input and output voltage. Or power loss will increase and actual output may not be as expected.

3. Actual output current is mainly decided by the load. Converter can only set a limit on output current.



Package

1 X Numerical Control Boost Converter

• Parameter --- Input voltage: DC 8-60V; Output voltage: DC 10-120V; Input current: 0-15A; Output current: 0-15A.
• Realtime LED Display & Indicators --- The transformer board is designed with bright 4-digit LED to display output voltage, current at default simple mode. By manual setting to fully functional mode, the stabilizer would show more parameters, such as power and capacity. Also the board is equipped with working indicators to show real-time working status.
• Data Save --- The boost converter can save up to 10 sets of parameter settings. It’s easy to save and very convenient to call out parameters at any time you would like to.
• Wide Application --- The step up power converter does great for wind power, DC generators, solar panels to charge battery, and it also can be made as a boost power supply to power devices.
• Notes --- 1) No big difference between input and output voltage. Otherwise the power loss will increase then the actual output may not be as what expected; 2) Actual output current is mainly decided by the load. Converter can only set a limit on output current; 3) When powering high-power appliances, please turn off the automatic output function, correctly connect the converter, and then press the "OK" button to output. After the voltage rises to the set voltage, turn on the appliances.

Product description

Good Function:

The high-voltage module output voltage current, small size , high efficiency, simple external circuit .



Specification:

Voltage: Input DC3.6-6V, output DC400kV - 600KV

High Type : Pulse Current

High voltage bipolar discharge distance : 10mm-20mm

Output voltage lines Length: about 100mm

Input power cable length: about 10mm ( red is positive )

Dimensions : |μ24 * 63mm



About Power :

3.7V Li-ion battery can be used single or two series ( to remove the for protection board , the proposed capacity of 2000mAh or more ) or NiCd / NiMH battery pack , 4V or 6V Lead Acid batteries.

Determine whether the battery capacity can be driven approach is the maximum power output of the battery when the voltage measurement arcing . If so you can 6V maximum power output .

Two sections of small capacity lithium series of 7.2V, measured arc voltage has dropped to about 4V state , the capacity of the smaller voltage pulled lower. It is recommended to use more than one lithium battery 2000mA , 4000mA best conditions with more battery .

Applications: Can be used as high school science experiments , electronic equipment, negative ion generator, high voltage source to use when making small science .

Commonly used in 105 high-voltage generator, high voltage ignition, teaching experiments



Note:

1.It should avoid the use of electricity in high voltage no-load . (Power must be adjusted to a suitable distance to the high-voltage output line , battery capacity is proportional to the distance and the use of the high-pressure arc (must provide enough current ) .



2. Experimental test of the arc distance from short to long , Do not exceed the maximum arc distance electricity.



3. Every power-on time should be controlled within a minute.

Package Included:

1x DC Boost Step-up Power Module

• [Output High Voltage] Our high-voltage generator module is based on the principle of Tesla Coil. It's small size and work with high efficiency, the voltage input 2 A-5 A, DC3.6-6V and output DC 400kV - 600KV. Please use it carefully.
• [Easy To Use] This small high efficiency module can release high- voltage pulse output with simple external circuit power supply. Just plug in the switch , the battery can be discharge intensity violent.
• [Green & Red Wire Connection] This high voltage generator with red and green power connection, red line:"+" , green line "-" output : the other side ,same color cable.
• [Proper Connected Distance] The distance between high pressure discharges is 10 mm-20 mm, output voltage lines Length is about 100mm. To avoid burning, use the time limit of 1 minute.
• [Widely Application] This high voltage generator is safety and can be used as the high voltage source for high school scientific experiment, negative ion generator, electronic salute, electronic instrument, negative ion generator and small scientific production.

Product description

XL6009 is a high-performance 4A switch current boost (BOOST) module. The module uses the second-generation high-frequency switching technology XL6009E1 as the core chip, far more than the first generation of technology performance LM2577. The XL6009 boost module features lower Cost and superior performance, and the LM2577 module is about to be eliminated. ● wide input voltage 3V ~ 32V, the best operating voltage range is 5 ~ 32V; ● Wide output voltage 5V ~ 35V; ● Built-in 4A high efficiency MOSFET switch, the efficiency of up to 94%; (LM2577 current of only 3A) ● high switching frequency of 400KHz, you can use a small capacity of the filter capacitor that can buy very good results, smaller ripple, smaller. (LM2577 frequency is only 50KHz)

