10 best backup camera for farms

Product description

PACKAGE INCLUDING:



◇A. 7" WIRED SINGLE VIEW MONITOR*1

◇B. AHD 720P WATERPROOF CAMERA*1

◇C. 15METERS EXTENSION CABLE*1

◇D. MONITOR POWER CABLE*1



MONITOR SPECIFICATION:



◇7 Inch Wired Color Single View AHD monitor

◇Resolution: 1024(RGB)*600

◇TV System: NTSC/PAL

◇Multiple menu languages

◇Brightness;450cd/m2

◇Support 3 cameras video input

◇Separate trigger control wires for AV2/AV3.

◇Menu to set up reversing image delay time 0-15s, mirror/normal image.

◇Monitor will automatic switch-over the image to related camera and back to

the original mode when the trigger stops.

◇In standby mode, monitor will turn on automatically when triggered and will

switch to back up camera image，Trigger end after shutdown

◇Working voltage: DC12V-36V

◇Keys with LED backlit

◇Built-in short-circuit protector(When installing and connecting the kit,

people connects the female 4-pin connectors to the male one from the camera

and monitor, they sometimes connect the video pin of the camera to the power

pin of the monitor. It may cause a short-cut, the built-in protector may keep

the monitor away from being burnt.)

CAMERA SPECIFICATIONS:



◇sensor：SONY AHD 720P

◇Video format: PAL / NTSC optional

◇Lens: f=2.5mm

◇Lens Angle: 120°

◇Infrared LED light: 18PCS

◇IR Distance: 35ft

◇Waterproof Rate：IP69K,

◇Housing:aluminum alloy (camera never gets rusty, and has a higher

ability in heat radiation than iron housing.)

◇Dustproof, waterproof, hydrochloric acid prevention, explosion prevention

• 【APPLICATIONS】This is an upgraded industrial grade wired one camera system. For its high vibration resisance ability of 10G and wide power input range DC12-36V, it is suitable for large vehicles, such as buses, box trucks, pickup trucks, garbage trucks, flatbed trucks, dump trucks, street sweeper trucks, refrigerator trucks, motor homes, vans, skid steers, farm tractors, combines, cotton pickers, crop sprayers, bulldozers, snow plows, forklifts, excavators, heavy equipments,etc.
• 【MONITOR】7”LCD AHD 720P color monitor with U-type metal bracket and with 1024RGB x600 HD resolution. It is compatible with most of the vehicles with a free power input range DC12-32V and supports with max 3 cameras. TVS device is built in to protect the monitor from being damaged by the transient high power of vehicles. And this monitor only supplies camera which is in use with DC12V, it saves energy. It is compatible with PAL/NTSC/AUTO.
• 【HEAVY DUTY CAMERA】It is color AHD 720P, provides super clear and real color image, and no delay. The viewing angle is 120 degree. With waterproof rating IP69K(the highest level), with night vision. So it works perfectly in kinds of weathers. With Heavy duty, 10G vibration-proof rating, it works well with the vehicle which has intensive vibration in extreme conditions.
• 【Unique Selling Proposition】①.The buttons have automatic LED backlight, drivers can operate exactly at night. ②.Monitor has a built-in protector for protecting monitor from being damaged by power polarities reversed. ③With built-in innovative system previous option settings memory even after it's turned off. ④.Camera's image can be set as mirror, non-mirror or up-side-down by OSD menu. ⑤Distance grid line can be turned on or off by OSD menu.
• Unique Selling Proposition】①Monitor has two trigger wires. Monitor will be triggered to be turned on automatically to display camera image when reversing. After reversing, the monitor will be back to the pervious mode. ②This system has two viewing options(view when reverse or remain on continuously). ③We uses waterproof Aviation 4-pin screw connectors, NO BNC/RCA. ④Easy to install. ⑤Two-year warranty and life-time tech support.⑥Contact us to tell us your needs, we can customize a kit for you.

Product description

PACKAGE INCLUDING:



◇A. 9" WIRED SINGLE VIEW MONITOR*1

◇B. AHD 720P WATERPROOF CAMERA*1

◇C. 15METERS EXTENSION CABLE*1

◇D. MONITOR POWER CABLE*1



MONITOR SPECIFICATION:



◇9 Inch Wired Color Single View AHD monitor

◇Resolution: 1024(RGB)*600

◇TV System: NTSC/PAL

◇Multiple menu languages

◇Brightness;450cd/m2

◇Support 3 cameras video input

◇Separate trigger control wires for AV2/AV3.