User questions & answers

Question:	I received these today, they work ok, down to 9.5 volts, but i need them to go down to 5 volts, on a 3.3vdc input. what is needed to get 5vdc out
Answer:	This is the booster module，Test comparison sample reference: Input 5V output 12V 0.8A 9.6W Input 7.4V output 12V 1.5A 18W Input 12V output 15V 2A 30W Input 12V output 16V 2A 32W Input 12V output 18V 1.6A 28.8W Input 12V output 19V 1.5A 28.5W Input 12V output 24V 1A 24W Input 3V output 12V 0.4A 4.8W
Question:	Does this boost converter have any sort of input or output reverse protection; current protection; short circuit protection, or otherwise
Answer:	no,not have
Question:	Can these power supplies keep a constant output when the input voltage varies above and below the output
Answer:	As the previous answer indicated, these are boost only. This means that the input voltage must always be less than the output voltage. If you are interested in a power source that can keep a constant voltage with higher or lower voltage then the output, you can search Amazon for buck/boost converters. Their are quite a few available to cover most needs.
Question:	what would the maximum output of these be, say could they do 36v at 3.5 amps
Answer:	Listing spec says 4 amps and 35V out max.. You dont want to push the max on things typically. My educated guess is that it depends on the input voltage and I would cap the input current at 4A max . Think about the power in/out .. This thing doesnt make energy, it converts energy from one voltage to another higher voltage - at the expense of lower output current. At best its 94% efficient so it loses 6% in heat. For example if you needed 25VDC at 3A out , thats 75 watts, plus 4.5W heat loss (75W x 0.06) , so you need 79.5W input. If your input voltage is 12VDC, you need 79.5W of input power so that's 6.6 Amps (79.5W/12) - not likely, plus 4.5Watts of heat is a lot . Lets try an input of 20V , thats 79.5W/20 = 3.975A input ... might work for a while, still putting out 4.5W heat losses. Short of any better specs, I dont think I'd push it past 3A in or out and 60W of total power transfer for a long term solution but you can probably get out more if you have good airflow and its only peaking hard for say 1 or two minutes. Try it, observe temps, watch current input, if it starts running away getting higher and higher input current at same output then you are doomed, but if it fits your needs then its ok for a while at least. These seem to be good units generally, just need to understand the limitations. Also note that these have 50V in/out electrolytic caps. Thats good, some other brands have 35V caps and you need some margin if you are near 35V , its not good design to run at the max.

Product description

Parameters:

Module Name: 1200W Boost Constant Current Module(Non-isolated)

Input voltage: DC10-60V (direct input 10-60V without jumper cap selection voltage)

Input current: 20A (MAX) exceeds 15A, please add fan cooling (add fan input current can reach 25A when the fan input voltage is 12-24V)

Static working current: 15mA (12V liter 20V, the output voltage, the higher the current will increase too quiet)

Output voltage: 12-83V continuously adjustable (default output is adjusted to 19V shipment, please adjust to other voltage values.) 12-83V fixed output (for bulk customers)

Output current: 18A MAX More than 10A, please strengthen the heat dissipation (related to the input and output voltage difference, the larger the differential pressure, the smaller the output current)

Constant current range: 0.5-18A (+/-0.3A)

Low battery protection: yes (9-50V adjustable)

Working temperature: -40~+85 degrees (enhance heat dissipation when the ambient temperature is too high)

Working frequency: 150KHz

Conversion efficiency: 92%-97% (efficiency and input and output voltage, current, pressure related)

Input overcurrent protection: Yes (input over 25A, automatic protection, power does not boost)

Short circuit protection: Yes (input 30A fuse) Double short circuit protection, safer to use.

Input reverse connection protection: Yes (150A power MOS tube anti-reverse. Can be reversed for a long time)

Wiring method: 4 3mm copper columns, terminal block (please use high current pure copper wire)

Module size: length 130mm width 52mm height 53mm

Output power: = input voltage * 20A, such as: input 12V * 20A = 240W The maximum power when inputting 12V is 240W

Input voltage *20A For example: input 24V * 20A = 480W, that is: the maximum power is 480W when inputting 24V



Package Included:

1 x1200W 20A DC Converter Boost Power Supply Module

• 1200W 20A DC converter boost step-up power supply module 8-60V to 12-80V, it's a non-isolated boost power supply module
• Features:①Input overcurrent protection; ②Short circuit protection; ③Input reverse connection protection; ④Low battery protection
• Note: The maximum power is 240W when inputting 12V, the maximum power is 480W when inputting 24V, and the maximum power is 720W when inputting 36V
• Widely Application:① DIY a regulated power supply, input 12V, the output can be adjusted 12-80V; ②As a car power supply, power your laptop, PDA or a variety of digital products
• Widely Application:③DIY a high-power notebook mobile power; ④Solar panel voltage regulator; ⑤Drive high-power LED lights

User questions & answers

Question:	how do i set the max oputput current that i want to set
Answer:	as per this picture adjust the pot. in the top right corner to your requirements....Ted
Question:	what are the 3 potentiometers for and how do I adjust them? What does it mean when the red led light closer to the input light up? Voltage too low
Answer:	The three potentiometers are to allow you to adjust the output voltage set point, the output current limit point and the input under voltage fault point. The red fault light will turn on when the input voltage is below the set under voltage fault point. Under voltage is intended to protect your supply battery by preventing the battery from over discharging. The instructions provided state, "With the input connected, turn the UV (under voltage) pot counter-clockwise until the fault light turns off. It may take up to 30 rotations."
Question:	Can i hook this up to a atx power supply behind a digital voltmeter and ammeter display and adjust the volts with display module
Answer:	Yes, you can
Question:	Can someone please send me some instructions and or pinout diagram for this item? I just ain’t getting it. If I need an electrical engineer to operate
Answer:	I doubt you can find any instructions or datasheet from whatever vender is selling these mass produced Chinese modules. Im sure YouTube has some videos on using these or very similar boost modules.

Product description

Features: This is a non-isolated DC power converter module with long service life. High power and stable output, it converts 10-60VDC to 12-97VDC. High quality components ensures high conversion efficiency, up to 97% Designed with smart temperature control fan, which will automatically work when temperature reaches about 60℃, and stop when temperature drops below 60℃. Widely used for high power solar street lamp driving, various LED lighting CV driving, vehicle-mounted and mobile device power supply, DIY adjustable CV CC power supply, solar power charging, and various batteries charging. Specification: Name: 1500W step up constant current module Type: Non-isolated step-up module (BOOST) Input Voltage: DC10V to 60V Input Current: 10V-30V input voltage, maximum current is 35A-40A; 31-60V input voltage, maximum current is 30A-35A Quiescent Current: 15mA(when convert 12V to 20V, higher output voltage will increase quiescent current) Output Voltage: 12-97V continuously adjustable (cannot be used to step down voltage) Output Current: 22A (related to the input and output voltage difference, the greater voltage difference is, the smaller output current will be. please enhance heat dissipation when current is over 15A) Constant Current Range: 0.8-22A(+/-0.3A) Reverse Input Protection: Yes (150A power MOS reverse protection) Input Low Voltage Protection: Yes (10V-50V adjustable, self-recovery) Operating Temperature: -40℃ to 85℃(if temperature is too high, please enhance heat dissipation) Frequency: 150KHz Conversion Efficiency: 92% to 97% (Efficiency is related to input/output voltage, current and voltage difference. The smaller difference is, the higher efficiency will be) Input Over Current Protection: Yes (automatically protect when input is more than 40A, and power supply voltage will not increase) Short Circuit Protection: Yes (input 60A fuse) please operate carefully, try not to cau

User questions & answers

Question:	I have a 60v speed controller, can i use this before the speed controller
Answer:	DC-DC boost constant voltage constant current adjustable power module 12-60V liter 12-90V
Question:	So if i only input 12v 5a this will output 48v 10amp
Answer:	If your input is 12V 5A = 60W the output at 48V will be at best 1.21A @ 97% efficiency. The output power can NEVER be higher than the input power (Watt)
Question:	Can this be used to power a variable speed motor
Answer:	Depends on the type of "variable speed motor" if it's a brushless type motor then no, it requires a actual brushless speed controller. If it's a brushed type motor, that falls within the amperage and voltage rating of this boost converter- then yes you most likely would be able to.

• PARAMETER --- buck boost converter, input voltage range 5.5-30V; output voltage range 0.5-30V; working current 4A; power 35W.
• APPLICATION --- as a normal boost buck converter module with over-current protection; as a battery charger; as a high-power LED constant current driver module, etc.
• PROTECTION --- soft start; input reverse connection protection; output anti-backflow protection; short-circuit protection; over-current protection; over-power protection; over-temperature protection.
• DISPLAY --- clear LCD screen displays input voltage, output voltage, temperature, output current & output power (switched by button).
• OTHER FEATURES --- with buttons to switch displayed parameter & set output ON/OFF; with CC & CV potentiometer; with protective case (needs to be manually assembled); with LC filter.