◇Menu to set up reversing image delay time 0-15s, mirror/normal image.

◇Monitor will automatic switch-over the image to related camera and back to

the original mode when the trigger stops.

◇In standby mode, monitor will turn on automatically when triggered and will

switch to back up camera image，Trigger end after shutdown

◇Working voltage: DC12V-36V

◇Keys with LED backlit

◇Built-in short-circuit protector(When installing and connecting the kit,

people connects the female 4-pin connectors to the male one from the camera

and monitor, they sometimes connect the video pin of the camera to the power

pin of the monitor. It may cause a short-cut, the built-in protector may keep

the monitor away from being burnt.)

CAMERA SPECIFICATIONS:



◇sensor：SONY AHD 720P

◇Video format: PAL / NTSC optional

◇Lens: f=2.5mm

◇Lens Angle: 120°

◇Infrared LED light: 6PCS

◇IR Distance: 35ft

◇Waterproof Rate：IP69K,

◇Housing:aluminum alloy (camera never gets rusty, and has a higher

ability in heat radiation than iron housing.)

◇Dustproof, waterproof, hydrochloric acid prevention, explosion prevention

• 【APPLICATIONS】This is an upgraded industrial grade wired one camera system. For its high vibration resisance ability of 10G and wide power input range DC12-36V, it is suitable for large vehicles, such as buses, box trucks, pickup trucks, garbage trucks, flatbed trucks, dump trucks, street sweeper trucks, refrigerator trucks, motor homes, vans, skid steers, farm tractors, combines, cotton pickers, crop sprayers, bulldozers, snow plows, forklifts, excavators, heavy equipments,etc.
• 【MONITOR】9”LCD AHD 720P color monitor with U-type metal bracket and with 1024RGB x600 HD resolution. It is compatible with most of the vehicles with a free power input range DC12-32V and supports with max 3 cameras. TVS device is built in to protect the monitor from being damaged by the transient high power of vehicles. And this monitor only supplies camera which is in use with DC12V, it saves energy. It is compatible with PAL/NTSC/AUTO.
• 【HEAVY DUTY CAMERA】It is color AHD 720P, provides super clear and real color image, and no delay. The viewing angle is 120 degree. With waterproof rating IP69K(the highest level), with night vision. So it works perfectly in kinds of weathers. With Heavy duty, 10G vibration-proof rating, it works well with the vehicle which has intensive vibration in extreme conditions.
• 【Unique Selling Proposition】①.The buttons have automatic LED backlight, drivers can operate exactly at night. ②.Monitor has a built-in protector for protecting monitor from being damaged by power polarities reversed. ③With built-in innovative system previous option settings memory even after it's turned off. ④.Camera's image can be set as mirror, non-mirror or up-side-down by OSD menu. ⑤Distance grid line can be turned on or off by OSD menu.
• 【Unique Selling Proposition】①Monitor has two trigger wires. Monitor will be triggered to be turned on automatically to display camera image when reversing. After reversing, the monitor will be back to the pervious mode. ②This system has two viewing options(view when reverse or remain on continuously). ③We uses waterproof Aviation 4-pin screw connectors, NO BNC/RCA. ④Easy to install. ⑤Two-year warranty and life-time tech support.⑥Contact us to tell us your needs, we can customize a kit for you.

User questions & answers

Question:	Does your camera have a rating IPx7? This is a temp/water test rating
Answer:	Well, the waterproof rating for this camera is IP69. All the product will be tested under three meters depth water for 2 hours before they left the factory. Hope the answer can help you.
Question:	Can this system be used continuously and direct power ACC
Answer:	Yes dear, it can always stay power state and work continuously, voltage range is between DC12V --- 32V. This YW-17211 system supports 4 wireless cameras, one of them is using for reversing, the other three can be always in a very power state, it can monitor three different places through the button of the monitor. What’s more, the signal it is still stable in range of 50ft, image can be shown as normal even the car speed reaches 70mile / h.
Question:	Where can I get an operations/instruction manual? One did not come with it. It's installed
Answer:	My system didn't come with instructions on how to install the camera and if it will transmit around obstacles on top of my RV even trying it without obstacles I can't get a signal
Question:	What is the difference between digital signal and analog signal
Answer:	Dear Roger Yap:Thanks so much for your question.There are three signal for car wireless reversing product at present;1)Analog signal;2)WIFI signal;3)Digital signal;The common feature of them is easy installation, you do not need to worry about how to hide the over 30ft signal cable.(from the monitor to the camera)Respective characteristics of them:1)Analog signal:a, Will be interfered from other electronic product signals, flashing image, the receiver even will receive the signal from other transmitter;b, Low price is its biggest advantage;C, Has a long time and high visibility in the filed of car reversing.2)WIFI signal:a, Just need the transmitter (WIFI transmitter & camera), the phone or IPAD can be used for receiver directly, it is rather inconvenient to get such equipment out when reversing;b, Image will be delayed and easy to be disturbed;c, Cheap price3)Digital signal(Yuwei model# YW-17211)a, No interference;b, Can work as normal even car speed reaches 70MILEC, Wireless transmission distance up to 150ft in open area, applicable to all models within 100ftd, The cost is a little high, suitable for high quality buyer.

Product features

Monitor Installation

Monitor installation just takes one minute.

Camera Installation

1) Camera mount installation;

2) Drill hole for the camera’s wiring with a 12mm diameter bit; ( the only operation tool you need)

3) Connect the red wire of the camera to DC12V or DC24V voltage, black to negative pole.

Enjoy the DIY 40 minutes, which will be a rewarding and fulfilling experience.

• 7" LCD digital monitor, Built-in recorder. Real time recording, video playback
• 10-32V wide voltage input, Support 4 wireless camera input,120° wide viewing angle, Wireless Line of Sight Range Up to 984 feet (This kit include 1 monitor+ 1 camera)
• Split mode, auto-scan mode and single-display mode available, Normal, mirror, FLIP, MIRROR-FLIP viewing options available
• HD 720P Digital Wireless Backup camera system, it has far better image resolution, stronger lens and longer transmission distance, which will bring you a whole new driving experience
• The camera’s waterproof level is IP69K rating (highest IP rating) and the vibration rating is 5.9G, Built-in SMART IR-CUT filter image color and more realistic.

User questions & answers

Question:	We are pre-wired for Furrion 729125. Will this work or is an adapter available if needed
Answer:	Mine was wired for furrion but if you pull out the wires enough you will see the factory connections and just cut them and splice in the halos mine works great and just a heads up if you have not had a camera system before mine was wired for hot all the time but the fuse was not put in at the factory so you will have to put one in
Question:	Bought several brand's system( yarky, xroose cm1, zeroxclub w701, amifo a7...)for company's business, want to compare more, but haven't test this unit
Answer:	After search all of these product, answer as below: 1.As for the price, Haloview>Xroose>Zeroxclub>Amifo>Yarky, Haloview has the highest price. 2.As for the picture quality, i found that Xroose and Haloview is the best, then turn to the Zeroxclub and Amifo, finally is the Yarky. the follow result just from other customers. 3.As for rating, Xroose>Amifo>Haloview>Zeroxclub>Yarky. 4.As for the range, Haloview says 982ft, Amifo says 982ft, Xroose says 328ft, Zeroxclub says 100ft, Yarky do not mention. 5.As for the monitor, both are 7 inch, Zeroxclub and Xroose' s monitor has the capacitive touch button. but i haven't use it, so i don't know how it feel. 6.As for the camera, Haloview and Zeroxclub has the glass cover, Yarky Xroose and Amifo do not have.
Question:	Will this have a strong enough signal for a 45’ fifth wheeler
Answer:	Yes...it should. I have a 40 foot diesel pusher motorhome and I pull a 29 foot trailer. The camera is on the back of my trailer, the monitor is on the dash of motorhome. Camera works great...even going down the highway. That is 69 feet of separation.
Question:	Does the camera have audio
Answer:	Yes it does. You can adjust the volume and also turn it off.

Product features

High Resolution

720P, high definition image quality improve your viewing experience

Long Range Signal Transmission

A long monitor antenna allows better reception for long range signal ,wireless signal range up to 984 feet.

Recording

Monitor support 4-channel composite and single-channel recording in AVI signal format.