User questions & answers

Question:	Can this be set to always power on in CC mode
Answer:	If you're asking whether the voltage and current reset when the device is powered down, then the answer is no. The device will have the same output when powered back up because voltage and current are adjusted mechanically (w/ a small flathead screwdriver), not digitally, so the "constant" part really does mean constant in the physical sense, as long the supplied voltage and current remain high enough to provide desired output.
Question:	What does opp error mean
Answer:	Dear customer, OPP:Over-power Protection When output power reaches 35W, OPP will be enable. Best regards.
Question:	I need to increase voltage from 11V to 15V, can it do it
Answer:	Yes this will work. This morning I needed to run 2 12V PC fans from a USB 2.0 port. It worked drawing around 400mA.
Question:	How would i use this as a constant voltage supply if i don’t want a constant current supply (eg, i don’t want to accidentally spike the output v
Answer:	For me this has been a marvelously useful device. I power it with the charger "brick" from a retired laptop PC, capable of as much as a couple amps at 25VDC. The specifications don't make it clear, but you independently set the maximum output current and output voltage using the on-board 10-turn pots while monitoring it on the display. For example when charging a lithium-ion battery, its specs might suggest a the maximum charging current of 0.5A and maximum output voltage of 4.2V. So first, you set the open-circuit voltage to 4.2V. Turn the output current to minimum and connect the batery. Assuming the battery is pretty well discharged, when you first connect it you could potentially sink as much as several amps but that would hurt the battery. No problem, you've set the current to minimum (a few mA). When you connect the battery, turn up the current to 0.5A; the voltage will rise as you turn up the current, probably settling around 3.5V. (I am assuming that your power source will easily supply the required power.) As the battery charges, the voltage will gradually increase to 4.2V while the current stays at 0.5A. But once the voltage gets close to 4.2V the current will start to taper off. If left for several hours the voltage will still be at 4.2V but the current will be only a few mA. So the supply acts like constant current, then transitions to constant voltage. I hope this answers your question. I haven't seen any evidence of loss of control over either output voltage or current. FYI it's worthwhile to experiment with the unit connected to an output load resistor first, to get an understanding of which buttons to press to read the desired values. From memory, you can read input voltage and current, temperature of the heat sink in F or C, and output voltage and current. And you can also read output voltage independent of supplying power to the load (i.e. it can act like a voltmeter).

Product features

Integrity, Quality, Innovation, Customer" --- DROK

DROK has been engaged in technical research, development, manufacture and sale of all kinds of boost buck converters for many years.

With acquisition of leading technology, we strictly enforce quality management system and improve operational management, dedicate to produce high performance meters for customers.

Enjoy life, enjoy DIY, enjoy spare time with DROK components.

Product description

Product Description:

Automatic boost module provide a stable power supply.Applicable to unstable voltage source or voltage conversion.



Performance parameters:

Input voltage range:3~35VDC(Note: the input voltage is less than 4V, voltmeter failure)

Input current:9A (max)

Output voltage range:3.5~35VDC(please to ensure that output voltage above on input voltage)

Output current: 6A (max)

Output power: 75W (when the input and output voltages greater than 20V up to 128W)

Conversion efficiency: 96.4% (max)

Voltmeter range: 4 to 40V, error ±0.1V

Short circuit protection: yes(limit current 14A). (Note: connected to high-power load, just switched on the impact of current very general meeting current limiting self-locking protection, it is recommended to be switched on firstly, and then access the load).

Input reverse polarity protection: None (if required, high current diode in series with the input).

Size: 67 * 43 * 12mm (L x W x H)



Use manual:

Connect load at OUT+ and OUT- at first.Please note the positive and negative.

Connect power supply at IN+ and IN-.Please note the positive and negative.

Press the button to switch the display input or output voltage value.



Warm tip:

When the high power load is connected, because the shock current of the start-up is very limited, it is recommended to start up and then connect the load.



Application:

DIY a regulated power supply, 5V input can be output 5-35V adjustable.

The power supply for your electronic equipment. For example, 3.7V lithium boost to 5V for mobile power; 7.4V or 12V boost to the laptop power supply to 19V.