120 degree

A wide viewing angle of 120 degree

IPS Panel

IPS Panel , You can see the image at any angle.

SMART IR-CUT

This camera system built-in SMART IR-CUT filter makes image more realistic. If you use 650nm filter at daytime, it will automatically switch to 850nm at night. It makes color more realistic and avoid color blur.

Backup Camera Bracket Adapter

Haloview backup camera bracket adapter compatible with Furrion pre-wired RVs.

Please find the bracket adapter by searching this ASIN : B07LGLJWG2

What's in the Box

• 7" Monitor x1
• Wireless Backup Camera x1
• U-Support Bracket x1
• Sun Shied x1
• Angle Adjustment Screw x4
• Center Mount Bracket x1
• BMW Connector Adapter x1
• Cigarette Lighter x1
• Trigger Wires x1
• Camera Conversion Cable x1

Product description

AHD Reversing camera monitoring system can be applied to Truck/Semi-Trailer/Box Truck/RV/Camper/Bus/Van/Farm Mach/Trailer/Motorhome/5th Wheel and so on.



Two installation methods for the 7” HD monitor, all accessories included. It automatically displays blue screen when there is no video signal.



The reverse camera works well under bad weather, 8PCS of LEDs for night vision and the LED brightness will adjust by itself.



The whole system is powered by cigarette lighter, you just need to press the on/off button on it to make the monitor and camera work when the vehicle starts.

• Integrated Back Up Camera Monitor System---This set of wired back up camera system is designed for large vehicles like Truck/Semi-Trailer/Box Truck/RV/Camper/Bus/Van/Farm Mach/Trailer/Motorhome/5th Wheel and so on, the cigarette lighter supplies power for both monitor and camera.
• Better Choice for 7 INCH TFT Monitor---Ultra Clear True Picture from AHD camera shown on the monitor, powerful functions can be achieved like auto-dimming, image flip, brightness adjusting, V1/V2 switching by pressing the buttons on the monitor or through the remote control. Two installation methods for you.
• AHD 960P Rear View Camera---Much more stable signal transmission and clearer image shown. Mini size, IP68 waterproof, 960P 1280*960 pixels, 1000TVL, 150 degrees wide viewing angle, durable metal housing. Can be used as rearview, sideview or front view camera as you need.
• Easy Installation, No Signal Interference---Just need to find a suitable place for the monitor and camera, connect them with the 49FT video cable with aviation 4-pin connectors which ensures stable video signal transmission. There is an on/off button on the cigarette lighter to supply power for the whole system.
• ANY QUESTIONS, PLEASE CONTACT US FREELY, WE WILL REPLY BACK WITHIN 24 HOURS.

User questions & answers

Question:	Can this be hard wired into a power source is there an option to do this
Answer:	Hi, you can just use the cigarette lighter to power the whole backup camera system. Anything unclear, please contact us freely. Thank you

• Digital Wireless transmitter takes the place of complicated cable wiring and provides stable signals without any interference within 30m.
• 7" Full-color LCD rearview monitor with built-in speaker and remote control.Two video inputs,one audio input and optional PAL&NTSC TV system.
• 18 IR lamps 1/3-inch color SONY CCD camera with 120 degrees lens angle and 8M night vision range gives you safer driving experience in the day/night.
• Suitable for most gigantic vehicles, such as Excavator, Cement Truck, Farm Tractor, Trailer&RV, Heavy Truck, School Bus.
• AUTO-VOX MW3 is designed only for reversing. It mainly avoids blind spots when parking and can not be used as driving monitor at highway.

User questions & answers

Question:	What is the warranty
Answer:	They took it back without a problem. It lasted for one hour.
Question:	need camera & monitor for 22ft rv trailer. want to plug into cigarette lighter, need to work on highway for changing lanes. no backup light.model
Answer:	Hi， it has the backup light model.
Question:	Aside from price, how is mw3 different than mw3-n
Answer:	Hi.The cameras of them are a bit different. The camera of MW3-N is much better than that of MW3.Auto-Vox Service Team
Question:	Can this system be used for a full time rear view monitor
Answer:	Sorry, It is designed only for reversing not for driving monitor.If you want this unit to work as a driving monitor on highway to watch for the behind carriages, the screen may flick,not sync or lose signal since the transmission frequency has be changed by the high speed. We call it “Doppler Effect ”.The normal transmission frequency of our transmitter is 2.4G which offers the best signal when reversing(If you do want to use it as a rear view monitor, we suggest to buy 2 of the “Proxicast Extra Large 3-inch Magnetic Antenna Base (SMA Jack/SMA Plug) 6.5 ft.)” to extend the antennas to the outside of the cab of the truck, and to the roof of the trailer. It will enhance the signal and fix the problem of losing connection. Hope it helps.

Product features

Digital Wireless backup camera

This 7’’TFT LCD monitor with Wireless Digital system camera is suitable for most truck, bus, trailer and other vehicles. Easy installation without extra confused long connecting cables which can save much more time.Instructions with diagrams are also included in the manual which comes with your package.

• Multiple video formats: 1080P 25fps, 1080P 30fps, 720P 25fps, 720P 30fps, PAL D1, NTSC D1 Automatically switches to back-up,left,right camera views
• NOTE: Extension wires are not included in the kit. For extension wires, please purchase separately: HD-5(5M) B07K2PVPX4 HD-10(10M) B07K2RZ6S1 HD-20(20M) B07K2PXXL8
• Picture image may be adjusted for Horizontal, Vertical, Mirror and Normal viewing
• TFT LCD monitor with wide angle view and high resolution display. Up to 3 camera inputs
• backup camera installation rv backup camera rv backup cameras rv backup camera system observation camera for travel trailer

User questions & answers

Question:	Does it work with Furrion pre-wired system
Answer:	I ran it to the fuse box under the dash. The wiring harness that came in the package didn't include na adaptor to go to a cigarette accessory. i'm sure you could buy one and wire it in.
Question:	Can this run with rear view while travelling
Answer:	This system does not but here's one that does: https://www.amazon.com/Rear-View-Safety-RVS-770614-213-Camera/dp/B00CWFW5L8/ref=sr_1_1?ie=UTF8&qid=1514305847&sr=8-1&keywords=B00CWFW5L8
Question:	Can you buy just the CA611 camera, and will the cameras work with a different monitor
Answer:	I'm sure it could with the right attachments, but there are too many heavy wires to the monitor provided to clip to a visor, and it's too large to mount to the rear view mirror. I would have preferred a smaller monitor, but it does work well.
Question:	It plugs into the cigarette lighter
Answer:	You'd have to take the output coax from the camera and put it into your recording device, then add a coax from your recording device to the main controller. As long as your recording device allows a pass-thru signal, you should be fine.

Product features

High resolution display

• Multiple video formats: 1080P 25fps, 1080P 30fps, 720P 25fps, 720P 30fps, PAL D1, NTSC D1.

Up to 3 camera inputs

• Automatically switches to back-up,left,right camera views

With SONY STARVIS

• Camera equipped with SONY STARVIS Sensor(used for image noise reduction) to monitor your vehicle.

IPS Panel

• You can see the image at any angle

130 degree Viewing angle

• With an ultra wide viewing angle, the rear camera will provide a complete view from behind your vehicle.

Built-in MIC

• The backup camera has a built-in mic and the monitor built-in speakers so that not only visual but even aural information will be transmitted from the back of the vehicle.

IP 69K Rating

• IP69K Waterproof
• Camera equipped with SONY STARVIS Sensor

View Switch

• Automatically switches to back-up,left,right camera views
• This allows the connected cameras to be used either as backup or forward facing cameras even a side camera when with the bracket.

Parking Line

• The scale can be adjusted for left, right, up and down

• ✔ 1080P Fookoo Technology: The 1st to Introduce 1080P Technology for Backup Cameras. Digital High definition Image Processor Will Make Your Backing More Confident and Safe. This Wired System Never Has Picture Delay or Signal Issues, Different From the Unstable Wireless Products.
• ✔ 2 Million Pixel Camera: IP69 Waterproof Camera has 18 Infrared Lights and “No Wash Out in Bright light” Sharp CCD Sensor with Excellent Night Vision, You Will Get the Clear and Vivid Images.
• ✔ Auto Dimming Feature: Featuring of it, Monitor Will Automatically Adjust the Brightness Based on Ambient Light. This Means Monitor Won't Be Super Bright During the Day and Dimmer At Night to Effect Your Driving.
• ✔ Flexible Vehicle Comatability: Voltage Range From 9-36V DC Power To Accomodate a Wide Variety of Large Vehicle as Semi-Trailer/Box Truck/5th Wheel/Trailer/Bus. Hard Wired System is Also Easy to Install with the Included Professional Instructions.
• ☺After-Sales Service: If You Found the Product was Defitive or Need Another Lengths Cable, Please Ask Us for Help. We are Online 24 hours, Offer A 18-month Replacement Service and Lifetime Technology Support.