As the vehicle power supply for your laptop, PDA or a variety of digital products supply. Frequency asked questions:

1>. Can it output 35V at 6A?

Q : No,it can not.The output max is 100W.Only 75W for stable operation.

• No user/operator instructions or data sheets.Find the download data by yourself, please make sure you consider whether you know the operation before buying. Size: 68x42x14mm, LTC1871 IC with External MOSFET.
• Conversion Efficiency: Up to 96%. Low input voltage or a large difference between input and output voltage will degrade the current capacity and efficiency.
• Boost voltage to a stable regulated output. Useful for a wide range of applications, such as powering 5V USB devices from a 3.7V lithium cell, powering higher powered electronics from a 12V battery, and a wide range of automotive and electronic projects. Constant voltage regulation, not for raw LEDs.
• Button to switch measurement of the input or output voltage, and LED indicates the current measurement of the input or output voltage; The nixie tube can be turned off by another button. Mentioned states are able to be memorized, is not lost even if the power is disconnected. (On-board marked "IN" LED is turned on, the nixie tube display input voltage value, "OUT" LED bright display is the output voltage value).
• Output voltage must be greater than input voltage, do not apply reverse polarity voltage, voltmeter works only when input is >= 4V.

Product description

Specification:

Input voltage: 12V-60V

Input current: input current 15A

Output voltage: 12V-80V continuously adjustable

Output current: Maximum output current 10A (adjustable)

Output power: effective power P = input voltage V * 10A

Conversion efficiency: up to 95% (input voltage and current; output voltage and current affect conversion efficiency)

Short circuit protection: fuse

Module size: 73*51mm

Weight: 265g

Working frequency: 150KHz

Working temperature: -40~+85° (please strengthen heat dissipation when the ambient temperature is too high)



Static working current: 15mA (measured when 12V rises to 20V, the higher the output voltage, the higher the static current will increase)



Over-current protection: Yes (input exceeds 17A, the output voltage is automatically reduced, and there is a certain range of error.)



Input reverse connection protection: none



If you need more power, you can use two modules in parallel. For example, if the output is 15A, you can use two modules in parallel to adjust the current of each module to 8A.





Inductance magnetic ring adopts 27mm iron silicon aluminum magnetic ring, 1mm double wire wound inductor, high quality filter capacitor, input one 1000uF63V electrolytic capacitor, output two 470uF100V electrolytic capacitors, boost output power quality is better, onboard power supply The switch, power supply indicator light, and voltage adjustment and current adjustment potentiometers make the output more convenient. The output voltage and current can be adjusted at any time. The input and output adopt 8500 terminal blocks. The strong current capability ensures reliable operation for a long time.



Package Included:

1 x DC to DC Boost Converter



NOTICE:

Using this kit require professional electrician knowledge,please make sure you know that before use.

• 【DC to DC Boost Converter】600W high power booster module, wide voltage input: 10V ~ 60V, 12V ~ 80V adjustable wide voltage output; output current can be adjusted; ultra-low input and output pressure difference.
• 【DC to DC Boost Converter】Specifications: Radiator bottom plate thickness 5mm, tooth height 21mm, length 85mm, width 63mm, booster plate fixed above the radiator, rational design, integrated design of radiator and booster plate, convenient for users to use directly, use long screws fixed directly.
• 【DC to DC Boost Converter】The module has a constant voltage and constant current function, but it is a non-isolated boost mode, due to its characteristics, the constant current range depends on the input and output voltage and load.
• 【DC to DC Boost Converter】Please Power on the module first, then connect the load, which is especially important in high-power loads; the input voltage should be stable, especially when some low-voltage (12V) input power supply is connected to the load voltage, it will fall below 10V, and it is easy to break down the power tube at this time.
• 【DC to DC Boost Converter】Two or more modules can not be used in parallel input and output, otherwise the current limit function will be invalid

User questions & answers

Question:	i use a AGM battery for camping, would this work for 12v agm battery to 13.5v (16amps
Answer:	agm ? you mean a deep cycle battery ? Im nit certsin. Mine had no spec sheet with it so Im not sure what will kill it or what wont
Question:	Nowhere in the specs does it mention "step up". my application requires 12vdc in and 20vdc out with 3amp. anybody know if this can be done? doug
Answer:	Yes. Description says step up transformer. 12v min input. Max out 80v. 10 amps max adjustable.
Question:	can this boost 24v 6a to 32v 8a
Answer:	No, you can't get more power for "free". 24 volts at 6 amps is 144 watts (24 * 6). 32 volts at 8 amps is 256 watts. This only changes the voltage, so at 32 volts, you'll get about 4.5 amps (144 / 32).
Question:	With 12v input, will i able to adjust the output to 75v? thanks
Answer:	Yes