User questions & answers

Question:	Can you use this camera as an observation camera to view what is behind while driving and for lane changes
Answer:	Yes, leave it on as a rear camera, reverse the view to act like a rear view MIRROR. Note that a right-side camera is helpful for lane changes in US (Right lane)
Question:	My question does the camera just need power to connect to your monitor or is it hard wired from camera to monitor
Answer:	Hi, friend. The camera need to get power from monitor, so it need to conect to the monitor with the extended 4-pin cable. Because this system is suitable for the long vehicle, the camera will be far away from the monitor, you need a cable to connect them. Hope my answer will help you. If you still have any questions or needs, please contact us at [email protected] Best regards, FOOKOO Support Team
Question:	This is listed as 1080p - can you confirm -both- the camera and monitor are true 1920 x 1080 resolution (1080p
Answer:	I recently purchased this system and while I cannot scientifically verify that it is 1080P it is extremely sharp, at least as good and maybe better than the resolution on my flagship model Dell laptop. I could not ask more from a 7" monitor, very pleased.
Question:	What is diameter of the camera cable not including the connector
Answer:	Hi, there. It includes a 50ft cable for camera. If you need one more cables, please contact us for it. Here is our email: [email protected] Any quetsions or needs please contact us, we will help you. Best regards, FOOKOO Customer Service Team

Product features

Parking Lines Assistance

Image Flip

IP69 Waterproof & Durable

• 【Support 4 wireless camera input】Support 4 wireless camera input,120° wide viewing angle. (This kit include 1 monitor+ 2 cameras)
• 【Digital Stable Signal Transmission】Wireless Line of Sight Range Up to 984 feet, stable signal
• 【Vivid Image Display】5" LCD digital monitor, Built-in SMART IR-CUT filter image color and more realistic, HD 720P Digital Wireless Backup camera system, which will bring you a whole new driving experience
• 【Built-in DVR and Split mode】Built-in recorder. Real time recording, video playback. Split mode, auto-scan mode and single-display mode available, Normal, mirror, FLIP, MIRROR-FLIP viewing options available
• 【Mini camera support multiple installation methods】 With license plate bracket and Bracket Adapter Compatible with Furrion Pre-Wired RVs. The camera’s waterproof level is IP69K rating (highest IP rating).

User questions & answers

Question:	can i mount the license plate camera on the back of my airstream where the plate is ? Will the camera work fine there
Answer:	If the camera is far from the display and the license plate position is installed low, the signal may be affected.
Question:	How many license plate brakes come in the package? I need
Answer:	Only one license plate bracket. The other bracket included fits the furion system prewired in most newer rvs
Question:	How much lag do you get when you use the camera as a live-view source backing up or when driving
Answer:	I get no lag during backup operation, but there is lag during operation of the rear camera during driving. Sometimes the camera freizes and then recovers and most times the picture displayed is one second behind what is actually there.
Question:	Is the furrion power plug the same to connect this camera or does it have to be stripped and hard wired
Answer:	It wasn’t connected. We had to modify the mount and then strip and hard wire it. Quite a process but works well
Question:	I have a rvs rear view wired camera system on my rv. can i wired the haloview 7601 to my existing cables
Answer:	This camera has 3 camera hookups that come of it. I tried cutting one and splicing the wires and could not get a connection. I tried splicing it back to its own fitting and also could not get a connection so Im not sure whats going on.
Question:	Is this compatible with Furrion
Answer:	No, you need to purchase separately. It is CF100.
Question:	Is this compatible with Furrion or will I need to use the bracket you supply
Answer:	You need to use it with CF100.
Question:	Will this monitor work with a CA611 camera I already have? getting max resolution isn't a problem for me just want to make sure it will work
Answer:	No, it can work with CA611.

Product features

M7601 Monitor

• 7" TFT LCD monitor,120°wide viewing angle,16:9 and 800 x 3 (RGB) x 480
• Picture image can be adjusted for Horizontal, Vertical, Mirror and Normal viewing.
• 8 languages optional: English, Dutch, French, Portuguese, Spanish, Russian, German, Italian.
• Automatic scanning function, Video formats: NTSC.
• Up to 3 cameras input with auto-scan mode
• Operates from 10 -32V.
• The Parking line can adjustable for left, right, up and down.
• Suport automatically corresponding to camera views switching
• Built-in SMART IR-CUT, which can filter the image color and gurantee a more realistic effect

CA601 Camera

• 4 IR LED provide 32ft of night vision for camera 　
• The camera’s waterproof level is IP69K rating (highest IP rating) and the vibration rating is 10G.　
• The camera which built-in SMART IR-CUT filter gain more realistic color image in daytime.
• The infra-red sensor opens automatically at low light and the image is black-and-white for low illumination.

Adjustable Parking line

The Parking line can be adjusted to left, right, up and down

120°wide viewing angle

120°wide viewing angle

Installation

Please do not wire to trigger when you no need to automatically switches camera views

Accessories

Note: The MC7601 set does not include cable, please purchase the appropriate length of cable as needed

Digital Stable Signal Transmission

Wireless Line of Sight Range Up to 984 feet, stable signal

DVR Function

Built-in DVR Function

Easy to install

Quickly and securely mount the 5” LCD color monitor to the windshield using the suction cup.

High Resolution HD 720P

720P, high definition image quality improve your viewing experience

Two installation options are available

• Mount on the US License Plate
• Install with a Bracket

As a hitch camera

Easy to use as a hitch camera

Support for up to 4 camera inputs

Support for up to 4 camera inputs, supports quad split

Built-in MIC

The backup camera has a built-in mic and the monitor built-in speakers so that not only visual but even aural information will be transmitted from the back of the vehicle.

Parking Line

The scale can be adjusted for left, right, up and down

Product description

If you have a Pickup Truck,Trailer,SUV, RV,etc., the original camera cable may be not enough to install the dash cam, this ultra long dash cam cable let routing wires easily!





★33 Ft 2.5mm Male to 5 Pin Back Up Camera Cable

This extra long backup camera extension cable is long enough to run the wire when install the camera.





★.Friendly Reminders about this 5 Pin Rearview Camera Cord

1.⚠️ Please select the right pins configuration and suitable length (5 pin: 23ft, 33ft√),if you need one 4 pin cable,please search YQMAJIM.



2.Before installing this cord, please first test whether this cord fit your camera.



3.⚠️ If you need to continue to extend this cable, please search YQMAJIM to order one suitable extra extension cable. But please note that long cord will lead to voltage drop, so the 4 pin cord can be extended to 100 ft in max, and the 5 pin cord can be extended to 40 ft in max.



4.⚠️ For the 5 pin cord, if your original cable has a controller (as shown in the image), please do not purchase this cable,it won't fit your camera. 5. If you are not sure which cable you need, please contact us first. If the cable does not work after correct installing, please be assured, you will get a refund.











backup camera cord backup camera extension cable backup camera cable 4pin backup camera cable 5pin backup camera cable adapter backup camera cable kit backup camera cable for Trailer, RV,SUV, Bus, Trucks, School Bus, Farm Machine,etc backup camera cable rca backup camera cable connector backup camera extension cable 2.5mm to 4 pin rearview camera cable rear view camera extension cable rear view camera cable dash cam cable backup camera extension cable dash cam cable dash cam rear view backup camera reverse car recorder cable extension cord rear cam extension cable 4 pin camera cable navigation and rearview camera dash camera for cars backup camera cable dash cam

• ★.⚠️ Please select the right pins configuration and suitable length (5 pin: 23ft, 33ft√),if you need one 4 pin cable,please search YQMAJIM.
• ★.Before installing this cord, please first test whether this cord fit your camera.
• ★.⚠️ If you need to continue to extend this cable, please search YQMAJIM to order one suitable extra extension cable. But please note that long cord will lead to voltage drop, so the 4 pin cord can be extended to 100 ft in max, and the 5 pin cord can be extended to 40 ft in max.
• ★. ⚠️ For the 5 pin cord, if your original cable has a controller (as shown in the image), please do not purchase this cable,it won't fit your camera.
• ★. If you are not sure which cable you need, please contact us at any time. If the cable does not work after correct installing, please be assured, you will get a refund.