Product description

DROK 1500W Boost Voltage Converter



Parameters:

Module type: non-isolated step-up module (BOOST)

Input voltage range: DC 10V~60V

Input current: 10~30V input voltage, maximum current 30A; 31~60V input voltage, maximum current 25A

Static operating current: 15 mA (when 12V step up to 20V, the higher the output voltage, the current will increase)

Output voltage: 12~90V continuously adjustable (default 19V)

Output current: 20A MAX, more than 15A please enhance heat dissipation

Constant current range: 0.8~20A (±0.3A)

Temperature: -40~ + 85℃(if the ambient temperature is too high, please enhance heat dissipation)

Operating frequency: 150 KHz

Conversion efficiency: 92% ~ 97%

Protection: input over-current protection, battery low voltage protection, input reverse polarity protection, input short circuit protection

Installation: 4 x 3 mm screw holes

Module size(L*W*H): 130 x 52 x 85 mm



Applications:

1. DIY a power supply, input 12V and output can be 12-90V adjustable.

2. Charge for your electromobile.

3. As the car power supply, charge for your laptop, PDA or a variety of digital products.

4. DIY a notebook mobile power supply: with 12V big-capacity lithium battery pack, get your notebook on anywhere.

5. Solar panel regulator.



Note:

This item is not designed with display. If need to check output current various, please use a multimeter.



Package Including:

1 x Power Converter Module

• DROK boost voltage converter input voltage range is DC 10-60V, max input current is 30A; continuously adjustable output voltage range is DC 12-90V, max output current is 20A, more than 15A please enhance heat dissipation.
• Application: DIY a power supply, input 12V and output can be 12-90V adjustable; used as the car power supply, charge for your laptop, PDA or a variety of digital products; used as a solar panel regulator, etc.
• Protection: this step-up power regulator is designed with input over-current protection, battery low voltage protection, input MOS reverse polarity protection.
• Special Design: the voltage transformer is equipped with thickening radiator and intelligent temperature control cooling fan.
• Note: When using battery, switching power supply, solar panel, or generator as input power, please it is necessary to decrease the battery protection voltage value. Otherwise it will cause damage to the battery and the power supply.

User questions & answers

Question:	Please explain: "When using battery, switching power supply, solar panel...as input power, it is necessary to decrease the battery protection
Answer:	You should adjust it to turn off the output when the input is 10.5V or less
Question:	I have 11v - 5amps. How many volts/amps can I get out of this
Answer:	About 50W. Watts is Volts times Amps, Amps = Watts/Volts. Example: you want 24V, 50/24=2.08A At 24V output, you can get is ~2.08A output
Question:	can I step up 30v to 48v with 300amp
Answer:	This performs well If you don’t put it to the extreme. Mine works perfectly and perform this job for the last year and it is a recommend
Question:	Can this take 9v dc input and output 14-15v. 20a for 8-10 second bursts? long rest times in between ops. is this a good choice or is there better
Answer:	Not likely with this converter because the input range is 10-60vdc. It’s theoretically possible but only if your 9v source can provide the necessary amperage without voltage drop. It’s more likely to go from a higher voltage source to your 14-15v instead. I would suggest buffering the output 14-15v with super capacitors to achieve your specs.

Product description

Parameters:

-Input Voltage: 3.5V-12V

-Output Voltage: 1.2V- 24V

NOTE:

This product is not a high-power power supply, please use it within the power range.

-Output Voltage 1.2V ~ 2V, work within 2W

-Output Voltage 2V ~ 20V, work within 3W

-Output Voltage 20V ~ 24V, work within 2.5W

Package Included:

3 x USB Adjustable Buck Boost Converte

• Precise Calibration：this power supply module display with voltage, USB adjustable buck boost power supply module 3.5-12V to 1-24V
• Output: plug in USB or micro USB can easily output adjustable voltage from 1V to 24V and the power is 3W
• Adjustable voltage: adopt multi-turn precision adjustable potentiometer to adjust voltage.
• Data storage: automatically save the state before the power failure, the output data will not be lost.
• One key to turn off the output, and store the state before power off, no worry about data loss