User questions & answers

Question:	is it compatible with VanTop H610 dash camera
Answer:	Yes
Question:	Is there an instruction manual? The original cable has only a red wire exposed but this one has a red wire plus a black wire exposed
Answer:	When I used my extension cable it was just an extra wire I capped/taped off didn't use. It might be needed in some instances. Best advice is to hook everything up to verify connections and power it up before spending time running cable through vehicle. Hope this helps.
Question:	I'm trying to use this with my aukey dra2. i haven't connected the wire to the reverse light, but when plugged in i can not see the camera. any help
Answer:	Not sure I hooked it all up before check didnt have any problems

Product description

Professional Backup Camera for Heavy Duty Vehicle

With 18 IR led lights, upgraded camera chip, the LASTBUS backup camera can provide you with wider and clearer pictures when you are driving or parking.



Great Night Vision Function:

With 18 pcs smart built-in IR LED , this camera has over 25 meters (50ft) IR range, and catch clear picture during both day and night.



Applicable to Your Car:

This camera with 4-pin connector is designed for your bus, trailer, van, truck, or other vehicle using 12-24V DC, and is easy to install.



Excellent Performance:

This camera has a full metal shell and glass screen , which can make it work well and longer.



Customer Service:

24-Hour Online Customer Service, 60-Day Money-Back Guarantee, 12-Month Replacement Warranty, and Lifetime Support.

If you have any question or need any help, or have any dissatisfaction about the order, please contact us first, we will do our best for you.

Customer Service Email Address: [email protected].



Specification:

Connector: Standard GX12-4

Image Sensor : 1/4'' 2.5mm Color Sensor

Horizontal Resolution : 700TV Lines

Power Supply : 12-24V DC

Fomat : NTSC

View Angle: 130°

Waterproof: IP69

Night Vision Function: Supported



What's in the Box:

Backup Camera x 1



Warning: The camera is using the standard GX12-4 or M12 4 pin connector, so please confirm your monitor or your wires system is using the standard GX12-4 or M12 4 pin connectors. Otherwise the camera cannot be compatible with your monitor system.

If your monitor only support AHD, this camera will not be compatible with your monitor system.

• 【Bright & Clear Picture】 CMOS image sensor, 700 TV lines and other HD camera technologies ensure you can get clear and detailed color images so that no detail on the road can be overlooked.
• 【Night Vision Function】The rear view camera adopts 18 built-in IR LED and the design of automatic switch to night vision mode when getting dark to guarantee your safety on the road.
• 【Wide Angle Vision】The backup camera, with 360 degree adjustment and wide angle design, can provide you with a 130° view angle to help you check unseen blind spots in your vehicle's mirrors.
• 【High Quality】Metal shell makes this camera can be waterproof, shockproof and can work longer. And the reversing camera adopts glass scene instead of plastic screen to make sure clearer images and longer life. IP69 waterproof can ensure that it can be able to work well in all bad weathers. in all bad weathers.
• 【Customer Service】24-Hour Online Customer Service, 60-Day Money-Back Guarantee, 12-Month Replacement Warranty, and Lifetime Support. Customer Service Email Address: 【[email protected]】. If you have any question or need any help, contact us, you will have our full attention.

User questions & answers

Question:	what type of monitor will work with this camera
Answer:	Standard color monitor (not AHD monitor) with GX12-4 4pin connector can work with this backup camera .
Question:	will this go with kirwood system
Answer:	Yes if we can help sombody why not
Question:	The email address for this Lastbus camera doesn’t work , can this camera replace existing camera using existing wire
Answer:	If the existing wire is using the standard 4 pin m12 connector, then yes, this backup camera can replace the existing camera. If you have any question or need any help, contact us, we will do our best for you,like better customer service, longer warranty period, free replacement, Email address: [email protected] (NOT [email protected])
Question:	Would this work ok with a 480 tv lines monitor
Answer:	Generlly speaking, this backup camera will work with a standard monitor no matter how many tv lines it has, but please make sure the monitor you have does not support AHD camera only. If you have any question or need any help, contact us, we will do our best for you,like better customer service, longer warranty period, free replacement, Email address: [email protected] (NOT [email protected])
